Электросхемы Противоугонная система Сигнализация Subaru Forester XS 2010

Противоугонная система Сигнализация

Электросхема открывания авто (1 из 2) для Subaru Forester XS 2010

Электросхема открывания авто (1 из 2) для Subaru Forester XS 2010 - Список элементов:

• B144
• B158
• B186
• B279
• B280
• B281
• B434
• B440
• B444
• B52
• Body integrated unit (behind center of dash)
• F35
• Fuse & relay box (f/b) (behind left side of dash)
• Fuse 10a
• Fuse 15a
• Fuse 20a
• Gb-3 (right side of dash)
• Gb-4 (center of dash)
• Gb-5 (left side of dash)
• Gb-8 (right front floor pan)
• Gb-9 (left rear of vehicle chassis)
• Hood switch (right front of engine compt)
• Horn (behind center of front grille)
• Horn (front of engine compt)
• Hot at all times
• Hot w/ horn relay energized
• Hot w/ ig2 relay energized
• I84
• Impact sensor (left side of dash)
• Key warning switch (left side of dash)
• Keyless buzzer (left front of engine compt)
• Keyless entry control module (left rear vehicle chassis)
• Left front door switch
• Left rear door switch (rear of left rear door)
• Main fuse box (m/b) (left side of engine compt)
• Multi j/c b434 & b444
• Multi j/c b440 & b443 b443
• R168
• Remote engine start control module (left side of dash)
• Right front door switch
• Right rear door switch

Электросхема открывания авто (2 из 2) для Subaru Forester XS 2010

Электросхема открывания авто (2 из 2) для Subaru Forester XS 2010 - Список элементов:

• (center of dash) gb-6
• (right side of dash) j/c i97 & i98
• Combination meter
• D125
• Door
• Door warning light
• Driver circuit
• Gb-10 (center of dash)
• Gb-11 (center of dash)
• Gb-8 (right front floor pan)
• I97
• I98
• Interior lights system
• J/c i98 (right side of dash)
• Left front door lock actuator (rear of left front door)
• Left rear door lock actuator (rear of left rear door)
• Micro computer
• Nca
• Off
• Passenger's door lock switch
• Power window main switch (door lock switch)
• Rear gate latch switch (lower center of rear gate)
• Rear gate opener button
• Right front door lock actuator (rear of right front door)
• Right rear door lock actuator (rear of right rear door)
• Room light
• Security ind
• W/ sunroof
• W/o sunroof

Электросхема иммобилайзера для Subaru Forester XS 2010

Электросхема иммобилайзера для Subaru Forester XS 2010 - Список элементов:

• B136
• B186
• B279
• B280
• B52
• Body integrated unit (behind center of dash)
• Combination meter
• Computer data lines system
• Door locks system
• Engine control module (ecm) (under right side of dash)
• Fuse & relay box (f/b) (behind left side of dash)
• Fuse 15a
• Gb-4 (center of dash)
• Hot at all times
• I84
• Immobilizer antenna (behind left side of dash)
• Key warning switch (left side of dash)
• Keyless entry control module (left rear vehicle chassis)
• Main fuse box (m/b) (left side of engine compt)
• Pnk
• R168
• Security/ immobilizer ind
