Электросхема навигации GPS (1 из 2) для Nissan Murano SE 2007

Электросхема навигации GPS (1 из 2) для Nissan Murano SE 2007 - Список элементов:

• (behind right end of dash)
• (behind right rear seat) b116
• 12a
• 8p/r
• Acc
• B20 (behind left rear seat)
• Back-up lamp relay (under left side of dash,
• Bat
• Block (j/b))
• Bus shield
• Bus+
• Bus-
• Camera +
• Camera -
• Camera 6v
• Camera on
• Camera+
• Camera-
• Can-h
• Can-l
• Compo +
• Compo -
• Computer data lines system
• Control 1
• Data link connector (below left side of dash)
• Ddl
• F103
• Fuse & fusible link block (left front of engine compt,
• Fuse 10a
• Fuse 15a
• Fuse block (j/b) (below left side of dash)
• Gnd
• Gnd (pwr)
• Gps ant
• Gps antenna
• Hot at all times
• Hot in on or acc
• Hot in on or start
• Ign
• Ill
• Interior lights system
• M351
• M49
• M50
• M62
• M63
• M78
• M78 (behind right end of dash)
• Navi control unit (under front of center console)
• Nca
• Near battery)
• Near fuse
• Rear view camera (in back door)
• Rear view camera control unit (right rear of cargo area)
• Red
• Rev
• Rev lamp rly transmission control module (tcm) (behind right side of dash)
• Rgb shield
• Rgb sync
• Shield
• Speed
• Sync shield
• Unified meter & a/c amplifier (behind lower center of dash)
• Voice guid +
• Voice guid -

Электросхема навигации GPS (2 из 2) для Nissan Murano SE 2007

Электросхема навигации GPS (2 из 2) для Nissan Murano SE 2007 - Список элементов:

• A/c & av switch
• Acc
• Audio unit
• Bus shield
• Bus+
• Bus-
• Can-h
• Can-l
• Combination switch (spiral cable)
• Computer data lines system
• Dcu-dsp
• Defogger system
• Display
• Display control unit (behind center of dash)
• Down
• Dsp gnd
• Dsp shield
• Dsp-dcu
• Gnd
• Ign
• Ill
• Ill cont
• Ill+
• Interior lights system
• Inv gnd
• Inv vcc
• M203
• M42
• M43
• M44
• M46
• M78 (behind right end
• M78 (behind right end of dash)
• Mode switch
• Nca
• Of dash)
• Off
• Pnk
• Power switch
• Red
• Rgb gnd
• Rgb shield
• Rgb sync
• Rr def on
• Rv cam
• Rx (aud-dcu)
• Rx (dcu-aud)
• Seek switch
• Shield
• Sig gnd
• Sig vcc
• Sign gnd
• Sign vcc
• Speed
• Steering switch
• Strg sw a
• Strg sw b
• Strg sw c
• Sync gnd
• Sync shield
• Tv+/vtr+
• Tv-/vtr-
• Tx (aud-dcu)
• Tx (dcu-aud)
• Voice guid +
• Voice guid -
• Volume switch
