Все схемы для электропроводки Mitsubishi Endeavor XLS 2004

Автомтическая коробка Передач (АКПП) Полная привод (4WD) Блокировка Дифференциала

Электросхема коробки передач АКПП (1 из 4) для Mitsubishi Endeavor XLS 2004

Электросхема коробки передач АКПП (1 из 4) для Mitsubishi Endeavor XLS 2004 - Список элементов:

28

(left front of engine compt)
(left side of dash) j/c 1
(left side of eng compt) relay box
(pedal support member) stoplight switch
(under left side of dash) data link connector
A/t control solenoid valve assembly (left side of engine compartment)
B-18
B-19
B-20
Computer data lines system
Cruise control system
Engine controls system
Fuse 10a
Fuse 15a
Fuse 20a
G12
Hot at all times
Instrument cluster system
J/c 2
Low & reverse solenoid valve
Overdrive solenoid valve
Power distribution system
Powertrain control module (left front of engine compt)
Red
Second solenoid valve
Torque converter clutch control solenoid valve
Transmission fluid temperature sensor
Under drive solenoid valve

Электросхема коробки передач АКПП (2 из 4) для Mitsubishi Endeavor XLS 2004

Электросхема коробки передач АКПП (2 из 4) для Mitsubishi Endeavor XLS 2004 - Список элементов:

14

(engine compt relay box) mfi relay
(main)
(sub)
Accelerator pedal position sensor (above accelerator pedal)
C-211
C-214
Engine controls system
Fuse 7.5a
Hall ic
Hot in on or start
J/c 1 (left side of dash)
J/c 3
Junction block (left end of dash)
Red

Электросхема коробки передач АКПП (3 из 4) для Mitsubishi Endeavor XLS 2004

Электросхема коробки передач АКПП (3 из 4) для Mitsubishi Endeavor XLS 2004 - Список элементов:

13

(behind lower center of dash)
A/t temperature ind
Combination meter
Computer data lines system
Cpu
D ind
Ind
Interior lights system
N ind
P ind
R ind
Red
Rheostat circuit

Электросхема коробки передач АКПП (4 из 4) для Mitsubishi Endeavor XLS 2004

Электросхема коробки передач АКПП (4 из 4) для Mitsubishi Endeavor XLS 2004 - Список элементов:

16

(engine compt relay box) a/t control relay
(top of transaxle) input shaft speed sensor
(top of transaxle) output shaft speed sensor
(top of transaxle) transmission range switch
Auto mode
B-21
Crankshaft position sensor (front of engine)
Engine controls system
Exterior lights system
Powertrain control module (left front of engine compt)
Red
Select switch
Shift switch (down)
Shift switch (up)
Shift switch assembly
Sport mode

БАГАЖНИК ЗАДНЯЯ ДВЕРЬ ЛЮЧОК ТОПЛИВНОГО БАКА

Электросхема открывания багажника и лючка топливного бака для Mitsubishi Endeavor XLS 2004

Электросхема открывания багажника и лючка топливного бака для Mitsubishi Endeavor XLS 2004 - Список элементов:

25

(center of liftgate) g9
C211
C214
C215
C217
C218
C219
Contact connector (above license plate light)
Engine compartment relay box (left side of engine compt)
Etacs ecu
Fuse 15a
Fuse 7.5a
G7 (behind instrument cluster)
G8 (behind lower center of dash)
Headlights, exterior lights & wiper/washer systems
Hot at all times
Hot in acc or on
Hot in on or start
Junction block (left end of dash)
Junction connector 1
Liftgate & liftgate glass hatch actuator (lower center of liftgate)
Liftgate glass hatch opener switch
Liftgate opener switch
Nca
Pnk

БЛОК ПРЕДОХРАНИТЕЛЕЙ И РЕЛЕ

Электросхема блока предохранителей и реле (1 из 2) для Mitsubishi Endeavor XLS 2004

Электросхема блока предохранителей и реле (1 из 2) для Mitsubishi Endeavor XLS 2004 - Список элементов:

54

(at positive battery terminal connection)
Air conditioning & cooling fans systems
Air conditioning system
Anti-lock brakes system
Anti-lock brakes, cruise control, transmissions, exterior lights & anti-theft systems
Battery
Cruise control, engine controls, air conditioning, anti-theft, transmissions & cooling fans systems
Door locks, exterior lights systems
Engine compartment relay box (left side of engine compartment)
Engine controls system
Exterior lights system
Front ecu
Fuse 10 10a
Fuse 11 15a
Fuse 12 20a
Fuse 13 7.5a
Fuse 14 10a
Fuse 15 20a
Fuse 16 10a
Fuse 17 10a
Fuse 18 10a
Fuse 19 10a
Fuse 20 7.5a
Fuse 21 7.5a
Fuse 22 15a
Fuse 24 15a
Fuse 6 15a
Fuse 7 20a
Fuse 8 15a
Fuse 9 20a
Fusible link 1 80a
Fusible link 2 50a
Fusible link 26 120a
Fusible link 3 60a
Fusible link 4 40a
Fusible link 5 30a
G10 (front of engine compt)
G3 (left rear of engine compt)
Headlight relay high
Headlight relay low
Headlights & anti-theft systems
Headlights system
Horns, door locks & anti-theft systems
Off
Red
Seats system
Starting/ charging system
Starting/charging system
Taillight relay
To fuse 3 (diagram 2 of 2)
To fuse 6 (diagram 2 of 2)
To ignition switch (diagram 2 of 2)
To junction block (diagram 2 of 2)
Transmissions system

Электросхема блока предохранителей и реле (2 из 2) для Mitsubishi Endeavor XLS 2004

Электросхема блока предохранителей и реле (2 из 2) для Mitsubishi Endeavor XLS 2004 - Список элементов:

69

(+)
(-)
(left end of dash) junction block
Acc
Accessory socket 1
Accessory socket 2
Accessory socket 3
Accessory socket 4
Air conditioning system
Air conditioning, wiper/washer headlights, exterior lights & navigation systems
Anti-lock brakes & power tops systems
C114
C115
C126
C211
C212
C215
Defogger relay
Door locks & interior lights systems
Early
Engine compartment relay box (left side of engine compartment)
Engine controls system
From fuse 20 (diagram 2 of 2)
From fusible link 1 (diagram 1 of 2)
From fusible link 1 (diagram 2 of 2)
From fusible link 4 (diagram 1 of 2)
From fusible link 5 (diagram 1 of 2)
From junction block (diagram 2 of 2)
Fuse 1 7.5a
Fuse 10 15a
Fuse 11 15a
Fuse 13 7.5a
Fuse 14 7.5a
Fuse 16 15a
Fuse 17 7.5a
Fuse 20 7.5a
Fuse 22 7.5a
Fuse 23 10a
Fuse 23 7.5a
Fuse 24 10a
Fuse 25 30a
Fuse 3 20a
Fuse 4 20a
Fuse 5 30a
Fuse 6 30a
Fuse 9 15a
G12 (left front of engine compt)
G14 (under right front seat)
G8 (behind lower center of dash)
Ignition switch
Interior lights, door locks, wiper/washer & systems
Junction block (left end of dash)
Late production
Lock
Mirrors system
Off
Power tops system
Power windows system
Production
Red
Seat system
Sound systems
Sound, air conditioning & navigation systems
Start
Starting/charging & cruise control systems
To defogger relay relay (diagram 2 of 2)
To fuse 1 (diagram 2 of 2)
To fuse 4 (diagram 2 of 2)
Wiper/ washer system

