АНТЕННА ПИТАНИЯ БАГАЖНИК ЗАДНЯЯ ДВЕРЬ ЛЮЧОК ТОПЛИВНОГО БАКА Звуковой сигнал Гудок Магнитола Мультимедия Подогрев стекол и зеркал ПРИВОД ЗЕРКАЛ ПРИВОД СТЕКЛОПОДЪЕМНИКОВ СИСТЕМА ОХЛАЖДЕНИЯ СИСТЕМЫ СИДЕНИЙ Стартер Генератор Стеклоочистители и Стеклоомыватели Дворники ЦЕНТРАЛЬНЫЙ ЗАМОК
АНТЕННА ПИТАНИЯ Электросхема антенны для Pontiac Grand Prix SE 1990 Электросхема антенны для Pontiac Grand Prix SE 1990 - Список элементов: 17 30a Antenna Antenna coax lead Antenna motor Antenna relay (in fender, behind right rear wheelhouse) C c Component center Down switch G300 (1993) (under left front seat) G301 (1988-92) (under right front seat) Hot at all times Nca Pnk Pwr acc circuit breaker Radio Radio on output Up switch
БАГАЖНИК ЗАДНЯЯ ДВЕРЬ ЛЮЧОК ТОПЛИВНОГО БАКА Электросхема открывания багажника для Pontiac Grand Prix SE 1990 Электросхема открывания багажника для Pontiac Grand Prix SE 1990 - Список элементов: 12 1995 vftc c Door locks system (keyless entry) Door locks system (keyless entry) (cutlass supreme) Hot at all times (grand prix, lumina, regal) Hot in run (cutlass supreme) Luggage compt release fuse 15a Release solenoid Release switch Rs electrical center (in engine compartment, front of right strut tower) Transaxle position switch W/ automatic transaxle W/ manual transaxle
Звуковой сигнал Гудок Электросхема звукового сигнал Гудка для Pontiac Grand Prix SE 1990 Электросхема звукового сигнал Гудка для Pontiac Grand Prix SE 1990 - Список элементов: 10 Forward light electrical center (right side of engine compt) Fuse block (right side of i/p) G108 (left radiator support) Horn (front left side of engine compt) Horn fuse 15a Horn relay Horn switch Hot at all times Slip ring Steering wheel
Магнитола Мультимедия Электросхемы магнитолы, С Спикеры U66, С Кассета или CD-плеер для Pontiac Grand Prix SE 1990 Электросхемы магнитолы, С Спикеры U66, С Кассета или CD-плеер для Pontiac Grand Prix SE 1990 - Список элементов: 78 Acc b+ in Antenna Antenna input Assembly line diagnostic link connector (on bottom of i/p, right of steering column) Bat Bat power Bat pwr in Bat pwr input Bat pwr output Battery pwr in Cancel cam assembly (under steering wheel hub) Cassette/ equalizer/ compact disc player Coaxial cable Data bus Data gnd out Data ground Data in Data line Data out Dataline Elec fuse 2 15a Fuse block (right side of i/p, in i/p compartment) G129 (vin r) (left front of engine, on transaxle stud) (vin w) (on engine stud, front of transaxle assembly) G202 (behind left side of i/p, on right side of brake pedal support) Ground Ground in Heater and a/c control assembly Hot at all times Hot in accy or run Ignition input Illumination Interior lights system Left front speaker Left rear speaker Lights on Lights on in Lights on input Lights on out Lt audio input Lt audio out Lt front spkr Lt rear spkr Memory pwr Mute input Mute output Nca On output Panel light Pnk Power antenna system Radio Radio control head Radio fuse 1 10a Radio on in Radio on out Radio pwr in Receivers Right front speaker Right rear speaker Rt audio input Rt audio out Rt front spkr Rt rear spkr Spring loaded Steering wheel control head switch and electronics module Tan Tape on input Tape on out Translator module Transmitters Turn signal switch Vcc +5 Vf dim in Vf dim input Vf dim out Vf dim signal W/ trip computer W/o trip computer Электросхемы магнитолы, С Спикеры U66, без Кассета или CD-плеер для Pontiac Grand Prix SE 1990 Электросхемы магнитолы, С Спикеры U66, без Кассета или CD-плеер для Pontiac Grand Prix SE 1990 - Список элементов: 62 Acc b+ in Antenna Antenna input Assembly line diagnostic link connector (on bottom of i/p, right of steering column) Bat Bat power Bat pwr input Bat pwr out Battery pwr in Cancel cam assembly (under steering wheel hub) Coaxial cable Data bus Data gnd out Data ground Data in Data line Data out Elec fuse 2 15a Fuse block (right side of i/p, in i/p compartment) G129 (vin r) (left front of engine, on transaxle stud) (vin w) (on engine stud, front of transaxle assembly) G202 (behind left side of i/p, on right side of brake pedal support) Ground Ground in Heater and a/c control assembly Hot at all times Hot in accy or run Ignition input Illumination Interior lights system Left front speaker Left rear speaker Lights on in Lights on input Lights on out Lt front spkr Lt rear spkr Nca On output Panel light Pnk Power antenna system Radio Radio control head Radio fuse 1 10a Radio