Dodge Dakota 1997 - 1997 CHRYSLER Dakota

Dodge Dakota 1997 - BUZZERS, RELAYS & TIMERS

Dodge Dakota 1997 BUZZERS, RELAYS & TIMERS

Component	Component Location
ABS Pump Motor Relay	In fuse/relay block.
ABS System Relay	In power distribution center.
A/C Compressor Clutch Relay	In power distribution center.
Automatic Shutdown Relay	In power distribution center.
Blower Motor Relay	In power distribution center.
Combination Flasher	In junction block.
Coolant Fan Relay (2.5L)	In power distribution center.
Engine Starter Motor Relay	In power distribution center.
Fog Lamp Relays	In power distribution center.
Fuel Pump Relay	In power distribution center.
Headlight Relay	In junction block.
Horn Relay	In power distribution center.
Trailer Relays	In power distribution center.
Transmission Relay	In power distribution center.
Wiper Relay	In power distribution center.

Dodge Dakota 1997 - CIRCUIT PROTECTION DEVICES

Dodge Dakota 1997 CIRCUIT PROTECTION DEVICES

Component	Component Location
Brake Warning Lamp Diode	In instrument panel harness, near park brake switch.
Junction Block	Behind left side of dash.
Power Distribution Center	In engine compartment, on left inner fender panel.
Power Window Circuit Breaker	In junction block.

Dodge Dakota 1997 - CONTROL UNITS

Dodge Dakota 1997 CONTROL UNITS

Component	Component Location
Air Bag Control Module	On bracket, under center of dash, above transmission tunnel.
Central Timer Module	Behind right side of dash, near glove box.
Controller Anti-Lock Brake (ABS)	In engine compartment, on left inner fender panel.
Controller Anti-Lock Brake (RWAL)	On right side of steering column support.
Daytime Running Lamps (DRL) Module	On left inner fender panel.
Fuel Pump Module	Top of fuel tank.
Hydraulic Control Unit	In engine compartment, on left inner fender panel.
Powertrain Control Module	In engine compartment, on right inner fender panel. See Fig. 1 .

Dodge Dakota 1997 - MOTORS

Dodge Dakota 1997 MOTORS

Component	Component Location
A/C-Heater Blower Motor	Behind right side of dash.
Coolant Fan Motor (2.5L)	Behind center lower radiator.
Fuel Pump Motor	Integral to fuel pump module.
Idle Air Control Motor (2.5L)	On throttle body. See Fig. 4 .
Idle Air Control Motor (3.9L)	On throttle body. See Fig. 7 .
Idle Air Control Motor (5.2L)	On throttle body. See Fig. 7 .
Vehicle Speed Control Servo	Right side of firewall.
Windshield Washer Fluid Pump Motor	In bottom of windshield washer reservoir.
Windshield Wiper Motor	In engine compartment, on left side of firewall.

Dodge Dakota 1997 - SENDING UNITS & SENSORS

Dodge Dakota 1997 SENDING UNITS & SENSORS

Component	Component Location
Ambient Photocell Sensor	On automatic day/night mirror.
Ambient Temperature Sensor	Radiator top support.
Automatic Transmission Oil Temperature Sensor	Sensor integral to automatic transmission solenoids.
Battery Temperature Sensor	On bottom of battery tray.
Camshaft Position Sensor	In ignition distributor.
Crankshaft Position Sensor (2.5L)	On top left of transmission.
Crankshaft Position Sensor (3.9L)	On top of cylinder block, rear of right cylinder head.
Crankshaft Position Sensor (5.2L)	On top of cylinder block, rear of right cylinder head.
Downstream Heated Oxygen Sensor	Near outlet of catalytic converter.
Engine Coolant Temperature Sensor (2.5L)	On left side of engine, behind distributor ignition coil. See Fig. 4 .
Engine Coolant Temperature Sensor (3.9L)	Between generator & A/C compressor. See Fig. 6 .
Engine Coolant Temperature Sensor (5.2L)	Between generator & A/C compressor. See Fig. 6 .
Engine Oil Pressure Sensor (2.5L)	Near distributor.
Engine Oil Pressure Sensor (3.9L)	In rear of intake manifold, near distributor. See Fig. 7 .
Engine Oil Pressure Sensor (5.2L)	In rear of intake manifold, near distributor. See Fig. 7 .
Fuel Gauge Sending Unit	Integral to fuel pump module.
Headlight Sensor	On automatic day/night mirror.
Intake Air Temperature Sensor (2.5L)	On intake manifold. See Fig. 4 .
Intake Air Temperature Sensor (3.9L)	On intake manifold, near throttle body. See Fig. 6 .
Intake Air Temperature Sensor (5.2L)	On intake manifold, near throttle body. See Fig. 6 .
Left & Right Front Wheel Speed Sensors	On left & right front wheel assemblies.
Manifold Absolute Pressure (MAP) Sensor (2.5L)	On throttle body. See Fig. 4 .
Manifold Absolute Pressure (MAP) Sensor (3.9L)	On throttle body. See Fig. 7 .
Manifold Absolute Pressure (MAP) Sensor (5.2L)	On throttle body. See Fig. 7 .
Output Shaft Speed Sensor (3.9L) (2WD)	On left bottom of transmission. See Fig. 2 .
Output Shaft Speed Sensor (5.2L) (2WD)	On left bottom of transmission. See Fig. 2 .
Output Shaft Speed Sensor (3.9L) (4WD)	On left bottom of transmission. See Fig. 3 .
Output Shaft Speed Sensor (5.2L) (4WD)	On left bottom of transmission. See Fig. 3 .
Rear Wheel Speed Sensor	In differential housing.
Throttle Position (TP) Sensor (2.5L)	On throttle body. See Fig. 4 .
Throttle Position (TP) Sensor (3.9L)	On throttle body. See Fig. 7 .
Throttle Position (TP) Sensor (5.2L)	On throttle body. See Fig. 7 .
Upstream Heated Oxygen Sensor	Near inlet of catalytic converter.
Vehicle Speed Sensor (3.9L) (2WD)	Left rear of transmission. See Fig. 2 .
Vehicle Speed Sensor (5.2L) (2WD)	Left rear of transmission. See Fig. 2 .
Vehicle Speed Sensor (3.9L) (4WD)	Left rear of transfer case. See Fig. 3 .
Vehicle Speed Sensor (5.2L) (4WD)	Left rear of transfer case. See Fig. 3 .
Windshield Washer Low Fluid Level Sensor	In washer fluid reservoir.

