Разделы схем — 30 (всего 60)
Автомтическая коробка Передач (АКПП) Полная привод (4WD) Блокировка Дифференциала БЛОК ПРЕДОХРАНИТЕЛЕЙ И РЕЛЕ БЛОК УПРАВЛЕНИЯ КУЗОВОМ БЛОКИРОВКИ СЕЛЕКТОРА СТОЯНОЧНЫЙ ТОРМОЗ ВНЕШНЕЕ ОСВЕЩЕНИЕ ВНУТРЕННЕЕ ОСВЕЩЕНИЕ ЗАЗЕМЛЕНИЕ ПОДКЛЮЧЕНИЕ МАССЫ Звуковой сигнал Гудок Магнитола Мультимедия Подогрев стекол и зеркал ПОДУШКИ БЕЗОПАСНОСТИ AIR BAG ПРЕДУПРЕЖДАЮЩИЕ СИСТЕМЫ ПРИБОРНАЯ ПАНЕЛЬ ПРИВОД ЗЕРКАЛ ПРИВОД ЛЮКА И КРЫШИ ПРИВОД СТЕКЛОПОДЪЕМНИКОВ Противоугонная система Сигнализация СИСТЕМА АНТИБЛОКИРОВОЧНОЙ ТОРМОЗНОЙ СИСТЕМЫ ABS СИСТЕМА КОНДИЦИОНЕРА СИСТЕМА КРУИЗКОНТРОЛЯ СИСТЕМА ОХЛАЖДЕНИЯ СИСТЕМА ПЕРЕДАЧИ ДАННЫХ СИСТЕМА УПРАВЛЕНИЯ ДВИГАТЕЛЯ СИСТЕМА УСИЛИТЕЛЯ РУЛЯ Система Фар СИСТЕМЫ ПОДВЕСКИ СИСТЕМЫ СИДЕНИЙ Стартер Генератор Стеклоочистители и Стеклоомыватели Дворники ЦЕНТРАЛЬНЫЙ ЗАМОК
Автомтическая коробка Передач (АКПП) Полная привод (4WD) Блокировка Дифференциала
4.6L 4.6L, Электросхема коробки передач АКПП, 4R70 Вт для Ford Expedition 1997 4.6L, Электросхема коробки передач АКПП, 4R70 Вт для Ford Expedition 1997 - Список элементов: 95 (backup lamp sw to rear lamp harn, right rear of engine compt) (bare) (engine ctrl harn, near breakout to pcm) (engine ctrl harn, near breakout to pdb) (engine ctrl harn, near breakout to starter motor relay) (engine ctrl harn, near breakout to vapor mgt valve) s127 (engine ctrl harn, near breakout to vapor mgt valve) s143 (engine ctrl harn, right rear of engine compt) (fuel charge harn, near breakout to fuel inj 4) (left side of engine compt) power distribution box (main harn, right side of dash) (under center of dash) 4r70w transmission (mounted under center of vehicle) Anti- theft system Autolamp module, instrument cluster Boo Brake pedal position switch (under left side of dash) Brake pressure switch C174 C236 Case gnd Data Data link connector (dlc) (partial) Digital transmission range sensor (left side of transmission) Dlc (+) Dlc (-) Ect Electronic pressure control solenoid Engine controls system Engine coolant temperature (ect) sensor (top front of engine) Engine fuse module (in engine compt, near pdb) Epc Fuse 13 15a Fuse 24 30a Fuse 29 5a Fuse 30 30a Fuse 5a G108 (left front radiator support) G123 (rear of engine compartment) G200 (lower left kick panel) Hot at all times Hot in run or start Iat Ignition coils, radio noise capacitor Instrument cluster Intake air temperature sensor (on intake manifold) Junction box fuse/ relay panel (under left side of dash) Kapwr Malfunction indicator lamp (mil) (check engine) Mil O/d off ind Oss Output shaft speed sensor (left side of transmission) Pcm power diode Pcm power relay Power distribution box (left side of engine compt) Powertrain control module (pcm) (right side of engine compt) Pwr gnd R p Red S100 S101 S106 S107 S116 S128 S135 S137 S138 S140 S141 S144 S225 S275 S276 Shift solenoids (ss) Sig rtn Ss1 Ss2 Tcc Tcil Tcs Tft Throttle position (tp) sensor (on throttle body) Torque converter clutch (tcc) solenoid Tr1 Tr2 Tr3 Tr4 Transmission control switch (tcs) (end of transmission selector lever) Transmission fluid temperature sensor Vehicle speed sensor (vss) (left rear of transmission) Vpwr Vref Vss
5.4L 5.4L, Электросхема коробки передач АКПП, E4OD для Ford Expedition 1997 5.4L, Электросхема коробки передач АКПП, E4OD для Ford Expedition 1997 - Список элементов: 98 (1997) (1998) (backup lamp sw to rear lamp harn, right rear of eng compt) (bare) (eng ctrl harn, right rear of engine compt) (engine ctrl harn, near breakout to starter motor relay) (engine ctrl harn, near breakout to vapor mgt valve) s127 (engine ctrl sensor harn, near breakout to c165, windshield wiper motor) s143 (fuel charge harn, near breakout to fuel inj 4) (left side of engine compt) power distribution box (main harn, right side of dash) Anti- theft system Autolamp module, instrument cluster Boo Brake pedal position switch (under left side of dash) Brake pressure switch Breakout to pdb) C174 C236 C237 Case gnd Ccs Coast clutch solenoid Data Data link connector (dlc) (partial) (under center of dash) Digital transmission range sensor (left side of transmission) Dlc (+) Dlc (-) E4od transmission Ect Electronic pressure control (epc) solenoid Eng coolant temp gauge Engine controls system Engine coolant temperature (ect) sensor (top front of engine) Engine fuse module (expedition) mini fuse block (navigator) (in engine compt, near pdb) Epc Fuse 13 15a Fuse 24 30a Fuse 29 5a Fuse 30 30a Fuse 5a G108 (left front radiator support) G123 (rear of engine compartment) G200 (lower left kick panel) Hot at all times Hot in run or start Iat Ignition coils, radio noise capacitor Instrument cluster Intake air temperature sensor (on intake manifold) Junction box fuse/ relay panel (under left side of dash) Kapwr Malfunction indicator lamp (mil) (check engine) Mil O/d off ind Pcm power diode Pcm power relay Power distribution box (left side of engine compt) Powertrain control module (pcm) (right side of engine compt) Pwr gnd R p Red S100 S101 S106 S107 S116 S123 S128 (engine ctrl harn, near breakout to pcm) S135 S137 S138 S140 S141 S207 S225 S275 S276 Shift solenoid Sig rtn Ss1 Ss2 Tcc Tcil Tcs Tft Throttle position (tp) sensor (on throttle body) Torque converter clutch (tcc) solenoid Tr1 Tr2 Tr3 Tr4 Transmission control switch (tcs) (end of transmission selector lever) Transmission fluid temperature sensor Vehicle speed sensor (vss) (left rear of transmission) Vpwr Vref Vss
БЛОК ПРЕДОХРАНИТЕЛЕЙ И РЕЛЕ Электросхема блока предохранителей и реле (1 из 4) для Ford Expedition 1997 Электросхема блока предохранителей и реле (1 из 4) для Ford Expedition 1997 - Список элементов: 64 (body harn, near breakout to power distribution relay box) s216 (console harn, near breakout to console blower motor) s305 (main harn, in breakout to engine fuse module) s110 (main harn, near breakout to main light switch) s211 (main harn, near breakout to main light switch) s212 (main harn, near console) s281 Air bag diagnostic monitor Air suspension compressor relay Air suspension service switch All lock relay All unlock relay Anti-lock brake system module (4wabs) Auxiliary a/c relay Auxiliary power socket Battery C142 C147 C209 Cd changer Console auxiliary power socket Daytime running lamps module Driver's unlock relay Engine fuse module (near pdc) Fog lamp relay From a fuse 3 (diagram 1 of 4) Fuse 10a Fuse 15a Fuse 20a Fuse 25a Fuse 30a Fuse 40a Fuse 50a Fuse 60a Generator Headlamp relay Horn relay Inline mini fuse 20a (near generator) Main light switch Mega fuse 175a (alternator) (right rear of engine compartment) Mega fuse 175a (pdb) (right rear of engine compartment) Multi- function switch Park lamp relay Power distribution box Power distribution box (left side of engine compartment) Power distribution relay box Premium sound amplifier Radio (premium sound) Rear integrated control panel Rear wiper down relay Rear wiper up relay Red Rpo relay box S108 (engine compt harn, in breakout to pdb) S288 (main harn, near breakout to radio amplifier) Starter motor Starter relay Subwoofer amplifier To fuse 17 (diagram 2 of 4) To fuse 6 (diagram 1 of 4) Trailer tow backup lamp relay Trailer tow battery charge relay Trailer tow left turn relay Trailer tow right turn relay Trailer tow running lamp relay Электросхема блока предохранителей и реле (2 из 4) для Ford Expedition 1997 Электросхема блока предохранителей и реле (2 из 4) для Ford Expedition 1997 - Список элементов: 81 (diagram 3 of 4) (engine compt harn, left rear of engine compt) s112 (engine compt harn, left rear of engine compt) s113 (engine compt harn, left rear of engine compt) s154 (main harn, in breakout to fuse relay panel) s265 (main harn, in breakout to transfer case) s213 (main harn, near breakout to instrument cluster) s222 (main harn, near steering wheel rotation sensor) s226 4 wheel air suspension module Acc Acc delay relay Blend door actuator Blower relay Blower/ flasher relay box C142 C242 C243 C256 C267 C294 C295 C928 Circuit breaker 30a Compass sensor Cooling fan relay Daytime running lamps module Digital trans- mission range sensor Digital transmission range sensor Electronic variable orifice module Engine fuse module (near pdc) From b fuse 16 (diagram 1 of 4) Fuel pump relay Function selector switch Fuse 15a Fuse 20a Fuse 30a Fuse 40a Fuse 50a Fuse 5a Generic electronic module Ignition switch Junction box fuse/ relay panel Junction box fuse/ relay panel (under left side of i/p) Lock Main light switch Moonroof relay Not used Off Overhead trip computer module Pcm power relay Power distribution box Power distribution box (left side of engine compartment) Power distribution relay box Power seat control switch Powertrain control module Radio (premium) Rear defogger relay Rear washer pump relay Red Remote anti-theft personality module Rpo relay box Run S214 (main harn, near steering wheel rotation sensor) S215 (main harn, in breakout to ignition switch) S223 (main harn, near breakout to instrument cluster) S426 (in seat belt harn) Shift lock actuator Speed control servo/ amplifier assembly Start Steering wheel rotation sensor To fuse 1 (diagram 3 of 4) To fuse 19 (diagram 3 of 4) To fuse 20 To fuse 22 (diagram 4 of 4) Torque on demand relay Trailer adapter (electronic brake control) Transfer case shift relays Washer pump relay Windshield wiper motor Wiper hi/lo relay Wiper run/park relay Электросхема блока предохранителей и реле (3 из 4) для Ford Expedition 1997 Электросхема