Component Component Location A/C CLU Relay In underhood electrical center. See Fig. 1 . Air Pump Relay In underhood electrical center. See Fig. 1 . Air Relay In underhood electrical center. See Fig. 1 . Blower Motor Relay In underhood electrical center. See Fig. 1 . Bose Relay In dash electrical center. See Fig. 1 . Cooling Fan 1 Relay In underhood electrical center. See Fig. 1 . Cooling Fan 2 Relay In underhood electrical center. See Fig. 1 . Cooling Fan 3 Relay In underhood electrical center. See Fig. 1 . Courtesy Lamp Relay In dash electrical center. See Fig. 1 . Daytime Running Lamp Relay (2) In dash electrical center. See Fig. 1 . Defogger RR Relay In dash electrical center. See Fig. 1 . Fog LP Relay In underhood electrical center. See Fig. 1 . Fuel Pump Relay In underhood electrical center. See Fig. 1 . Hatch/Tonn Relay In dash electrical center. See Fig. 1 . Horn Relay In underhood electrical center. See Fig. 1 . Ignition Relay In underhood electrical center. See Fig. 1 . Monitored Micro Relay In dash electrical center. See Fig. 1 . Perim Lamp Relay In underhood electrical center. See Fig. 1 . RTD Relay In underhood electrical center. See Fig. 1 . Theft Deterrent Relay In dash electrical center. See Fig. 1 .
Chevrolet Corvette 1997 - CIRCUIT PROTECTION DEVICES
Chevrolet Corvette 1997 CIRCUIT PROTECTION DEVICES
Component Component Location Electrical Center, Dash On right side of dash. See Fig. 1 . Electrical Center, Underhood On right rear of engine compartment. See Fig. 1 . Right Relay Center Under right seat. See Fig. 1 .
Chevrolet Corvette 1997 - CONTROL UNITS
Chevrolet Corvette 1997 CONTROL UNITS
Component Component Location Blower Motor Control Module Behind right side of dash. See Fig. 1 . Body Computer Module (BCM) Mounted on toe board. Daytime Running Lamps (DRL) Module Behind left side of dash. See Fig. 1 . Door Control Module (2) In lower center of respective door. Driver Seat Control Module On underside of driver's seat. See Fig. 1 . Electronic Brake/Traction Control Module (EBTCM) Rear of vehicle, behind center of axle. See Fig. 1 . Electronic Suspension Control Module In rear compartment, inside rear tub. See Fig. 1 . Electronic Throttle Actuator Control (TAC) Module On right side of engine compartment, mounted on side of PCM. See Fig. 1 . Electronic Traction/ Suspension Control Module In rear compartment, inside rear tub. See Fig. 1 . Headlamp Opening Door Actuator Control Module In lower right front of engine compartment. See Fig. 1 . HVAC Programmer Module On HVAC control panel, under radio. See Fig. 1 . Ignition Control Module (8) On valve covers, at top of respective cylinders. Inflatable Restraint Diagnostic Energy Reserve Module (DERM) Module Below center of dash. See Fig. 1 . Inflatable Restraint Diagnostic Energy Reserve (DERM) with Sensor Module Behind right side of dash. See Fig. 1 . Powertrain Control Module (PCM) On right side of engine compartment. See Fig. 1 .
Chevrolet Corvette 1997 - MOTORS
Chevrolet Corvette 1997 MOTORS
Component Component Location Blower Motor On right side of firewall. Door Lock Motor (2) In respective door. Electronic Throttle Actuator Motor On left side of throttle body. Engine Coolant Fan, Left Behind left side of radiator. Engine Coolant Fan, Right Behind right side of radiator. Fuel Tank Filler Door Lock Actuator Solenoid Actuator On left side of cargo compartment, rear of fuel filler door. Headlamp Opening Door Assembly (2) Behind respective headlamp assembly. Magnasteer Actuator On left side of steering gear. Power Seat Motor (3) Under each seat. Power Window Motor (2) In lower section of each door. Secondary Air Injection (AIR) Pump Motor On left front of engine compartment, on skid bar. Temperature Door Motor Behind dash, mounted on heater plenum. Windshield Washer Pump Motor On left rear of engine compartment, in washer fluid reservoir. Windshield Wiper Motor On left side of firewall.
