Электросхемы Стартер Генератор Nissan Murano SL 2004

Стартер Генератор

Электросхема Генератора для Nissan Murano SL 2004

Электросхема Генератора для Nissan Murano SL 2004 - Список элементов:

• Alternator
• Battery
• Charge ind
• Combination meter
• E29 (at right side of engine compt)
• E35
• F26
• F27
• Fuse & fusible link block (left front of engine compt, near battery)
• Fuse 10a
• Fuse 33 10a
• Fuse block (j/b) (left side of dash)
• Fusible link holder (left front of engine compt, at positive battery terminal)
• Hot at all times
• Hot in on or start
• M25
• Nca

Электросхема стартера для Nissan Murano SL 2004

Электросхема стартера для Nissan Murano SL 2004 - Список элементов:

• Acc
• Battery
• Can- h rly
• Can- l rly
• Computer data lines system
• Cpu
• Cvt unit (at bottom left of transmission)
• E13 (at left front corner of engine compt)
• E28 (at right side of engine compt)
• F103
• F104
• Fuse & fusible link block (left front of of engine compt, near battery)
• Fuse 10a
• Fuse 15a
• Fusible link m 40a
• Hot at all times
• Ignition switch
• Inh sw1
• Inh sw2
• Inh sw3
• Inh sw3 mon
• Inh sw3m
• Inh sw4
• Intelligent power distribution module engine room (right front of engine compt, behind headlight)
• Lock
• Nca
• Off off off on on
• Off off on on on
• Off on
• Off on off on off
• Off on on on off
• P r n d l
• Park/ neutral position switch
• Shift position
• Start
• Starter motor
• Starter relay
• Starter rly
• Transmission control module (tcm) (behind right side of dash)