блока предохранителей и реле (3 из 4) для Ford Expedition 1997 - Список элементов: 67 (body harn, near breakout to park brake switch) s220 (engine compt harn, near breakout to ground g108) s114 (engine harn, in breakout to noise capacitor 1) s118 (main harn, near breakout to evo module) s219 (main harn, near breakout to instrument cluster) s225 (main harn, near breakout to instrument cluster) s289 4 wheel air suspension module 4.6l engine 5.4l engine Airbag diagnostic monitor Autolamp module Battery saver relay Blower/ flasher relay box Brake on/off switch Brake pressure switch C142 C216 C242 C243 C257 C267 C268 C295 Cigar lighter Datalink connector Daytime running lamps module Flasher relay From fuse 21 (diagram 2 of 4) From fuse 22 (diagram 2 of 4) c From ignition switch (diagram 2 of 4) Fuse 10a Fuse 15a Fuse 20a Fuse 25a Fuse 30a Fuse 5a G203 (right kick panel) Generic electronic module Headlamp relay Ignition coil Ignition coils 1 & 2 Ignition coils 3 & 4 Instrument cluster Interior lamp relay Junction box fuse/ relay panel (under left side of i/p) Left headlamp Multi- function switch Overhead trip computer module Park lamp relay Passive anti-theft system module Pcm power diode Pcm power relay Power distribution box Power mirror switch Radio noise capacitor Remote anti- theft personality module Right headlamp Rpo relay box S116 (engine harn, left rear of engine compt) S117 (engine compt harn, right rear of engine compt) S161 (engine harn, in breakout to fuel injector 3) S162 (engine harn, in breakout to fuel injector 7) S205 S277 (main harn, near breakout to rpo relay box) Transmission control switch W/ drl W/o drl Электросхема блока предохранителей и реле (4 из 4) для Ford Expedition 1997 Электросхема блока предохранителей и реле (4 из 4) для Ford Expedition 1997 - Список элементов: 42 (engine compt harn, in breakout to 4wabs module) s121 (engine compt harn, left rear of engine compt) s120 (engine compt harn, near breakout to ambient temp sensor) s122 (main harn, front center of console) s279 (main harn, in breakout to fuse/ relay panel) s228 4 wheel anti-lock brake system module 4wabs relay 4x2 center axle disconnect solenoid 4x4 center axle disconnect solenoid Airbag diagnostic monitor Auxiliary a/c blend module Auxiliary a/c control module Auxiliary a/c mode actuator Auxiliary a/c relay Blower relay Blower/ flasher relay box C142 C146 C242 C243 C243 tan/red C436 Console blower motor Daytime running lamps module Exterior lights Flasher relay Fog lamp relay From ignition switch (diagram 2 of 4) Function selector switch Fuse 10a Fuse 5a Junction box fuse/ relay panel (under left side of i/p) Left headlamp Main light switch Multi- function switch Not used Power distribution box Rear integrated control panel Right headlamp Rpo relay box Tan/red Trailer tow battery charge relay
БЛОК УПРАВЛЕНИЯ КУЗОВОМ Электросхема блока управления кузовом (1 из 2) для Ford Expedition 1997 Электросхема блока управления кузовом (1 из 2) для Ford Expedition 1997 - Список элементов: 46 87a Accessory delay relay Accessory delay relay ctrl Battery saver relay Battery saver relay ctrl C242 C243 C267 Electronic suspension system Engine controls system Fuse 15a Fuse 30a Fuse 5a G200 (lower left cowl panel) G203 (lower right cowl panel) Generic electronic module (gem) Ground Heated grid relay Heated grid relay ctrl Hot at all times Hot in Hot in run Hot in run or acc Ign (start) gnd (park/neutral) Ignition (acc/run) Ignition (run) Instrument cluster system Interior lamp relay Interior lamp relay ctrl Interior lights system Junction box fuse/ relay panel (under left side of i/p) Lf window motor sense (high) Lf window motor sense (low) Lf window switch in (down) Lf window switch in (up) One touch down relay One touch down relay ctrl One touch down switch in Power (b+) Power distribution box (left side of engine compt) Power windows system Running lamp relay ctrl S205 S207 Start Vehicle speed (+) Электросхема блока управления кузовом (2 из 2) для Ford Expedition 1997 Электросхема блока управления кузовом (2 из 2) для Ford Expedition 1997 - Список элементов: 99 (near 4wd mode switch) s238 (park/headlamps on) in 4 high to 4 low relay ctrl 4 low to 4 high relay ctrl 4x2 center axle solenoid ctrl 4x4 center axle solenoid ctrl 4x4 high range ind ctrl 4x4 low range ind control 4x4 mode switch in A4wd indicator ctrl Abs active in Air suspension out Anti-lock brakes system (abs control module) Anti-theft system (rap module) Brake on/off switch C239 C240 C241 Computer data lines system (datalink pin 7) Contact plate a in Contact plate b in Contact plate c in Contact plate d in Defogger system (rear defogger switch) Diagnostic link Door ajar indicator ctrl Door ajar out Electronic suspension system (4was module) Exterior lights system (brake on/off switch) Front shaft speed sensor in G200 (lower left cowl panel) Generic electronic module (gem) (behind center of i/p) Ground Hall effect speed sensor out Ignition key warning switch in Illuminated entry request in Instrument cluster system (i/c c236 pin 2) Instrument cluster system (i/c c236 pin 3) Instrument cluster system (i/c c236 pin 4) Instrument cluster system (i/c c236 pin 5) Instrument cluster system (i/c c238 pin 11) Instrument cluster system (i/c c238 pin 9) Instrument cluster system (washer fluid level switch) Interval delay/wash in Lf door ajar switch in Liftgate and glass ajar in Low washer fluid out Lr door ajar switch in Rear shaft speed sensor in Rear washer pump relay out Rear window defrost switch in Rear wiper relay ctrl (down) Rear wiper relay ctrl (up) Rear wiper sense (hi/low/park) Rear wiper switch in Red Rf door ajar switch in Rr door ajar switch in S208 Seat belt indicator ctrl Seat belt warning switch in Signal return Tan Tan/red Torque on demand relay out Trans in neutral in Trans low range out Transfer case return Transmission controls system (4 wheel drive mode switch) Transmission controls system (4wd mode switch) Transmission controls system (4x2 axle disconnect solenoid) Transmission controls system (4x4 axle disconnect solenoid) Transmission controls system (pcm c174 pin 14) Transmission controls system (torque on demand relay) Transmission controls system (transfer case assembly) Transmission controls system (transfer case shift relays) Transmission controls system (transmission range sensor) Warning systems (ignition key warning switch) Warning systems (lf door ajar switch) Warning systems (liftgate & glass ajar switches) Warning systems (lr door ajar switch) Warning systems (main light switch) Warning systems (rf door ajar switch) Warning systems (rr door ajar switch) Warning systems (seat belt switch) Washer fluid level switch in Washer pump ctrl Wiper hi/lo relay ctrl Wiper mode select switch in Wiper motor park sense Wiper run/park relay ctrl Wiper/washer system (hi/lo relay) Wiper/washer system (multi-function switch) Wiper/washer system (rear washer pump relay) Wiper/washer system (rear wiper down relay) Wiper/washer system (rear wiper motor) Wiper/washer system (rear wiper up relay) Wiper/washer system (run/park relay) Wiper/washer system (washer pump relay)
БЛОКИРОВКИ СЕЛЕКТОРА СТОЯНОЧНЫЙ ТОРМОЗ Электросхема блокировки селектора для Ford Expedition 1997 Электросхема блокировки селектора для Ford Expedition 1997 - Список элементов: 12 Brake pedal position (bpp) switch (under left side of dash) Exterior lights system Fuse 13 15a Fuse 6 5a G203 (lower right kick panel) Hot at all times Hot in run Junction box fuse/relay panel (under left side of dash) S204 S265 Shift lock actuator (in steering column) Solid state
ВНЕШНЕЕ ОСВЕЩЕНИЕ Электросхема заднего хода для Ford Expedition 1997 Электросхема заднего хода для Ford Expedition 1997 - Список элементов: 18 (near fuel tank) Anti-theft system Backup C242 Digital transmission range (dtr) sensor (below center of vehicle, left side of transmission) Exterior lamps circuit (trailer backup lamps relay) Fuse 5 15a G414 Hot in run Junction box fuse/relay panel Lamp Left Right backup lamp S150 (eng control sens harn, left rear of eng compt) S222 S263 (main harn, near left cowl panel) S414 S421 (seat belt retractor harn, near seat belt warning switch breakout) Электросхема внешнего освещения для Ford Expedition 1997 Электросхема внешнего освещения для Ford Expedition 1997 - Список элементов: 55 (left rear wheel well) (main harn, behind left side of i/p) (main harn, behind left side of i/p) s261 (main harn, near main light switch breakout) s224 (rear high mount lamp harn, in high mount stop lamp breakout) s911 (seat belt ret harn, near right license plate lamp breakout) Blower/ flasher relay block Brake on/ off (boo) switch (behind left side i/p, top left side of brake/clutch pedal support) C237 C242 C243 Flasher relay Fuse 10a Fuse 15a G109 (right front radiator support) G203 (lower right cowl panel) G402 Hazard Head High mount stop lamp 1 High mount stop lamp 2 High mount stop lamp 3 Hot at all times Hot in run Instrument cluster Junction box fuse/relay panel Left Left front park/turn lamp Left rear park/stop/ turn lamp Left turn indicator License lamps Main light switch Multi-function switch Normal Off Park Power distribution box Right Right front park/turn lamp Right rear park/stop/ turn lamp Right turn indicator S104 S115 (eng cntrl sensor harn, left side of eng compt) S202 S211 S228 S246 (main harn, behind left side of i/p) S247 (main harn, behind left side of