Dodge Dakota 1997 - SOLENOIDS & SOLENOID VALVES

Dodge Dakota 1997 SOLENOIDS & SOLENOID VALVES

Component	Component Location
ABS Solenoids	In left side of engine compartment, in ABS hydraulic control unit.
Automatic Transmission Solenoids (3.9L) (2WD)	Left side of transmission. See Fig. 2 .
Automatic Transmission Solenoids (5.2L) (2WD)	Left side of transmission. See Fig. 2 .
Automatic Transmission Solenoids (3.9L) (4WD)	Left side of transfer case. See Fig. 3 .
Automatic Transmission Solenoids (5.2L) (4WD)	Left side of transfer case. See Fig. 3 .
Duty Cycle Purge Solenoid (2.5L)	On right center of firewall. See Fig. 1 .
Duty Cycle Purge Solenoid (3.9L)	Rear of fuel rail. See Fig. 7 .
Duty Cycle Purge Solenoid (5.2L)	Rear of fuel rail. See Fig. 7 .

Dodge Dakota 1997 - SWITCHES

Dodge Dakota 1997 SWITCHES

Component	Component Location
A/C High Pressure Switch (2.5L)	On A/C compressor. See Fig. 5 .
A/C High Pressure Switch (3.9L)	On A/C compressor.
A/C High Pressure Switch (5.2L)	On A/C compressor.
A/C Low Pressure Switch	On receiver/dryer. See Fig. 1 .
Back-Up Lamp Switch (M/T)	On left side of transmission.
Brake Pressure Switch	In hydraulic combination valve.
Clutch Pedal Position Switch	On clutch pedal bracket.
Four Wheel Drive (4WD) Switch	On front of frame.
Park Brake Switch	On parking brake pedal bracket.
Park/Neutral Position Switch (A/T)	On transmission.
Power Steering Pressure Switch	In power steering pressure line.
Seat Belt Switch	Integral to driver's seat belt buckle.
Stop Lamp Switch	On brake pedal bracket.

Dodge Dakota 1997 - MISCELLANEOUS

Dodge Dakota 1997 MISCELLANEOUS

Component	Component Location
Blower Resistor Block	In cowl plenum panel, below right side of windshield.
Clockspring	Top of steering column, below steering wheel.
Data Link Connector (DLC) 1	Bottom edge of knee bolster, right of steering column.
Data Link Connector (DLC) 2	Right fender side shield.
Daytime Running Lamps (DRL) Module Jumper	Left front inner fender.
Driver Air Bag Squib	Left side of dash panel.
Electric Brake (Trailer Towing)	Lower left of dash panel.
Passenger Air Bag Squib	Right center of dash panel.
Power Amplifier	At right side kick panel.
Trailer Tow Connector	Rear of frame.

Dodge Dakota 1997 - CONNECTORS

Dodge Dakota 1997 CONNECTORS

Component	Component Location
C105 (Natural, 4 Pin)	At left fender side shield.
C106 (16 Pin)	At left fender side shield.
C111 (3 Pin)	At left inner fender.
C162 (Black, 3 Pin)	At top of transmission.
C182 (Black, 2 Pin)	At top of transmission.
C200 (Black, 74 Pin)	Behind lower left side of dash.
C205 (Black, 12 Pin)	At right door.
C228 (Black, 12 Pin)	At left door.
C240 (Black, 10 Pin)	At left door.
C241 (Black, 10 Pin)	At right door.
C243 (Black, 12 Pin)	Behind right side of dash.
C244 (10 Pin)	Behind right side of dash.
C246 (Black, 12 Pin)	Behind lower left side of dash.
C247 (Black, 12 Pin)	Behind lower left side of dash.
C322 (Black, 4 Pin)	At left inner fender.
C323 (Black, 2 Pin)	At right rear of frame.
C325 (Black, 4 Pin)	Below left taillight.
C329 (Black, 6 Pin)	Near cargo lights.
C341 (Black, 10 Pin)	In trailer tow wiring harness, at rear of vehicle.
C352 (Gray, 8 Pin)	At left inner fender.
C353 (Black, 5 Pin)	At left inner fender.
C360 (Black, 4 Pin)	At left inner fender.