БЛОКИ УПРАВЛЕНИЯ КУЗОВОМ

Электросхема блоков управления кузовом для Mitsubishi Endeavor XLS 2004

Электросхема блоков управления кузовом для Mitsubishi Endeavor XLS 2004 - Список элементов:

51

A11x
A12x
Acc or on
Air conditioning, computer data lines & sound systems
All times
Anti-theft & interior lights systems
Anti-theft system
C204
C205
C211
C214
C217
C218
C219
Computer data lines system
Door locks system
Engine compartment relay box (left side of engine compartment)
Etacs ecu
Exterior lights system
Exterior lights, headlights systems
Front ecu
Fuse 10a
Fuse 15a
Fuse 30a
Fuse 7.5a
G13 (early production) (near engine compt, relay box) g12 (late production) (left front of engine compt)
G7 (behind instrument cluster)
G8 (behind lower center of dash)
Headlights & exterior lights systems
Headlights system
Headlights, air conditioning & interior lights systems
Horns system
Hot at
Hot in
Hot in acc
Hot in on
Interior lights & anti-theft systems
Interior lights & door locks systems
Interior lights system
Joint connector 1
Joint connector 3
Jumper connector
Junction block (left end of dash)
Or on
Or start
Pnk
Power window relay
Red
Trunk, tailgate, fuel doors system
Warning system
Wiper/washer system

ВНЕШНЕЕ ОСВЕЩЕНИЕ

Электросхема заднего хода для Mitsubishi Endeavor XLS 2004

Электросхема заднего хода для Mitsubishi Endeavor XLS 2004 - Список элементов:

14

C214
Fuse 22 7.5a
G14 (under right front seat)
G16 (on top of left rear wheelwell)
Hot in on or start
Joint connector 1
Junction block (left end of dash)
Left back-up light
Left rear combination light
Nca
Right back-up light
Right rear combination light
Transmission range switch (on top of transaxle)
Transmissions system

Электросхема внешнего освещения (1 из 2) для Mitsubishi Endeavor XLS 2004

Электросхема внешнего освещения (1 из 2) для Mitsubishi Endeavor XLS 2004 - Список элементов:

35

(near engine compt relay box) (early production) g13
(on top of left rear wheelwell) g16
A11x
A12x
Back-up lamps circuit
C204
C214
Cruise control system
Engine compartment relay box (left side of engine compartment)
Front ecu
Fuse 11 15a
Fuse 12 20a
Fuse 14 10a
Fuse 20 7.5a
Fuse 21 7.5a
Fuse 22 10a
G12 (late production) (left front of engine compt)
G12 (left front of engine compt)
G14 (under right front seat)
G16 (on top of left rear wheelwell)
G9 (center of liftgate)
High mounted stop light
Hot at all times
Joint connector 1
Junction block (left end of dash)
Left front combination light
Left rear combination light
License plate light
Nca
Off
Right front combination light
Right rear combination light
Spare connector (trailer lights) (center rear of vehicle)
Stoplight switch
Taillight relay

Электросхема внешнего освещения (2 из 2) для Mitsubishi Endeavor XLS 2004

Электросхема внешнего освещения (2 из 2) для Mitsubishi Endeavor XLS 2004 - Список элементов:

38

Air conditioning, computer data lines, anti-theft, warning,exterior lights & sound systems
C204
C211
C214
C218
C219
Column ecu
Column switch
Combination meter
Computer data lines system
Cpu
Early production
Etacs ecu
Fuse 20 7.5a
Fuse 23 7.5a
G7 (behind instrument cluster)
G8 (behind lower center of dash)
Gnd
Hazard warning light switch
Head
Hot in acc or on
Hot in on or start
Interior lights system
Joint connector
Junction block (left end of dash)
Left
Left front door switch
Left turn ind
Left turn signal light relay
Lighting switch
Off
Power source
Red
Right
Right turn ind
Right turn signal light relay
Tail
Turn signal light

ВНУТРЕННЕЕ ОСВЕЩЕНИЕ

Электросхема подсветки (1 из 2) для Mitsubishi Endeavor XLS 2004

Электросхема подсветки (1 из 2) для Mitsubishi Endeavor XLS 2004 - Список элементов:

44

(behind lower center of dash) g8
10a
15a
C102
C204
C205
C211
C214
C217
C218
C219
Combination meter
Computer data lines system
Cpu
Dome
Door
Door ind
Engine compartment relay box (left side of engine compartment)
Etacs ecu
Fuse
Fuse 15a
Fuse 7.5a
G6 (front center of roof)
G7 (behind instrument cluster)
G8 (behind lower center of dash)
Hot at all times
Hot in on or acc
Hot in on or start
J/c 1 (left side of dash)
J/c 3
J/c 4
Joint connector 3
Junction block (left end of dash)
Left front door light
Left front foot light
Left rear personal light
Luggage dome light (early production) cargo area light (late production)
Map
Off
Overhead console assembly
Red
Right front door light
Right front foot light
Right rear personal light

Электросхема подсветки (2 из 2) для Mitsubishi Endeavor XLS 2004

Электросхема подсветки (2 из 2) для Mitsubishi Endeavor XLS 2004 - Список элементов:

16

(late production)
Early production
G6 (front center of roof)
G8 (behind lower center of dash)
Glass hatch latch (early production) liftgate glass hatch latch switch
Key reminder switch (when key is removed)
Late production
Left front door lock actuator (rear of left front door)
Left front door switch
Left rear door switch
Left vanity miirror light
Liftgate latch switch
Nca
Right front door switch
Right rear door switch
Right vanity miirror light

Электросхема подсветки приборов для Mitsubishi Endeavor XLS 2004

Электросхема подсветки приборов для Mitsubishi Endeavor XLS 2004 - Список элементов:

41

7.5a
A/c- ecu (center of dash)
A11x
A12x
C-211
C-214
C06
C105
C17
C211
Circuit rheostat
Column switch
Column-ecu
Combination meter
Cpu
Diode (early pro- duction) (upper center of dash)
Early production
Engine compartment relay box (at left side of engine compartment)
Fog light switch
Front ecu
Fuse
Fuse 20 7.5a
Fuse 22 15a
G8 (behind lower center of dash)
Glove box light
Hazard warning light switch
Head
Heated seat switch
Hot at all times
Hot in on or start
Illum
Joint connector 1 (left side of dash)
Joint connector 3
Junction block (left end of dash)
Lighting switch
Multi center display unit
Radio & cd player
Rheostat
Tail
Tail- light relay
Tcl switch

ЗАЗЕМЛЕНИЕ ПОДКЛЮЧЕНИЕ МАССЫ

Электросхема подключение массы заземления для Mitsubishi Endeavor XLS 2004

Электросхема подключение массы заземления для Mitsubishi Endeavor XLS 2004 - Список элементов:

35

Abs-ecu, abs/tcl-ecu & asc/tcl-ecu
Accessory socket 2, rear washer motor, (late production) floor console rear a/c switch assembly, powertrain control module, (late production) heated oxygen sensor shields, left headlight, front ecu, (late production) left front combination light, right front combination light, left fog light, right fog light, stoplight switch, windshield wiper motor & fan control relay (early production)
Battery
Fan control relay, powertrain control module, fan controller, brake fluid level switch & hood switch
G1 (right side of engine compartment)
G10 (front of engine compartment)
G11 (front of engine compartment)
G12 (left front of engine compartment)
G13 (early production) (near engine compartment relay box)
G13 (late production) (near engine compartment relay box)
G14 (under right front seat)
G15 (under left front seat)
G16 (on top of left rear wheelwell)
G2 (right side of engine compartment)
G3 (left rear of engine compartment)
G4 (behind upper center of dash)
G5 (behind upper center of dash)
G6 (front center of roof)
G7 (early production) (behind instrument cluster)
G7 (late production) (behind instrument cluster)
G8 (behind lower center of dash)
G9 (center of liftgate)
Heated seat relay, a/c-ecu, multi center display unit, rheostat, tpms receiver, g & yaw rate sensor, steering wheel sensor, right remote controlled mirror, rear blower relay, power transistor, key reminder switch, front power window sub switch, right front door lock actuator, hazard warning light switch, glove box light, fog light swich, etacs ecu, column switch, combination meter, heated seat switch accessory socket 4 & 1 & immobilizer ecu
Ignition coils 1, 2, 3, 4, 5, 6 & knock sensor shield
Left rear door lock actuator, right rear door lock actuator, fuel pump module, left rear combination light, high-mounted stop light & spare connector (for trailer)
Left vanity mirror light, right vanity mirror light, right rear personal light, left rear personal light, overhead console assembly, rear seat entertainment display unit assembly & sunroof assembly
Multi center display unit, tpms receiver, (late production) a/c-ecu, srs-ecu, rheostat, tcl switch, accessory socket 4 & 1 audio amplifier, right remote controlled mirror, left remote controlled mirror, remote controlled mirror switch, key reminder switch, door lock key cylinder switch, front power window sub switch, right front door lock actuator, left front door lock actuator, power window main switch, hazard warning light switch, glove box light, fog light switch, etacs ecu, column switch, combination meter, fuel pump relay 1, data link connector & immobilizer ecu (early production)
Power transistor, rear blower relay, multi center display unit, steering wheel sensor, g & yaw rate sensor, tpms receiver, heated seat switch, heated seat relay & etacs ecu
Powertrain control module, fan control module rear washer motor front ecu brake fluid level switch & hood switch
Rear wiper motor, liftgate glass hatch opener switch, (late production) license plate light, liftgate opener switch, (late production) liftgate handle & (early production) glass hatch handle (early production)
Right headlight, windshield washer motor, abs-ecu, abs/tcl-ecu & asc/tcl-ecu
Right rear combination light, accessory socket 3 & occupant classification-ecu (late production)
Seat belt switch, fuel pump module, left rear door lock actuator, right rear door lock actuator, power seat assembly, left heated seat assembly & right heated seat assembly
W/ multi center display (low)
W/ multi center display (middle)

Звуковой сигнал Гудок

Электросхема звукового сигнал Гудка для Mitsubishi Endeavor XLS 2004

Электросхема звукового сигнал Гудка для Mitsubishi Endeavor XLS 2004 - Список элементов:

10

Clock spring
Engine compartment relay b0x (left side of engine compt)
Fuse 8 15a
Horn (high)
Horn (low)
Horn relay (on engine compartment relay box)
Horn switch
Hot at all times
Joint connector 3
Nca

Магнитола Мультимедия

схема с 6 акустическими системами для Mitsubishi Endeavor XLS 2004

схема с 6 акустическими системами для Mitsubishi Endeavor XLS 2004 - Список элементов:

22

Antenna feeder cable
C105
C110
Engine compartment relay box (left side of engine compt)
Fuse 20 7.5a
Fuse 22 15a
Fuse 23 10a
Hot at all times
Hot in acc or on
Hot w/ taillight relay energized
Interior lights system
Joint connector 2
Left front door speaker
Left rear door speaker
Left tweeter
Mast antenna
Multi center display unit
Radio & cd player
Red
Right front door speaker
Right rear door speaker
Right tweeter

схема с 7 акустическими системами для Mitsubishi Endeavor XLS 2004

схема с 7 акустическими системами для Mitsubishi Endeavor XLS 2004 - Список элементов:

38

(right end of dash) audio amplifier
Antenna feeder cable
C105
C11
C110
C113
C12
C303
C306
Clock spring
Early production
Engine compartment relay box (left side of engine compt)
Fuse 20 7.5a
Fuse 22 15a
Fuse 23 10a
Fuse 3 20a
G8 (behind lower center of dash)
Hot at all times
Hot in acc or on
Hot w/ taillight relay energized
Interior lights system
Joint connector 2
Junction block (left end of dash)
Late production
Left front door speaker
Left rear door speaker
Left remote controlled radio switch
Left tweeter
Mast antenna
Multi center display unit
Pnk
Radio, cd player & cd changer
Red
Right front door speaker
Right rear door speaker
Right remote controlled radio switch
Right tweeter
Woofer

Электросхема Видео системы для Mitsubishi Endeavor XLS 2004

Электросхема Видео системы для Mitsubishi Endeavor XLS 2004 - Список элементов:

10

Din cable
Engine compartment relay box (left side of engine compt)
Fuse 22 15a
G6 (front center of roof)
Hot at all times
Nca
Radio & cd player or radio, cd player & cd changer
Rear display unit (overhead type)
Rear seat entertainment display unit assembly
Speaker

Подогрев стекол и зеркал

Электросхема подогрева стекол и зеркал для Mitsubishi Endeavor XLS 2004

Электросхема подогрева стекол и зеркал для Mitsubishi Endeavor XLS 2004 - Список элементов:

25

(behind lower center of dash) g8
A/c ecu (center of dash)
C16
C17
C204
C211
Defogger
Defogger relay
Engine compartment relay box (left side of engine compt)
F01
F05
Fuse 19 7.5a
Fuse 20 7.5a
Fuse 5 30a
G8 (behind lower center of dash)
Hot at all times
Hot in acc or on
Hot w/ tail relay energized
Interior lights system
Joint connector 2
Junction block (left end of dash)
Left remote controlled mirror (w/ door mirror heater)
Mirror heater
Nca
Right remote controlled mirror (w/ door mirror heater)

ПОДУШКИ БЕЗОПАСНОСТИ AIR BAG

Электросхема подушек безопасности SRS AirBag (1 из 3) для Mitsubishi Endeavor XLS 2004

Электросхема подушек безопасности SRS AirBag (1 из 3) для Mitsubishi Endeavor XLS 2004 - Список элементов:

37

(in dash harn, left side of dash) s048
Air bag drive
C-101
C-211
C-214
C-26
Center of dash)
Combination meter
Connector lock switch (connector coupled: on) (connector uncoupled: off)
Cpu
Data
Data link connector (dlc) (partial) (under left side of dash)
Detection circuit
Engine compt relay box (left side of engine compt)
Fuse 7.5a
G8 (behind lower center of dash)
Grd
Hot at all times
Hot in on or start
Hot with taillight relay energized
Indicator drive ckt
Interface
J/c 1
J/c 3
J/c 4
Junction block (left end of dash)
Off
Passenger's side air bag off indicator light
Passenger's side seat belt warning light
Pnk
Power
Red
S032 (in dash harn, center of dash)
S088 (in dash harn, left end of dash)
Side impact
Srs ecu (under front of center console)
Srs indicator

Электросхема подушек безопасности SRS AirBag (2 из 3) для Mitsubishi Endeavor XLS 2004

Электросхема подушек безопасности SRS AirBag (2 из 3) для Mitsubishi Endeavor XLS 2004 - Список элементов:

13

(connector coupled: on) (connector uncoupled: off) connector lock switch
(connector coupled: on) connector uncoupled: off) connector lock switch
Clock spring
Driver's side air bag module squib
G14 (under right front seat)
Left front impact sensor (at right front corner of engine compartment)
Left occupant classification sensor (under left front seat)
Nca
Occupant classification ecu (under left front seat)
Off
Passenger's side air bag module squib
Right front impact sensor (at left front corner of engine compartment)
Right occupant classification sensor (under right front seat)