i/p) S260 S414 S415 S416 S417 S909 Trailer/ camper adapter Схема Адаптера трейлера/Туриста для Ford Expedition 1997 Схема Адаптера трейлера/Туриста для Ford Expedition 1997 - Список элементов: 53 (engine cntrl sensor harn, near brake pressure switch breakout) (left front radiator support) g108 (main harn, behind left side of i/p) (main harn, behind left side of i/p) s261 Back-up lamps circuit Brake on/off & left turn signal output Brake on/off & right turn signal output Brake on/off (boo) switch C242 Engine fuse module Exterior lights system Fuse 1 20a Fuse 10a Fuse 15a Fuse 16 40a Fuse 20a Fuse 28 30a G416 (left rear of frame) Head Hot at all times Hot in run Instrument cluster breakout) Junction box fuse/relay panel Main light switch Multi- function switch Nca Off Park Power distribution box Power distribution center Rear exterior lamps Red S105 S108 S110 S111 S115 S224 (main harn, in main light switch breakout) S228 S260 Trailer electronic brake control Trailer tow backup lamp relay Trailer tow battery charge relay Trailer tow left turn relay Trailer tow right turn relay Trailer tow running lamp relay Trailer/ camper adapter Trailer/ camper adapter (trailer backup lamps) Trailer/ camper adapter (trailer battery) Trailer/ camper adapter (trailer ground) Trailer/ camper adapter (trailer left turn lamps) Trailer/ camper adapter (trailer right turn lamps) Trailer/ camper adapter (trailer running lamps)
ВНУТРЕННЕЕ ОСВЕЩЕНИЕ Электросхема подсветки для Ford Expedition 1997 Электросхема подсветки для Ford Expedition 1997 - Список элементов: 93 g105 (rear of right fender off (body main harn, near lock relays breakout) s239 (exterior lights system) (trailer/ camper adapter) (int lamp feed harn, near rear blower switch breakout) (int lp feed harn, near left side rail lamp breakout) (rear windows reg control harn, near backlite feed breakout) s427 (seat belt ret harn, near left rear wheel well) s413 (seat belt ret harn, near right cowl panel) s420 (seat belt ret harn, near torque on demand breakout) Apron) Battery saver input Battery saver relay C242 C243 C245 C246 C267 C928 Dome lamp Dome lamp switch Dome/ map lamp Door Engine compartment lamp Engine fuse module Fuse 10a Fuse 15a Fuse 40a G108 (left front radiator support) G203 (lower right cowl panel) G402 (left rear wheel well) G414 (near fuel tank) Generic electronic module (gem) Glove compartment lamp Hot at all times Hot in run Interior lamp relay Interior lamp relay input Junction box fuse/ relay panel Left door courtesy lamp Left front running board lamp Left map/ dome lamp Left rear running board lamp Left side rail lamp Left vanity lamp Main light switch Map lamps Nca Off Overhead trip computer Pnk Power distribution box Rear cargo lamp Right side rail lamp Right door courtesy lamp Right front running board lamp Right map/ dome lamp Right rear running board lamp Right vanity lamp Rpo relay box Running board lamp relay S102 S105 S110 S164 (eng cntrl sens harn, left rear of eng compt) S200 S203 S204 S228 S240 (main harn, near ashtray illum breakout) S400 S408 (rear lamp harn, in left side running board) S418 (seat belt ret harn, near dome lamp breakout) S419 S428 S429 S500 S501 S600 S900 (int lamp harn, near right rear vent window switch breakout) S912 S917 S925 Trailer tow battery charge relay (in power distri- bution box) W/ aux a/c W/ full console only W/ mini console W/ mini console only W/ overhead condsole W/o aux a/c W/o overhead condsole W/o overhead console Wiper/ washer system Электросхема подсветки приборов для Ford Expedition 1997 Электросхема подсветки приборов для Ford Expedition 1997 - Список элементов: 51 (main harn, behind left side of i/p) s242 (premium sound) (standard) 4wheel drive mode switch Ashtray illumination C219 C230 C236 C237 C242 C245 C246 C255 C262 C508 C510 C608 C609 Clock- spring assembly Dimmer module Function selector switch Fuse 15a Fuse 5a G203 (lower right cowl panel) Head Hot at all times Hotin acc or run Instrument cluster (6 bulbs) Junction box fuse/relay panel Left power door lock switch Left power window switch Main light switch Nca Off Park Power distribution box Radio Right power door lock switch Right power window switch S201 S202 S203 S204 S211 S223 S224 (main harn, near main light switch breakout) c243 S243 (body main harn, near lock relays breakout) S500 S502 Steering assembly Trailer electronic brake control
ЗАЗЕМЛЕНИЕ ПОДКЛЮЧЕНИЕ МАССЫ Электросхема подключение массы заземления (1 из 4) для Ford Expedition 1997 Электросхема подключение массы заземления (1 из 4) для Ford Expedition 1997 - Список элементов: 66 (main harn, near breakout to evo module) (main harn, near breakout to rpo relay box) 4 wheel air suspension module 4 wheel compressor motor/ vent solenoid 4 wheel drive mode switch 48 (bare) A/c clutch diode A/c compressor clutch solenoid Ashtray illumination Battery Blend door actuator Blower motor resistor Blower relay Blower/ flasher relay block C174 48 (bare) Camshaft position sensor shield Clock spring assembly Crankshaft position sensor shield Datalink connector Digital transmission range sensor Electronic variable orifice module Engine compartment lamp Flasher relay Front air fill solenoid Front gate solenoid Function selector switch G105 (rear of right fender apron) G109 (right front radiator support) G123 (rear of engine compt, right side of cowl panel) G133 (on engine) G203 (lower right cowl panel) Glove compartment lamp Hybrid cooling fan Instrument cluster Knock position sensor shield Left fog lamp Left front park/turn lamp Main light switch Mass air flow (maf) sensor Passive anti-theft system module Power distribution relay box Powertrain control module Radio (premium) Rear defogger switch Rear wiper down relay Rear wiper up relay Right fog lamp Right front park/turn lamp Right headlamp S100 (engine compt harn, in breakout to pcm) S101 (engine compt harn, in breakout to pcm) S104 (engine compt harn, near breakout to ground g109) S177 (airspring harn, near battery) S199 engine compt harn, right rear of engine compt) S200 (main harn, behind right side of i/p) S202 (main harn, in breakout to blower/flasher relay block) S204 (main harn, near breakout to instrument cluster) S266 (main harn, near breakout to datalink) Shift lock actuator Speed control/ servo amplifier assembly Starter motor) Torque on demand relay Trailer adapter (electronic brake control) Transfer case shift relay Washer fluid level switch Windshield wiper motor Электросхема подключение массы заземления (2 из 4) для Ford Expedition 1997 Электросхема подключение массы заземления (2 из 4) для Ford Expedition 1997 - Список элементов: 68 (body harn, in breakout to left rear grommet) (body harn, in breakout to right rear grommet) 4 wheel anti-lock brake system module 4wabs relay 87a Air suspension compressor relay All lock relay All unlock relay Auxiliary power socket Brake fluid level indicator switch Cigar lighter Compressor motor/ vent solenoid Console auxiliary power socket Cooling fan relay Fuel pump module G108 (left front radiator support) G109 (right front radiator support) G203 (lower right cowl panel) Junction box fuse/relay panel Left air spring solenoid Left front door ajar switch Left front door courtesy lamp Left front power door lock switch Left front power window switch Left front running board lamp Left headlamp Left power/ heated/ signal mirror Left rear door ajar switch Left rear running board lamp Left rear window switch One touch down relay Overhead trip computer module Pcm power relay Power distribution box Power mirror switch Rear air fill solenoid Rear washer pump relay Remote integrated control panel (audio) Remote integrated control panel (blower) Right air spring solenoid Right front door ajar switch Right front door courtesy lamp Right front power door lock switch Right front power window switch Right front running board lamp Right power/ heated/ signal mirror Right rear door ajar switch Right rear running board lamp Right rear window switch S105 (engine compt harn, in breakout to pdc) S106 (engine compt harn, near breakout to ground g108) S155 (engine compt harn, near breakout to compressor motor/ vent solenoid assembly) S205 (main harn, near breakout to evo module) S251 (body harn, near breakout to rap module) S258 (body harn, behind right side of i/p) S322 (console harn, near breakout to console blower motor) S400 (rear lamp harn, near breakout to fuel pump assembly) S428 (rear lamp harn, near breakout to running board lamp 1) S429 (rear lamp harn, near breakout to running board lamp 3) S500 (body harn, near breakout to left power mirror switch) S501 (body harn, near breakout to left power mirror switch) S600 (body harn, near breakout to right door courtesy lamp) Trailer tow backup lamp relay Trailer tow battery charge relay Trailer tow left turn relay Trailer tow right turn relay Trailer tow running lamp relay Washer pump relay Электросхема подключение массы заземления (3 из 4) для Ford Expedition 1997 Электросхема подключение массы заземления (3 из 4) для Ford Expedition 1997 - Список элементов: 63 (seatbelt harn, near breakout to rpo relay box) 4 wheel suspension module Airbag diagnostic monitor Auxiliary a/c blend actuator (w/ aux a/c) Auxiliary a/c control module (w/ aux a/c) Auxiliary a/c mode actuator (w/ aux a/c) Auxiliary a/c relay C242 Compass sensor Electronic variable orifice module Engine coolant temperature sensor Front blower motor switch