Chevrolet Corvette 1997 - SENDING UNITS & SENSORS
Chevrolet Corvette 1997 SENDING UNITS & SENSORS
Component Component Location Ambient Light Sensor On top of dash, next to defroster duct. Automatic Transmission Fluid Temperature (TFT) Sensor Inside transmission. Camshaft Position Sensor On top center rear of engine. Crankshaft Position Sensor On lower right side of engine. Electronic Suspension Position Sensor (4) On rear of respective shock spring. Engine Coolant Temperature (ECT) Sensor On left side of engine, below generator. Fuel Level Sensor Inside fuel tank. Fuel Pressure Sensor Inside fuel tank. Heated Oxygen Sensors (HO2S), Front (2) On exhaust system, forward of catalytic converter's. Heated Oxygen Sensors (HO2S), Rear (2) On exhaust system, rear of catalytic converter's. Inflatable Restraint Front End Sensor On lower front center of body frame. Inside Air Temperature Sensor In air outlet, right of dash. Intake Air Temperature (IAT) Sensor On front center of engine, in air intake duct. Knock Sensors (2) On center of engine, below intake manifold. Manifold Absolute Pressure (MAP) Sensor On top rear of intake manifold. Mass Air Flow (MAF) Sensor On air filter assembly. Oil Level Sensor On left side of oil pan. Oil Pressure Sensor Near oil filter. Oil Temperature (EOT) Gage Sensor On top center rear of engine. Outside Air Temperature Sensor On right front of engine compartment. Pedal Position Sensor On base of accelerator pedal. Steering Wheel Position Sensor On left side of steering gear. Sunload Sensor On center of dash. Throttle Position (TP) Sensor On throttle body assembly. Transmission Output Speed Sensor Inside transmission. Vehicle Speed Sensor (VSS) On right side of differential. Wheel Speed Sensors (4) Part of front wheel hub & rear wheel suspension knuckle.
Chevrolet Corvette 1997 - SOLENOIDS & SOLENOID VALVES
Chevrolet Corvette 1997 SOLENOIDS & SOLENOID VALVES
Component Component Location 2-3 Gear Block Out Solenoid (M/T) Under vehicle, on left side of transmission. Brake Pressure Modulator (BPM) Valve Mounted behind center rear axle. Brake/Transmission Shift Interrupt (BTSI) Solenoid Under center console, near transmission range switch. Brake Transmission Shift Lock Control (M30) Solenoid Under center console. Evaporative Emission (EVAP) Canister Purge Solenoid Valve On top left side of engine, on intake manifold. Idle Air Control (IAC) Valve On front of engine, in throttle body assembly. Pressure Control Valve Solenoid (PC SOL) Inside transmission. Rear Compartment Lid Lock Release Solenoid (2) On latch of respective rear compartment. Reverse Inhibit Solenoid On left side of transmission. Shock Absorber Solenoid (4) On bottom of respective shock spring. Torque Converter Clutch Pulse Width Modulation Valve Solenoid (TCC PWM SOL) Inside transmission. Torque Converter Control (TCC) Solenoid On side of transmission housing. Torque Converter Clutch Valve (TCC SOL) Solenoid Inside transmission. Valve 1-2 Shift Solenoid (1-2 SS) Inside transmission. Valve 2-3 Shift Solenoid (2-3 SS) Inside transmission. Valve 3-2 Shift Solenoid (3-2 SS) Inside transmission.
Chevrolet Corvette 1997 - SWITCHES
Chevrolet Corvette 1997 SWITCHES
Component Component Location Automatic Transmission Fluid Pressure (TFP) Manual Valve Position Switch Inside transmission. Back-Up Lamp Switch (M/T) On lower left side of transmission. Brake Fluid Level Indication Switch In master cylinder reservoir. Brake/Cruise Switch On top of brake pedal bracket. Brake Transmission Interrupt (BTS) (M30) Switch On bottom of brake pedal. Clutch Pedal Position Switch On top of clutch pedal. Evaporative Emission (EVAP) Vacuum Purge Switch On top left side of engine, on intake manifold. Hood Ajar Switch On engine compartment support bracket. Engine Coolant Level (ECL) Switch On bottom of coolant reservoir. Low Oil Level Switch Lower left rear of engine, forward of oil filter. Park/Neutral Position Switch On left side of transmission. Oil Pressure/Fuel Pump Switch On top rear of engine. Park Brake Switch On parking brake lever. Seat Belt Switch In driver's seat belt buckle assembly. Stoplamp Switch On top of brake pedal support. Torque Converter Clutch (TCC)/ Cruise Switch On top of brake pedal support. Transmission Range Switch (A/T) At base of gear selector lever. Windshield Washer Solvent Level Switch Inside solvent container.