on out Radio pwr in Receivers Right front speaker Right rear speaker Rt front spkr Rt rear spkr Spring loaded Steering wheel control head switch and electronics module Tan Translator module Transmitters Turn signal switch Vcc +5 Vf dim input Vf dim out W/ trip computer W/o trip computer Электросхемы магнитолы, С Спикеры UW4, С Кассета или CD-плеер для Pontiac Grand Prix SE 1990 Электросхемы магнитолы, С Спикеры UW4, С Кассета или CD-плеер для Pontiac Grand Prix SE 1990 - Список элементов: 91 Acc b+ in Amplifier Amplifier switch Antenna Antenna input Assembly line diagnostic link connector (on bottom of i/p, right of steering column) Bat Bat power Bat pwr in Bat pwr input Bat pwr output Battery pwr in Cancel cam assembly (under steering wheel hub) Cassette/ equalizer Coaxial cable Data bus Data gnd out Data ground Data in Data line Data out Dataline Elec fuse 2 15a Fuse block (right side of i/p, in i/p compartment) G129 (vin r) (left front of engine, on transaxle stud) (vin w) (on engine stud, front of transaxle assembly) G202 (behind left side of i/p, on right side of brake pedal support) G300 (under left front seat) Ground Ground in Heater and a/c control assembly Hot at all times Hot in accy or run Ignition input Illumination Interior lights system Left front door speaker Left front speaker Left rear speaker Lf front in Lights on Lights on in Lights on input Lights on out Lt audio input Lt audio out Lt front in Lt front out Lt front spkr Lt rear spkr Memory pwr Mute in Mute input Mute output Nca Off On output Panel light Pnk Power antenna system Radio Radio control head Radio fuse 1 10a Radio on in Radio on input Radio on out Radio pwr in Receivers Right front door speaker Right front speaker Right rear speaker Rt audio input Rt audio out Rt front in Rt front out Rt front spkr Rt rear spkr Spring loaded Switch and electronics module (steering wheel control head) Tan Tape on input Tape on out Translator module Transmitters Turn signal switch (in steering column, below steering wheel) Vcc +5 Vf dim in Vf dim input Vf dim out Vf dim signal W/ trip computer W/o trip computer Электросхемы магнитолы, С Спикеры UW4, без Кассета или CD-плеер для Pontiac Grand Prix SE 1990 Электросхемы магнитолы, С Спикеры UW4, без Кассета или CD-плеер для Pontiac Grand Prix SE 1990 - Список элементов: 75 Acc b+ in Amplifier Amplifier switch Antenna Antenna input Bat Bat power Bat pwr input Bat pwr out Battery pwr in Cancel cam assembly (under steering wheel hub) Coaxial cable Data bus Data gnd out Data ground Data in Data line Data out Elec fuse 2 15a Fuse block (right side of i/p, in i/p compartment) G129 (vin r) (left front of engine, on transaxle stud) (vin w) on engine stud, front of transaxle assembly) G202 (behind left side of i/p, on right side of brake pedal support) G300 (under left front seat) Ground Ground in Heater and a/c control assembly Hot at all times Hot in accy or run Ignition input Illumination Interior lights system J assembly line diagnostic link connector (on bottom of i/p, right of steering column) Left front door speaker Left front speaker Left rear speaker Lf front in Lights on in Lights on input Lights on out Lt front in Lt front out Lt front spkr Lt rear spkr Mute in Nca Off On output Panel light Pnk Power antenna system Radio Radio control head Radio fuse 1 10a Radio on input Radio on out Radio pwr in Receivers Right front door speaker Right front speaker Right rear speaker Rt front in Rt front out Rt front spkr Rt rear spkr Spring loaded Steering wheel control head switch and electronics module Tan Translator module Transmitters Turn signal switch Vcc +5 Vf dim input Vf dim out W/ trip computer W/o trip computer
Подогрев стекол и зеркал Электросхема подогрева стекол и зеркал для Pontiac Grand Prix SE 1990 Электросхема подогрева стекол и зеркал для Pontiac Grand Prix SE 1990 - Список элементов: 36 ('91-'93 w/ c68) (1990 regal & cut supreme) (1990-92) (1993) (all others) (c67) (c67) (c68) (c68) (c67) 1990-91 1990-92 1992-93 C1 c1 C1 c3 C3 c1 Clust fuse 10a Component center (right side of i/p) Defogger switch Fuse block (right side of i/p) G102 (left strut tower) G110 (lower left front of eng) G205 (right side of steering column bracket) G300 (under left front seat) G301 (under right front seat) Heater & a/c control assembly Hot at all times Hot in run Hot in run, bulb test or start Illum Indic fuse 10a Interior lights system Nca On ind Rear defog circuit breaker 30a Rear defogger Rear defogger timer relay (in component center) Timer
