Все схемы для электропроводки BMW 318is 1996

Автомтическая коробка Передач (АКПП) Полная привод (4WD) Блокировка Дифференциала

Электросхема коробки передач АКПП (1 из 2) для BMW 318is 1996

Электросхема коробки передач АКПП (1 из 2) для BMW 318is 1996 - Список элементов:

74

(318is & 318ti)
(318is only)
(328i) (318is & 318ti)
(behind right footwell trim)
(behind right g201 footwell trim)
(except 318ti)
(not used)
Asc sig
Auto
Auto mode sig
Automatic transmission range switch (center console near gearshift lever)
B+ junction point
Band sol ctrl
Battery volt
Brake light switch (on brake pedal support bracket)
Brake pdl posit
C 1995 vftc
Chime module (below left side of dash)
Closed in reverse position
Clr
Cruise control module (tempomat) (behind glove box)
Dimmer
Egs a4s 310r
Egs warning lp
Electronic immobilizer control module (behind glove box)
Exterior lights system
Fault ind sig
Front power distribution box (left rear side of engine compartment)
Fuse f26 10a
Fuse f28 5a
Fuse f46 15a
G123 (right rear side of eng compt)
G201
Gnd
Gr rng sig l1
Gr rng sig l2
Gr rng sig l3
Gr rng sig l4
Hot at all times
Hot in accy, run & start
Hot in run & start
Hyd ctrl (-)
Instrument cluster
Interior lights system
Kick down switch (left footwell)
Kick-down sig
M-prog ind
Man
Man mode sig
Nca
Off
Oil temp sig
Oil temp sig (+)
Ouput speed (-)
Output
Output speed (+)
Program switch
Red
Rpm speed sig
S-prog ind
Shift-lock sol
Sol val 1 ctrl
Sol val 2 ctrl
Speed sens shd
Sport mode sig
Tcc sol ctrl
Transmission control module (egs) (right rear side of engine compt)
Transmission position indicator light
W/ ccm
W/o ccm
X10017
X10018
X16
X69

Электросхема коробки передач АКПП (2 из 2) для BMW 318is 1996

Электросхема коробки передач АКПП (2 из 2) для BMW 318is 1996 - Список элементов:

60

(1996)
(1997)
(318is & 318ti)
(318is only)
(318is) (318ti)
(328i only)
(328i w/ asc)
(below left side of i/p)
(not used)
318is &
318is
318is & 318ti
318ti
328i
87a
A-prog ind
A/c comp ctrl
A/c comp on sig
Band solenoid
Bk sw test sig
Brake light switch (on brake pedal support bracket)
C 1995 vftc
Can-high
Can-low
Clr
Compressor control relay
Computer data lines system
Cruise control module (tempomat) (behind glove box)
Cruise ctrl sig
Data link connector (right rear side of eng compt)
Engine control module (dme) (right rear side of engine compartment in e-box behind trim panel)
Engine control module relay
Engine controls system
Front power distribution box (left rear side of eng compt)
G200
Hydraulic pressure regulator
Instrument cluster system
Nca
Not used
Oil temperature sensor
On-board computer (multi-function clock)
Others
Prog voltage
Red
Rpm speed sig
Rxd data link
Shift lock (center console, right of gearshift selector)
Slip control module (behind glove box)
Solenoid valve 1
Solenoid valve 2
Speed sensor
Torque converter clutch solenoid valve
Tramsmission control module (egs) (right rear side of engine compt)
Transmission valve unit
Txd data link
Volt press reg
X1070
X69
X8516
X8521

БЛОК ПРЕДОХРАНИТЕЛЕЙ И РЕЛЕ

Электросхема блока предохранителей и реле (1 из 5) для BMW 318is 1996

Электросхема блока предохранителей и реле (1 из 5) для BMW 318is 1996 - Список элементов:

24

1996 & 1997 318i, 318is, 318i convertible
1996 m3 & 328i, 328is, 328i convertible
1996 w/ engine compt mounted battery
1996 w/ trunk mounted battery
1997 m3 & 328i, 328is, 328i convertible
B+ jump start junction point
B+ junction point
B+jump start junction point
Battery
Data link connector
Engine control module
Engine control module relay
Engine controls
Fuel pump relay
Fuse link
Generator
Red
Secondary air pump relay
Starter
To front distribution box (diagram 2 of 5)
To fuse f49 (diagram 2 of 5)
Transmission control module (egs)
Unloader relay
Unloader relay (1997)

Электросхема блока предохранителей и реле (2 из 5) для BMW 318is 1996

Электросхема блока предохранителей и реле (2 из 5) для BMW 318is 1996 - Список элементов:

64

Auxiliary fuse box (behind left kick panel)
Auxiliary fuse box (luggage compartment)
Body electronics control module
Body electronics control module (zke iv)
Canada
Check control module
Comfort relay (1997)
Compressor control relay
Convertible top control module (1997 328)
From battery (diagram 1 of 5)
From fuel pump relay (diagram 1 of 5)
Front fog light relay
Front power distribution box (rear left side of engine compartment)
Fuel pump
Fuse f1 30a
Fuse f11 7.5a
Fuse f12 7.5a
Fuse f13 5a
Fuse f14 30a
Fuse f15 15a
Fuse f17 10a
Fuse f18 20a
Fuse f19 30a
Fuse f29 7.5a
Fuse f3 30a
Fuse f30 7.5a
Fuse f39 7.5a
Fuse f4 15a
Fuse f40 30a
Fuse f41 30a
Fuse f48 40a
Fuse f49 15a
Fuse f5 30a
Headlight/ foglight cleaning module (spa) (1996)
High beam light relay
High speed relay (318)
High speed relay (328, m3)
Instrument cluster
Left fog light
Left high beam light
Left low beam headlight
Left seat control switch
Left seat lumbar switch
Low beam light relay
Not used
Rear fog light switch
Red
Relay module
Right fog light
Right high beam light
Right low beam headlight
Right seat control switch
Secondary air pump relay (1997 328, m3)
Sunroof control assembly
To fuse f20 (diagram 4 of 5)
To fuse f35 (diagram 5 of 5)
To fuse f47 (diagram 4 of 5)
To fuse f6 (diagram 5 of 5) (1997)
To fuse f8 (diagram 5 of 5)
To ignition switch (diagram 3 of 5)
Unloader relay
W/ ccm
W/o ccm
Wiper/ washer module (1997)

Электросхема блока предохранителей и реле (3 из 5) для BMW 318is 1996

Электросхема блока предохранителей и реле (3 из 5) для BMW 318is 1996 - Список элементов:

61

(diagram 3 of 5)
Acc
Anti-theft control module
Blower relay
Body electronics control module (zke iv)
Brake light switch
Center console telephone connector (1997)
Check control module
Convertible top control module
Cruise control module
Cruise control switch
Datalink connector
Electronic immoblizer control module (ews ii)
Engine control module (dme)
From front power distribution box (diagram 2 of 5)
From fuse f44 m (diagram 3 of 5)
Front dome/ map light assembly
Front power distribution box (rear left side of engine compartment)
Fuse f42 7.5a
Fuse f43 5a
Fuse f44 15a
Fuse f45 7.5a
Fuse f46 15a
Glove box light
Horn relay
Ignition switch
Instrument cluster
Instrument cluster (1996)
Left makeup mirror light
Left side impact sensor (1997)
Luggage compartment telephone connector (1997)
Not used
Off
On-board computer
Radio
Rear interior
Red
Right makeup mirror light
Right side impact sensor (1997)
Rollover sensor
Run
Seat occupancy detector (1996)
Seat occupancy detector (1997)
Spatial sound switch
Srs control module
Start
Starter immobilization switch (1997)
Telephone transceiver (1996)
To fuse f16 (diagram 4 of 5)
To fuse f24 (diagram 4 of 5)
To fuse f28 (diagram 4 of 5)
To fuse f45
Transmitter module
Transmitter module (1996)
Twin relay module (1996 canada)
Unloader relay
Washer pump
Wiper motor relay (1996)
Wiper relay (1996)
Wiper/ washer module
Wiper/ washer module (1996 canada)

Электросхема блока предохранителей и реле (4 из 5) для BMW 318is 1996

Электросхема блока предохранителей и реле (4 из 5) для BMW 318is 1996 - Список элементов:

56

1996 0r 1997 w/ ihka
1996 w/ park ventilation
1997 or 1996 w/o park ventilation
Abs relay
Abs slip control module
Anti-theft control module
Asc switch
Automatic climate control module
Automatic transmission range switch
Auxiliary connector (1996)
Auxiliary fuse box (behind left kick panel)
Blower relay
Combination switch
Compressor control relay
Data link connector
From front power distribution box (diagram 2 of 5)
From ignition j switch (diagram 3 of 5)
From ignition k switch (diagram 3 of 5)
From ignition switch (diagram 3 of 5)
From n fuse f24 (diagram 4 of 5)
Front power distribution box (left rear side of engine compartment)
Fuse f16 5a
Fuse f20 30a
Fuse f21 5a
Fuse f22 5a
Fuse f23 5a
Fuse f24 10a
Fuse f25 5a
Fuse f26 10a
Fuse f27 5a
Fuse f28 5a
Fuse f47 15a
High beam light relay
High speed relay
Horn relay
Instrument cluster
Light switch
Mirror control switch
Multi- function clock
Normal speed relay
Park heating ventilation relay box
Program switch
Rear defogger relay
Red
Reversing light switch
Servotronic control module (1996)
Slip control module (abs) (1996)
Thermostat
Throttle flap heater (1996)
To fuse f23 (diagram 4 of 5)
Unloader relay
W/ asc
W/ hr
W/o asc
W/o egs only
Water valve assembly

Электросхема блока предохранителей и реле (5 из 5) для BMW 318is 1996

Электросхема блока предохранителей и реле (5 из 5) для BMW 318is 1996 - Список элементов:

72

1996 only
1997 only
328, m3 w/ asc
Abs control module
Abs pump motor relay
Abs relay
All w/ abs
Automatic climate control module
Body electronics control module (1996)
Body electronics control module (zke iv)
Canada
Cd changer
Center console telephone connector
Central lcoking switch
Charging socket
Chime module
Convertible top control module
Convertible top control module (1996)
Convertible top storage lid lock motor
Crash control module
Electronic immobilizer control module
From front power distribution box (diagram 2 of 5)
From fuse f34 (diagram 5 of 5)
From g front power distribution box (diagram 2 of 5)
Front cigar lighter
Front dome/map light assembly
Front power distribution box (rear left side of engine compartment)
Fuse f10 30a
Fuse f31 5a
Fuse f32 30a
Fuse f33 10a
Fuse f34 15a
Fuse f35 25a
Fuse f36 30a
Fuse f37 10a
Fuse f38 30a
Fuse f6 20a
Fuse f7 5a
Fuse f8 15a
Fuse f9 20a
G203 (right kick panel)
Hazard flasher relay
Hifi amplifier
Horn relay
Ignition switch
Instrument cluster
Left door lock motor
Left door lock switch
Light switch
Light switch (usa)
Luggage compartment telephone connector
Multi- function clock
Obd ii connector
On-board computer (1997)
Radio
Rear defogger relay
Red
Right door lock motor
Right door lock switch
Slip control module
Telephone transceiver (1996)
To fuse f33 (diagram 5 of 5)
Trunk lid micro- switch
Trunk lid relay
Trunk light
Trunk lock motor
Usa
W/ asc
W/ hifi, ten speaker system
Water valve asssembly
Wiper relay
Wiper/ washer module

БЛОК УПРАВЛЕНИЯ КУЗОВОМ

Электросхема блока управления кузовом для BMW 318is 1996

Электросхема блока управления кузовом для BMW 318is 1996 - Список элементов:

27

(1994 early prod)
(1994 late prod to 1996)
1994-1996
Air conditioning system
All except 1997
Auxiliary fuse box (behind left kickpanel)
Body computer system
Computer data lines system
Engine controls system
Exterior lights system
Front power distribution box (rear left side of engine compartment)
Fuse f23 5a
Fuse f3 15a
Fuse f45 7.5a
Fuse f47 15a
G203 (right kickpanel)
Ground
Hot at all times
Hot in run and start
Instrument cluster system
Interior lights system
On-board computer (center console)
On-board computer temp sensor (front right side of engine compt)
Starting/charging system
Warning system
X1070
X1071

компьютерная схема модуля тела для BMW 318is 1996

компьютерная схема модуля тела для BMW 318is 1996 - Список элементов:

31

(1996)
(1997)
(1997, 98)
(1998)
(behind glove box) (partial) body electronics control module (zke iv)
1997,
Anti-theft
Computer data lines
Defogger
Door locks
Exterior lights
Front power distribution box (left rear corner of engine compartment)
Fuse f14 30a
Fuse f33 10a
Fuse f35 25a
Fuse f43 5a
Fuse f7 5a
G203 (behind right kick panel)
Hot at all times
Hot in accy, run and start
Interior lights
On-board computer
Power tops
Power windows
Red
Starting/charging
X10182
X13252
X13253
X13254
X13255

бортовая компьютерная схема для BMW 318is 1996

бортовая компьютерная схема для BMW 318is 1996 - Список элементов:

27

(1994 early prod)
(1994 late prod to 1996)
1994-1996
Air conditioning system
All except 1997
Auxiliary fuse box (behind left kickpanel)
Body computer system
Computer data lines system
Engine controls system
Exterior lights system
Front power distribution box (rear left side of engine compartment)
Fuse f23 5a
Fuse f3 15a
Fuse f45 7.5a
Fuse f47 15a
G203 (right kickpanel)
Ground
Hot at all times
Hot in run and start
Instrument cluster system
Interior lights system
On-board computer (center console)
On-board computer temp sensor (front right side of engine compt)
Starting/charging system
Warning system
X1070
X1071

БЛОКИРОВКИ СЕЛЕКТОРА СТОЯНОЧНЫЙ ТОРМОЗ

Электросхема блокировки селектора для BMW 318is 1996

Электросхема блокировки селектора для BMW 318is 1996 - Список элементов:

26

(right rear side of engine compt.)
Automatic transmission range switch (near gearshift lever)
B+ junction point
Battery voltage
Brake light switch (support bracket)
Brake pedal position
Front power distribution box (rear left side of engine compt.)
Fuse f28 5a
Fuse f46 15a
G123
Gear range signal l1
Gear range signal l2
Gear range signal l3
Gear range signal l4
Ground
Hot at all times
Hot in accy, run and start
Hot in run and start
Nca
Red
Shift lock solenoid control
Shift lock solenoid ground
Shift-lock (right side of gearshift selector)
Transmission control module (e-box)
X10017
X10018

ВНЕШНЕЕ ОСВЕЩЕНИЕ

Электросхема заднего хода для BMW 318is 1996

Электросхема заднего хода для BMW 318is 1996 - Список элементов:

17

(2 door)
A/t
A/t only
Automatic transmission range switch (center console, on shifter mechanism)
Chime module (except 1998) (left side of dash)
Front power distribution box (left rear corner of engine compartment)
Fuse 10a
G312 (behind upper left rear seat back)
Hot in run and start
Left back up light
Left trunk light assembly
M/t
Reversing light switch (left side of transmission)
Right back up light
Right trunk light assembly
X10017
X1426

внешняя осветительная сеть, Канада (1 из 3) для BMW 318is 1996

внешняя осветительная сеть, Канада (1 из 3) для BMW 318is 1996 - Список элементов:

48

(2 door)
(not used)
(right kick panel)
(upper left rear seat back)
Anti-theft system (anti-theft control module)
Central locking module (behind glove box)
Combination switch
Crash control module (driver's side footwell)
Front power distribution box (left rear side of engine compt.)
Fuse f23 5a
Fuse f34 15a
G111 (front left side of engine compt.)
G202 (left side of i/p)
G203
G203 (right kick panel)
G312
G312 (upper left rear seat back)
Hazard flasher relay (power distribution box)
Hazard indicator
Hazard switch
Hot at all times
Hot in run and start
Instrument cluster
Interior lights system
Left
Left front auxiliary turn light
Left front light assembly
Left front turn lamp
Left rear turn lamp
Left trunk light assembly
Left turn indicator
Nca
Off
Right
Right front auxiliary turn light
Right front light assembly
Right front turn lamp
Right rear turn lamp
Right trunk light assembly
Right turn indicator
Turn signal switch
W/ crash control module
W/o crash control module
X10017
X10018
X13012
X16
X17

внешняя осветительная сеть, Канада (2 из 3) для BMW 318is 1996

внешняя осветительная сеть, Канада (2 из 3) для BMW 318is 1996 - Список элементов:

39

(2 door)
(left side of i/p)
(right kick panel)
(upper left rear seat back)
Central locking module (behind glove box)
Check control module (left side of dash)
Front power distribution box (left rear side of engine compartment)
Fuse 10a
Fuse 5a
G111 (front left side of engine compt.)
G202
G202 (left side of i/p)
G203
G312
Head
Hot at all times
Hot in run and start
Interior lights system
Left front light assembly
Left license plate light
Left park light
Left park light relay (behind glove box)
Left tail light
Left trunk light assembly
Light switch
Off
Park
Right front light assembly
Right license plate light
Right park light
Right park light/license plate light relay (behind glove box)
Right tail light
Right trunk light assembly
W/ check control module
W/o check control module
X10018
X1074
X1075
X13014

внешняя осветительная сеть, Канада (3 из 3) для BMW 318is 1996

внешняя осветительная сеть, Канада (3 из 3) для BMW 318is 1996 - Список элементов:

30

(2 door)
(upper left rear seat back)
A/t
A/t only
Automatic transmission range switch (center console near gearshift lever)
Brake light switch (brake pedal support)
Check control module (left side of dash)
Chime module (left side of dash)
Front power distribution box (left rear corner of engine compartment)
Fuse 10a
Fuse 15a
G312
High level stop light
Hot in accy, run and start
Hot in run and start
Left back up light
Left brake light
Left trunk light assembly
M/t
Nca
Reversing light switch (left side of transmission)
Right back up light
Right brake light
Right trunk light assembly
W/ check control module
W/o check control module
X10018
X1074
X1075
X1426

внешняя осветительная сеть, США (1 из 3) для BMW 318is 1996

внешняя осветительная сеть, США (1 из 3) для BMW 318is 1996 - Список элементов:

47

(2 door)
(right kick panel)
(upper left rear seat back)
Anti-theft system (anti-theft control module)
Body control module (behind glove box)
Combination switch
Crash control module (driver's side footwell)
Front power distribution box (left rear side of engine compt.)
Fuse f23 5a
Fuse f34 15a
G111 (front left side of engine compt.)
G202 (left side of i/p)
G203
G203 (right kick panel)
G312
G312 (upper left rear seat back)
Hazard flasher relay (power distribution box)
Hazard indicator
Hazard switch
Hot at all times
Hot in run and start
Instrument cluster
Interior lights system
Left
Left front auxiliary turn light
Left front light assembly
Left front turn lamp
Left rear turn lamp
Left trunk light assembly
Left turn indicator
Nca
Off
Right
Right front auxiliary turn light
Right front light assembly
Right front turn lamp
Right rear turn lamp
Right trunk light assembly
Right turn indicator
Turn signal switch
W/ crash control module
W/o crash control module
X10017
X10018
X10182
X16
X17

внешняя осветительная сеть, США (2 из 3) для BMW 318is 1996

внешняя осветительная сеть, США (2 из 3) для BMW 318is 1996 - Список элементов:

29

(2 door)
(upper left rear seat back)
Check control module (left side of dash)
Front power distribution box (left rear side of engine compartment)
Fuse 10a
G111 (front left side of engine compt.)
G202 (left side of i/p)
G312
Head
Hot at all times
Interior lights system
Left front light assembly
Left license plate light
Left park light
Left tail light
Left trunk light assembly
Light switch
Off
Park
Right front light assembly
Right license plate light
Right park light
Right tail light
Right trunk light assembly
W/ check control module
W/o check control module
X10018
X1074
X1075

внешняя осветительная сеть, США (3 из 3) для BMW 318is 1996

внешняя осветительная сеть, США (3 из 3) для BMW 318is 1996 - Список элементов:

30

(2 door)
(upper left rear seat back)
A/t
A/t only
Automatic transmission range switch (center console near gearshift lever)
Brake light switch (brake pedal support)
Check control module (left side of dash)
Chime module (left side of dash)
Front power distribution box (left rear corner of engine compartment)
Fuse 10a
Fuse 15a
G312
High level stop light
Hot in accy, run and start
Hot in run and start
Left back up light
Left brake light
Left trunk light assembly
M/t
Nca
Reversing light switch (left side of transmission)
Right back up light
Right brake light
Right trunk light assembly
W/ check control module
W/o check control module
X10018
X1074
X1075
X1426

ВНУТРЕННЕЕ ОСВЕЩЕНИЕ

Электросхема освещения салона (1 из 2) для BMW 318is 1996

Электросхема освещения салона (1 из 2) для BMW 318is 1996 - Список элементов:

56

(1994) (others)
(center console)
(left side of i/p) g202 g302 (center console)
(right kick panel)
Asc switch (ex. 1994)
Body electronics control module (zke iv)
Canada
Cassette box light
Central power window switch (2 door, ex. 1994)
Check control module
Daytime running lights coding diode (left side of i/p)
Dimmer
Driver's power window switch
Ex. 1994 & 1995
Exterior lights system
Exterior lights system (turn/hazard lights)
Front ashtray light
Front cigar lighter light
Front power distribution box (left rear side of engine compartment)
Fuse f22 5a
Fuse f37 10a
G202 (left side of i/p)
G203
G203 (right kick panel)
G302
G302 (center console)
Hazard switch
Head
Hot at all times
Hot in run and start
Ihkr control panel
Instrument cluster
Integrated climate regulation control module
Left pop out window switch
Left rear window switch
Left seat heater switch
Light switch
Off
Park
Passenger's power window switch
Radio
Rear ashtray light
Right park light/license plate light relay (right side of dash)
Right rear window switch
Right seat heater switch
Spacial sound switch (ex. 1994)
Sunroof control assembly (under roof center panel)
Sunroof switch
Transmission position indicator light
U.s.a.
Under hood light switch
Underhood light
Wiper/ washer module (behind glove box) (canada)
X16
X18126
X18154

Электросхема освещения салона (2 из 2) для BMW 318is 1996

Электросхема освещения салона (2 из 2) для BMW 318is 1996 - Список элементов:

39

(2 door)
(4 door)
1994 late production
2 door
4 door
Anti- theft system
Anti-theft system
Body electronics control module (zke iv)
Driver's door jamb switch
Driver's makeup mirror light (ex. 1997)
Driver's makeup mirror switch
Front dome light/ map reading assembly
Front power distribution box (left rear side of engine compartment)
Fuse f33 10a
Fuse f43 5a
Fuse f44 15a
G203 (right kick panel)
G310 (upper right rear seatback)
G310 (upper right rear seatback) g203 (right kick panel)
G312 (upper left rear seatback)
G312 (upper left rear seatback) g203 (right kick panel)
Glove box light switch
Hot at all times
Hot in accy, run and start
Left rear door contact
Left rear door jamb switch
Left rear interior light
Off
Others
Passenger's door jamb switch
Passenger's makeup mirror light (ex. 1997)
Passenger's makeup mirror switch
Reading lights
Right rear door contact
Right rear door jamb switch
Right rear interior light
Trunk compartment light
Trunk light switch (left side of trunk lid)
X13254

ЗАЗЕМЛЕНИЕ ПОДКЛЮЧЕНИЕ МАССЫ

Электросхема подключение массы заземления (1 из 5) для BMW 318is 1996

Электросхема подключение массы заземления (1 из 5) для BMW 318is 1996 - Список элементов:

67

Airbag system control module
Anti- theft horn
Auxiliary fan motor
Blower relay
Brake fluid level switch
Brake light switch
Cassette box light (1996)
Central power window switch (convertible)
Child protection control (console)
Chime module
Convertible top control module
Cruise control actuator
Dimmer
Drivers power window switch
Electronic immobilizer control module
Engine coolant level switch
Front fog light relay
G100 (front left side of engine compartment)
G202 (below left side of dash)
G203 (right kick panel)
G302 (center console, near gearshift lever)
G303 (under right rear seat)
Hazard flasher relay
Headlight/ fog light washer pump
High beam light relay
Horn switch
Ignition switch
Instrument cluster
Instrument cluster (1997)
Inter- mediate pressure switch (1997)
Left fog light
Left front auxiliary turn light
Left front turn light
Left high beam light
Left horn
Left low beam light
Left park light
Left pop-out window switch
Left rear door (console) power window switch (4 door)
Left rear window switch (4 door)
Left washer jet heater
Light switch
Low beam light relay
Obd ii connector
Only
Passengers power window switch
Pressure switch (1996)
Right fog light
Right front auxiliary turn light
Right front turn light
Right high beam light
Right horn
Right low beam light
Right park light
Right pop-out window switch
Right rear door (console) power window switch (4 door)
Right washer jet heater
Starter immobilizer switch (1997)
Temperature switch
Throttle flap heater (1997)
Unloader relay
Washer fluid level switch
Washer pump (1996) (canada)
Wiper motor
Wiper relay (canada) (1997)
Wiper/ washer module (low ii)
Wiper/ washer switch