Электросхема подушек безопасности SRS AirBag (3 из 3) для Mitsubishi Endeavor XLS 2004

Электросхема подушек безопасности SRS AirBag (3 из 3) для Mitsubishi Endeavor XLS 2004 - Список элементов:

25

(connector coupled: on) (connector uncoupled: off) connector lock switch
Air bag drive circuit
Buckle sw
C-25
C-40
Connector lock switch (connector coupled: on) (connector uncoupled: off)
Driver's side seat belt buckle switch (in driver's seat belt buckle)
Front impact sensor
Left seat belt pretensioner (base of left "b" pillar)
Left side air bag module squib (with side air bag)
Left side impact sensor (with side air bag) (at base of left "b" pillar)
Nca
Occ sensor
Off
Passenger's side seat belt buckle switch (in passenger's seat belt buckle)
Pretensioner drive circuit
Red
Right seat belt pretensioner (base of right "b" pillar)
Right side air bag module squib (with side air bag)
Right side impact sensor (with side air bag) (at base of right "b" pillar)
Seat belt buckle switch
Seat slide sensor (under left front seat)
Seat slide sensor detection
Solid state
Srs-ecu (under front of center console)

Электросхема подушек безопасности SRS AirBag, Дорестайлинг (1 из 2) для Mitsubishi Endeavor XLS 2004

Электросхема подушек безопасности SRS AirBag, Дорестайлинг (1 из 2) для Mitsubishi Endeavor XLS 2004 - Список элементов:

37

(at left front of engine compartment) left front impact sensor
(at right front of engine compartment) right front impact sensor
(partial) (below left side of
Air bag drive circuit
C-102
C-211
C-26
Clock spring
Combination meter
Computer data lines system
Connector lock switch (connector coupled: on) (connector uncoupled: off)
Cpu
Dash)
Data
Data link connector (dlc)
Driver's side air bag module (squib)
Engine compt relay box (left side of engine compt)
Fuse 15a
Fuse 7.5a
G8 (behind lower center of dash)
Grd
Ground
Hot at all times
Hot in on or start
Ignition
J/c 1
J/c 2
J/c 3
Junction block (behind left end of dash)
Nca
Off
Red
S032 (in dash harn, center of dash)
S043 (in dash harn, center of dash)
Srs ecu (under front of center console)
Srs indicator
Warning light

Электросхема подушек безопасности SRS AirBag, Дорестайлинг (2 из 2) для Mitsubishi Endeavor XLS 2004

Электросхема подушек безопасности SRS AirBag, Дорестайлинг (2 из 2) для Mitsubishi Endeavor XLS 2004 - Список элементов:

17

(connector coupled: on) (connector uncoupled: off) connector lock switch
Air bag drive circuit
C-25
Connector lock switch (connector coupled: on) (connector uncoupled: off)
Interface
Left seat belt pretensioner (base of left "b" pillar) (with side air bags)
Left side air bag module squib (if equipped)
Left side impact sensor (if equipped) (at base of left "b" pillar)
Nca
Off
Passenger's side air bag module squib
Red
Right seat belt pretensioner (base of right "b" pillar) (with side air bags)
Right side air bag module squib (if equipped)
Right side impact sensor (if equipped) (at base of right "b" pillar)
Solid state
Srs-ecu (under front of center console)

ПРЕДУПРЕЖДАЮЩИЕ СИСТЕМЫ

Электросхема сигнала для Mitsubishi Endeavor XLS 2004

Электросхема сигнала для Mitsubishi Endeavor XLS 2004 - Список элементов:

31

(under left front seat) g15
C204
C211
C214
C217
C218
C219
Column switch
Combination meter
Computer data lines system
Cpu
Door ind
Early production
Engine compartment relay box (left side of engine compt)
Etacs ecu
Fuse 22 15a
Fuse 23 7.5a
G7 (behind instrument cluster)
G8 (behind lower center of dash)
Head/tail lamp on
Hot at all times
Hot in run or start
Joint connector 1
Joint connector 3
Junction block (left end of dash)
Key reminder switch
Late production
Left front door switch
Nca
Seat belt ind
Seat belt switch (in driver's seat belt buckle)

Электросхема системы контроля давления в шинах для Mitsubishi Endeavor XLS 2004

Электросхема системы контроля давления в шинах для Mitsubishi Endeavor XLS 2004 - Список элементов:

31

Antenna
B18
C102
C118
C118-1
C211
Combination meter
Connector 1
Connector 2
Connector 3
Control circuit
Cpu
Data link connector (under left side of dash)
Early production
Engine compartment relay box (left side of engine compt)
Feeder cable
Fuse 22 15a
Fuse 23 7.5a
G7 (behind instrument cluster)
G8 (behind lower center of dash)
Hot at all times
Hot in run or start
Interior lights system
Joint
Joint connector 2
Junction block (left end of dash)
Late production
Powertrain control module (left front of engine compt)
Tire air ind
Tpms antenna
Tpms receiver (lower center of dash)

ПРИБОРНАЯ ПАНЕЛЬ

Электросхема панели приборов для Mitsubishi Endeavor XLS 2004

Электросхема панели приборов для Mitsubishi Endeavor XLS 2004 - Список элементов:

86

(behind lower center of dash) g8
(left end of dash)
(upper center of dash) (middle) diode
A/t temp ind
Anti lock ind
Anti-theft system
Asc/tcl ind
B18
B19
Brake fluid level switch (in brake fluid reservoir)
Brake ind
C204
C211
C217
C218
C219
Combination meter
Connector (under left side of dash)
Cpu
Cruise ind
Data link
Door ind
Early production
Early production middle
Engine compartment relay box (left side of engine compt)
Engine oil pressure switch
Etacs-ecu
Except early production middle
Fog ind
Fuel gauge
Fuel ind
Fuel level sensor (main)
Fuel level sub sensor (top of fuel tank)
Fuel pump module (in top of fuel tank)
Fuel temp sensor
Fuse 20 7.5a
Fuse 22 15a
Fuse 23 10a
Fuse 23 7.5a
Fuse 7.5a
G13 (near engine compt relay box)
G16 (front center of roof)
G7 (behind instrument cluster)
Generator malfunction ind
Grounding connector (left side of engine compt)
Hot at all times
Hot in on or acc
Hot in on or start
Hot w/ taillight relay enerigized
Illum
Immobilizer ind
Interior lights system
Joint connector
Joint connector 1
Joint connector 2
Junction block
Junction block (left end of dash)
Lcd odo/trip
Left front door switch
Left rear door switch
Left turn ind
Low
Main clock
Malfunction ind
Multi center display unit
Odo/trip switch
Oil ind
Parking brake switch (under left end of dash)
Powertrain control module (left front of engine compt)
Radio & cd player (low) radio, cd player & cd changer
Red
Rheostat circuit
Right front door switch
Right rear door switch
Right turn ind
Seat belt ind
Speedometer
Srs ind
Sub clock
Tachometer
Tcl ind
Tcl off ind
Temp gauge
Tire air ind
Upper beam ind
Warning system

ПРИВОД ЗЕРКАЛ

Электросхема привода зеркал для Mitsubishi Endeavor XLS 2004

Электросхема привода зеркал для Mitsubishi Endeavor XLS 2004 - Список элементов:

17

(behind lower center of dash) g8
C211
Capacitor (right kick panel)
Defogger system
Down
Fuse 14 7.5a
G8 (behind lower center of dash)
Hot in acc or run
Junction block (left end of dash)
Left
Left remote controlled mirror
Mirror heater
Nca
Off
Remote controlled mirror switch
Right
Right remote controlled mirror

