Разделы схем — 11 (всего 14)
БАГАЖНИК ЗАДНЯЯ ДВЕРЬ ЛЮЧОК ТОПЛИВНОГО БАКА Звуковой сигнал Гудок Магнитола Мультимедия Подогрев стекол и зеркал ПРИВОД ЗЕРКАЛ ПРИВОД СТЕКЛОПОДЪЕМНИКОВ СИСТЕМА ОХЛАЖДЕНИЯ СИСТЕМЫ СИДЕНИЙ Стартер Генератор Стеклоочистители и Стеклоомыватели Дворники ЦЕНТРАЛЬНЫЙ ЗАМОК
БАГАЖНИК ЗАДНЯЯ ДВЕРЬ ЛЮЧОК ТОПЛИВНОГО БАКА Электросхема привода багажника и лючка топливного бака для Porsche 944 S2 1991 Электросхема привода багажника и лючка топливного бака для Porsche 944 S2 1991 - Список элементов: 14 (1988) (1989-91) Alarm control unit Central electric (left rear side of engine compt) Fuse 1 25a G406 (1988) (on trunk lid) Hot at all times J35 Nca Red Tailgate unlock motor Tailgate unlock switch Tailgate unlocking switch W/o alarm
Звуковой сигнал Гудок Электросхема звукового сигнал Гудка для Porsche 944 S2 1991 Электросхема звукового сигнал Гудка для Porsche 944 S2 1991 - Список элементов: 18 (left front side of engine compartment, on longitudinal support) g100 Central electric (left rear corner of engine compartment) Contact unit (on steering wheel) Fuse 3 15a Horn 1 (left front mudguard) Horn 2 (left front mudguard) Horn contact Horn switch Hot at all times Hot in run or start L35 N24 Sliding contact Steering wheel Two tone horn relay W/airbag W/o airbag Wiper/ washer switch
Магнитола Мультимедия Электросхемы магнитолы для Porsche 944 S2 1991 Электросхемы магнитолы для Porsche 944 S2 1991 - Список элементов: 23 Antenna Antenna amplifier (right side footwell) Central electric (left rear of engine compartment) Clock Deep range speaker Deep range speaker w/ frequency switch Equalizer Front left speaker assembly Front right speaker assembly Fuse 15a G116 (left side of safety wall) G13 High range speaker Hot at all times Hot in accy, run or start L13 Middle range speaker Nca Not used Radio Rear left speaker assembly Rear right speaker assembly Red Электросхемы магнитолы, без Уравнитель для Porsche 944 S2 1991 Электросхемы магнитолы, без Уравнитель для Porsche 944 S2 1991 - Список элементов: 15 Antenna Antenna amplifier (right side footwell) Central electric (left rear of engine compartment) Front left speaker Front right speaker Fuse 15a G116 (left side of safety wall) Hot at all times Hot in accy, run or start Nca Not used Radio Rear left speaker Rear right speaker Red
Подогрев стекол и зеркал Электросхема подогрева стекол и зеркал для Porsche 944 S2 1991 Электросхема подогрева стекол и зеркал для Porsche 944 S2 1991 - Список элементов: 26 (left front side of luggage compartment) g400 (left side of safety wall) g116 Central electric (left of washer reservoir) D13 D32 Driver's side mirror Fuse 13 30a Fuse 28 30a Fuse test Hot at all times Hot in acc or run Individual gas pressure prop lead Interior lights system Interior lights system, anti- theft system L21 L22 L23 L43 Left gas pressure prop Nca Passenger's side mirror Rear window defogger Rear window defogger relay Rear window defogger switch Right gas pressure prop Wiper/washer system (rear wiper washer switch)
ПРИВОД ЗЕРКАЛ Электросхема привода зеркал для Porsche 944 S2 1991 Электросхема привода зеркал для Porsche 944 S2 1991 - Список элементов: 14 Central electric (left rear corner of engine compartment) Change- over switch Driver's side mirror Fuse 28 30a G116 (left side of engine compartment, inside safety wall) G407 (center rear of luggage compartment, behind cover panel) Hot in acc or run L21 L22 L44 Mirror switch Passenger's side mirror Rear window defogger relay Wiper/washer system (rear window wiper motor)
ПРИВОД СТЕКЛОПОДЪЕМНИКОВ Электросхема стеклоподъемников для Porsche 944 S2 1991 Электросхема стеклоподъемников для Porsche 944 S2 1991 - Список элементов: 22 (1985-90) 85h Central electric (left rear engine compt) D32 Driver's power window motor Driver's switch (driver's window) Driver's switch (passenger's window) Fuse 4 30a G104 (rear of left front fender) G407 (center rear of trunk) Hot at all times Hot in acc and run Junction connector K45 L33 Left door contact Luggage compt light switch Passenger's power window motor Passenger's switch (passenger's window) Power window relay Right door contact Solid state
