Электросхемы СИСТЕМА АНТИБЛОКИРОВОЧНОЙ ТОРМОЗНОЙ СИСТЕМЫ ABS Ford Explorer 1997

СИСТЕМА АНТИБЛОКИРОВОЧНОЙ ТОРМОЗНОЙ СИСТЕМЫ ABS

Электросхема антиблокировочной тормозной системы АБС (ABS) для Ford Explorer 1997

Электросхема антиблокировочной тормозной системы АБС (ABS) для Ford Explorer 1997 - Список элементов:

• (left front of engine compartment, near radiator) g108
• (near breakout to 4wabs pump motor)
• (near breakout to relay module) s255
• 4wabs control module (left rear corner of engine compartment)
• 4wabs hydraulic unit (left side of engine compartment)
• 4wabs main relay
• 4wabs pump motor (left side of engine compt)
• 4wabs pump relay
• 87a
• Abs diode
• Acceleration sensor (left frame rail, under driver seat)
• Anti-lock brakes indicator
• Auxiliary relay box #1
• Brake on/off (boo) switch (on brake pedal support)
• Brake on/off sw feed
• C282
• C287
• C288
• Datalink connector (behind left side of i/p)
• Exterior lights system
• Fuse 10a
• Fuse 15a
• Fuse 30a
• Fuse 7.5a
• G-switch #1
• G-switch status
• G104 (left rear corner of engine compt, at fender apron)
• Gem iso link
• Generic electronic module (gem) (behind center of i/p)
• Ground
• Hot at all times
• Hot in run
• Hot in run or start
• Ignition
• Instrument cluster
• Interior interior fuse panel
• L fnt dump valve
• L fnt iso valve
• L fnt sensor (hi)
• L fnt sensor (lo)
• Left front dump valve
• Left front iso valve
• Left front wheel 4wabs sensor
• Motor speed sens #2
• Nca
• Pnk
• Power
• Power power distribution distribution box box
• Powertrain control module (at right kick panel)
• Pump motor rly ctrl g-switch #2
• Rear axle sensor
• Rear dump valve
• Rear iso valve
• Rear sensor (hi)
• Rear sensor (lo)
• Red/pnk
• Relay coil (-)
• Right front dump valve
• Right front iso valve
• Right front wheel 4wabs sensor
• Rt fnt dump valve
• Rt fnt iso valve
• Rt fnt sensor (hi)
• Rt fnt sensor (lo)
• S137
• S155
• S173
• S173 (near breakout to 4wabs pump motor)
• S174
• S212
• S213
• S601
• Tan
• Tan/ red
• Tan/red
• Warning lamp
