Электросхема панели приборов для Ford Explorer XLT 2013

Электросхема панели приборов для Ford Explorer XLT 2013 - Список элементов:

• (body main wiring assembly near breakout to c213) s280 (police)
• (left rear quarter panel) g301
• (under right front of center console) g201
• (w/o intelligent access) ignition switch
• 2.0l
• 3.5l
• 3.5l turbo
• 4 way down
• 4 way left
• 4 way right
• 4 way up
• A/d channel 1 a/d rtn
• A/d rtn
• Ajar lf door
• Body control module (left end of dash)
• Brake fluid level switch (on master cylinder)
• Brk fluid sw
• C1381b
• C1381e
• C1551b
• C1551e
• C175b
• C175e
• C210
• C211
• C218b
• C218c
• C2238
• C2280b
• C2280c
• C2280f
• C228oa
• C228ob
• C2414a
• C2414d
• C263
• C291
• C3053
• C3138
• C3139
• C316
• C327
• C4174a
• C4174b
• C934
• Cbp35
• Cdc30
• Cet52
• Clockspring (top of steering column)
• Cmc19
• Cmc20
• Cmc24
• Cmc25
• Computer data lines system
• Cpl26
• Cpl31
• Cpl36
• Cpl39
• Cpl58
• Except police
• Fuel level sensor (in fuel tank)
• Fuel pump (fp) assembly (under right side of vehicle)
• Fuel return
• Fuse 10a
• Fuse 15a
• Fuse 5a
• G103 (left front corner of engine compt)
• G200 (under left front of center console)
• G201 (under right front of center console)
• G300 (left kick panel)
• G302 (right rear quarter panel)
• Gd214
• Gd215
• Gd349
• Gnd
• Head up display module (w/ adaptive cruise) (left side of dash)
• Hot at all times
• Hot in run or start
• Hs can+
• Hs can-
• I can+
• I can-
• Input 1
• Input 2
• Instrument panel cluster (ipc)
• Key in
• Key in ignition
• Left front door latch
• Left rear door latch
• Left steering wheel switch
• Liftgate ajar
• Liftgate latch
• Liftgate/trunk module (base of left "d" pillar)
• Low washer
• Lr door ajar
• Micro
• Nca
• Oil pressure switch (left side of engine block)
• Ops
• Park brake sw
• Park detect
• Parking brake switch
• Pnk
• Police
• Powertrain control module (pcm) (center rear of engine compt)
• Push button
• Red
• Rf door ajar
• Right front door latch
• Right rear door latch
• Right steering wheel switch
• Rmc19
• Rmc32
• Rmc33
• Rr door ajar
• Run/start
• S200
• S204 (w/ adaptive cruise)
• S211
• S217
• S410
• S501
• S602
• S700
• S800
• Sbp11
• Sbp23
• Shift interlock system
• Steering column control module (top of steering column)
• Sw rtn brake fluid
• Taped to harness near c2238 (police)
• Vbatt
• Vdb04
• Vdb05
• Vdb13
• Vdb14
• Vmc11
• Vmc23
• W/ manual liftgate
• W/ power liftgate
• Wiper/washer system