ПРИВОД ЛЮКА И КРЫШИ

Электросхема привода люка или крыши для Mitsubishi Endeavor XLS 2004

Электросхема привода люка или крыши для Mitsubishi Endeavor XLS 2004 - Список элементов:

36

(front center of roof) g6
C205
C211
C214
C218
C219
Circuit breaker
Close/ down
Computer data lines system
Cpu
Engine compartment relay box (left side of engine compt)
Etacs ecu
Fuse 13 7.5a
Fuse 22 15a
Fuse 23 7.5a
Fuse 4 20a
G6 (front center of roof)
G7 (behind instrument cluster)
G8 (behind lower center of dash)
Headlights, exterior lights & wiper/washer systems
Hot at all times
Hot in on
Hot in on or start
Joint connector 1
Joint connector 3
Junction block (left end of dash)
Motor assembly
Nca
Open
Overhead console assembly
Red
Sensor unit
Sunroof assembly
Sunroof ecu
Sunroof motor
Sunroof switch

ПРИВОД СТЕКЛОПОДЪЕМНИКОВ

Электросхема стеклоподъемников для Mitsubishi Endeavor XLS 2004

Электросхема стеклоподъемников для Mitsubishi Endeavor XLS 2004 - Список элементов:

45

Auto down
C204
C211
C212
C214
C215
C218
C219
Computer data lines system
Cpu
Door lock switch
Door locks system
Down
Engine compartment relay box (left side of engine compartment)
Etacs-ecu
Fuse 22 15a
Fuse 7.5a
Fusible link 5 30a
G7 (behind instrument cluster)
G8 (behind lower center of dash)
Headlights, exterior lights & wiper/washer systems
Hot at all times
Hot in on or start
Illumination
Joint connector 1
Junction block (left end of dash)
Left front door switch
Left front door window regulator motor (early production) left front power window motor (late production)
Left front power window switch
Left rear door window regulator motor (early production) left rear power window motor (late production)
Left rear power window sub switch
Left rear power window switch
Lock
Lock switch
Power window main switch
Power window relay
Right front door switch
Right front door window regulator motor (early production) right front power window motor (late production)
Right front power window sub switch
Right front power window switch
Right rear door window regulator motor (early production) right rear power window motor (late production)
Right rear power window sub switch
Right rear power window switch
Sound systems
Unlock

Противоугонная система Сигнализация

Электросхема открывания авто для Mitsubishi Endeavor XLS 2004

Электросхема открывания авто для Mitsubishi Endeavor XLS 2004 - Список элементов:

45

(behind instrument cluster) g7
(behind lower center of dash) g8
(early production)
(late production)
(rear of right front door) right front door lock actuator
C204
C211
C214
C217
C218
C219
Computer data lines system
Door lock key cylinder switch
Engine compartment relay box (left side of engine compt)
Etacs-ecu
Fuse 22 15a
Fuse 23 7.5a
G13 (near engine compt relay box)
G15 (under left front seat)
G8 (behind instrument cluster)
G8 (behind lower center of dash)
Hood switch (left side of engine compt)
Horns system
Hot at all times
Hot in on or start
Ind
Joint connector 1
Jumper connector
Junction block (left end of dash)
Key reminder switch
Left front door lock actuator (rear of left front door)
Left front door switch
Left rear door lock actuator (rear of left rear door)
Left rear door switch
Liftgate glass hatch latch switch
Liftgate latch switch
Lock
Nca
Power distribution system
Red
Right front door switch
Right rear door lock actuator (rear of right rear door)
Right rear door switch
Theft-alarm indicator
Unlock

Электросхема иммобилайзера, Дорестайлинг для Mitsubishi Endeavor XLS 2004

Электросхема иммобилайзера, Дорестайлинг для Mitsubishi Endeavor XLS 2004 - Список элементов:

21

(behind lower center of dash) g8
B18
B19
C20
Combination meter
Computer data lines system
Engine compartment relay box (at left side of engine compt)
Engine controls system
Fuse 15a
Fuse 20a
Hot at all times
Ignition key
Ignition key ring antenna
Immobilizer ecu (behind lower center of dash)
Immobilizer ind
Joint connector 1
Mfi relay (on engine compartment relay box)
Nca
Powertrain control module (left front of engine compt)
Red
Stoplight switch

Электросхема иммобилайзера, Посол Рестайлинга для Mitsubishi Endeavor XLS 2004

Электросхема иммобилайзера, Посол Рестайлинга для Mitsubishi Endeavor XLS 2004 - Список элементов:

21

(left front of engine compt) powertrain control module
B18
B19
B20
Combination meter
Computer data lines system
Engine compartment relay box (at left side of engine compt)
Engine controls system
Fuse 15a
Fuse 20a
G7 (behind instrument cluster)
Hot at all times
Ignition key
Ignition key ring antenna
Immobilizer ecu (behind lower center of dash)
Immobilizer ind
Joint connector 2 (behind instrument cluster)
Key reminder switch
Mfi relay (on engine compartment relay box)
Nca
Red

СИСТЕМА АНТИБЛОКИРОВОЧНОЙ ТОРМОЗНОЙ СИСТЕМЫ ABS

Электросхема антиблокировочной тормозной системы АБС (ABS) для Mitsubishi Endeavor XLS 2004

Электросхема антиблокировочной тормозной системы АБС (ABS) для Mitsubishi Endeavor XLS 2004 - Список элементов:

36

(right side of engine compt) g1
(right side of engine compt) g2
Abs ecu (at right rear corner of engine compartment)
Abs g sensor (awd) (under center console)
Abs solenoid valve
Anti lock ind
B-18
Brake ind
C-211
C-214
Combination meter
Cpu
Data link connector (under left side of dash)
Engine compartment relay box (left side of engine compartment)
Fuse 11 15a
Fuse 13 7.5a
Fuse 22 15a
Fuse 23 7.5a
Fusible link 3 60a
G8 (behind lower center of dash)
Hot at all times
Hot in on
Hot in on or start
Hydraulic unit
J/c 1
J/c 3
Joint connector 4
Junction block (left end of dash)
Left front wheel speed sensor (at left front wheel)
Left rear wheel speed sensor (at left rear wheel)
Nca
Powertrain control module (left front of engine compt)
Red
Right front wheel speed sensor (at right front wheel)
Right rear wheel speed sensor (at right rear wheel)
Stoplight switch

Схема Регулирования тягового усилия, С Активное Управление Блоком для Mitsubishi Endeavor XLS 2004

Схема Регулирования тягового усилия, С Активное Управление Блоком для Mitsubishi Endeavor XLS 2004 - Список элементов:

46

(right side of engine compt) g1
Abs solenoid valve
Anti lock ind
Asc/ tcl ind
Asc/tcl ecu
B-18
Brake ind
C-211
C-214
Combination meter
Cpu
Data link connector (under left side of dash)
Early production
Engine compartment relay box (left side of engine compt)
Fuse 11 15a
Fuse 13 7.5a
Fuse 20 7.5a
Fuse 22 15a
Fuse 23 7.5a
Fusible link 3 60a
G & yaw rate sensor (under center console)
G2 (right side of engine compt)
G7 (behind instrument cluster)
G8 (behind lower center of dash)
Hot at all times
Hot in on
Hot in on or start
Hot w/ taillight relay energized
Hydraulic unit
Illum
Interior lights system
J/c 1
J/c 3
Joint connector 4
Junction block (left end of dash)
Left front wheel speed sensor (at left front wheel)
Left rear wheel speed sensor (at left rear wheel)
Nca
Powertrain control module (left front of engine compt)
Red
Right front wheel speed sensor (at right front wheel)
Right rear wheel speed sensor (at right rear wheel)
Steering wheel sensor (on steering column)
Stoplight switch
Tcl off ind
Tcl switch

