Электросхемы СИСТЕМА КРУИЗКОНТРОЛЯ Mazda B3000 Dual Sport 2005

СИСТЕМА КРУИЗКОНТРОЛЯ

Электросхема системы круизконтроля для Mazda B3000 Dual Sport 2005

Электросхема системы круизконтроля для Mazda B3000 Dual Sport 2005 - Список элементов:

• 0318-03
• 0922-102
• 0922-202
• 10a
• A/t
• Air bag sliding contact (on steering column)
• Brake pedal position switch (behind left side of dash, on brake pedal support)
• Brake pressure switch (at master cylinder)
• Clutch pedal position switch (behind left side of dash, top of clutch pedal support)
• Coast(-)
• Cruise control indicator
• Cruise ctrl ind
• Engine controls system
• Four-wheel drive control module (behind center of dash)
• Fuse 20
• Fuse 26
• Fuse 32
• Fuse 7
• G10 (under driver's seat)
• G5 (at right rear corner of engine compt)
• G8 (under center of dash)
• Gnd
• Ground steering wheel assembly
• Head
• Horns system
• Hot at all times
• Hot in run
• Hot in start or run
• Illumination
• In put
• Instrument cluster
• Interior lights system
• J-2280b
• J-2280c
• M/t
• Main light switch
• Microcomputer
• Nca
• Off
• Output shaft speed sensor
• Park
• Powertrain control module (pcm) (at right rear of engine compt, through firewall)
• Rest
• Resume
• Set(+)
• Sig rtn
• Smart junction box (at right kick panel)
• Speed control servo (in right rear of engine compartment)
• Speed control on/off switch
• Speed control set/ resume switch
• Vpwr
• Vref
• Vss
