ПРИБОРНАЯ ПАНЕЛЬ

Электросхема панели приборов для Mazda B4000 2006

Электросхема панели приборов для Mazda B4000 2006 https://portal-diagnostov.com/license.html
https://portal-diagnostov.com/license.html Automotive Electricians Portal FZCO Automotive Electricians Portal FZCO
Получить доступ ко всем электросхемам автомобиляDownload PDF file

Электросхема панели приборов для Mazda B4000 2006 - Список элементов:

  • (under center of dash) g8
  • (under driver's seat) g10
  • 0922-101
  • 0922-102
  • 2.3l
  • 4wd high ind
  • 4wd low ind
  • 4x4 status
  • A10
  • A11
  • A12
  • A13
  • A14
  • A15
  • A16
  • A17
  • A18
  • A19
  • A20
  • Abs ind
  • Air bag ind
  • Anti-lock brakes system
  • Anti-theft system
  • B10
  • B11
  • B12
  • B13
  • B14
  • B15
  • B16
  • B18
  • B20
  • Can +
  • Can -
  • Charge ind
  • Check engine ind
  • Check fuel cap ind
  • Chime
  • Computer data lines system
  • Cruise control ind
  • Cruise control system
  • Door ajar ind
  • Driver side rear door ajar switch
  • Ect sig
  • Engine controls system
  • Engine coolant temperature gauge
  • Exterior lights system
  • Failsafe cooling ind
  • Fuel gauge
  • Fuel lvl sig
  • Fuel tank unit (in fuel tank)
  • Fuse 10a
  • Fuse 5a
  • G10 (under driver's seat)
  • G8 (under center of dash)
  • G8 (under center of dash)
  • G9 (at left kick panel)
  • Gnd
  • Headlights system
  • High beam ind
  • Hot at all times
  • Hot in run or start
  • Illumination (6 bulbs)
  • Immobilizer ind
  • Instrument cluster
  • Interior lights system
  • J-2280b
  • J-2280c
  • J-2280d
  • Left front door ajar switch
  • Left turn signal ind
  • Low brake fluid level/park brake ind
  • Low fuel ind
  • Microprocessor
  • Nca
  • O/d off ind
  • Odometer/ tripmeter
  • Oil pressure ind
  • Oil pressure switch (on lower left rear of engine)
  • Park lmp rly out
  • Parking brake switch (behind left side of dash, on park brake assembly)
  • Passenger side rear door ajar switch
  • Powertrain control module (pcm) (at right rear of engine compt, through firewall)
  • Prndl
  • Right front door ajar switch
  • Right turn signal ind
  • Safety belt ind
  • Smart junction box (at right kick panel)
  • Solid state
  • Speedometer
  • Starting/charging system
  • Tach sig
  • Tachometer
  • Tone sig
  • Transmissions & cruise control systems
  • Transmissions system
  • Transmissions system transmissions & engine controls systems engine controls system
  • Vbatt
  • Voltmeter
  • Vpwr
  • Vss
  • Warning chime
  • Warning system
  • Water temperature sender (2.3l: at rear of engine) (3.0l & 4.0l: on top front center of engine)