ПРИВОД ЗЕРКАЛ Электросхема привода зеркал для Pontiac Grand Prix SE 1990 Электросхема привода зеркал для Pontiac Grand Prix SE 1990 - Список элементов: 15 Ctsy fuse 15a Drive unit Fuse block G300 (below left front seat) Hot at all times J/c c200 (behind right side of i/p) Left outside mirror Left- right m Mirror position switch Mirror select switch Motor Nca Outside mirror control switch Right outside mirror Up- down m
ПРИВОД СТЕКЛОПОДЪЕМНИКОВ Электросхема стеклоподъемников, Купе для Pontiac Grand Prix SE 1990 Электросхема стеклоподъемников, Купе для Pontiac Grand Prix SE 1990 - Список элементов: 18 (under left front seat) g300 Component center Down Express down Express down module Hot in run Illumination Interior lights system Led Left front Left front window motor Left master switch Pnk Power windows circuit breaker 30a Right front Right front window motor Right front window switch Tan Электросхема стеклоподъемников, седан для Pontiac Grand Prix SE 1990 Электросхема стеклоподъемников, седан для Pontiac Grand Prix SE 1990 - Список элементов: 24 (under left front seat) g300 1991-93 ste Component center Express down Express down module G300 (under left front seat) Hot in run Interior lights system Led Left front window Left front window motor Left master switch Left rear window Left rear window motor Left rear window switch Pnk Power windows circuit breaker 30a Right front window Right front window motor Right front window switch Right rear window Right rear window motor Right rear window switch Tan
СИСТЕМА ОХЛАЖДЕНИЯ
2.3L 2.3L (VIN D), Электросхема системы охлаждения для Pontiac Grand Prix SE 1990 2.3L (VIN D), Электросхема системы охлаждения для Pontiac Grand Prix SE 1990 - Список элементов: 22 A/c pressure transducer (top left side of engine) C10 C16 C21 Coolant temperature sensor (left side of engine) Electronic control module (right front engine compt) Engine controls system Fusible element e 30a (grand prix) Fusible element g 60a (grand prix) Fusible element l 60a (cutlass supreme) Fusible element n 30a (cutlass supreme) G125 (cutlass supreme) (below starter assembly) G133 (grand prix) (below exhaust manifold) Hot at all times Hot in run, bulb test or start Ign fuse 10a Primary coolant fan relay Primary cooling fan motor Red Right side electrical center (right side of engine compt) Secondary coolant fan relay Secondary cooling fan motor
3.1L 3.1L (VIN T), Электросхема системы охлаждения для Pontiac Grand Prix SE 1990 3.1L (VIN T), Электросхема системы охлаждения для Pontiac Grand Prix SE 1990 - Список элементов: 23 (below exhaust manifold) g133 (grand prix) (cutlass supreme) A/c intermediate pressure sensor (left front engine compt, on accumulator) B20 C10 C16 Coolant temperature sensor (left front of engine) D21 Engine control module (right front engine compt) Engine controls system Fusible element e element n 30a Fusible element g element l 60a G108 (cutlass supreme) (left radiator support) G133 (grand prix) (below exhaust manifold) Hot at all times Hot in run Ign fuse 10a 15a Primary coolant fan relay Primary cooling fan Red Right side electrical center (right side of engine compt) Secondary coolant fan relay Secondary cooling fan
СИСТЕМЫ СИДЕНИЙ Электросхема привода сидений с 6 путями для Pontiac Grand Prix SE 1990 Электросхема привода сидений с 6 путями для Pontiac Grand Prix SE 1990 - Список элементов: 20 (below left Back Breaker 30a Component center Down Entire seat Front height Front height motor Front seat) Fwd Fwd/ back motor G300 Hot at all times Left front seat Left seat switch Pwr/acc circuit Rear height Rear height motor Tan Tan a Электросхема регулировки поясницы для Pontiac Grand Prix SE 1990 Электросхема регулировки поясницы для Pontiac Grand Prix SE 1990 - Список элементов: 37 15a 1995 vftc c 30a Ctsy fuse Cushion Cushions Def Deflate relay Driver's seat solenoid valve assembly Fuse block G110 (left front of engine) G300 (under left front seat) Headrest Hot at all times Illumination Inf Inflate relay Interior lights system Left thigh Lower lumbar Lt thigh Lumbar seat switch Middle lumbar Nca Off Passenger's seat solenoid valve assembly Pnk Pressure cut-out relay Pressure cut-out switch Pwr acc circuit breaker Right thigh Rt thigh Seat air pump assembly (under left front seat) Seat control module (under left front seat) Seat select switch Tan Upper lumbar