Схема Регулирования тягового усилия, без Активное Управление Блоком для Mitsubishi Endeavor XLS 2004

Схема Регулирования тягового усилия, без Активное Управление Блоком для Mitsubishi Endeavor XLS 2004 - Список элементов:

42

(right side of engine compt) g2
Abs solenoid valve
Abs/tcl ecu (at right rear corner of engine compartment)
Anti lock ind
B-18
Brake ind
C-211
C-214
Combination meter
Cpu
Data link connector (under left side of dash)
Engine compartment relay box (left side of engine compartment)
Fuse 11 15a
Fuse 13 7.5a
Fuse 20 7.5a
Fuse 22 15a
Fuse 23 7.5a
Fusible link 3 60a
G1 (right side of engine compt)
G8 (behind lower center of dash)
Hot at all times
Hot in on
Hot in on or start
Hot w/ taillight relay energized
Hydraulic unit
Illum
Interior lights system
J/c 1
J/c 3
Joint connector 4
Junction block (left end of dash)
Left front wheel speed sensor (at left front wheel)
Left rear wheel speed sensor (at left rear wheel)
Nca
Powertrain control module (left front of engine compt)
Red
Right front wheel speed sensor (at right front wheel)
Right rear wheel speed sensor (at right rear wheel)
Stoplight switch
Tcl ind
Tcl off ind
Tcl switch

СИСТЕМА КОНДИЦИОНЕРА

Электросхема кондиционера (1 из 2) для Mitsubishi Endeavor XLS 2004

Электросхема кондиционера (1 из 2) для Mitsubishi Endeavor XLS 2004 - Список элементов:

36

(under rear of center console) resistor
A/c ecu (center of dash)
A/c pressure sensor (right front of engine compt)
Air mixing damper control motor & potentiometer
Air thermo sensor (above accelerator pedal)
Ambient temperature sensor (behind left side of front bumper)
C16
C17
C211
C214
Defogger system
Engine compartment relay box (left side of engine compartment)
Floor console rear a/c switch assembly
Fuse 10a
Fuse 15a
Fuse 20a
Fuse 7.5a
Fusible link 2 50a
G12 (below right side of battery)
G8 (behind lower center of dash)
Hot at all times
Hot in acc or on
Hot w/ tailgate relay energized
Illum
Interior lights system
Interior temperature sensor (left side of dash, right of steering column)
Joint connector
Joint connector 2
Joint connector 3
Junction block (left end of dash)
M:n
Max
Mode selection damper control motor & potentiometer
Pnk
Rear a/c ind
Red

Электросхема кондиционера (2 из 2) для Mitsubishi Endeavor XLS 2004

Электросхема кондиционера (2 из 2) для Mitsubishi Endeavor XLS 2004 - Список элементов:

62

(behind left side of dash,
(left front of
(near engine compt relay box) (late production) g13
(near engine compt relay box) g13
(rear of center console) rear blower motor
(right front of engine compt) a/c compressor assembly
(under left
A/c compressor clutch
A/c compressor clutch relay (on engine compt relay box)
A/c refrigerant temperature switch
A23
A23-1
Anti-lock
Anti-lock brakes system
B18
B20
B21
Brakes system
C211
C213
C214
C215
C218 etacs ecu
Condenser fan motor
Connector
Data link
Early production
Engine compt)
Engine controls system
Engine coolant temperature sensor (near throttle body)
Fan control
Fan control relay (on engine compt relay box)
Front blower motor
Front blower relay
Fuse 30a
Fuse 5a (early production) 7.5a (late production)
Fuse 7.5a
G12 (early production) (left front of engine compt)
G7 (behind instrument cluster)
Hot at all times
Hot in on
Joint connector
Joint connector 2
Joint connector 4
Junction block (left end of dash)
Late
Late production
Mfi relay (on engine compt relay box)
Module
Mutli center display unit
Nca
Near junction block)
Outside/inside air selection damper control motor
Photo sensor (top front center of dash)
Pnk
Power transistor
Powertrain control module (left front of engine compt)
Production
Radiator fan motor
Rear blower relay
Red
Side of dash)

Электросхема кондиционера с ручный управлением (1 из 2) для Mitsubishi Endeavor XLS 2004

Электросхема кондиционера с ручный управлением (1 из 2) для Mitsubishi Endeavor XLS 2004 - Список элементов:

32

(behind lower center of dash) g8
A/c ecu (center of dash)
A/c pressure sensor (right front of engine compt)
Accelerator
Air mixing damper control motor & potentiometer
Air thermo
Ambient temperature sensor (behind left side of front bumper)
Anti-lock brakes system
C16
C17
C218
Connector (under left side of dash)
Data link
Defogger system
Engine compartment relay box (left side of engine compartment)
Etacs ecu (behind left side of dash, near junction block)
Fuse 10a
Fuse 15a
Fuse 20a
Fuse 7.5a
Hot at all times
Hot in acc or on
Hot w/ tailgate relay energized
Interior lights system
Joint connector
Joint connector 2
Joint connector 3
Joint connector 4
Mode selection damper control motor & potentiometer
Pedal)
Red
Sensor (above

Электросхема кондиционера с ручный управлением (2 из 2) для Mitsubishi Endeavor XLS 2004

Электросхема кондиционера с ручный управлением (2 из 2) для Mitsubishi Endeavor XLS 2004 - Список элементов:

47

(left front of
(left front of engine compt) (late production) g13
(near engine compt relay box) g13
(right front of engine compt) a/c compressor assembly
A/c compressor clutch
A/c compressor clutch relay (on engine compt relay box)
A/c refrigerant temperature switch
A23
A23-1
B18
B20
B21
C211
C214
C215
Condenser fan motor
Early production
Engine compartment relay box (left side of engine compartment)
Engine compt)
Engine controls system
Engine coolant temperature sensor (near throttle body)
Fan control
Fan control relay (on engine compt relay box)
Front blower motor
Front blower relay
Fuse 10a
Fuse 30a
Fuse 7.5a
Fusible link 2 50a
G12 (early production) (left front of engine compt)
G7 (behind instrument cluster)
Hot at all times
Hot in on
J/c 1
Joint connector 3
Junction block (left end of dash)
Late
Late production
Mfi relay (on engine compt relay box)
Module
Nca
Outside/inside air selection damper control motor
Power transistor
Powertrain control module (left front of engine compt)
Production
Radiator fan motor
Red

СИСТЕМА КРУИЗКОНТРОЛЯ

Электросхема системы круизконтроля для Mitsubishi Endeavor XLS 2004

Электросхема системы круизконтроля для Mitsubishi Endeavor XLS 2004 - Список элементов:

59

(at right rear corner of engine compartment) abs/tcl ecu
(main)
(sub)
Acc
Accelerator pedal position sensor (above accelerator pedal)
Auto-cruise control switch
B-18
B-19
B-20
B-21
B-22
C211
C214
C303
C306
C308
Can
Clock spring
Combination meter
Computer data lines system
Cpu
Cruise ind
Engine compartment relay box (left side of engine compt)
Engine controls system
Fuse 11 15a
Fuse 7.5a
Fuse 9 20a
G12 (left front of engine compartment)
Hall ic
Hot at all times
Hot in on or start
Ignition switch
Interior lights system
Joint connector 1 (left side of dash)
Joint connector 3
Joint connector 4
Junction block (left end of dash)
Lock
Main
Mfi relay (on engine compt relay box)
Off
On off
Output shaft speed sensor (on top of transaxle)
Powertrain control module (left front of engine compartment)
Red
Res
Rheostat circuit
Set
Start
Starting/ charging system
Stoplight switch
Throttle actuator control motor
Throttle actuator control motor relay (on engine compt relay box)
Throttle body assembly
Transmission range switch (on top of transaxle)
Transmissions system
W/ electronic brake-force distribution, anti-lock braking system & active skid control system
W/ electronic brake-force distribution, anti-lock braking system & traction control system
W/o electronic brake-force distribution & anti-lock braking system