Dodge Dakota 1997 - GROUNDS

Dodge Dakota 1997 GROUNDS

Component	Component Location
G101	On right front of engine compartment.
G102	On left front frame rail, inside fender.
G103	Near battery.
G106	On left front inner fender.
G107 (2.5L)	On rear of valve cover.
G107 (3.9L)	On left front of engine. See Fig. 6 .
G107 (5.2L)	On left front of engine. See Fig. 6 .
G108 (2.5L)	On right side of engine, near distributor. See Fig. 5 .
G108 (3.9L)	On right front of engine.
G108 (5.2L)	On right front of engine.
G110	On left front inner fender.
G111	Engine ground.
G200	Behind lower left side of dash.
G201	Behind lower center of dash.
G202	Behind right side of dash.
G203	Behind right side of dash.
G305	On rear of frame.

Dodge Dakota 1997 - SPLICES

Dodge Dakota 1997 SPLICES

Component	Component Location
S100	At rear of engine compartment. See Fig. 1 .
S101	At rear of engine compartment. See Fig. 1 .
S102 (2.5L)	Near A/C compressor.
S102 (3.9L)	At right rear of engine, near breakout to fuel injector No. 6.
S102 (5.2L)	At right rear of engine, near breakout to fuel injector No. 6.
S103	At rear of engine.
S104	Near A/C compressor.
S105	At rear of engine.
S106 (2.5L)	At rear of engine. See Fig. 4 .
S106 (3.9L)	Near fuel injector No. 4.
S106 (5.2L)	Near fuel injector No. 4.
S107 (2.5L)	At rear of engine.
S107 (3.9L)	At left rear of engine. See Fig. 7 .
S107 (5.2L)	At left rear of engine. See Fig. 7 .
S108 (2.5L)	At rear of engine, near breakout to distributor.
S108 (3.9L)	At rear of engine, near breakout to distributor. See Fig. 7 .
S108 (5.2L)	At rear of engine, near breakout to distributor. See Fig. 7 .
S109	Near breakout to right headlight.
S110 (3.9L)	Near breakout to fuel injector No. 6. See Fig. 7 .
S110 (5.2L)	Near breakout to fuel injector No. 7. See Fig. 7 .
S111	Near breakout to distributor.
S112	At rear of engine.
S113	Near breakout to underhood light.
S115 (3.9L)	At left rear of engine. See Fig. 7 .
S115 (5.2L)	At left rear of engine. See Fig. 7 .
S149	Near breakout to fuel tank.
S156	At left side of engine compartment, in wiring trough.
S157	At left side of engine compartment, in wiring trough.
S158	At left side of engine compartment, in wiring trough.
S159	Near breakout to battery harness.
S160	At left fender side shield.
S161	At left fender side shield.
S162	At left fender side shield.
S163	At left fender side shield.
S164	At left fender side shield.
S165	At left fender side shield.
S166	Near breakout to left headlight.
S167	Near battery.
S168	Near battery.
S169	Near battery.
S170	Near breakout to ambient temperature sensor.
S200	Near breakout to junction block.
S201	Near breakout to junction block.
S202	Behind instrument cluster.
S203	Behind instrument cluster.
S204	In breakout to steering column.
S205	In breakout to steering column.
S206	Near stoplight switch.
S207	Behind right center of dash.
S208	Behind right center of dash.
S209	Behind center of dash.
S210	Behind center of dash.
S211	In breakout to air bag control module.
S212	In breakout to air bag control module.
S213	Behind center of dash.
S214	Near air bag control module.
S215	Behind center of dash.
S216	Near breakout to cigar lighter.
S217	Near breakout to cigar lighter.
S218	Behind right side of dash.
S219	Behind right side of dash.
S220	Behind right side of dash.
S221	Behind right side of dash.
S222	Behind right side of dash.
S223	Behind right side of dash.
S224	Behind right side of dash.
S225	Above right kick panel.
S231	Near breakout to overhead console.
S232	Near breakout to overhead console.
S233	Near breakout to rear speaker.
S240	Above right kick panel.
S306	Near breakout to fuel tank.
S314	Near breakout to taillights.
S316	At left rear frame rail.
S317	At left side of frame, near aftermarket CHMSL connector.
S318	At left side of frame, near aftermarket CHMSL connector.
S330	Near breakout for speaker, in front door.
S331	Near breakout for speaker, in front door.
S332	Near breakout for speaker, in front door.
S333	Near breakout for speaker, in front door.
S334	Near breakout to right door jamb switch.
S401	In taillight harness.
S403	Near breakout to right rear speaker.
S404	In taillight harness.
S405	Near right license plate light.
S406	Near right license plate light.