Электросхема подключение массы заземления (2 из 5) для BMW 318is 1996

Электросхема подключение массы заземления (2 из 5) для BMW 318is 1996 - Список элементов:

56

1996 & 1997 w/ asc
318, 328
328, m2
Abs control module/ hydraulic unit
Abs hydraulic unit
Abs pump motor relay
Abs relay (1996)
All 1996, 1997 328, m3
Body electronics control module
Body electronics control module (zke iv)
Cd changer
Clutch switch
Convertible top storage lid lock motor
Crash control module
Cruise control actuator
Cruise control module
Door lock heater
Drivers door handle switch
Drivers makeup mirror switch
Drivers side mirror
Drivers window motor
Front dome light/ map reading assembly
G103 (rear of right shock tower)
G202 (below left side of dash)
G203 (behind right footwell trim)
Ground
Inertia switch
Instrument cluster
Left footwell light
Left front speed sensor
Left front speed sensor (1997 318)
Mirror control switch
On-board computer temp sensor
Only
Passengers door jamb switch
Passengers makeup mirror switch
Passengers seat control switch
Passengers seat heater
Passengers seatback heater
Passengers side mirror
Passengers window motor
Rear lights relay
Relay module
Right footwell light
Right front speed sensor
Right front speed sensor (1997 318)
Slip control module
Spatial sound switch
Sunroof control assembly
Thermostat (1997)
Transmitter module
Trunk lid micro switch
W/ abs
W/ asc
Wiper/ washer module (1996) (canada)
Wiper/ washer module (low ii) (usa)

Электросхема подключение массы заземления (3 из 5) для BMW 318is 1996

Электросхема подключение массы заземления (3 из 5) для BMW 318is 1996 - Список элементов:

38

Air pump
Air pump (1996)
Camshaft position sensor shield
Change- over valve
Crankshaft position/ rpm sensor shield
Crankshaft position/rpm sensor shield
Cyl 1 ignition coil
Cyl 2 ignition coil
Cyl 3 ignition coil
Cyl 4 ignition coil
Cyl 5 ignition coil
Cyl 6 ignition coil
Data link connector
Delay relay (1996)
Engine control module (dme)
Fuel pump/ start identification relay
G103 (1996) (m3 canada) (rear of right shock tower)
G119 (328, m3) (right front of engine)
G123 (1996) (328 canada) (rear of right shock tower)
G123 (328, m3) (rear of right shock tower)
Heated oxygen sensor
Heated oxygen sensor 2
Heated oxygen sensor 2 shield
Heated oxygen sensor shield
Hot film air mass meter
Ignition coil shield
Nca
Resistor
Secondary air pump relay
Sensor 1 shield
Sensor 2 shield
Shield
Solenoid valve (1996)
Transmission control module (egs)
Unloader valve (1997)
Variable camshaft control module (vanos)
Variable camshaft control sensor 1
Variable camshaft control sensor 2

Электросхема подключение массы заземления (4 из 5) для BMW 318is 1996

Электросхема подключение массы заземления (4 из 5) для BMW 318is 1996 - Список элементов:

60

Air pump
Anti- theft control module
Cd changer
Check control module
Convertible top actuating switch
Convertible top control module
Convertible top position micro- switch
Convertible top-end position micro- switch
Crankshaft position sensor shield
Cyl 1 ignition coil
Cyl 2 ignition coil
Cyl 3 ignition coil
Cyl 4 ignition coil
Data link connector
Door lock heater
Driver door handle switch
Drivers seat heater switch
Drivers seatbelt switch
Drivers side impact sensor (1997)
Drivers side mirror
Drivers window monitioring switch (1997)
Drivers window motor light
Engine control module (dme)
G119 (318) (right front of engine)
G123 (318) (rear of right shock tower)
G202 (left side of i/p)
G203 (1996) (behind right footwell)
G203 (right kick panel)
G302 (1996) (center console, near gear shift lever)
G313 (4 door) (in upper right rear seat back)
Ground (318)
Hall effect camshaft sensor
Hifi amplifier
Hot film air mass meter (1996)
Ignition coil shield
Left rear door contact
Mirror control switch
Nca
Only
Passengers door jamb switch
Passengers seat control switch
Passengers seat heater
Passengers seat heater switch
Passengers seatback heater
Passengers seatbelt switch
Passengers side impact sensor (1997)
Passengers window monitioring switch (1997)
Radio
Right rear door contact
Right rear interior light
Right rear interior light (1997)
Right rear window switch
Rollover sensor
Seat occupancy detector
Suppression filter
Transmission control module (egs)
Unloader relay (1997)
W/ hifi, ten speaker system
W/ stereo 6 speaker system
Windscreen cowl panel lock micro- switch

Электросхема подключение массы заземления (5 из 5) для BMW 318is 1996

Электросхема подключение массы заземления (5 из 5) для BMW 318is 1996 - Список элементов:

69

1997 w/ hr
1997 w/ ihka or all 1996
1997 with convertible
All others
Asc switch
Automatic climate control module
Blower motor
Cassette box light (1997)
Cd changer (1997)
Center console telephone connector (1997)
Central locking switch
Charging socket
Convertible top control module
Convertible top storage lid micro- switch
Drivers door jamb switch
Drivers lumbar support motor/valve (1996)
Drivers seat control switch
Drivers seat heater
Drivers seatback heater
Engine hood switch
Final stage unit
Front ashtray light
Front cigar lighter
Front cigar lighter light
Fuel pump
G203 (right kick panel)
G312 (convertible) (upper left rear seatback)
G312 (upper left rear seatback)
Glove box light switch
Hard top connector 1
Hazard switch
Headlight/ foglight cleaning module (1996) (canada)
High level stop light
Intensive wash pump
Left back-up light
Left brake light
Left license light
Left rear fog light
Left rear interior light
Left rear interior light (1997)
Left rear turn light
Left tail light
Left trunk light assembly
Luggage compartment telephone connector (1997)
Multi- function clock
On-board computer (1996)
Passengers door jamb switch (1997)
Program switch (w/ egs)
Radio micro- switch (1996)
Rear ashtray light
Rear window blower
Rear window blower micro switch
Right back-up light
Right brake light
Right defogger
Right license light
Right rear brake pad sensor
Right rear door contact (1997)
Right rear fog light
Right rear interior light
Right rear turn light
Right tail light
Right trunk light assembly
Servotronic control module
Suppression filter (2 door)
Telephone trans- ceiver (1996)
Transmission position indicator light
Wiper/ washer module (1997)
Wiper/ washer switch (1997)

Звуковой сигнал Гудок

Электросхема звукового сигнал Гудка для BMW 318is 1996

Электросхема звукового сигнал Гудка для BMW 318is 1996 - Список элементов:

17

(front left
(left
Acc
Front power distribution box (left rear side of engine compt.)
Fuse f8 15a
G111 side of engine compt.)
G202 side of i/p)
Horn relay (power distribution box)
Horn switch
Hot at all times
Ignition switch
Left horn
Off
Power distribution
Right horn
Run
Start

Магнитола Мультимедия

Электросхемы магнитолы, 10 акустических систем для BMW 318is 1996

Электросхемы магнитолы, 10 акустических систем для BMW 318is 1996 - Список элементов:

44

(1994-1996)
(1997 only)
(1997)
(4 door)
(others)
20a
Antenna amplifier
Cd changer
Connector x400 (left rear side of luggage compt)
Front power distribution box (rear left side of engine compartment)
Fuse f33 10a
Fuse f44 15a
Fuse f9 20a
G202 (below left side of dash)
G203 (right kick panel) (2 door) g310 (right rear seatback)
Hifi amplifier
Hot at all times
Hot in accy, run and start
Instrument cluster
Interior lights system
Left front high range speaker
Left front low range speaker
Left front midrange speaker
Left mid-high range speaker
Left rear high range speaker
Left rear low range speaker
Left rear speaker
Nca
Radio
Red
Right front high range speaker
Right front low range speaker
Right front midrange speaker
Right mid-high range speaker
Right rear high range speaker
Right rear low range speaker
Right rear speaker
Telephone
Telephone transceiver
Vss output
X18126
X18520
X605
X606

Электросхемы магнитолы, 6 акустических систем для BMW 318is 1996

Электросхемы магнитолы, 6 акустических систем для BMW 318is 1996 - Список элементов:

24

(1994-1996)
(1997)
(others) (1997)
Antenna amplifier
Cd changer (1997)
Front power distribution box (rear left side of engine compartment)
Fuse f44 15a 20a
Fuse f9 20a
G202 (below left side of dash)
Hot at all times
Hot in accy, run and start
Instrument cluster
Interior lights system
Left front high range speaker
Left front low range speaker
Left rear speaker
Of luggage compt)
Radio
Right front high range speaker
Right front low range speaker
Right rear speaker
Telephone connector (left rear side x400
Telephone transceiver
Vss output

Подогрев стекол и зеркал

Электросхема подогрева стекол и зеркал для BMW 318is 1996

Электросхема подогрева стекол и зеркал для BMW 318is 1996 - Список элементов:

17

(w/ 3 antenna diversity)
Antenna amplifier (w/ 3 antenna diversity) (in upper left "c" pillar)
Diversity (w/ 3 antenna diversity) (in upper left "c" pillar)
Front power distribution box (rear left side of engine compt)
Fuse f23 5a
Fuse f6 20a
G313 (4 door) (upper right rear seatback)
G314 (2 door) (upper left rear seatback)
Hifi amplifier (w/ ten speaker system only)
Hot at all times
Hot in run and start
Integrated climate regulation control module (center console)
Nca
Radio
Rear defogger relay (rear left side of engine compartment)
Rear defogger/ antenna
Suppression filter (in upper right "c" pillar)

ПОДУШКИ БЕЗОПАСНОСТИ AIR BAG

Электросхема подушек безопасности SRS AirBag для BMW 318is 1996

Электросхема подушек безопасности SRS AirBag для BMW 318is 1996 - Список элементов:

50

(1994)
(1995-1996)
(2-door)
(318ti)
(4-door)
(ex. 318ti) (318ti)
(note: module connector is 30 pin)
(right kick panel) g203
(right kick panel) g203 g404 (left rear of luggage compartment)
(under
(underside of rear seat)
1995 late production and 1996
3ie
Abbf+
Abbf-
Abf+
Abf-
Acc
Air bag indicator
Awl
Body electronics control module (behind glove box)
Contact rings
Data link connector (front of battery)
Driver's airbag gas generator
Driver's seat belt switch (in seat belt buckle)
Front power distribution box (rear left side of engine compartment)
Fuse f42 7.5a
Fuse f43 5a
G201 (right side of i/p)
G303
G303 (under right rear seat)
G404 (left rear of luggage compartment)
Gkbf
Gkf
Hot at all times
Ignition switch
Instrument cluster
Nca
Off
Passenger's airbag gas generator
Passenger's seat belt switch (in seat belt buckle)
Right rear seat)
Run
Sbe
Seat belt warning lamp control
Seat occupancy detector (under right front seat)
Start
Txd
X16
X17

ПРЕДУПРЕЖДАЮЩИЕ СИСТЕМЫ

Электросхема предупреждающей системы для BMW 318is 1996

Электросхема предупреждающей системы для BMW 318is 1996 - Список элементов:

19

Automatic transmission range switch (center console near gearshift lever)
Chime module (below left side of dash
Exterior lights system (back-up lights)
Front power distribution box (rear left side of engine compt.)
Fuse f26 10a
Fuse f31 5a
G202 (left side of i/p)
Hot at all times
Hot in run and start
Instrument cluster
On-board computer (center console)
Sound
Tone signal x17
X10017
X10018
X1070
X1426
X518
X522

ПРИБОРНАЯ ПАНЕЛЬ

Электросхема панели приборов (1 из 2) для BMW 318is 1996

Электросхема панели приборов (1 из 2) для BMW 318is 1996 - Список элементов:

97

(near oil level stick)
0nly
A10
A11
A12
A13
A14
A15
A16
A17
A18
A19
A20
A21
A22
A23
Abs ind
Acc
Anti- lock brakes system
Anti-lock brakes system
Anti-lock brakes system (ex 1992 & 1993)
Asc+t ind
B11
B12
B14
B15
B16
B17
B18
B19
B21
B23
B24
B26
Body computer system
Brake fluid ind
Brake fluid level switch (top of brake fluid reservoir)
Brake warning ind
Charge
Check engine ind
Check ind
Conn a
Conn b
Conn c
Convert-
Engine controls system
Engine controls system (1997 only)
Except
Except &
Except 1992 &
Exterior lights system
Front fog lt ind
Front power distribution box (rear left side of engine compt)
Fuel consumption meter
Fuel gauge
Fuel reserve ind
Fuse f27 5a
Fuse f31 5a
G202 (below left side of dash)
G203 (behind right footwell trim)
Ground
Hazard ind
Headlights system
High beam ind
Hot at all times
Hot in run and start
Ible only
Ignition switch
Illum (3 used)
Ind
Instrument cluster
Interior lights system
Left turn ind
Lock
Nca
Oil ind
Oil pressure switch 1) normal 2) 0.2-0.5 bar
Only
Park brake ind
Park brake switch
Power tops system
Rear fog lt ind (canada)
Right turn ind
Rollover protection ind (convertible)
Run
Seat belt ind
Solid state
Speedometer
Srs ind
Start
Starting/ charging system
Tachometer
Temp gauge
Transmission malfunction ind
Transmission system
W/ asc
W/o asc

Электросхема панели приборов (2 из 2) для BMW 318is 1996

Электросхема панели приборов (2 из 2) для BMW 318is 1996 - Список элементов:

47

(1992 & 1993 usa, & 1997)
(behind right footwell trim) (1992 & 1993 2 door, & convertible) g203
(below left side of dash) (g202)
(ex 1992 & 1993 2 door, & 1994 convertible) (upper left rear seat)
(ex 1992 & 1993 usa, & 1997)
Air condition- ing system
Brake light switch
Check control module (below left side of dash)
Chime module (below left side of dash)
Clc
Computer data lines system
Cruise control system
Data
Data link connector (rear right side of engine compt)
Driver's seat belt switch
Drivers door jamb switch
Engine controls system
Engine coolant temperature sensor (right front of engine, below intake manifold)
Except 1992 &
Front power distribution box (rear left side of engine compartment)
Fuel level sensor (below left side of rear seat)
Fuel tank sensor ii (top of fuel tank)
Fuse f23 5a
Fuse f45 7.5a
Fuse f46 15a
G203 (behind right foot well trim)
G203 (behind right footwell trim)
G312
G312 (in upper left rear seat back)
Hot in accy, run and start
Hot in run and start
Interior lights system
Lac
Left front brake pad sensor
Multi-function clock
Oil temperature sensor (left side of engine)
On-board computer temp sensor (front right side of engine compt)
On-board display/computer (center console)
Power tops system
Radio
Right rear brake pad sensor
Starting/charging system
Tach
Vehicle speed sensor (under rear of car)
W/ ccm
W/ccm
Wiper/ washer module (behind glove box)

ПРИВОД ЗЕРКАЛ

Электросхема привода зеркал для BMW 318is 1996

Электросхема привода зеркал для BMW 318is 1996 - Список элементов:

14

Down
Driver's
Driver's side mirror
Front power distribution box (left rear corner of engine compartment)
Fuse f24 10a
G203 (behind right kick panel)
Hot in run and start
Left
Mirror control switch
Nca
Passenger's
Passenger's side mirror
Right
X10017

ПРИВОД ЛЮКА И КРЫШИ

Электросхема привода люка для BMW 318is 1996

Электросхема привода люка для BMW 318is 1996 - Список элементов:

14

(right kick panel)
Body electronics control module (zke iv) (behind glove box)
Close
Front power distribution box (rear left side of engine compartment)
Fuse f1 30a
G203
Hot at all times
Interior lights system
Off
Open
Sunroof control assembly (under roof center panel)
Sunroof switch
X13176
X272

ПРИВОД СТЕКЛОПОДЪЕМНИКОВ

Электросхема стеклоподъемников (1 из 2) для BMW 318is 1996

Электросхема стеклоподъемников (1 из 2) для BMW 318is 1996 - Список элементов:

47

(behind right footwell trim)
(behind right footwell trim) (convertible) g203
(console)
(convertible) g203
(in upper left rear seat back)
(in upper right rear seat back)
2 door or conv
Anti-theft control module (behind glove box
Body electronics control module (zke iv) (behind glove box)
Child protect sig
Child protection control (4 door only)
Close auto
Close sig
Close wdo
Conn 10182
Conn 13252
Conn 13253
Conn 13254
Conn 13255
Data sig
Data sig (conv) close sig (4 door)
Data sig (conv) open sig (4 door)
Door sig
Drivers door jamb switch
Drivers power window motor
Drivers power window switch
Ex 2 door or conv
Front power distribution box (rear left side of engine compartment)
Fuse f14 30a
G203 (behind right footwell trim)
G302 (center console near gearshift lever)
G303 (ex convertible)
G304 (ex convertible)
Hot at all times
Instrument cluster system
Interior lights system
Mtr sig
Off
Open auto
Open sig
Open wdo
Passengers door jamb switch
Passengers power window motor
Passengers power window switch
Revolution sig
Starting/charging system
Terminal 30h