СИСТЕМА ОХЛАЖДЕНИЯ

Электросхема системы охлаждения для Mitsubishi Endeavor XLS 2004

Электросхема системы охлаждения для Mitsubishi Endeavor XLS 2004 - Список элементов:

25

(near engine compt relay box)
(near engine compt relay box) (late production) g13
A23
A23-1
B18
B20
B21
Condenser fan motor
Engine compartment relay box (left side of engine compartment)
Engine controls system
Engine coolant temperature sensor (near throttle body)
Fan control module (left front of engine compt)
Fan control relay (on engine compt relay box)
Fuse 20a
Fusible link 2 50a
G12 (early production) (left front of engine compt)
G13
Hot at all times
Late
Mfi relay (on engine compt relay box)
Nca
Powertrain control module (left front of engine compt)
Production
Radiator fan motor
Red

СИСТЕМА ПЕРЕДАЧИ ДАННЫХ

Электросхема линии передачи данных CAN для Mitsubishi Endeavor XLS 2004

Электросхема линии передачи данных CAN для Mitsubishi Endeavor XLS 2004 - Список элементов:

34

(behind lower center of dash) g8
A/c ecu (center of dash)
A12x
Abs/tcl ecu (at right rear corner of engine compt)
B18
C16
C211
C218
C26
Column switch
Combination meter
Cpu
Data link connector (under left side of dash)
Early production
Etacs ecu
Front ecu (on engine compt relay box)
Fuse 10 15a
G & yaw rate sensor (w/ abs, asc & ebd) (under center console)
Hot at all times
Joint connector 2
Joint connector 3
Joint connector 4
Junction block (left end of dash)
Late production
Multi center display unit
Nca
Powertrain control module (left front of engine compt)
Red
Srs ecu (late production) (under front of center console)
Steering wheel sensor (w/ abs, asc & ebd) (on steering column)
Sun roof motor assembly (right front of roof)
W/ electronic brake-force distribution, anti-lock braking system & active skid control system
W/ electronic brake-force distribution, anti-lock braking system & traction control system
W/o electronic brake-force distribution & anti-lock braking system

СИСТЕМА УПРАВЛЕНИЯ ДВИГАТЕЛЯ

3.8L

3.8L, Электросхема системы управления двигателем (1 из 5) для Mitsubishi Endeavor XLS 2004

3.8L, Электросхема системы управления двигателем (1 из 5) для Mitsubishi Endeavor XLS 2004 - Список элементов:

34

(left side of dash) j/c 1
(left side of eng compt) relay box
(main)
(near eng compt relay box)
(near fuel tank) evaporative emission ventilation solenoid
(pedal support member) stoplight switch
(sub)
(under left side of dash) data link connector
A/c system
Accelerator pedal position sensor (above accelerator pedal)
Anti-theft system
B-18
B-19
B-20
Computer data lines system
Cruise control system
Fuel tank differential pressure sensor (top of fuel tank)
Fuse 15a
Fuse 20a
G11 (front of eng compt)
G13
G13 (near eng compt relay box)
Grounding connector (a-18)
Hall ic
Hot at all times
Instrument cluster system
J/c 2
Knock sensor (top center of engine)
Nca
Power distribution system
Power steering pressure switch (lower right side of eng compt)
Powertrain control module (left front of engine compt)
Red
Starting circuit

3.8L, Электросхема системы управления двигателем (2 из 5) для Mitsubishi Endeavor XLS 2004

3.8L, Электросхема системы управления двигателем (2 из 5) для Mitsubishi Endeavor XLS 2004 - Список элементов:

24

(engine compt relay box) mfi relay
(engine compt relay box) throttle actuator control motor relay
A/t control solenoid valve assembly (left side of engine compartment)
C-204
C-211
C-214
Engine coolant temperature sensor (near throttle body)
Fuel pump relay 1
Fuel pump relay 2
Fuse 10a
Fuse 7.5a
G8 (behind center of dash)
Hot in on or start
J/c 1 (left side of dash)
J/c 3
Junction block (left end of dash)
Low & reverse solenoid valve
Manifold absolute pressure sensor (on intake manifold)
Overdrive solenoid valve
Red
Second solenoid valve
Torque converter clutch control solenoid valve
Transmission fluid temperature sensor
Underdrive solenoid valve

3.8L, Электросхема системы управления двигателем (3 из 5) для Mitsubishi Endeavor XLS 2004

3.8L, Электросхема системы управления двигателем (3 из 5) для Mitsubishi Endeavor XLS 2004 - Список элементов:

21

(behind lower center of dash)
A/t temp ind
Combination meter
Computer data lines system
Cpu
D ind
G12 (left front of eng compt)
Ind
Interior lights system
Left bank heated oxygen sensor (front) (left catalytic converter inlet)
Left bank heated oxygen sensor (rear) (left catalytic converter outlet)
Mass airflow sensor (left side of engine compt)
N ind
Nca
P ind
Pnk
R ind
Red
Rheostat circuit
Right bank heated oxygen sensor (front) (right catalytic converter inlet)
Right bank heated oxygen sensor (rear) (right catalytic converter outlet)

3.8L, Электросхема системы управления двигателем (4 из 5) для Mitsubishi Endeavor XLS 2004

3.8L, Электросхема системы управления двигателем (4 из 5) для Mitsubishi Endeavor XLS 2004 - Список элементов:

21

(engine compt relay box) a/t control relay
(top of fuel tank) fuel pump module
(top of transaxle) transmission range switch
Auto mode
Camshaft position sensor (rear of engine)
Crankshaft position sensor (front of engine)
Exhaust gas recirculation valve (left side of engine compt)
Exterior lights system
Fuel level sensor (main)
Fuel tank temperature sensor
G15 (under left front seat)
G16 (top of left rear wheel- well)
Injector
Instrument cluster system
Pnk
Red
Select switch
Shift switch (down)
Shift switch (up)
Shift switch assembly
Sport mode

3.8L, Электросхема системы управления двигателем (5 из 5) для Mitsubishi Endeavor XLS 2004

3.8L, Электросхема системы управления двигателем (5 из 5) для Mitsubishi Endeavor XLS 2004 - Список элементов:

26

(front of engine compt)
(main)
(sub)
(top of transaxle) input shaft speed sensor
(top of transaxle) output shaft speed sensor
B-21
B-22
Capacitor (rear of engine)
Charging circuit
Evaporative emission purge solenoid (center rear of engine compt)
G11
G11 (front of engine compt)
Hall ic
Ignition coil 1
Ignition coil 2
Ignition coil 3
Ignition coil 4
Ignition coil 5
Ignition coil 6
Nca
Pnk
Powertrain control module (left front of engine compt)
Red
Spark plug
Throttle actuator control motor
Throttle body assembly

Система Фар

Электросхема фар для Mitsubishi Endeavor XLS 2004

Электросхема фар для Mitsubishi Endeavor XLS 2004 - Список элементов:

63

(behind lower center of dash) g8
(early: near engine compt relay box)
(late: left front of engine compt)
A11x
A12x
Air conditioning, computer data lines, anti-theft, warning, exterior lights & sound systems
C204
C211
C214
C218
C219
Canada early production & all late production
Column ecu
Column switch
Combination meter
Computer data lines system
Cpu
Dimmer
Dimmer/ passing switch
Early production
Engine compartment relay box (left side of engine compt)
Etacs ecu
Fog ind
Fog light relay (on engine compt relay box)
Fog light switch
Front ecu
Fuse 10a
Fuse 15a
Fuse 17 10a
Fuse 18 10a
Fuse 19 10a
Fuse 20 7.5a
Fuse 23 7.5a
G1 (right side of engine compt)
G12 (left front of engine compt)
G13 (early production) g12 (late production)
G7 (behind instrument cluster)
G8 (behind lower center of dash)
Head
High headlight relay
Hot at all times
Hot in on
Hot in on or start
Illum
Interior lights system
Joint connector
Joint connector 1
Junction block (left end of dash)
Left fog light
Left front door switch
Left headlight
Lighting switch
Low headlight relay
Off
Passing
Pulse width modulator
Red
Rheostat circuit
Right fog light
Right headlight
Tail
Upper beam ind
Usa early production

СИСТЕМЫ СИДЕНИЙ

Электросхема подогрева сидений для Mitsubishi Endeavor XLS 2004

Электросхема подогрева сидений для Mitsubishi Endeavor XLS 2004 - Список элементов:

26

(behind instrument cluster) g7
(under left front seat) g15
C211
C213
Engine compartment relay box (left side of engine compt)
Fuse 20 7.5a
Fuse 7 20a
Heated seat relay
Heated seat switch
Heater
Hot at all times
Hot in on or start
Illum
Ind
Interior lights system
Joint connector
Junction block (left end of dash)
Left
Left heated seat assembly
Nca
Off
Right
Right heated seat assembly
Seat back heater
Seat cushion heater
Thermo- stat

Электросхема привода сидений для Mitsubishi Endeavor XLS 2004

Электросхема привода сидений для Mitsubishi Endeavor XLS 2004 - Список элементов:

18

Down
Engine compartment relay box (left side of engine compt)
Front height
Front height motor
Fusible link 5 30a
Fwd
G15 (under left front seat)
Hot at all times
Nca
Power seat assembly
Power seat switch
Rear height
Rear height motor
Reclining
Reclining motor
Rwd
Slide
Slide motor

Стартер Генератор

Электросхема Генератора для Mitsubishi Endeavor XLS 2004

Электросхема Генератора для Mitsubishi Endeavor XLS 2004 - Список элементов:

28

(at positive battery terminal connection)
Acc
B23
Battery
C102
C211
C215
Comb- ination meter
Cpu
Engine comp- artment relay box (at left side of engine compt)
Fuse 23 7.5a
Fuse 7.5a
Fusible link 26 120a
Fusible link 4 40a
G10 (front of engine compt)
G3 (left rear of engine compt)
G8 (behind lower center of dash)
Generator
Generator malfunction light ind
Ignition switch
Interior lights system
Joint connector 3
Junction block (left end of dash)
Lock
Off
Powertrain control module (left front of engine compt)
Start
Starting circuit

Электросхема стартера для Mitsubishi Endeavor XLS 2004

Электросхема стартера для Mitsubishi Endeavor XLS 2004 - Список элементов:

13

Acc
Battery
Engine compartment relay box (left side of engine compartment)
Engine controls system
Fusible link 4 40a
G10 (front of engine compt)
G3 (left rear of engine compt)
Ignition switch
Lock
Off
Start
Starter
Transmission range switch (on top of transaxle)

Стеклоочистители и Стеклоомыватели Дворники

Электросхема передних стеклоочистителей дворников и омывателя лобового стекла для Mitsubishi Endeavor XLS 2004

Электросхема передних стеклоочистителей дворников и омывателя лобового стекла для Mitsubishi Endeavor XLS 2004 - Список элементов:

52

(hi)
(int)
(lo)
(mist)
A11x
A12x
All times
C211
C214
C218
C219
Circuit breaker
Column ecu
Column switch
Computer data lines system
Connector 1
Engine compartment relay box (left side of engine compartment)
Engine compartment relay box (left side of engine compt)
Etacs ecu
Fast
Front ecu
Fuse 20 7.5a
Fuse 22 15a
Fuse 23 10a
Fuse 23 7.5a
Fuse 25 30a
G1 (right side of engine compt)
G12 (late production) (left front of engine compt)
G13 (early production) (near engine compt relay box)
G7 (behind instrument cluster)
G8 (behind lower center of dash)
Gnd
Ground
Hot at
Hot in acc or on
Hot in on
Joint
Joint connector 2
Joint connector 3
Junction block (left side of dash)
Off
Or start
Pnk
Slow
Variable intermittent wiper control switch
Washer relay
Wind- shield washer switch
Wind- shield wiper switch
Windshield washer motor (in washer tank assembly)
Windshield wiper motor (on left side of firewall)
Wiper auto- matic stop relay
Wiper speed switching relay

Электросхема заднего стеклоочистителя и омывателя стекла для Mitsubishi Endeavor XLS 2004

Электросхема заднего стеклоочистителя и омывателя стекла для Mitsubishi Endeavor XLS 2004 - Список элементов:

39

A12x
All times
C204
C211
C214
C217
C218
C219
Column ecu
Column switch
Computer data lines system
Contact connector (above license plate light)
Engine compartment relay box (left side of engine compartment)
Etacs ecu
Front ecu (on engine compt, relay box)
Fuse 11 15a
Fuse 22 15a
Fuse 23 10a
Fuse 23 7.5a
G12 (late production) (left front of engine compt)
G13 (early production) (near engine compt relay box)
G7 (behind instrument cluster)
G8 (behind lower center of dash)
G9 (center of liftgate)
Ground
Hot at
Hot in acc
Hot in on
Joint connector 3
Junction block (left end of dash)
Nca
Nca nca
Off
Or on
Or start
Rear washer motor
Rear washer switch
Rear wiper motor
Rear wiper switch

ЦЕНТРАЛЬНЫЙ ЗАМОК

Электросхема центрального замка для Mitsubishi Endeavor XLS 2004

Электросхема центрального замка для Mitsubishi Endeavor XLS 2004 - Список элементов:

56

(behind instrument cluster) g7
(behind lower center of dash) g8
(center of liftgate) g9
(early production)
(late production)
(rear of right front door) right front door lock actuator
C204
C205
C211
C214
C217
C218
C219
Computer data lines system
Contact connector 13
Door lock key cylinder switch
Engine compartment relay box (left side of engine compt)
Etacs ecu
Exterior lights system
Front power window sub switch
Fuse 10 15a
Fuse 11 15a
Fuse 14 10a
Fuse 22 15a
Fuse 23 10a
Fuse 23 7.5a
G8 (behind lower center of dash)
G9 (center of liftgate)
Horns system
Hot at all times
Hot in acc or on
Hot in on or acc
Hot in on or start
Interior lights system
Joint connector 1
Junction block (left end of dash)
Key reminder switch
Latch switch
Left front door lock actuator (rear of left front door)
Left front door switch
Left rear door lock actuator (rear of left rear door)
Liftgate
Liftgate & liftgate glass hatch actuator (lower center of liftgate)
Liftgate glass hatch latch switch
Liftgate glass hatch opener switch
Liftgate opener switch
Lock
Nca
Pnk
Power distribution system
Power window main switch
Red
Right front door switch
Right rear door lock actuator (rear of right rear door)
Right rear door switch
Unlock