Chevrolet Corvette 1997 - MISCELLANEOUS
Chevrolet Corvette 1997 MISCELLANEOUS
Component Component Location A/C Diode Taped in harness, near A/C compressor clutch connector. Data Link Connector (DLC) Under dash, to right of steering column. Electrical Accessory Plug In center console assembly. Fuel Injector (8) On top of intake manifold, at respective intake port. Ignition Coil (8) On top of cylinder heads, at respective cylinder. Remote Control Door Lock Receiver On left side of rear compartment. Secondary Air Inlet Valve Electric Vacuum Pump Behind right front bumper. Subwoofer Amplifier (2) On respective rear side of cargo compartment.
Chevrolet Corvette 1997 - CONNECTORS
Chevrolet Corvette 1997 CONNECTORS
Component Component Location C100 (8 Pin) At right side of engine compartment, behind headlight. C101 (3 Pin) On engine, above left lower control arm. C102 (Early Production) (8 Pin) At right rear of engine compartment. C102 (Late Production) (20 Pin) At right rear of engine compartment. C103 (2 Pin) On engine, above left lower control arm. C104 (3 Pin) On engine, above right lower control arm. C105 (2 Pin) On engine, above left lower control arm. C106 (2 Pin) On engine, above right lower control arm. C107 (2 Pin) On center of steering rack. C108 (2 Pin) On engine, above right lower control arm. C109 (7 Pin) At top center of left valve cover. C110 (7 Pin) At top center of right valve cover. C112 (2 Pin) At top rear of engine, mounted to vacuum hose. C140 (10 Pin) At right side of engine compartment. C142 (20 Pin) At right rear of engine compartment, below battery. C144 (20 Pin) At right rear of engine compartment, below battery. C146 (Early Production) (20 Pin) At right rear of engine compartment, below battery. C146 (Late Production) (10 Pin) At right rear of engine compartment, below battery. C148 (10 Pin) At right rear of engine compartment, below battery. C150 (Early Production ) (8 Pin) At right rear of engine compartment, below battery. C150 (Late Production) (10 Pin) At right rear of engine compartment, below battery. C200 (6 Pin) In grommet, on right door. C201 (6 Pin) In grommet, on left door. C202 (10 Pin) In grommet, on right door. C203 (10 Pin) In grommet, on left door. C204 (4 Pin) At right rear of engine compartment, below battery. C205 (6 Pin) At right rear of engine compartment. C206 (3 Pin) Under electronic traction/suspension control switch. C207 (4 Pin) Attached to lower dash bar for steering column lock. C209 (23 Pin) At left side of steering column, on lower dash bar. C211 (2 Pin) At left side of steering column, on lower dash bar. C213 (2 Pin) Taped to dash harness, left of Bose signal processor. C215 (10 Pin) Behind hazard warning switch. C217 (4 Pin) At left side of steering column, on lower dash bar. C219 (6 Pin) At left side of steering column, on dash lower bar. C301 (6 Pin) Under left seat. C302 (6 Pin) Under right seat. C400 (8 Pin) At rear of right rear control arm. C401 (3 Pin) On frame, below left rear shock absorber. C402 (10 Pin) Between transmission harness & fuel tank jumper harness. C403 (2 Pin) On frame, below left rear shock absorber. C404 (3 Pin) On frame, below right rear shock absorber. C406 (2 Pin) On frame, below left rear shock absorber. C408 (4 Pin) Fuel tank jumper harness to left fuel tank.
Chevrolet Corvette 1997 - GROUNDS
Chevrolet Corvette 1997 GROUNDS
Component Component Location G101 On left frame rail, between left headlight opener & generator. See Fig. 1 . G102 Between battery & underhood electrical center. See Fig. 1 . G104 On right frame rail, below battery tray. See Fig. 1 . G105 On left bottom of engine. G106 On right side of engine, above starter. G107 At top of left rear of engine. G201 At base of left "A" pillar. See Fig. 1 . G202 At base of right "A" pillar. G205 Behind left seat, at antenna module. See Fig. 1 . G301 In front body harness, 13 cm from left rear speaker breakout. G302 In front body harness. G401 At rear of vehicle, on inner side of left frame rail. See Fig. 1 . G402 At rear of vehicle, on inner side of right frame rail.