Электросхема стеклоподъемников (2 из 2) для BMW 318is 1996

Электросхема стеклоподъемников (2 из 2) для BMW 318is 1996 - Список элементов:

25

4 door
Auto close
Auto open
Central power window switch (convertible only)
Close
Close wdo
Convertible
Copy
Front power distribution box (rear left side of engine compartment)
Fuse f19 30a
G203 (behind right footwell trim)
G302 (center console, near gearshift lever)
Ground
Hot at all times
Interior lights system
Left rear door (console) power window switch (4 door) left rear power window switch (convertible)
Left rear door (door) power window switch (4 door only)
Left rear window motor
Off
Open
Open wdo
Relay module (behind glove box)
Right rear door (console) power window switch (4 door) right rear power window switch (convertible)
Right rear door (door) power window switch (4 door only)
Right rear window motor

Противоугонная система Сигнализация

Электросхема противоугонной сигнализации для BMW 318is 1996

Электросхема противоугонной сигнализации для BMW 318is 1996 - Список элементов:

33

Antenna
Anti- theft horn
Anti-theft control module (behind glove box)
Auxiliary fuse box (behind left kickpanel)
Body electronics control module (zke iv) (behind glove box)
Crash control module (left footwell)
Drivers door handle switch
Drivers door jamb switch
Engine hood switch
Exterior lights system
Front power distribution box (left rear side of engine compartment)
Fuse f43 5a
Fuse f47 15a
G200 (right kick panel)
G310 (4 door) g203 (2 door) (4 door: upper right rear seat back) (2 door: right kick panel)
G312 (upper left rear seat back)
Horn relay (behind glove box)
Hot at all times
Hot in accy, run and start
Led
Left rear door contact
Low-noise microphone
Nca
On-board computer (center console)
Passengers door jamb switch
Radio microswitch (center of dash)
Right rear door contact
Trunk light switch
X10182
X10244
X13025
X13253
X13254

защита двигателя далеко (EWS II) для BMW 318is 1996

защита двигателя далеко (EWS II) для BMW 318is 1996 - Список элементов:

32

(left side) of dash) g202
Acc
Anti-theft control module (alpine) (behind glove box)
Automatic transmission range switch (o off (low)) (1 on (high)) (center console near gearshift lever)
Body electronics control module (zke iv) (behind glove box)
Data link connector
Electronic immobilizer control module (behind glove box)
Engine control module (dme) (right rear side of eng compt)
Except 318ti
Front power distribution box (left rear side of engine compt)
Fuse f28 5a
Fuse f31 5a
Fuse f45 (1996 318ti) 7.5a
Fuse f46 (except 1996 318ti) 15a
G203 (behind right footwell trim)
Hot at all times
Hot in accy, run and start
Hot in run all start
Ignition switch
Lock
Nca
On-board computer (center console)
Run
Start
Starting system
Transmissions system
Transmitter module (ews ii) (right side of steering column)
X10182
X13253
X1659
X1660
X90260

Электросхема открывания авто для BMW 318is 1996

Электросхема открывания авто для BMW 318is 1996 - Список элементов:

33

Antenna
Anti- theft horn
Anti-theft control module (behind glove box)
Auxiliary fuse box (behind left kickpanel)
Body electronics control module (zke iv) (behind glove box)
Crash control module (left footwell)
Drivers door handle switch
Drivers door jamb switch
Engine hood switch
Exterior lights system
Front power distribution box (left rear side of engine compartment)
Fuse f43 5a
Fuse f47 15a
G200 (right kick panel)
G310 (4 door) g203 (2 door) (4 door: upper right rear seat back) (2 door: right kick panel)
G312 (upper left rear seat back)
Horn relay (behind glove box)
Hot at all times
Hot in accy, run and start
Led
Left rear door contact
Low-noise microphone
Nca
On-board computer (center console)
Passengers door jamb switch
Radio microswitch (center of dash)
Right rear door contact
Trunk light switch
X10182
X10244
X13025
X13253
X13254

СИСТЕМА АНТИБЛОКИРОВОЧНОЙ ТОРМОЗНОЙ СИСТЕМЫ ABS

Электросхема антиблокировочной тормозной системы АБС (ABS), С Регулирование тягового усилия для BMW 318is 1996

Электросхема антиблокировочной тормозной системы АБС (ABS), С Регулирование тягового усилия для BMW 318is 1996 - Список элементов:

31

Abs hydraulic unit (rear left side of engine compt)
Abs pump motor relay (power distribution box) (rear left side of engine compartment)
Abs warn ind
Asc switch
Asc warn ind
Brake light switch (brake pedal support bracket)
Data link connector (rear right side of engine compartment)
Engine control system
Front power distribution box (rear left side of engine compartment)
Fuse f10 30a
Fuse f21 15a
Fuse f27 5a
Fuse f38 30a
Fuse f46 15a
G202 (left side of dash)
G203 (right kick panel)
Hot at all times
Hot in accy, run and start
Hot in run and start
Instrument cluster
Interior lights system
Left front abs speed sensor
Left front solenoid valve
Left rear abs speed sensor
Left rear solenoid valve
Right front abs speed sensor
Right front solenoid valve
Right rear abs speed sensor
Right rear solenoid valve
Separating valve
Slip control module (abs) (right side of dash, behind glove box)

Электросхема антиблокировочной тормозной системы АБС (ABS), без Регулирование тягового усилия для BMW 318is 1996

Электросхема антиблокировочной тормозной системы АБС (ABS), без Регулирование тягового усилия для BMW 318is 1996 - Список элементов:

54

(left side of dash) g202
Abs hydraulic unit (rear left side of engine compt)
Abs pump motor relay (power distribution box)
Abs pump mtr rly ctrl
Abs relay (power distribution box)
Abs relay ctrl
Abs warn ind
Abs warn lp ctrl
Brake light switch
Brake lp sig
Data link connector (rear of engine compartment)
Fl spd sens gnd
Fl speed sens signal
Fr spd sens gnd
Fr speed sens signal
Front power distribution box (rear left side of engine compt)
Fuse f10 30a
Fuse f21 5a
Fuse f23 5a
Fuse f27 5a
Fuse f38 30a
Fuse f46 30a
G203 (right kick panel)
Ground
Hot at all times
Hot in accy, run and start
Hot in run and start
Instrument cluster
Left front abs speed sensor
Left front inlet valve
Left front outlet valve
Left rear abs speed sensor
Lf inlet vlv ctrl
Lf outlet vlv ctrl
Nca
Operating voltage
Over voltage protection
Rear axle inlet valve
Rear axle inlet vlv ctrl
Rear axle outlet valve
Rear axle outlet vlv
Rf outlet vlv ctrl
Right front abs speed sensor
Right front inlet valve
Right front outlet valve
Right rear abs speed sensor
Rl spd sens gnd
Rl speed sens signal
Rr spd sens gnd
Rr speed sens signal
Rt fnt inlet vlv ctrl
Slip control module (abs) (behind glove box)
Txd diag
Volt mon, hydraulics

СИСТЕМА КОНДИЦИОНЕРА

Электросхема кондиционера для BMW 318is 1996

Электросхема кондиционера для BMW 318is 1996 - Список элементов:

61

(left side of dash)
(not used)
(right side of plenum)
1) below 21 bar
2) above 30 bar 3) above 2.6 bar 4) below 1.5 bar
4- cyl
4-cyl
5) above 18 bar 6) below 15 bar 7) 4cyl: above 88 deg c 6cyl: above 99 deg c 8) 4cyl: above 88 deg c 6cyl: above 91 deg c
6- cyl
6-cyl
A/c compressor
Acc
Automatic climate control module (behind center console)
Auxiliary fan motor (4-cyl)
Auxiliary fan motor (6-cyl)
Auxiliary fuse box
Blower motor (rear of engine compt)
Blower relay (in power dist box)
Compressor control relay (in power dist box)
Data link connector (right rear of eng compt)
Defogger system
Defroster flap motor
Engine control module (right rear of engine compt)
Evaporator temp sensor (right side of left footwell)
Final stage unit (behind left side of dash)
Fresh air flap motor (below dash, right of steering column)
Front power distribution box
Fuse 30a
Fuse 40a
Fuse 5a
Fuse 7.5a
G100 (left front of engine compt)
G202
G203 (right kick panel)
High speed relay (in power dist box)
Hot at all times
Hot in run and start
Ignition switch
Instrument cluster
Interior lights system
Left heat exchanger temp sensor (center console)
Lock
Nca
Normal speed relay (in power dist box)
Outside temp sensor (rear of engine compt)
Pressure switch
Rear recirculation flap motor
Recirculation flap motor
Red
Regulation flap motor
Run
Start
Starting system
Temperature switch (right front of eng compt)
Trans- mission controls system
Veh speed
Water valve assembly (left rear side of engine compt)
X10016
X10017
X10018
X1588

