СИСТЕМА АНТИБЛОКИРОВОЧНОЙ ТОРМОЗНОЙ СИСТЕМЫ ABS

Электросхема антиблокировочной тормозной системы АБС (ABS), С VDC (1 из 2) для Subaru Forester X 2006

Электросхема антиблокировочной тормозной системы АБС (ABS), С VDC (1 из 2) для Subaru Forester X 2006 - Список элементов:

• B136
• B368
• B54
• Data link connector (under dash, left of steering column)
• Engine control module (under right side of dash)
• Fl inlt
• Fl outlt
• Fr inlt
• Fr outlt
• Motor relay
• Nca
• Pri cut
• Pri press sen
• Pri suct
• Pump motor vdc hydraulic unit (right side of engine compt)
• Red
• Rl inlt
• Rl outlt
• Rr inlt
• Rr outlt
• Sec cut
• Sec press sens
• Sec suct
• Transmission control module (behind left side of dash)
• Valve relay
• Vdc cm (behind right side of dash)
• Vdc hydraulic unit (right side of engine compt)
• Vdc1

Электросхема антиблокировочной тормозной системы АБС (ABS), С VDC (2 из 2) для Subaru Forester X 2006

Электросхема антиблокировочной тормозной системы АБС (ABS), С VDC (2 из 2) для Subaru Forester X 2006 - Список элементов:

• Abs warning light ind
• B158
• B352
• B355
• B52
• Brake fluid warning indicator light
• Can joint connector
• Combination meter
• F41
• Fuse & relay box (behind left side of dash)
• Fuse 14 10a
• Fuse 18 15a
• Fuse 8 30a
• Gb-1 (at left kick panel)
• Gb-3 (at right kick panel)
• Hot at all times
• Hot in on or start
• I10
• I11
• I12
• Interior lights system
• Kick panel) gb-3
• Left front abs wheel speed sensor (at right rear of engine compt)
• Left rear abs wheel speed sensor (at left rear wheel hub assembly)
• Nca
• Red
• Right front abs wheel speed sensor (at right rear of engine compt)
• Right rear abs wheel speed sensor (at right rear wheel hub assembly)
• Sbf holder (on left side of engine compt)
• Sbf-7 fuse 50a
• Steering angle sensor (behind left side of dash)
• Vdc off switch
• Vdc operation indicator light
• Vdc shield j/c (behind right side of dash)
• Vdc warning light ind
• Yaw rate & lateral g sensor (below center console)

Электросхема антиблокировочной тормозной системы АБС (ABS), без VDC для Subaru Forester X 2006

Электросхема антиблокировочной тормозной системы АБС (ABS), без VDC для Subaru Forester X 2006 - Список элементов:

• (on left side of engine compt)
• Abs "g" sensor (under rear of center console)
• Abs control module (on right front side of engine compt)
• Abs warning light ind
• B136
• B158
• B302 (abs motor ground) (at front center of engine compt)
• B52
• B54
• Can joint connector (a/t)
• Combination meter
• Data link connector (under dash, left of steering column)
• Engine control module (a/t) (under right side of dash)
• F41
• Fl in
• Fl out
• Fr in
• Fr out
• Fuse & relay box (behind left side of dash)
• Fuse 14 10a
• Fuse 16 20a
• Fuse 18 15a
• Fuse 8 30a
• Gb-2 (at base of right "a" pillar)
• Hot at all times
• Hot in on or start
• I10
• I11
• Left front abs wheel speed sensor (at right rear of engine compt)
• Left rear abs wheel speed sensor (at left rear wheel hub assembly)
• Motor relay
• Parking brake fluid level warning light ind
• Pump motor
• Red
• Reverse circuit
• Right front abs wheel speed sensor (at right rear of engine compt)
• Right rear abs wheel speed sensor (at right rear wheel hub assembly)
• Rl in
• Rl out
• Rr in
• Rr out
• Sbf holder
• Sbf-7 fuse 30a
• Solenoid valve
• Stop & brake switch (under left side of dash)
• Transmission control module (a/t) (behind left side of dash)
• Valve relay
