ЗАЗЕМЛЕНИЕ ПОДКЛЮЧЕНИЕ МАССЫ

Электросхема подключение массы заземления для Suzuki SX4 2012

Электросхема подключение массы заземления для Suzuki SX4 2012 https://portal-diagnostov.com/license.html
https://portal-diagnostov.com/license.html Automotive Electricians Portal FZCO Automotive Electricians Portal FZCO
Получить доступ ко всем электросхемам автомобиляDownload PDF file

Электросхема подключение массы заземления для Suzuki SX4 2012 - Список элементов:

  • 2wd/4wd switch
  • 4wd control module
  • A/b sdm
  • Abs control module
  • Accessory socket
  • Audio
  • Battery
  • Bcm
  • Blower motor relay
  • Blower motor resistor
  • Blower speed selector
  • Body control module (bcm)
  • Brake fluid level switch
  • Ckp sensor
  • Cmp sensor
  • Combination meter
  • Combination switch
  • Condenser cooling fan motor
  • Contact coil
  • Cpp cut switch (if equipped)
  • Cvt control
  • Cvt relay
  • Dlc
  • Driver seat heater
  • Driver seat heater switch
  • Driver side actuator state switch
  • Driver side front power door lock switch
  • Driver side position sensor
  • Driver side power door lock main switch
  • Driver side power mirror motor
  • Driver side power window main switch
  • Driver side request switch
  • Driver side seat belt switch
  • Driver side seat heater
  • Driver side seat heater switch
  • Elcm (if equipped)
  • Engine control module (ecm)
  • Esp control module
  • Esp off switch
  • Flasher relay
  • Front fog light switch
  • Fuel pump & fuel gauge
  • G1 (left front of engine compt)
  • G11 (behind right kick panel)
  • G12 (behind left kick panel)
  • G13 (behind left kick panel)
  • G14 (behind right side of dash)
  • G15 (under front passenger's seat)
  • G16 (under front passenger's seat)
  • G17 (under driver's seat)
  • G18 (under driver's seat)
  • G19 (hatch back: base of right "d" pillar) (sedan: at right rear wheel well)
  • G2 (on transaxle)
  • G20 (hatch back: base of right "d" pillar) (sedan: at right rear wheel well)
  • G21 (hatch back: base of left "d" pillar) (sedan: at left rear wheel well)
  • G22 (hatch back: base of left "d" pillar) (sedan: at left rear wheel well)
  • G23 (hatchback) (right side of tailgate)
  • G24 (top of fuel tank)
  • G25 (at right "c" pillar)
  • G3 (right rear of engine)
  • G4 (right rear of engine)
  • G6 (left rear of engine compt)
  • G7 (left rear of engine compt)
  • G8 (at right front strut tower)
  • G9 (at right front strut tower)
  • Hazard switch
  • Hazard warning light switch
  • High mounted brake light
  • High mounted brake light (sedan)
  • High mounted stop light
  • Hvac control module (automatic a/c)
  • Hvac control unit (manual a/c)
  • Id control module (if equipped)
  • Ignition coils 1 & 2
  • Ignition coils 3 & 4
  • Immobilizer control module
  • Interior light (hatchback)
  • Interior light (sedan)
  • Keyless start system control module
  • Left backup light
  • Left brake light
  • Left front fog light
  • Left front position light
  • Left front turn signal light
  • Left headlight hi relay
  • Left headlight lo relay
  • Left rear turn signal light
  • Left side marker
  • Left side marker light
  • Left tail light
  • License plate light 1
  • License plate light 1 (hatchback)
  • License plate light 1 (sedan)
  • License plate light 2
  • License plate light 2 (hatchback)
  • License plate light 2 (sedan)
  • Module
  • Passenger seat heater
  • Passenger seat heater switch
  • Passenger side actuator state switch
  • Passenger side power door lock sub switch (if equipped)
  • Passenger side power mirror motor
  • Passenger side request switch
  • Passenger side seat belt sensor
  • Passenger side seat heater
  • Passenger side seat heater switch
  • Power mirror switch
  • Radiator cooling fan relay 3
  • Radiator fan motor
  • Rear acc socket (hatchback)
  • Rear defogger
  • Rear defogger (hatchback)
  • Rear defogger (sedan)
  • Rear end door request switch
  • Rear end door request switch (hatchback)
  • Rear end power door lock solenoid
  • Rear end power door lock solenoid (hatchback)
  • Rear end power door lock switch
  • Rear end power door lock switch (hatchback)
  • Rear wiper & washer switch (hatchback)
  • Rear wiper motor
  • Rear wiper motor (hatchback)
  • Rear wiper relay (hatchback)
  • Right backup light (hatchback)
  • Right backup light (sedan)
  • Right brake light (hatchback)
  • Right brake light (sedan)
  • Right front fog light
  • Right front position light
  • Right front turn signal light
  • Right headlight hi relay
  • Right headlight lo relay
  • Right rear turn signal light (hatchback)
  • Right rear turn signal light (sedan)
  • Right side marker
  • Right side marker light
  • Right tail light (hatchback)
  • Right tail light (sedan)
  • Select lever assembly
  • Shift lock relay
  • Spot light (hatchback)
  • Spot light (sedan)
  • Starting motor relay
  • Steering angle sensor
  • Trunk room lock solenoid (sedan)
  • Trunk room request switch (sedan)
  • Turn signal switch
  • Windshield wiper & washer switch
  • Windshield wiper motor
  • Yaw/g sensor