СИСТЕМА КРУИЗКОНТРОЛЯ

Электросхема системы круизконтроля для BMW 318is 1996

Электросхема системы круизконтроля для BMW 318is 1996 - Список элементов:

26

Acccelerate/ set
Automatic transmission range switch (center console)
Brake light switch (top of brake pedal support)
Clutch switch (top of clutch pedal support)
Computer data lines system
Cruise control actuator (left front side of engine compartment)
Cruise control module (right side of i/p)
Cruise control switch
Decelerate/ set
Engine speed
Front power distribution box (rear left side of engine compartment)
Fuse f28 5a
Fuse f46 15a
G203 (right kick panel)
Hot in accy, run and start
Hot in run and start
Instrument cluster
Nca
Normal
Off
Resume
Transmission control module (right rear of engine compt)
Vehicle speed sensor
W/ ccm
W/ egs
W/o ccm

СИСТЕМА ОХЛАЖДЕНИЯ

вспомогательная Электросхема системы охлаждения для BMW 318is 1996

вспомогательная Электросхема системы охлаждения для BMW 318is 1996 - Список элементов:

33

(in power
1) above 88 deg c (1.8l) above 99 deg c (2.8l) 2) above 80 deg c (1.8l) above 91 deg c (2.8l)
318i/s
318ti
328, m3
Above 18 bar
Above 2.6 bar
Above 30 bar
Automatic climate control module
Aux- iliary fuse box
Auxiliary fan motor
Below 1.5 bar
Below 15 bar
Below 21 bar
Distribution box)
Double temper- ature switch (right front of engine compt)
Engine control module (dme) (right rear of engine compt)
Except 1996 318ti
Except 318ti
Fuse 30a
Fuse 40a
Fuse 5a
G110 (left front of engine compt)
High speed relay
Hot at all times
Hot in run and start front power distribution box (left rear of engine compt)
Integrated heating- and climate control module
M3,
M3, 318ti
M3, 328
M3, 328, 318i/s, 318ti
Normal speed relay
Pressure switch (near right headlight)

СИСТЕМА ПЕРЕДАЧИ ДАННЫХ

Электросхема компьютерной линии передачи данных CAN для BMW 318is 1996

Электросхема компьютерной линии передачи данных CAN для BMW 318is 1996 - Список элементов:

30

(not used)
318is
328i
328i, m3
Abs control module/ hydraulic unit (1997)
Automatic climate control module (center console)
B+ junction point (318is) b+ jump start junction point (m3, 328i)
Body electronics control module (zke iv) (behind glove box)
Convertible top control module (in lower left "c" pillar, behind side panel)
Cruise control module (behind glove box)
Data link connector (rear right side of engine compartment)
Electronic immobilizer control module (ews ii) (behind glove box)
Engine control module (dme) (rear right side of engine compartment)
Ex 1997
Front power distribution box (rear left side of engine compartment)
Fuse f26 10a
Fuse f46 15a
G101 (right side of engine compartment)
Generator
Hot at all times
Hot in accy, start and run
Hot in start and run
Instrument cluster
Obd ii connector
On-board computer (center console)
Others
Red
Slip control module (abs) (behind glove box)
Srs control module (under rear seat)
Transmission control module (egs) (rear right side of engine compartment)

СИСТЕМА УПРАВЛЕНИЯ ДВИГАТЕЛЯ

1.9L

1.9L, Электросхема системы управления двигателя (1 из 2) для BMW 318is 1996

1.9L, Электросхема системы управления двигателя (1 из 2) для BMW 318is 1996 - Список элементов:

65

(right rear side of engine compt)
(right rear side of engine compt) g117
1997 318ti except 1997 318ti
318ti
318ti only
A/c comp cut
A/c system
Acc
Activate a/c
Activate relay
Activate valve
Anti-theft system
B+ jump start junction point (right rear side of engine compt)
Battery volt
Camshaft pos
Crank pos/rpm
Cyl 1
Cyl 1 ign coil
Cyl 2
Cyl 2 ign coil
Cyl 3
Cyl 3 ign coil
Cyl 3-4 ks
Cyl 4
Cyl 4 ign coil
Drive away sig
Ecm rly ctrl
Eng indicator
Engine control module (dme) (right rear side of engine compt)
Engine control module relay
Evaporative emission valve (left side shock tower)
Except 318ti
Front power distribution box
Fuel consumpt
Fuel injection valves
Fuel pump relay
G117
G119 (right front of engine)
Ground
Hall effect camshaft sensor (front of engine)
Hot at all times
Hot film air mass meter (top front of engine)
Idle speed control valve (right front of engine)
Ign ground
Ign switch
Ignition coils (right side of engine compt)
Ignition switch
Inj ground
Intake air resonance changeover valve (left rear side of engine compt)
Intk air temp
Isc valve ctrl
Nca
Normal speed relay
O2 sensor sig
Off
Oxygen sensor (behind catalytic converter)
Oxygen sensor (in front of catalytic converter)
Power distribution
Red
Run
Signal input
Start
Throttle pos
Unloader relay terminal 15 (1997 only)
W/ egs

1.9L, Электросхема системы управления двигателя (2 из 2) для BMW 318is 1996

1.9L, Электросхема системы управления двигателя (2 из 2) для BMW 318is 1996 - Список элементов:

58

1997, w/ abs
318i/s/c
318ti
6 or 4
A/c signal on
A/c system
A/c system (except 318ti)
Abs control module/ hydraulic unit (back of left shock tower)
Activate relay
Activate valve
Can high
Can low
Computer data lines
Crankshaft position/rpm sensor (under right front of car)
Crnk pos/rpm
Crnk rpm spd
Cruise control module (tempomat) (behind glove box)
Cyl 1-2
Cyl 1-2 ks
Cyl 3-4
Data link connector (right rear side of engine compt)
Elctronic immobilizer control module (ews ii) (right side of dash)
Engine control module (dme) (right rear side of engine compt)
Engine coolant temperature sensor (right front of engine)
Except 318ti
Front power distribution box
Fuel pump (below right side of rear seat)
Fuse f18 15a (1997)
Fuse f46 15a
Fuse f5 10a (1996)
G117 (right rear side of engine compt)
G312 (upper left rear seatback)
Hot in accy, run and start
Hot in run and start
Instrument cluster
Intake air temperature sensor (left side of engine)
Knock sensor (top front of engine)
Nca
O2 sensor sig
Obd ii connector
On-board computer (center console)
Program volt
Red
Rr speed sig
Rxd
Sens ground
Slip control module (abs/asc) (behind glove box)
Temp signal
Throttle position sensor (left side of engine compt)
Transmission control module (egs) (right reear side of engine compt)
Txd
Vehicle speed
W/ asc, except 1996 318ti
W/ egs
X10016
X10018
X16
X17

Система Фар

Электросхема фар (1 из 2) для BMW 318is 1996

Электросхема фар (1 из 2) для BMW 318is 1996 - Список элементов:

43

(front left side of engine compt)
87b
Check control module (left side of dash)
Combination high beam switch
Except 1997 usa
Flash
Front power distribution box (left rear side of engine compartment)
Front power distribution box (left rear side of engine compt)
Fuse f11 7.5a
Fuse f12 7.5a
Fuse f23 5a
Fuse f25 5a
Fuse f29 7.5a
Fuse f30 7.5a
G111
G111 (front left side of engine compt)
G202 (below left side of dash)
Head
High
High beam indicator
High beam light relay (power distribution box)
Hot in run and start
Instrument cluster
Left high beam light
Left low beam light
Light switch
Low beam light relay (power distribution box)
Normal
Not used
Off
Park
Red
Right high beam light
Right low beam light
Switch
W/ccm
W/o ccm
X10016
X10017
X10035
X10036
X16
X17