Chevrolet Corvette 1997 - SPLICES
Chevrolet Corvette 1997 SPLICES
Component Component Location S100 In right ignition control module jumper, 6 cm from breakout to C110. S101 In left ignition control module jumper, 6 cm from breakout to C109. S102 In right ignition control module jumper, 5 cm from breakout to C110. S103 In left ignition control module jumper, 5 cm from breakout to C109. S104 In right ignition control module jumper, 4 cm from breakout to ignition coil/module No. 4. S105 In left ignition control module jumper, 4 cm from breakout to ignition coil/module No. 5. S106 In forward light harness, 12.5 cm from EBTCM connector breakout. S108 In forward light harness, 6 cm from EBTCM connector breakout. S120 In engine harness, 15 cm from main harness, in branch leading to powertrain control module. S200 In dash harness, 22.5 cm from inside rearview mirror breakout. S201 (Early Production) In dash harness, 30 cm from HVAC control head connector. S201 (Late Production) In dash harness, 35 cm from HVAC control head connector. S202 In dash harness, 46.5 from inside rearview mirror breakout. S204 In engine harness, 7.5 cm from breakout to C150. S205 In dash harness, 16.5 cm from breakout to data link connector. S206 In dash harness, 14 cm from breakout to blower motor control module connector. S207 In dash harness, 20 cm from daytime running lights connector. S208 In dash harness, 32.5 cm from radio connectors. S209 In dash harness, 20 cm from end of instrument cluster connector. S210 In dash harness, 10 cm from breakout to blower motor control module. S211 In dash harness, 29 cm from end of instrument cluster connector. S213 In dash harness, 7.5 cm right of brake switch connector breakout. S215 In dash harness, 6.5 cm left of inflatable restraint dash breakout. S217 In dash harness, 7 cm left of data link connector breakout. S300-IDC In right power seat harness, 13.5 cm from breakout to C302. S301-IDC In left power seat harness, 11 cm from breakout for C301. S302 In front body harness, 7.5 cm from right speaker breakout. S303 (Early Production) In front body harness, 22.5 cm from right speaker breakout. S303 (Late Production) In front body harness, 15 cm from right speaker breakout. S304 (Early Production) In front body harness, 15 cm from right rear speaker breakout. S304 (Late Production) In front body harness, 22.5 cm from right rear speaker breakout. S305-IDC In left power seat harness, 14.5 cm from C301. S306-IDC In left power seat harness, 18.5 cm from C301. S308 In dash harness, 19 cm right of yaw rate connector. S310 In dash harness, 9 cm right of yaw rate connector. S312 In front body harness, 63.5 cm from breakout to C302. S314 In front body harness, 63.5 cm from breakout to C302. S400 In transmission harness, 6.5 cm rearward of C402 breakout. S402 (Early Production) In transmission harness, 16 cm from EBTCM. S402 (Late Production) In transmission harness, 6.5 cm from breakout to right rear shock absorber connector. S404 In transmission harness, 6.5 cm forward of EBTCM breakout. S406 In transmission harness, 29.5 cm from EBTCM. S408 In fuel tank jumper harness, 6.5 cm from right fuel tank connector. S410 In fuel tank jumper harness, 81.5 cm from C408 breakout. S481 In rear body harness, 6.5 cm from breakout to left back-up light. S482 In rear body harness, 21.5 cm from SP400 breakout. S484 In rear body harness, 8 cm from SP400 breakout. S492 In rear body harness, 6.5 cm left of right turn signal breakout. S501-IDC In left door harness, 6 cm from outside rearview mirror connector breakout. S600 In right door harness, 6 cm from outside rearview mirror breakout. SP100 In forward light harness, on G102. SP101 In forward light harness, on G101. SP102 Taped to forward light jumper, 10 cm left of C100. SP122 In engine harness, 30 cm from breakout to starter solenoid. SP201 In dash harness. SP202 In dash harness. SP203 In dash harness. SP208 In dash harness, on right side of dash. SP302 In front body harness, 83.5 cm from right power seat breakout. SP400 In rear body harness, taped to harness, between back-up light & tail/stoplight breakout. SP402 In rear body harness, taped to harness, between auto fuse & right license light breakout.
Chevrolet Corvette 1997 - COMPONENT LOCATION GRAPHICS
NOTE:
Fig.res may show multiple component locations. - appropriate table for proper figure references.
Fig. 1: Chevrolet Corvette 1997 - Component Locations - Vehicle Overview
