Электросхемы СИСТЕМА КОНДИЦИОНЕРА Suzuki Grand Vitara 2007

СИСТЕМА КОНДИЦИОНЕРА

Электросхема кондиционера (1 из 2) для Suzuki Grand Vitara 2007

Электросхема кондиционера (1 из 2) для Suzuki Grand Vitara 2007 - Список элементов:

• (behind right side of dash) j/c g78
• (under left side of dash) j/c g09
• Automatic a/c unit
• Blower fan motor (behind right side of dash)
• Body control module (behind left side of dash)
• Computer data lines system
• Diode 2 (behind right side of dash)
• Dome fuse 15a
• E82
• Ect sensor (left rear of engine)
• Fan driver (behind right side of dash)
• Fr blw fuse 40a
• Fuse box 2 (left rear of engine compartment)
• G03
• G11
• G12
• G30
• Hot at all times
• Hot in on
• Hot in on or start
• Ig2 sig fuse 15a
• Interior lights system
• J/c g10 (under right side of dash)
• J/c g76 (behind left side of dash)
• Junction block (behind left side of dash)
• Meter fuse 10a
• Pnk
• Radiator fan motor 1 (left front of engine compt)
• Room temperature sensor (behind left side of dash)
• Sunlight sensor (under top left side of dash)

Электросхема кондиционера (2 из 2) для Suzuki Grand Vitara 2007

Электросхема кондиционера (2 из 2) для Suzuki Grand Vitara 2007 - Список элементов:

• (behind right headlight assembly) g7
• (under right center of dash) fresh/recircle actuator
• A/c compressor (left front of engine)
• A/c compressor relay
• A/c pressure sensor (left front of engine compt)
• C37
• Cprsr fuse 15a
• E23
• E37
• E58
• E82
• Ecm (left side of engine compartment)
• Fuse box 1 (right rear of engine compartment)
• G7 (behind right headlight assembly)
• G9 (behind left headlight assembly)
• Heater motor relay (in fuse box 2)
• Hot at all times
• Hot in on
• Ig2 sig fuse 15a
• Junction block (behind left side of dash)
• Mode selecting actuator (under right center of dash)
• Pnk
• Power integration
• Radiator fan motor 2 (left front of engine compt)
• Radiator fan relay 1 (in relay box)
• Radiator fan relay 2 (in relay box)
• Radiator fan relay 3 (in relay box)
• Rdtr 2 fuse 30a
• Rdtr fuse 30a
• Red
• Temperature control actuator (under right center of dash)
• Thermistor
