Электросхемы ПРИВОД ЛЮКА И КРЫШИ Subaru Forester X 2006

  1. Главная
  2. >SUBARU
  3. >Subaru 2006
  4. >Subaru Forester X 2006
  5. >Subaru Forester X 2006 - Список всех электросхем

Download PDF file

ПРИВОД ЛЮКА И КРЫШИ

Электросхема привода люка для Subaru Forester X 2006

Электросхема привода люка для Subaru Forester X 2006 https://portal-diagnostov.com/license.html
https://portal-diagnostov.com/license.html Automotive Electricians Portal FZCO Automotive Electricians Portal FZCO
Получить доступ ко всем электросхемам автомобиляDownload PDF file

Электросхема привода люка для Subaru Forester X 2006 - Список элементов:

  • A/t
  • Acc
  • B17
  • B54
  • B72
  • Close
  • Exterior lights system
  • F36
  • F68
  • Fuse 5 15a
  • Gb-1 (at left kick panel)
  • Hot at all times
  • Ignition relay (under left side of dash, on relay block)
  • Ignition switch
  • Lock
  • M/t
  • Main fuse box (m/b) (at left side of engine compt)
  • Nca
  • Off
  • Open
  • Power window circuit breaker (behind left side of dash)
  • Power window relay (under left side of dash, on relay block)
  • Sbf-6 fuse 30a
  • Start
  • Sun roof control module & motor
  • Sun roof switch
  • Transmission control module (behind left side of dash)
  • Vehicle speed sensor (on right side of transmission case)
