СИСТЕМЫ ПОДВЕСКИ
Электросхема пневмоподвески для BMW X5 48i 2007
Электросхема пневмоподвески для BMW X5 48i 2007 - Список элементов:
- Air suspen- sion compressor relay
- Computer data lines system
- Electronic ride height control (right side of rear compt)
- Fuse f107 10a
- Fuse f32 30a
- Hot at all times
- Hot w/ term 30g relay energized
- Junction box (under right side of dash)
- Left rear level sensor
- Rear power distribution box (right side of rear compt)
- Right rear level sensor
- W/ vertical dynamics
- W/o vertical dynamics
- X11004
- X11006
- X11012
- X13790
- X14088
- X14089
- X14090
- X1448
- X166 (right front engine compt)
схема приостановки Динэмик-Драйв для BMW X5 48i 2007
схема приостановки Динэмик-Драйв для BMW X5 48i 2007 - Список элементов:
- (bottom of right "a" pillar) x490
- (under front passenger's seat) dynamic drive lateral-acceleration sensor
- Computer data lines system
- Dynamic drive (right side of dash)
- Dynamic drive valve block (under right center of vehicle)
- Fuse f14 10a
- Hot w/ term 30g relay energized
- Junction box (under right side of dash)
- Nca
- Oil level switch
- Red
- X10648
- X10649
- X10650
- X10651
- X10652
- X10653
- X10654
- X10655
- X11001
- X1877
- X1878
- X2042
- X490 (bottom of right "a" pillar)
Электросхема жесткости подвески для BMW X5 48i 2007
Электросхема жесткости подвески для BMW X5 48i 2007 - Список элементов:
- Computer data lines system
- Fuse f106 7.5a
- Fuse f120 5a
- Fuse f5 7.5a
- Hot w/ term 30g relay energized
- Junction box (under right side of dash)
- Left front damper satellite (front of left front wheel)
- Left front level sensor
- Left rear damper satellite (under vehicle)
- Left rear level sensor
- Nca
- Pnk
- Rear power distribution box (right side of rear compt)
- Red
- Right front damper satellite (behind right front wheel)
- Right front level sensor
- Right rear damper satellite (behind right rear wheel)
- Right rear level sensor
- Vertical dynamic management (right side of rear compt)
- X10275
- X10276
- X11002
- X11012
- X13790
- X1450
- X1451
- X165 (left side of engine compt)
- X167
- X16820
- X16821
- X1809
- X1810
- X1811
- X1812
- X405
- X406
- X407
- X408
- X498 (right side of rear compt floor)