Front blower motor switch (w/ aux a/c) Front blower switch illumination Front height sensor Fuel pump assembly G200 (lower left cowl panel) G402 (left rear wheel well) G414 (full console) (near fuel tank) Generic electronic module Glass ajar switch High mount stop lamp Instrument cluster Junction box fuse/relay panel Left backup lamp Left license lamp Left rear vent window switch Left side rail lamp Left stop/ park/ turn lamp Liftgate ajar switch Map/dome lamp switch (w/ aux a/c) Map/dome lamp switch (w/o aux a/c) Overhead trip computer module Overhead trip computer module (w/ aux a/c) Overhead trip computer module (w/o aux a/c) Power seat control switch Powertrain control module Rear blower switch illumination Rear cargo lamp Rear height sensor Rear window defrost grid Rear wiper motor Remote anti-theft personality module Right backup lamp Right license lamp Right rear vent window switch Right side rail lamp Rpo relay box S107 (engine compt harn, near starter motor relay) S207 (main harn, near ground g202) S208 (main harn, near ground g202) S250 (body harn, near rap module) S410 (rear lamp harn, near front height sensor) S417 (seatbelt harn, near breakout to right stop/park/turn lamp) S425 (seatbelt harn, near overhead console) S913 (interior lamp harn, near breakout to left side ral lamp) S925 (interior lamp harn, near breakout to powertrain switch) Seatbelt warning switch Steering wheel rotation sensor Vehicle speed sensor Vent window/ moonroof full relay W/ rear vent windows W/o rear vent windows Электросхема подключение массы заземления (4 из 4) для Ford Expedition 1997 Электросхема подключение массы заземления (4 из 4) для Ford Expedition 1997 - Список элементов: 20 Cd changer G202 (upper left cowl panel) G400 G414 (mini console) (near fuel tank) Left rear vent window switch Moonroof assembly Moonroof switch Not used Overhead trip computer module Radio (premium sound) Radio amplifier Remote integrated control panel Right rear vent window switch Rpo relay box S424 (seatbelt harn, near breakout rpo relay box) S922 (interior lamp harn, near breakout to moonroof) S923 (interior lamp harn) Subwoofer Trailer/ camper adapter Vent window/ moonroof full relay
Звуковой сигнал Гудок Электросхема звукового сигнал Гудка для Ford Expedition 1997 Электросхема звукового сигнал Гудка для Ford Expedition 1997 - Список элементов: 15 Clock- spring assembly Fuse 5 20a High pitch horn (on right radiator support) Horn relay Horn relay (in power disrtibution box) Horn switches Hot at all times Low pitch horn (on right radiator support) Nca Power distribution box (left side of engine compt) Remote anti-theft personality (rap) module (behind left side of i/p) S230 (main harn, near breakout to clockspring assembly) Steering assembly Steering column ground To low pitch horn) s145
Магнитола Мультимедия Электросхемы магнитолы для Ford Expedition 1997 Электросхемы магнитолы для Ford Expedition 1997 - Список элементов: 79 (dash harn, under center console) (main harn, behind center of dash) (upper left kick panel) g202 Amplifier (behind center of dash) Audio (+) Audio (-) C242 C261 C262 C263 C264 C314 C442 C443 Cd changer Cd left (+) Cd left (-) Cd right (+) Cd right (-) Engine fuse module (left side of engine compt) Fuse 10a Fuse 20a Fuse 5a G202 (upper left kick panel) G203 (lower right kick panel) Ground Hot at all times Hot in run or acc Ignition Illulmination Illumination Interior lights system Junction box fuse/relay panel (under left side of dash) L channel + L channel - L front (+) L front (-) L rear (+) L rear (-) Left front door speaker Left rear door speaker Mute Nca Power Power (b+) Protocal a Protocal b Protocol a Protocol b R channel + R channel - R front (+) R front (-) R rear (+) R rear (-) Radio Rear integrated control panel (audio) Right front door speaker Right rear door speaker S203 S223 S268 S280 S281 S282 S283 S284 S285 S303 S304 S305 S306 S322 S323 Shield Subwoofer Subwoofer amplifier (behind right side of dash) System on Tan
Подогрев стекол и зеркал Электросхема подогрева стекол и зеркал для Ford Expedition 1997 Электросхема подогрева стекол и зеркал для Ford Expedition 1997 - Список элементов: 31 (main harn, near break- out to heated window switch) s264 (main harn, right side of i/p) s259 C239 C242 C243 C267 Defrost relay control Defrost switch input Fuse 17 10a Fuse 27 20a Fuse 6 5a G203 (lower right cowl panel) G402 (left rear wheel well) Generic electronic module (center of i/p) Heated grid relay Hot at all times Hot in run Interior lights system Junction box fuse/relay panel (left side of i/p) Left power/ heated mirror Nca On indicator On/off switch Power distribution box (left side of engine compartment) Rear heated window switch Rear window defrost grid Right power/ heated mirror S204 S402 S427 (rear window regulator control harn, right side of rear window) Switch illum
ПОДУШКИ БЕЗОПАСНОСТИ AIR BAG Электросхема подушек безопасности SRS AirBag для Ford Expedition 1997 Электросхема подушек безопасности SRS AirBag для Ford Expedition 1997 - Список элементов: 41 (expedition-main harn, behind center of dash) (navigator-main harn, behind left of dash) (main harness, at upper left cowl panel near breakout to g202) (not used) (under center of dash) data link connector (dlc) * pin shorting bar is engaged when module connector is disconnected Air bag diagnostic monitor (behind right side of dash) Air bag ind Air bag indicator C208 C209 C228 C238 C242 C243 Clock- spring assembly Data link con Driver's air bag Drvr air bag Fuse 19 10a Fuse 2 10a Fuse 22 10a G200 (lower left kick panel) Ground Hot at all times Hot in run Hot in run or start Instrument cluster Junction box fuse/relay panel (under left side of dash) L crash sens Left primary crash sensor (in left front of engine compartment) Nca Pass air bag Passenger's air bag Power (bat) Power (run) Power distribution box (on left side of engine compt) R crash sens Right primary crash sensor (in right front of engine compartment) S208 S229 Shorting bar
ПРЕДУПРЕЖДАЮЩИЕ СИСТЕМЫ Электросхема предупреждающей системы для Ford Expedition 1997 Электросхема предупреждающей системы для Ford Expedition 1997 - Список элементов: 48 Bat C239 C242 C245 C267 Fuse 5a G200 (lower left cowl panel) G203 (lower right cowl panel) G402 (left rear wheel well) Generic electronic module (gem)/ central timer module (ctm) (behind center of i/p) Glass ajar switch Head Headlamp switch Hot at all times Hot in acc or run Hot in run Hot in start Ign Ignition key warning switch (inside steering assembly) nca Junction box fuse/relay panel Key in ignition Left front door ajar switch Left rear door ajar switch Lf door ajar Liftgate ajar Liftgate ajar switch Lr door ajar Nca Off Park Park/head input Rf door ajar Right front door ajar switch Right rear door ajar switch Rr door ajar S207 S251 S258 S402 S414 S500 S501 S600 S701 S801 Seat belt buckle Seat belt warning switch (in seat belt buckle) Steering column ground
ПРИБОРНАЯ ПАНЕЛЬ Электросхема верхней консоли управления для Ford Expedition 1997 Электросхема верхней консоли управления для Ford Expedition 1997 - Список элементов: 25 4 wheel air suspension module (behind center of i/p) C242 Compass sensor Fuel pump assembly (in fuel tank) Fuse 5a G108 (left front G200 (lower left cowl panel) G414 (near fuel tank) Hot at all times Hot in run Interior lights Junction box fuse/relay panel Left map/ dome lamp Overhead trip computer module Pnk Powertrain control module (right side of engine compt) Radiator support) Right map/ dome lamp S289 S298 (main harn, right side of i/p) S400 S425 S426 S923 Transmission controls
ПРИВОД ЗЕРКАЛ Электросхема привода зеркал для Ford Expedition 1997 Электросхема привода зеркал для Ford Expedition 1997 - Список элементов: 18 Defogger system Direct- tional switch Exterior lights system Fuse 4 15a G203 (lower right cowl panel) Hot at all times I/p fuse panel L/r motor Left p0wer/ heated mirror Left/ right switch Nca Power mirror switch Red Right p0wer/ heated mirror S220 S501 S503 (body main harn, in driver's door) Up/dn motor
ПРИВОД ЛЮКА И КРЫШИ Электросхемы привода люка или крыши для Ford Expedition 1997 Электросхемы привода люка или крыши для Ford Expedition 1997 - Список элементов: 59 (0.015 +/- 0.001 ohm) shunt 87a Accessory delay relay B pnk Batt saver Battery saver relay C242 C243 C267 C918 C919 Circuit breaker 30a Close Close/up Fuse 15a Fuse 50a G414 (mini console) (near fuel tank) G908 (near moonroof motor assembly) Generic elec- tronic module Ground Hot at all times Interior lights system Junction box fuse/ relay panel (under left side of i/p) Left rear vent window switch Left vent window motor Ls common Moonroof assembly (center of headliner) Moonroof motor assembly (center of headliner) Moonroof switch Motor out 1 Motor out 2 Nca One tch dn hi One tch dn lo Open Open/dn Pnk Power Power distribution box (left side of engine compt) Range Red Right rear vent window switch Right vent window motor Rpo relay box (above passenger's air bag) S154 S424 S901 (interior lamp harn, near breakout to right rear vent window switch) S914 (interior lamp harn, near breakout to moonroof) S922 S923 Soft stop Sw 1 Sw 2 Sw 3 Sw 3 flush Sw common Tan/ red Tan/red Vent window/ moonroof full relay
