Электросхемы Противоугонная система Сигнализация Ford Club Wagon E150 1996

Противоугонная система Сигнализация

Электросхема противоугонной сигнализации для Ford Club Wagon E150 1996

Электросхема противоугонной сигнализации для Ford Club Wagon E150 1996 - Список элементов:

• (right rear corner of engine compartment) anti-theft hood switch
• Alarm indicator
• Anti-theft indicator
• Anti-theft module (left side of vehicle, behind "b" pillar)
• Battery
• C333
• C334
• C335
• C336
• Circuit breaker 20a
• Courtesy lamp switch input
• Courtesy lp switches
• Diode b (in window reg. relay switch harness)
• Disarm switch
• Door lock control
• Door locks system (keyless entry circuit)
• Door open input
• Driver's door lock control
• Exterior lights system
• Fuse 10a
• Fuse 15a
• Fuse 20a
• G106 (left side of engine compartment, near battery)
• G200 (behind left cowl)
• Ground
• Headlights system
• Hood tamper det. input
• Horn relay output
• Horns system
• Hot at all times
• Hot in accy or run
• Hot in start
• Ign key cyl sensor
• Ignition key cylinder sensor
• Interior fuse panel (behind left side of i/p)
• Interior lights system (courtesy lights)
• Left courtesy lamp switch (mounted in left door jamb)
• Left door lock cylinder switch (lower left corner of left door)
• Lock all doors
• Low beam hdlps output
• Nca
• Panic activate out
• Panic alarm input
• Parking lamps output
• Rear courtesy lamp switch (in right rear door jamb)
• Rear door lock cylinder switch (below license plate)
• Red/ pnk
• Red/pnk
• Remote keyless entry module (behind left "b" pillar)
• Right courtesy lamp switch (mounted in right door jamb)
• Right door key cylinder switch in
• Right door key cylinder switch (lower right side of door)
• Run/accy input
• Side door courtesy lamp switch (behind right "b" pillar)
• Side door lock ctrl
• Starter interrupt in
• Starter interrupt out
• Starting/ charging system (starter circuit)
• Steering column assembly
• Unlock driver's door
• Unlock sense
• Warning buzzer module (below left side of i/p)
