СИСТЕМЫ ПОДВЕСКИ

Электросхема электроники подвески для Volkswagen Tiguan SEL 4Motion 2010

Электросхема электроники подвески для Volkswagen Tiguan SEL 4Motion 2010 https://portal-diagnostov.com/license.html
https://portal-diagnostov.com/license.html Automotive Electricians Portal FZCO Automotive Electricians Portal FZCO
Получить доступ ко всем электросхемам автомобиляDownload PDF file

Электросхема электроники подвески для Volkswagen Tiguan SEL 4Motion 2010 - Список элементов:

  • 14a
  • 56b
  • Computer data lines system
  • Dampening adjustment button & indicator lamp
  • Electronic damping control module (left side of luggage compt)
  • Fuse 10a
  • Fuse 15a
  • Fuse panel c (lower left end of dash)
  • G61 (left "c" pillar)
  • Hot at all times
  • Left front body acceleration sensor (on left front strut tower)
  • Left front damping adjustment valve (left front wheelwell)
  • Left front level control system sensor
  • Left rear damping adjustment valve (left rear wheelwell)
  • Left rear level control system sensor (left rear lower control arm)
  • Pnk
  • Rear body acceleration sensor (near top of left rear shock absorber)
  • Red
  • Right front body acceleration sensor (on right front strut tower)
  • Right front damping adjustment valve (right front wheelwell)
  • Right front level control system sensor (on right front axle housing)
  • Right rear damping adjustment valve (right rear wheelwell)