ПРИВОД СТЕКЛОПОДЪЕМНИКОВ Электросхема стеклоподъемников для Ford Expedition 1997 Электросхема стеклоподъемников для Ford Expedition 1997 - Список элементов: 52 (body harn, near breakout to 16 pin conn, behind right side of dash) (except 1998 ford) (1998 ford) 87a Acc delay relay Batt saver Battery saver relay C242 C243 C267 C509 C510 Circuit breaker 30a Down sw input Fuse 15a Fuse 50a G203 (lower right kick panel) Generic elec- tronic module Ground Hot at all times Interior lights system Junction box fuse/ relay panel (under left side of dash) Left front power window motor Left front power window switch Left rear power window motor Left rear power window switch Left rear switch Left switch Lock out One tch dn hi One tch dn lo One touch down relay Otd sw input Otd switch Power distribution box (left side of engine compt) Power tops system Right front power window motor Right front power window switch Right rear power window motor Right rear power window switch Right rear switch Right switch S205 S252 (body harn, near breakout to park brake switch) S257 S299 (except 1997) (main harn, near breakout to g200, left kick panel) S500 S502 (body harn, near breakout to left front grommet, ford) (body harn, near breakout to memory set sw, lincoln) S600 S701 s209 S801 Shunt (0.015 +/- 0.001 ohm) Up sw input
Противоугонная система Сигнализация Электросхема противоугонной сигнализации, КУСКИ для Ford Expedition 1997 Электросхема противоугонной сигнализации, КУСКИ для Ford Expedition 1997 - Список элементов: 30 (main harn, right side of i/p) s276 Anti- theft indicator Anti-theft transceiver module (behind i/p) Armed sig Bus (+) Bus (-) C236 C243 Datalink connector (behind center of i/p) Fuse 30a Fuse 5a G123 (right rear of engine compt) G203 (lower right cowl panel) Grd Hot at all times Hot in run or start Ign Instrument cluster Junction box fuse/ relay panel Passive anti-theft system (pats) control module (behind center of i/p) Powertrain control module (pcm) (right side of engine compt) Pwr Rec sig Rf grd Rf pwr S204 S266 S275 (main harn, right side of i/p) S277 Transmit Электросхема противоугонной сигнализации, РЭП для Ford Expedition 1997 Электросхема противоугонной сигнализации, РЭП для Ford Expedition 1997 - Список элементов: 62 (body harn, near breakout to in-line conn, near right side of i/p) s254 (body harn, near breakout to rap module) s234 All lock All unlock Antenna Boo switch Brake on/off switch (behind left side of i/p) C242 C256 C257 Datalink Datalink connector (behind center of i/p) Digital transmission range sensor (below center of vehicle, left side of transmission) Disable Door ajar Door ajar out Driver's unlock relay (behind right side of i/p) Drvr unlock Electronic suspension Ext lights Exterior lights Fuse 15a Fuse 20a Fuse 5a G200 (lower left cowl panel) G203 (lower right cowl panel) Generic electronic module (gem) (behind center of i/p) Ground Horn Horns system Hot at all times Hot in run Hot in run ar acc Ignition Illum entry in Int lights Interior lights system Junction box fuse/ relay panel Left front power door lock switch Lock Nca Not used Power Power distribution box (left side of engine compt) Remote anti-theft personality (rap) module (behind left side of i/p) Right front power door lock switch S216 S219 S222 S223 S229 (main harn, near breakout to evo module) S231 (main harn, near breakout to inst cluster) S235 (body harn, near break- out to lock relay box) S235 (body harn, near breakout to rap module) S250 S263 (main harn, near left cowl panel) S268 (main harn, near breakout to evo module) S500 S501 S600 Trans in Unlock
СИСТЕМА АНТИБЛОКИРОВОЧНОЙ ТОРМОЗНОЙ СИСТЕМЫ ABS Электросхема антиблокировочной тормозной системы АБС (ABS) для Ford Expedition 1997 Электросхема антиблокировочной тормозной системы АБС (ABS) для Ford Expedition 1997 - Список элементов: 50 4 wheel anti-lock brakes system (4wabs) module (left side of engine compt) 4 wheel drive input 4wabs ind ctrl 4wabs relay 4wabs relay cctrl Abs active out Anti-lock brake ind Brake fluid level switch (on brake fluid reservoir) Brake fluid lvl Brake on/off (boo) switch (behind left side of i/p) Brake on/off switch C146 C147 C242 C243 Datalink connector (left side of i/p) Diagnostic trigger Differential speed sensor (on rear axle) Fuse 15a Fuse 5a Fuse 60a G108 (left front radiator support) Generic electronic module Ground Hot at all times Hot in run Hot in run or start Ignition feed Instrument cluster Junction box fuse/relay panel Left front sensor (high) Left front sensor (low) Left front wheel speed sensor (at wheel) Power (b+) Power distribution box Rear sensor (high) Rear sensor (low) Red brake ind Red brake input Red/pnk Right front sensor (high) Right front sensor (low) Right front wheel speed sensor (at wheel) S106 S121 S144 S144 (engine control sensor harn, left side of engine compartment) S225 S229 Tan/red
СИСТЕМА КОНДИЦИОНЕРА Электросхема кондиционера (1 из 2) для Ford Expedition 1997 Электросхема кондиционера (1 из 2) для Ford Expedition 1997 - Список элементов: 62 (interior lamp feed harn, left front of left rear wheel well) (main harness, near fuse/relay panel breakout) s228 (main harness, near mode selector switch breakout) (seat belt retractor harn, near aux a/c mode switch breakout) Auxiliary a/c blend actuator Auxiliary a/c control module Auxiliary a/c mode actuator Blend door actuator (behind right side of i/p, top of a/c plenum) Blend door pot Blower motor switch C217 C218 C219 C220 C242 C243 Cooling fan relay (in power distribution box) Def Floor Flr & def Front blend potentiometer Front mode potentiometer Function selector switch Fuse 10a Fuse 15a Fuse 5a G108 (left front radiator support) G109 (right front radiator support) G203 (right kick panel) G415 (near fuel tank) Hot in run Hot in start or run Hybrid cooling fan Illumination Interior lights system Junction box fuse/relay panel Max Med hi Med lo Mode selector switch Norm Off Pan & flr Panel Power distribution box Rear blend potentiometer Rear mode potentiometer Red S104 (eng cntrl harn, front right side of eng compt) S105 (engine cntrl harn, in power distribution relay box) S154 (engine control sensor harness, left rear of engine compartment) S200 (main harn, behind right side of i/p) S202 (main harn, in blower/ flasher relay block breakout) S203 (main harn, near rpo relay block breakout) S222 (main harn, near instrument cluster breakout) S274 S422 S424 (seat belt retract harn, near rpo relay box breakout) S918 (int lamp feed harn, near left side rail lamp breakout) S919 S920 S921 Электросхема кондиционера (2 из 2) для Ford Expedition 1997 Электросхема кондиционера (2 из 2) для Ford Expedition 1997 - Список элементов: 46 (console panel harness, near console blower motor breakout) (engine cntrl sensor harn, right side of eng compt) (heater blower motor feed harn, in blower motor resistor breakout) (interior lamp feed harn, near left side rail lamp breakout) (main harn, front center of floor console) (seat belt retractor harn, left rear side panel) 0ff A/c compressor clutch solenoid A/c clutch cycling pressure switch (right side of engine compartment) A/c clutch diode A/c pressure cutoff switch (left side of engine compartment) Auxiliary a/c blower motor Auxiliary a/c blower motor resistor (near blower motor) Auxiliary a/c relay (in rpo relay box) Blower motor Blower motor resistor (near blower motor) Blower relay (in blower/ flasher relay block) Console blend door actuator (in i/p console) Console blower motor Console blower motor resistor (in i/p console) Front blower motor switch Fuse 30a Fuse 40a G105 (right rear corner of engine compt) G203 (right kick panel) G415 (near fuel tank) Hot at all times Med Nca Off Off lo Power distribution box Powertrain control module (pcm) (on right side of safety wall) Rear Rear blower motor switch Rear integrated control panel (ricp) Red/pnk S125 S126 S202 (main harn, in blower/ flasher relay block breakout) S279 S322 S423 S424 (seat belt retractor harn, near rpo relay box breakout) S916 S923 (interior lamp feed harness)
СИСТЕМА КРУИЗКОНТРОЛЯ Электросхема системы круизконтроля для Ford Expedition 1997 Электросхема системы круизконтроля для Ford Expedition 1997 - Список элементов: 52 (main harn, near breakout to clockspring assembly) s230 15a 20a Accel Brake on/off (boo) switch (on brake pedal support) Brake press in Brake pressure switch (left rear corner of engine compt) C233 C234 C239 C242 C256 Clock- spring assembly (top of steering column) Coast Control sw gnd Control sw in Driver's airbag Fuse 13 Fuse 5 G105 (rear of right fender apron) G200 (lower left cowl panel) G203 (lower right cowl panel) Generic electronic module (gem) (behind center of i/p) Ground Horn relay (in power distribution box) Horn switches Hot at all times Hot in run Ign Ignition key warning switch Interior lights system Junction box fuse/relay panel Nca Off Ohms Power distri- bution box Remote anti-theft personality (rap) module (behind left side of i/p) Resume S102 S107 S112 S143 (engine sensor harn, near breakout to windshield wiper motor) S144 (engine sensor harn, left rear of engine compt) S202 S231 (main harn, near breakout to instrument cluster) Set/ Speed control servo/ amplifier assembly (left rear of engine compt) Speed control switch assembly Steering assembly Steering column ground Vehicle speed input Vehicle speed sensor (vss) (left rear of trans)