Стартер Генератор Электросхема Генератора для Pontiac Grand Prix SE 1990 Электросхема Генератора для Pontiac Grand Prix SE 1990 - Список элементов: 25 1991-92 gauges cluster 1991-93 All other gauges clusters Alt fuse 10a (1990) Base cluster Battery Charge ind Check gauges ind Fuse block (right side of dash) Fusible link (10 ga rust) Fusible link (12 ga rust) Fusible link (20 ga rust) G108 (left front radiator support) G110 (left front of engine) Generator Hot in run Hot in run, bulb test or start Ign fuse 15a (1991-93) Ind control Indic fuse 10a Instrument cluster Red Right side electrical center (1991-93 3.4l) (ride side of engine compt) Right side electrical center (right side of engine compt) Starter assembly Электросхема стартера для Pontiac Grand Prix SE 1990 Электросхема стартера для Pontiac Grand Prix SE 1990 - Список элементов: 18 A/t Acc Battery Bulb test Clutch switch (on brake pedal support) G108 (left front radiator support) G110 (left front of engine) Hot at all times Ignition switch Lock M/t Off Power distribution system Run Start Starter motor Starter solenoid Transaxle position switch (left of engine, on transaxle)
Стеклоочистители и Стеклоомыватели Дворники Электросхема стеклоочистителя, дворников и омывателя С 2 скоростями для Pontiac Grand Prix SE 1990 Электросхема стеклоочистителя, дворников и омывателя С 2 скоростями для Pontiac Grand Prix SE 1990 - Список элементов: 20 (1990-91) (1990-92) (1992-93) (1993) Fuse block G106 (left front of eng compt) G110 (left front of engine) Hot in accy or run Mechanical arm Mist Off Park switch Pnk Red Washer pump motor Washer switch Wiper fuse 25a Wiper motor module Wiper switch Wiper/ washer switch Электросхема стеклоочистителя, дворников и омывателя Интервала для Pontiac Grand Prix SE 1990 Электросхема стеклоочистителя, дворников и омывателя Интервала для Pontiac Grand Prix SE 1990 - Список элементов: 27 (1990) (1990-92) (1991-93) (1993) (left front of eng compt) g106 (left front of engine) g110 Fuse block Hot in accy or run M r Mechanical arm Mist O l Off P k Park switch Pnk Pulse Pulse delay Q p Red Timer Washer pump motor Washer switch Wiper fuse 25a Wiper motor module Wiper switch Wiper/ washer switch
ЦЕНТРАЛЬНЫЙ ЗАМОК Электросхема центрального замка, С Вход Без ключа для Pontiac Grand Prix SE 1990 Электросхема центрального замка, С Вход Без ключа для Pontiac Grand Prix SE 1990 - Список элементов: 44 (buick & olds) (olds & buick) (or tan) (pont) A/t Antenna Battery Component center (right side of i/p) Ctsy fuse 15a Data encoder Data encoder connector (right side of luggage compt) Fuse block (right side of i/p) G202 (left side of i/p) G300 (under left front seat) G300 (under left g202 front seat) (left side of i/p) Ground Hot at all times Interior lights system Keyless entry module (olds: on top of right rear shelf; pont: right rear of luggage compt, on rear window panel; buick: right front of luggage compt, on rear shelf) Left front door lock motor Left master switch assembly or left door lock switch Left rear door lock motor (4 door) Lock Lock all doors Lock relay Lug compt rlse Luggage compt release fuse 15a M/t Park input Power acc circuit breaker 30a Power door lock relay (right shroud, above center access hole) Right front door lock motor Right rear door lock motor (4 door) Right switch assembly or right door lock switch Rs electrical center (right side of engine compartment) Tan Transaxle position switch (left of transaxle) Transmitter input Trunk lid release solenoid Trunk lid release switch Unlck drvr door Unlk pass door Unlock Unlock relay Электросхема центрального замка, без Вход Без ключа для Pontiac Grand Prix SE 1990 Электросхема центрального замка, без Вход Без ключа для Pontiac Grand Prix SE 1990 - Список элементов: 25 (olds & buick) (pontiac) Component center (right side of i/p) Ctsy fuse 14 15a Fuse block (right side of i/p) G202 (left side of i/p) G300 (under left front seat) Hot at all times Hot in run Left door lock motor Left door lock switch (olds only) Left master switch assembly or left door lock switch Left rear door lock motor (4 door) Lock Lock relay Pnk Power door lock relay (right shroud, above center access hole) Pwr acc circuit breaker 30a Pwr window circuit breaker (olds only) 30a Right door lock motor Right rear door lock motor (4 door) Right switch assembly or right door lock switch Unlock Unlock indicator (olds only) Unlock relay
