Электросхемы ПРЕДУПРЕЖДАЮЩИЕ СИСТЕМЫ Ford Contour SE 1996

ПРЕДУПРЕЖДАЮЩИЕ СИСТЕМЫ

Электросхема предупреждающей системы для Ford Contour SE 1996

Электросхема предупреждающей системы для Ford Contour SE 1996 - Список элементов:

• Acc
• C201
• C203
• C262
• C282
• C283
• C285
• C287
• C288
• Central timer module
• Courtesy lamp relay
• Defogger system
• Defrost refrost
• Defrost sw
• Door locks system
• Driver door sw
• Electronics fuse 7.5a
• Engine compartment fuse box (left front corner of engine compartment)
• G203 (right kick panel)
• G309 (left front rocker panel, under carpet)
• Ground
• Head
• Headlamp switch
• Hot at all times
• Hot in run
• Ignition sw
• Ignition switch
• Illum entry
• Instrument cluster
• Inter wiper sw
• Interior fuse panel (below left side of i/p)
• Interior lights system (illuminated entry)
• Interval wiper relay
• Key illum sw
• Key in ign sw
• Key in ignition switch
• Left front door courtesy lamp switch
• Left rear door courtesy lamp switch
• Lock
• Main fuse 80a
• Main light switch
• Off
• Park
• Park lamp sw
• Pass/rear doors sw
• Power (bat)
• Rear window defrost relay
• Red
• Remote entry mod in
• Right front door courtesy lamp switch
• Right rear door courtesy lamp switch
• Run
• Seat belt buckle sw
• Seat belt buckle switch
• Seat belt indicator
• Seat belt warn ind
• Shorting bar connector #1 (left side of steering column taped to harness)
• Start
• Washer sw
• Wiper park
• Wiper/rate select
• Wiper/washer system