СИСТЕМА ОХЛАЖДЕНИЯ Электросхема системы охлаждения для Ford Expedition 1997 Электросхема системы охлаждения для Ford Expedition 1997 - Список элементов: 12 A/c pressure cutoff switch (left side of engine compartment) A/c system (a/c comp clutch) A/c system (function selector switch) Cooling fan relay (in power distribution box) Fuse 10a G108 (left front radiator support) G109 (right front radiator support) Hot in start or run Hybrid cooling fan Power distribution box S105 (engine cntrl harn, in power distribution relay box) S154 (eng cntrl sens harn, left rear of eng compt)
СИСТЕМА ПЕРЕДАЧИ ДАННЫХ Электросхема компьютерной линии передачи данных CAN для Ford Expedition 1997 Электросхема компьютерной линии передачи данных CAN для Ford Expedition 1997 - Список элементов: 30 (behind center of i/p) data link connector (dlc) (behind left side of i/p) (main harn, near breakout to evo module) s229 (main harn, right side of i/p) 4 wheel air suspension (4was) module (behind center of i/p) 4 wheel anti-lock brake system (4wabs) control module (left side of engine compt) Air bag diagnostic monitor (right side of i/p) Bus + Bus - C208 C239 C242 C256 C296 Dlc Dlc bus (+) Dlc bus (-) Fuse 12 5a G123 (rear of engine compt, right side of cowl panel) G203 (lower right cowl panel) Generic electronic module (gem) (behind center of i/p) Hot at all times Junction box fuse/ relay panel (under left side of i/p) Passive anti-theft system (pats) module (behind center of i/p) Powertrain control module (pcm) (right side of engine compt) Remote anti-theft personality (rap) module S202 S266 S275 (main harn, right side of i/p) S276
СИСТЕМА УПРАВЛЕНИЯ ДВИГАТЕЛЯ
4.6L 4.6L, Электросхема системы управления двигателя (1 из 4) для Ford Expedition 1997 4.6L, Электросхема системы управления двигателя (1 из 4) для Ford Expedition 1997 - Список элементов: 86 (engine control harn, near breakout to pcm) (engine control sensor harn, in breakout to 42-pin conn, right rear of eng compt) (engine control sensor harn, near breakout to vapor management valve) (fuel charge harn, near breakout of 42-pin conn in right rear of engine compt) (fuel charge harn, near breakout to radio noise cap 1) s118 (fuel charge harn, near breakout to radio noise cap 2) s119 (left radiator support) g108 (lower left kick panel) g200 (rear of engine compt) g123 * expedition ** f150/f250 light duty 4x4 low ind sw 820 ohms Accel sig Accs Air conditioning system Body computer system C243 Case gnd Ckp(+) Ckp(-) Data link (+) Data link (-) Data link connector (partial) (center of dash) Digital transmission range sensor (dtr sensor) (left side of transmission) Ect Ect gauge Electronic suspension system Engine fuse module (left side of engine compt) Evr ctrl Feps (eprom) Fp sending unit Fuel pump mon Fuse 30a Fuse 5a Hot at all times Hot in run or start Iat Ign coil 1 Ign coil 2 Ignition coils 1 & 2 Ignition coils 3 & 4 Instrument cluster system Intake manifold Intake manifold communicator control (right side of engine) Junction box fuse/relay panel (under left side of dash) Maf Mil Nca Not used O/d off Octane adjust Otc module Pcm power diode Pcm power relay Power distribution box (left side of engine compt) Powertrain control module (right side of engine compt) Pwr gnd R n Radio noise capacitor 1 Radio noise capacitor 2 Red Rr ho2s sig (12) S100 S106 S107 S116 (engine control sensor harn, near breakout to engine fuse module) S117 S127 S128 S130 S225 S277 Shift sol 1 (a/t) Shift sol 2 (a/t) Spark plugs Tach out Tcs (a/t) Tft To dtr sensor (diagram 4 of 4) Tr1 Tr2a Tr4a Transmission control indicator lamp Transmission control switch (a/t) Vss (-) 4.6L, Электросхема системы управления двигателя (2 из 4) для Ford Expedition 1997 4.6L, Электросхема системы управления двигателя (2 из 4) для Ford Expedition 1997 - Список элементов: 43 (engine control sensor harn, near breakout to 35-pin conn in left rear of engine compt) (engine control sensor harn, near breakout to 38-pin conn in right rear of engine compt) (fuel charge harn, near breakout to starter motor relay) s137 (lower left kick panel) (speedometer/ odometer) vehicle speed input (under left side of dash) junction box fuse/relay panel C236 C237 C243 C267 Crankshaft position sensor (lower front of engine) Crankshaft position sensor shield Differential pressure feedback egr sensor (left side of engine) Electronic suspension system Engine coolant temperature gauge Engine coolant temperature sender (left front corner of engine) Engine coolant temperature sensor (front of engine) Fuel pump relay Fuel reset switch indicator Fuel tank pressure sensor (at fuel tank) Fuse 20a G123 (rear of engine compt) G200 Generic electronic module/ central timer module Hot at all times Instrument cluster Intake air temperature sensor (on intake manifold) Malfunction indicator Nca Octane adjust shorting bar (right rear corner of engine compt) Power distribution box (left side of engine compt) Red Red/pnk S101 (engine control harn, in breakout to pcm) S123 (engine control harn, near breakout to starter motor relay) S135 (fuel charge harn, near breakout to radio noise capacitor) S136 (fuel charge harn, near breakout to fuel injector 3) S138 S139 S207 Tachometer Throttle position sensor (attached to throttle body) Vss input 4.6L, Электросхема системы управления двигателя (3 из 4) для Ford Expedition 1997 4.6L, Электросхема системы управления двигателя (3 из 4) для Ford Expedition 1997 - Список элементов: 30 (backup lamp sw to rear lamp feed harn, at breakout to 38-pin conn in right rear of engine compt) (fuel charge harn, near breakout to 42-pin conn in right rear of engine compt) (fuel tank) fuel pump module (right side of dash) inertia fuel shut-off switch 4r70w transmission Egr vacuum regulator solenoid (left side of engine) Electronic pressure control solenoid Evap canister purge Fuel injectors G108 (left front radiator support) Idle air control valve (on left side of intake manifold) Instrument cluster system Nca Output shaft speed sensor (left side of transmission) Red Red/pnk S129 S131 (fuel charge harn, near breakout to radio noise capacitor) S140 S141 (backup lamp sw to rear lamp feed harn, in breakout to 38-pin conn in right rear engine compt) S400 Shift solenoids Ss1 Ss2 Tan Tan/ red Tan/red Torque converter clutch solenoid Transmission fluid temperature sensor Valve (left rear corner of engine compt) 4.6L, Электросхема системы управления двигателя (4 из 4) для Ford Expedition 1997 4.6L, Электросхема системы управления двигателя (4 из 4) для Ford Expedition 1997 - Список элементов: 80 (engine ctrl sensor harn, near breakout c165, windshield wiper motor) s143 (front of left head) cylinder head temperature sensor (left rear of engine compt) speed control servo/amplifier assembly (left rear of transmission) vehicle speed sensor (main harn, near breakout to instrument cluster) (near fuel tank) canister vent solenoid (right side of engine) knock sensor 5v ref volt A/t Brake on/off Brake on/off switch C242 Cam pos in Camshaft position sensor (left front of engine) Camshaft position sensor shield Canister vent Cyl head temp Digital transmission range sensor (dtr sensor-a/t) (left side of transmission) Dpfe sens Dtr sens Epc sol From dtr sensor (diagram 1 of 4) Fuel inj 1 Fuel inj 2 Fuel inj 3 Fuel inj 4 Fuel inj 5 Fuel inj 6 Fuel inj 7 Fuel inj 8 Fuel pump ctrl Fuel tank press Fuse (m/t only) 5a Fuse 15a G123 (rear of engine compt) G123 (rear of engine compt) G200 (lower left kick panel) Heated oxygen sensor (ho2s 11) (lower right rear of engine) Heated oxygen sensor (ho2s 12) (right rear of transmission) Heated oxygen sensor (ho2s 21) (lower left rear of engine) Heated oxygen sensor (ho2s 22) (left rear of transmission) Heater ctrl Hot at all times Hot in start, with clutch disengaged Iac sol Ign coil 3 Ign coil 4 Junction box fuse/ relay panel (under left side of dash) Kap b(+) Knock sensor Lf ho2s Lf ho2s sig (21) Lr ho2s Lr ho2s sig (22) M/t Maf sens in Mass air flow sensor (right side of engine compt, in air cleaner assembly) Nca Oss (+) (a/t) Powertrain control module (right side of engine compt) Pwr gnd Red Red/pnk Rf ho2s Rf ho2s sig (11) Rr ho2s S100 S101 S107 S231 Sig rtn Tan Tan/red Tcc sol Tp sens in Trans ctrl ind Vapor valve Vpwr Vss (+) Vss input