Электросхема фар (2 из 2) для BMW 318is 1996

Электросхема фар (2 из 2) для BMW 318is 1996 - Список элементов:

39

(1996 canada)
(1996 canada) (except 1996 canada)
(2 door)
(below left side of dash)
(except 1996 canada)
1996 canada only
87b
Canada
Except canada
Fog light switch
Front fog light relay (power distribution box)
Front fog lights indicator
Front power distribution box (left rear side of engine compt)
Fuse f15 7.5a
Fuse f17 7.5a
Fuse f22 5a
G111 (front left side of engine compt)
G202
G202 (below left side of dash)
G312 (upper left rear seatback)
Head
Hot at all times
Hot in run and start
Instrument cluster
Left fog light
Left rear fog light
Left trunk light assembly
Light switch
Off
Park
Rear fog light switch
Rear fog lights indicator
Red
Right fog light
X10016
X10017
X17
X217
X319

Электросхема фар, С DRL (1 из 2) для BMW 318is 1996

Электросхема фар, С DRL (1 из 2) для BMW 318is 1996 - Список элементов:

43

(front left side of engine compt)
87b
Check control module (left side of dash)
Combination high beam switch
Exterior lights system
Flash
Front power distribution box (left rear side of engine compartment)
Front power distribution box (left rear side of engine compt)
Fuse f11 7.5a
Fuse f12 7.5a
Fuse f23 5a
Fuse f25 5a
Fuse f29 7.5a
Fuse f30 7.5a
G111
G111 (front left side of engine compt)
G202 (below left side of dash)
Head
High
High beam ind
High beam light relay (power distribution box)
Hot in run and start
Instru- ment cluster
Left high beam light
Left low beam light
Light switch
Low beam light relay (power distribution box)
Normal
Not used
Off
Park
Red
Right high beam light
Right low beam light
Switch
W/ccm
W/o ccm
X10016
X10017
X10035
X10036
X16
X17

Электросхема фар, С DRL (2 из 2) для BMW 318is 1996

Электросхема фар, С DRL (2 из 2) для BMW 318is 1996 - Список элементов:

39

(2 door)
(below left side of dash)
(canada)
(canada) (except canada)
(except canada)
87b
Canada
Canada only
Except canada
Fog light switch
Front fog light relay (power distribution box)
Front fog lights indicator
Front power distribution box (left rear side of engine compt)
Fuse f15 7.5a
Fuse f17 10a
Fuse f22 5a
G111 (front left side of engine compt)
G202
G202 (below left side of dash)
G312 (upper left rear seatback)
Head
Hot at all times
Hot in run and start
Instrument cluster
Left fog light
Left rear fog light
Left trunk light assembly
Light switch
Off
Park
Rear fog light switch
Rear fog lights indicator
Red
Right fog light
X10016
X10017
X17
X217
X319

Электросхема подогрева сидений для BMW 318is 1996

Электросхема подогрева сидений для BMW 318is 1996 - Список элементов:

24

Driver's seat heater (under left front seat)
Driver's seat heater switch
Driver's seatback heater (in upper left front seatback)
Front power distribution box (left rear corner of engine compartment)
Fuse f23 5a
Fuse f4 15a
G202 (below left side of dash)
G203 (2 door) (behind right kick panel)
G300 (under left front seat)
G310 (4 door) (behind upper right rear seat back)
G312 (behind upper left rear seatback)
Hot at all times
Hot in run and start
Interior lights system
Max
Min
Nca
Passenger's seat heater (under right front seat)
Passenger's seat heater switch
Passenger's seatback heater (in upper right front seatback)
Test
Unloader relay, terminal 15 (under left side of dash)
X10015
X10017

Стартер Генератор

Электросхема Генератора для BMW 318is 1996

Электросхема Генератора для BMW 318is 1996 - Список элементов:

17

Acc
Battery
Charge ind
Data link connector (rear right side of engine compt)
Ex 1996
Generator
Hot at all times
Ignition switch
Instrument cluster
Integrated climate regulation control module
Lock
Not used
Red
Run
Start
Starter
Uncoupling diode (front of engine compt) (1994/1995 canada)

Электросхема стартера для BMW 318is 1996

Электросхема стартера для BMW 318is 1996 - Список элементов:

30

Acc
Automatic transmission range switch (center console)
Body elect control module
Canada
Electronic immobilizer control module (ewis ii)
Front power distribution box (left rear of engine compartment)
Fuel pump/start identification relay (rear left side of engine compartment)
Fuse 31 5a
Fuse f28 5a
Fuse f45 7.5a
G103 (rear right of engine compartment)
G202 (below left side of dash)
Generator
Hot at all times
Hot in run and start
Ignition switch
Integrated climate regulation control module
Lock
On-board computer
Power distribution
Red
Run
Start
Starter
Starter immobilization switch
Transmission system
Usa
W/ egs
W/o egs
Wiper/washer module

Стеклоочистители и Стеклоомыватели Дворники

Электросхема стеклоочистителя, дворников и омывателя, США для BMW 318is 1996

Электросхема стеклоочистителя, дворников и омывателя, США для BMW 318is 1996 - Список элементов:

27

(below left side of dash)
Fast
Front power distribution box (left rear corner of engine compt)
Fuse f36 30a
Fuse f44 15a
G202
G202 (except 1997, 98, 99) (below left side of dash)
G203 (1997, 98, 99) (behind right kick panel)
G203 (behind right kick panel)
Hot at all times
Hot in accy, run and start
Instrument cluster
Inter
Nca
Norml
Off
Park
Run
Single
Vehicle speed signal
Wash
Washer pump (front right side of engine compt, on washer fluid reservoir)
Wiper motor (rear of engine compartment)
Wiper/washer module (low ii) (except 1992: right side of dash, behind glove box; 1992: driver's side footwell)
Wiper/washer switch
X10018
X17

Схема Шайбы дворника/Шайбы/Фары для BMW 318is 1996

Схема Шайбы дворника/Шайбы/Фары для BMW 318is 1996 - Список элементов:

43

(ex 1992) (1992)
85b
87a
87b
Fast
Front power distribution box (rear left side of engine compartment)
Fuse f3 30a
Fuse f36 30a
Fuse f37 10a
Fuse f44 15a
Fuse f45 7.5a
G111 (front left side of engine compartment)
G202 (below left side of dash)
G203 (behind right footwell trim)
Headlight/foglight cleaning module (footwell, driver's side)
Headlight/foglight washer pump (front right side of engine compt, on washer fluid reservoir)
Hot at all times
Hot in accy, run and start
Instrument cluster
Intensive wash
Intensive washer pump (front right side of engine compartment)
Inter
Interior lights system
Nca
Normal
Off
Park
Right park light/license plate light relay (right side of dash, behind glove box)
Run
Single
Starting/charging system
Twin relay module (footwell, driver's side)
Vehicle speed signal
Wash
Washer pump (front right side of engine compt, on washer fluid reservoir)
Wiper motor (rear of engine compartment)
Wiper motor relay (below left side of dash)
Wiper relay (below left side of dash)
Wiper/washer module (except 1992: right side of dash, behind glove box; 1992: driver's side footwell)
Wiper/washer switch
X10015
X10018
X17

ЦЕНТРАЛЬНЫЙ ЗАМОК

Электросхема центрального замка для BMW 318is 1996

Электросхема центрального замка для BMW 318is 1996 - Список элементов:

47

1994-96
Auto int lt sig
Body electronics control module (zke iv) (behind glove box)
Central arrest sig
Central locking switch (from late production 1995)
Cerntral lock sig
Conn 10182
Conn 13252
Conn 13253
Conn 13254
Conv
Convertible top storage lid micro switch
Crash sig
Data link connector (rear right side of engine compartment)
Diag
Drive away protect
Drivers door lock motor
Drivers door lock switch
Early production
Ex conv
From late production
Front power distribution box (rear left side of engine compartment)
Fuse f35 25a
Fuse f7 5a
G203 (behind right footwell trim)
G312 (in upper left rear seat back)
Gas filler lock motor
Glove box lock motor
Gnd
Hot at all times
Inertia switch (in lower right "a" pillar)
Interior lights system
Left rear door lock motor
Lk sig drivers door
Lk sig passengers door
Lk sig trunk lid
Lock sig
On-board computer (cemter console)
Passengers door lock motor
Passengers door lock switch
Postn sig
Pwr lk sig
Right rear door lock motor
Starter immobilization relay
Trunk lid relay (behind glove box) (convertible only)
Trunk lid sig (conv) door sig (4 door)
Trunk lock motor