СИСТЕМА ОХЛАЖДЕНИЯ Электросхема системы охлаждения для Porsche 944 S2 1991 Электросхема системы охлаждения для Porsche 944 S2 1991 - Список элементов: 29 30m1 30m2 944 turbo Central electric (left in water box) Coolant temperature switch Coolant temperature switch (left side of radiator) F22 Fan motor 1 (on radiator) Fan motor 2 (on radiator) Fuse 24 30a Fuse 25a G100 (longi- tudinal support) G100 (longitudinal support) H12 Hot at all times Hot in accy or run Intake pipe cooling switch (1989-1991) J42 L32 N22 N23 N33 N34 N35 O21 O23 O33 Radiator relay Resistor
СИСТЕМЫ СИДЕНИЙ Электросхема привода сидений для Porsche 944 S2 1991 Электросхема привода сидений для Porsche 944 S2 1991 - Список элементов: 29 (left seat) (left seat) j13 k34 (left seat) j34 j25 (right seat) (right seat) 4-way seat switch 1 4-way seat switch 2 4-way seat switch 3 Backrest heating element Central electric (right rear side of luggage compartment) Comfort seat Front seat cushion height control Fuse 25 25a Fuse 6 30a G116 (left side of safety wall) Hot at all times Hot in acc or run Lumbar curve control Lumbar height control Nca Rear seat cushion height control Red Seat back forward control Seat backrest control Seat cushion heating element Seat heater delaying relay Seat heater switch Side pad heating element Solid state
Стартер Генератор Электросхема Генератора для Porsche 944 S2 1991 Электросхема Генератора для Porsche 944 S2 1991 - Список элементов: 23 1989-91 Acc Alarm control unit Alternator Battery Central electric (left rear side of engine compt) Charge indicator D44 G123 (right side of safety wall) G129 (on transmission/ transaxle) G23 Hot at all times Ignition switch Instrument cluster K13 Nca Off Power distribution system Red Start Starter W/ alarm (1988) W/o alarm (1988) Электросхема стартера для Porsche 944 S2 1991 Электросхема стартера для Porsche 944 S2 1991 - Список элементов: 19 15a A/t Acc Battery Central electric (left rear side of engine compt) Charging system E25 G123 (right side of safety wall) G129 (on transmission/ transaxle) G25 Hot at all times Ignition switch M/t Off Power distribution system Red Start Starter Starter interlock switch
Стеклоочистители и Стеклоомыватели Дворники Передняя Схема Шайбы Дворника/Шайбы и Фары для Porsche 944 S2 1991 Передняя Схема Шайбы Дворника/Шайбы и Фары для Porsche 944 S2 1991 - Список элементов: 43 (left side of safety wall) g116 (right front side of engine compartment, on longitudinal support) g101 1985,86 only 1a o 53m 53s 53a 53b 53c 53e 53f Central electric (left rear corner of engine compartment, left in water box) Cooling fans system D32 E23 Fuse 24 30a Headlight cleaner pump Headlight cleaner relay Headlights system Heated spray jet Hot at all times Hot in acc or run Iii Intermittent wiping control Interv. K25 L31 L32 M12 M21 M24 M25 M35 M43 M44 N25 N42 Red Right steering column switch (wipe/wash switch) Solid state Washing fluid pump Wiper intermittent control Wiper motor задняя схема дворника для Porsche 944 S2 1991 задняя схема дворника для Porsche 944 S2 1991 - Список элементов: 13 (on cover panel) g408 53a Central electric (left rear corner of engine compartment, left in water box) Defogger system Fuse 30a G116 (left side of safety wall) Ground distribution system Hot in acc or run L43 L44 Mirrors system Rear window wiper Rear window wiper switch
ЦЕНТРАЛЬНЫЙ ЗАМОК Электросхема центрального замка для Porsche 944 S2 1991 Электросхема центрального замка для Porsche 944 S2 1991 - Список элементов: 22 Central alarm locking control unit (in passengers footwell) Central electric (right rear of engine compt) Central lock button Central lock. button Driver's side driver motor Driver's side lock cylinder G104 (rear of left front fender) G22 G407 (center rear of trunk) Hot at all times Interior lights system Lamp button Lifting roof relay Limit switch close Limit switch open Motor close Motor open Passenger's side drive motor Passenger's side lock cylinder Power Prime alarm system Unprime alarm system