5.4L 5.4L, Электросхема системы управления двигателя (1 из 4) для Ford Expedition 1997 5.4L, Электросхема системы управления двигателя (1 из 4) для Ford Expedition 1997 - Список элементов: 84 (engine control harn, near breakout to pcm) (engine control sensor harn, near breakout to vapor management valve) (expedition) (fuel charge harn, in breakout to fuel injector 3) (fuel charge harn, in breakout to fuel injector 7) (fuel charge harn, near breakout to 42-pin inline conn in right rear of engine compt) (left radiator support) g108 (lower left cowl panel) g201 (overhead console) (rear of engine compt) 4x4 low ind sw A/c on sig Air conditioning system Air suspn vss Body computer system C243 Case gnd Ckp (+) Ckp (-) Data link (+) Data link (-) Data link connector (partial) (center of dash) Digital transmission range sensor (dtr sensor) (left side of transmission) Dtr-tr1 Dtr-tr2 Dtr-tr4 E4od ccs E4od ss1 E4od ss2 Ect Electronic suspension system Engine fuse module (left side of engine compt) Evr sol Feps (eprom) Fp sending unit Fuel pump mon Fuse 30a Fuse 5a G123 Hot at all times Hot in run or start Iat Ign coil 1 Ign coil 3 Ign coil 5 Ign coil 6 Ignition coils Instrument cluster system Intake tune vlv Junction box fuse/relay panel (under left side of dash) Maf Mil Nca O/d off Octane adjust Od off ind Ohms Otc module Pcm power diode Pcm power relay Power distribution box (left side of engine compt) Powertrain control module (right side of engine compt) Pwr gnd R n Radio noise capacitor Red Rr ho2s (12) S100 S106 S107 S116 S117 S127 S128 S161 S162 S225 Tach Tcs Tft To dtr sensor (diagram 4 of 4) Transmission control indicator lamp Transmission control switch Vss (-) 5.4L, Электросхема системы управления двигателя (2 из 4) для Ford Expedition 1997 5.4L, Электросхема системы управления двигателя (2 из 4) для Ford Expedition 1997 - Список элементов: 44 (engine control sensor harn, near breakout to 35-pin conn in left rear of engine compt) s139 (engine control sensor harn, near breakout to 38-pin conn in right rear of engine compt) (lower left kick panel) (speedometer/ odometer) vehicle speed input (under left side of dash) junction box fuse/relay panel C236 C237 C243 C267 Crankshaft position sensor (lower front of engine) Crankshaft position sensor shield Differential pressure feedback egr sensor (left side of engine) Electronic suspension system Engine coolant temperature gauge Engine coolant temperature sender (left front corner of engine) Fuel pump relay Fuel reset switch indicator Fuel tank pressure sensor (at fuel tank) Fuse 20a G123 (rear of engine compt) G200 Generic electronic module/ central timer module Hot at all times Instrument cluster Intake air temperature sensor (on intake manifold) Knock sensor (top right rear side of engine) Knock sensor shield Malfunction indicator Nca Octane adjust shorting bar (right rear corner of engine compt) Power distribution box (left side of engine compt) Red Red/pnk S101 nca S123 (engine control harn, near breakout to starter motor relay) S135 (fuel charge harn, near breakout to radio noise capacitor) S136 (fuel charge harn, near breakout to fuel injector 3) S137 (fuel charge harn, near breakout to starter motor relay) S138 S199 nca S207 Tachometer Throttle position sensor (attached to throttle body) Vss input 5.4L, Электросхема системы управления двигателя (3 из 4) для Ford Expedition 1997 5.4L, Электросхема системы управления двигателя (3 из 4) для Ford Expedition 1997 - Список элементов: 29 (backup lamp sw to rear lamp feed harn, at breakout to 38-pin conn in right rear of engine compt) (backup lamp sw to rear lamp feed harn, in breakout to 38-pin conn in right rear engine compt) (fuel charge harn, near breakout to 42-pin conn in right rear of engine compt) (fuel tank) fuel pump module (right side of dash) inertia fuel shut-off switch Coast clutch solenoid E4od transmission Egr vacuum regulator solenoid (left side of engine) Electronic pressure control solenoid Fuel injectors G108 (left front radiator support) Idle air control valve (on left side of intake manifold) Instrument cluster system Intake manifold tuning valve (on left side of engine) Nca Red Red/pnk S129 S131 (fuel charge harn, near breakout to radio noise capacitor) S140 S141 S400 Shift solenoid Tan Tan/ red Tan/red Torque converter clutch solenoid Transmission fluid temperature sensor Vapor management valve (vmv) (left rear corner of engine compt) 5.4L, Электросхема системы управления двигателя (4 из 4) для Ford Expedition 1997 5.4L, Электросхема системы управления двигателя (4 из 4) для Ford Expedition 1997 - Список элементов: 77 (engine control sensor harn, near breakout to c165, windshield wiper motor) (front of left head) cylinder head temperature sensor (left rear of engine compt) speed control servo/amplifier assembly (left rear of transmission) vehicle speed sensor (main harn, near breakout to 16-pin inline conn behind left side of dash) (near fuel tank) canister vent solenoid 270 ohms 5v ref Brake on/off Brake on/off switch C242 Camshaft position sensor (left front of engine) Camshaft position sensor shield Canister vent Cmp sensor Cyl head temp Digital transmission range sensor (dtr sensor-a/t) (left side of transmission) Dpfe sens Dtr-tr3a Epc sol From dtr sensor (diagram 1 of 4) Fuel inj 1 Fuel inj 2 Fuel inj 3 Fuel inj 4 Fuel inj 5 Fuel inj 6 Fuel inj 7 Fuel inj 8 Fuel pump ctrl Fuel tank press Fuse 15a G123 (rear of engine compt) G200 (lower left kick panel) Heater ctrl Hot at all times Idle air ctrl Ign coil 2 Ign coil 4 Ign coil 7 Ign coil 8 Junction box fuse/relay panel (under left side of dash) Kap b(+) Knock sensor Left front heated oxygen sensor (ho2s 21) (lower left rear of engine) Left rear heated oxygen sensor (ho2s 22) (left rear of transmission) Lf ho2s Lf ho2s sig (21) Lr ho2s Maf sens in Mass air flow sensor (right side of engine compt, in air cleaner assembly) Nca Powertrain control module (right side of engine compt) Pwr gnd Red Red/pnk Rf ho2s Rf ho2s sig (11) Rf ho2s sig (22) Right front heated oxygen sensor (ho2s 11) (lower right rear of engine) Right rear heated oxygen sensor (ho2s 12) (right rear of transmission) Rr ho2s S100 S101 S107 S143 S199 S231 Sig rtn Tan Tan/red Tcc sol Tp sens in Vapor valve Vpwr Vss (+) Vss input
СИСТЕМА УСИЛИТЕЛЯ РУЛЯ Электросхема усилителя руля, С пневматическая подвеска для Ford Expedition 1997 Электросхема усилителя руля, С пневматическая подвеска для Ford Expedition 1997 - Список элементов: 39 (behind steering wheel, in i/p) steering wheel rotation sensor (engine control sensor harn, near breakout to wiper motor) (main harn, near breakout to evo module) (main harn, near breakout to evo module) s269 (main harn, near breakout to evo module) s271 (right side of i/p) 4 wheel air suspension module (behind center of i/p) C242 C243 Diagnostic input Electronic variable orifice (evo) module (behind center of i/p) Evo act output Evo actuator (left side of engine compt) Evo test connector Fuse 15a G200 (lower left cowl panel) G203 (lower right cowl panel) Generic electronic module Ground Hot in run Ignition Instrument cluster Junction box fuse relay panel left side of i/p) Nca Red S107 S143 S203 S207 S208 S222 S265 S267 S270 (main harn, near breakout to 4 wheel air susp mod) S273 (main harn, near breakout to evo module) Steerg rot input Vehicle speed sensor (left rear of transmission) Vss gnd Vss in Электросхема усилителя руля, без пневматическая подвеска для Ford Expedition 1997 Электросхема усилителя руля, без пневматическая подвеска для Ford Expedition 1997 - Список элементов: 32 (eng control sensor harn, near breakout to wiper motor) (right side of i/p) C242 C243 Diagnostic input Electronic variable orifice (evo) module (behind center of i/p) Evo actuator (left side of engine compt) Evo test connector Fuse 15a G200 (lower left cowl panel) G203 (lower right cowl panel) Generic electronic module Ground Hot in run Ignition Instrument cluster Junction box fuse relay panel left side of i/p) Red S107 S143 S203 S207 S208 S222 S265 Steering act power Steering act return Steering rot input Steering wheel rotation sensor (behind steering wheel, in i/p) Vehicle speed sensor (left rear transmission) Vss gnd Vss in
Система Фар Электросхема Автоламп, С DRL для Ford Expedition 1997 Электросхема Автоламп, С DRL для Ford Expedition 1997 - Список элементов: 71 (main harn, in main light switch breakout) (main harn, near rpo relay box breakout) Auto- lamp on Auto- lamp on ind Autolamp module (behind center of i/p) Battery Brake ind out C236 C237 C242 C243 C244 C245 C246 C259 Daytime running lamps (drl) module (left front of engine compartment) Fog lamp relay Fog lamp sw Fog on ind Fuse 10a Fuse 15a Fuse 20a Fuse 30a Fuse 5a G108 (left front radiator support) G109 (right front radiator support) G203 (lower right cowl panel) Head Headlamp relay Headlamps Headlmps Hi-beam indicator Hot at all times Hot in run Hot in start or run Ignition Ind feed Instrument cluster Instrument cluster system (brake ind) Junction box fuse/relay panel Left fog lamp Left headlamp Main light Main light switch Multi- function switch Off Park Park brake input Park brake switch (right side of park brake lever) Park lamp relay Pass Power distribution box Relay output Right fog lamp Right headlamp Rpo relay box (behind right side of i/p) S104 S106 S109 S112 S114 S122 S147 (eng control sensor harn, in left fog lamp breakout) S204 S211 S212 S219 S224 S225 S245 Switch Электросхема Автоламп, без DRL для Ford Expedition 1997 Электросхема Автоламп, без DRL для Ford Expedition 1997 - Список элементов: 61 (main harn, in main light switch breakout) (main harn, near rpo relay box breakout) Auto- lamp on Auto- lamp on ind Autolamp module (behind center of i/p) Battery C236 C237 C242 C243 C244 C245 C246 C259 Fog lamp relay Fog lamp sw Fog on ind Fuse 10a Fuse 15a Fuse 20a Fuse 30a Fuse 5a G108 (left front radiator support) G109 (right front radiator support) G203 (lower right cowl panel) Head Headlamp relay Hi-beam indicator Hot at all times Hot in start or run Ignition Instrument cluster Junction box fuse/relay panel Left fog lamp Left headlamp Main light Main light switch Multi- function switch Off Park Park lamp relay Pass Power distribution box Relay output Right fog lamp Right headlamp Rpo relay box (behind right side of i/p) S104 S106 S109 S114 S147 (eng control sensor harn, in left fog lamp breakout) S204 S211 S212 S219 S224 S225 S244 (main harn, near upper cowl panel) S245 Switch Электросхема фар, С DRL для Ford Expedition 1997 Электросхема фар, С DRL для Ford Expedition 1997 - Список элементов: 55 Battery Brake ind out C236 C237 C242 C243 C244 C246 C259 Daytime running lamps (drl) module (left front of engine compartment) Fog lamp relay Fog lamp sw Fog on ind Fuse 10a Fuse 15a Fuse 20a Fuse 30a Fuse 5a G108 (left front radiator support) G109 (right front radiator support) G203 (lower right cowl panel) Head Headlamps Headlmps Hi-beam indicator Hot at all times Hot in run Ignition Ind feed Instrument cluster Instrument cluster system (brake ind) Junction box fuse/relay panel Left fog lamp Left headlamp Main light Main light switch Multi- function switch Off Park Park brake input Park brake switch (right side of park brake lever) Pass Power distribution box Right fog lamp Right headlamp S104 S106 S109 S112 S114 S122 S147 (eng control sensor harn, in left fog lamp breakout) S204 S212 Switch Электросхема фар, без DRL для Ford Expedition 1997 Электросхема фар, без DRL для Ford Expedition 1997 - Список элементов: 42 C236 C237 C242 C243 C244 C246 C259 Fog lamp relay Fog lamp sw Fog on ind Fuse 10a Fuse 15a Fuse 20a Fuse 30a Fuse 5a G108 (left front radiator support) G109 (right front radiator support) G203 (lower right cowl panel) Head Hi-beam indicator Hot at all times Instrument cluster Junction box fuse/relay panel Left fog lamp Left headlamp Main light Main light switch Multi- function switch Off Park Pass Power distribution box Right fog lamp Right headlamp S104 S106 S109 S114 S147 (eng control sensor harn, in left fog lamp breakout) S204 S212 Switch
СИСТЕМЫ ПОДВЕСКИ Электросхема электроники подвески (1 из 2) для Ford Expedition 1997 Электросхема электроники подвески (1 из 2) для Ford Expedition 1997 - Список элементов: 66 (main harn, near breakout to 4was module) s272 4 wheel air suspension (4was) module (behind center of i/p) 4x4 low sig Air suspension compressor motor and vent solenoid (right radiator support) Air suspension compressor relay (near right headlamp) Air suspension indicator Air suspension service switch (behind right side of i/p) All wheel drv Brake on/off sw C237 C242 C243 C295 C296 Comp mtr vent sol Compressor relay Datalink Datalink connector (behind center of i/p) Door ajar in Evo module Front air fill solenoid Front fill sol Front gate sol Front gate solenoid Front height sen Fuse 15a Fuse 50a Fuse 5a G108 (left front radiator suport) G109 (right front radiator suport) G109 (right front radiator support) G200 (lower left cowl panel) G203 (lower right cowl panel) Ground Height sen power Hot at all times Hot in run Hot in start Instrument cluster Junction box fuse/ relay panel Left rear air spring solenoid Lr spring sol Pcm accel sig Pnk Power (hot in run) Power (start) Power distribution box Rear air fill solenoid Rear fill sol Rear height sen Red Right rear air spring solenoid Rr spring sol S104 S155 S177 S229 (main harn, near breakout to evo module) S265 S400 Service switch Solid state Steering sensor Tan Transmission controls Vehicl speed (+) Warning indicator Электросхема электроники подвески (2 из 2) для Ford Expedition 1997 Электросхема электроники подвески (2 из 2) для Ford Expedition 1997 - Список элементов: 36 (main harn, near breakout to 4 wheel air susp mod) s270 (main harn, near breakout to evo module) s267 (main harn, near breakout to evo module) s273 (rear lamp harn, near breakout to front height sensor) (rear lamp harn, near breakout to front height sensor) s410 Brake on/off switch (on brake pedal) Breakout to inst cluster) C174 C240 C241 C256 C294 Electronic variable orifice (evo) module (behind right side of i/p) Engine controls Evo actuator (left side of engine compt) Front height sensor (behind left running board) Fuse 15a G200 (lower left cowl panel) Generic electronic (gem) module (behind center of i/p) Generic electronic module (gem) Hot at all times Instrument cluster Junction box fuse/ relay panel Nca Powertrain control module (pcm) (right side of engine compt) Rear height sensor (rear floor panel) Red Remote anti-theft personality (rap) module (behind left side of i/p) S268 (main harn, near breakout to evo module) S269 (main harn, near breakout to evo module) S271 (main harn, near breakout to evo module) S400 S409 Steering wheel rotation sensor (behind steering wheel, in i/p) Tan Vehicle speed sensor (on rear of trans)
СИСТЕМЫ СИДЕНИЙ Электросхема привода сидений для Ford Expedition 1997 Электросхема привода сидений для Ford Expedition 1997 - Список элементов: 15 Entire seat Forward/reverse motor Front height motor Front of seat Fuse 18 30a Fwd G402 (left rear wheelwell) Hot at all times Nca Power distribution box (on left side of eng compt) Power seat control switch Rear height motor Rear of seat Rwd S414
Стартер Генератор Электросхема Генератора для Ford Expedition 1997 Электросхема Генератора для Ford Expedition 1997 - Список элементов: 24 175a 20a Battery C166 C176 C177 C178 C238 C243 Charge indicator Fuse 10a G123 (rear of engine compt, right side of cowl panel) G133 (on engine) Generator/ voltage regulator Hot in start or run Inline mini fuse (near gener- ator) Instru- ment cluster Junction box fuse/ relay panel Mega fuse (alter- nator) (right rear of engine compt) Ohms Power distribution system Red Starter motor Starter motor relay (right rear of engine compt) Электросхема стартера для Ford Expedition 1997 Электросхема стартера для Ford Expedition 1997 - Список элементов: 27 175a Acc Battery C175 C182 C243 Charging circuit Digital trans- mission range (dtr) sensor (left side of trans) Fuse 15a Fuse 50a G123 (rear of engine compt, right side of cowl panel) G133 (on engine) Ignition switch Junction box fuse/relay panel Lock b4 Mega fuse (pdb) (right rear of engine compt) Off Power distri- bution box Red Run S214 S226 Sta Start Starter motor (lower right side of engine) Starter motor relay (right rear of engine compt) Tan/red
Стеклоочистители и Стеклоомыватели Дворники Электросхема передних стеклоочистителей дворников и омывателя лобового стекла для Ford Expedition 1997 Электросхема передних стеклоочистителей дворников и омывателя лобового стекла для Ford Expedition 1997 - Список элементов: 56 (1997 expedition) (1998 expedition) (1998 navigator) 103k ohms 3.3k ohms 4.08k ohms 7.25k C239 C240 C243 C259 Front washer pump ctrl Front washer pump relay Fuse 30a G105 (rear of right fender apron) G108 (left front radiator support) G109 (right front radiator support) Gem; navigator) Generic electronic module (behind left side of dash) Hot in acc or run Int max Int min Interval delay/wash Junction box fuse/relay panel (under left side of dash) Multi- function switch Off Off 36.27k ohms Ohms Park Park sense Power distri- bution box (left side of engine compt) Power distri- bution relay box (left side of engine compt) Rear washer pump ctrl Rear washer pump relay Red Run Run/park relay ctrl S102 S104 S105 S113 S146 (engine control sensor harn, left rear of engine compt; expedition) (engine control sensor harn, in breakout to pwr distr box; navigator) S233 (1998 expedition) (near gem) Signal return Tan/ red Transmissions system Washer fluid level Washer fluid level switch (in fluid reservoir) Washer pump assembly Washer switch Wind- shield wiper motor Wiper hi/lo relay Wiper mode select Wiper run/park relay Wiper speed ctrl Wiper switch Электросхема заднего стеклоочистителя дворника и омывателя для Ford Expedition 1997 Электросхема заднего стеклоочистителя дворника и омывателя для Ford Expedition 1997 - Список элементов: 57 (1997) (1998) (left rear wheelwell) g402 1000 ohms 2900 ohms 330 ohms Battery saver relay C239 C239 c239 c239 C240 C243 C258 C259 C267 Front washer front washer front washer pump ctrl pump ctrl pump ctrl Front washer pump relay Fuse 10a Fuse 15a Fuse 30a G105 (rear of right fender apron) G108 (left front radiator support) Generic electronic module Generic electronic module (behind left side of dash) Hot at all times Hot in acc or run Int1 Int2 Interior lamps system Interval delay/wash Junction box fuse/ relay panel (under left side of dash) Multi- function switch Nca Off Power distri- bution box (left side of engine compt) Power distri- bution relay box (left side of engine compt) Power distribution box (left side of engine compt) Rear washer pump relay Rear washer rear washer rear washer pump ctrl pump ctrl pump ctrl Rear wiper down relay Rear wiper hi/lo park sense Rear wiper motor Rear wiper switch Rear wiper up relay S102 S105 S113 S164 (engine sensor harn, left rear of engine compt) S233 (1998 expedition) (near gem) S402 (expedition) s404 (navigator) Signal return Tan Tan/ red Tan/ tan/ tan/ red red red Transmissions system Wash Washer pump assembly Washer switch
ЦЕНТРАЛЬНЫЙ ЗАМОК Электросхема центрального замка для Ford Expedition 1997 Электросхема центрального замка для Ford Expedition 1997 - Список элементов: 34 (body harn, near breakout to in-line conn, near right side of i/p) s254 (body harn, near breakout to park brake switch) s603 (body harn, near breakout to remote anti-theft person- ality module) s234 87a All lock relay All unlock relay C256 C257 Driver's unlock relay Fuse 20a G203 (lower right cowl panel) Hot at all times Interior lights system Left front door lock motor Left front power door lock switch Left rear door lock motor Lifgate door lock motor Lock Lock relay (behind right side of i/p) Power distribution box (left side of engine compt) Remote anti-theft personality module (behind left side of i/p) Right front door lock motor Right front power door lock switch Right rear door lock motor S216 S235 (body harn, near break- out to lock relay box) S235 (body harn, near breakout to remote anti-theft personality module) S258 S500 S501 S504 S600 S604 (body harn, near breakout to right door courtesy lamp) Unlock
