Connector | Pin | Terminal | Equipment H | Equipment M |
A | 1 | Supply (30), right lights | x | x |
A | 2 | Right dipped beam signal output | x | x |
A | 3 | Right main beam signal output | x | x |
A | 4 | Right fog light signal output | x | - |
A | 5 | Signal output for the activation of the gas discharge headlights on the right | x | - |
A | 6 | Signal output for front right turn signal | x | x |
A | 7 | Front left side light signal output | x | x |
A | 8 | Signal output for left side repeater turn signal | x | x |
A | 9 | Signal output for left side repeater turn signal | x | x |
A | 10 | Fuel pump relay signal output | x | x |
A | 11 | Voltage supply relay (50) signal output | x | x |
B | 1 | Right reversing light signal output | x | x |
B | 2 | | - | - |
B | 3 | | - | - |
B | 4 | Signal output for rear left fog light | x | x |
B | 5 | Signal output for rear left fog light | x | x |
B | 6 | | - | - |
B | 7 | Footwell light signal output | x | x |
B | 8 | | - | - |
B | 9 | Right tail light signal output | x | x |
B | 10 | Signal output for rear right turn signal | x | x |
B | 11 | Interior lighting signal output, door contact switch | x | x |
B | 12 | Illumination - switches and instruments (58d) signal output | x | x |
C | 1 | Signal output for switching heated seat off | x | x |
C | 2 | Left brake and tail light signal output | x | x |
C | 3 | Signal output for rear right fog light | x | x |
C | 4 | | - | - |
C | 5 | Left seat backrest switch signal input | x | x |
C | 6 | Right seat backrest switch signal input | x | x |
C | 7 | | - | - |
C | 8 | Number plate light signal output | x | x |
C | 9 | High level brake light signal output | x | x |
C | 10 | Left tail light signal output | x | x |
C | 11 | Left tail light signal output | x | x |
C | 12 | Left reversing light signal output | x | x |
D | 1 | Supply (30), left lights | x | x |
D | 2 | Left fog light signal output | x | - |
D | 3 | Left main beam signal output | x | x |
D | 4 | Left dipped beam signal output | x | x |
D | 5 | Signal earth (31), right lights | x | x |
D | 6 | Signal output for the activation of the gas discharge headlights on the left | x | - |
D | 7 | Supply (15) output signal, engine relay | x | x |
D | 8 | Headlight washer system relay signal output | x | x |
D | 9 | Signal output for right side repeater turn signal | x | x |
D | 10 | Front right side light signal output | x | x |
D | 11 | Signal output for front left turn signal | x | x |
E | 1 | Side light switch signal input | x | x |
E | 2 | Brake light switch signal input | x | x |
E | 3 | Come-Home potentiometer earth | x | x |
E | 4 | Come-Home potentiometer supply | x | x |
E | 5 | | - | - |
E | 6 | Fog light switch signal input | x | - |
E | 7 | Selector lever lock P/N signal input | x | x |
E | 8 | Dipped beam switch input signal | x | x |
E | 9 | | - | - |
E | 10 | | - | - |
E | 11 | | - | - |
E | 12 | Come-Home potentiometer input signal | x | x |
E | 13 | Rear fog light switch signal input | x | x |
E | 14 | Automatic driving lights switch signal input | x | x |
E | 15 | | - | - |
E | 16 | Light switch position "0" signal input | x | x |
F | 1 | Signal input (50), diagnosis | x | x |
F | 2 | Signal input (15), diagnosis engine | x | x |
F | 3 | LIN-Bus | x | x |
F | 4 | Signal (L) alternator | x | x |
F | 5 | Bonnet switch input signal | x | x |
F | 6 | Reversing light switch signal input | x | x |
F | 7 | Input signal for reference voltage (30) | x | x |
F | 8 | Input signal for earth - reference voltage (31) | x | x |
G | 1 | Voltage supply signal input (50) for ignition/starter switch | x | x |
G | 2 | Hazard warning light system warning lamp signal output | x | x |
G | 3 | Heated rear window warning lamp signal output | x | x |
G | 4 | Signal earth for illumination regulators - switches and instruments (31) | x | x |
G | 5 | | - | - |
G | 6 | Heated rear window button input signal | x | x |
G | 7 | Convenience CAN-L | x | x |
G | 8 | Convenience CAN-H | x | x |
G | 9 | Hazard warning light switch signal input | x | x |
G | 10 | Supply for switches and instruments illumination regulator | x | x |
G | 11 | Voltage supply signal input (15) for ignition/starter switch | x | x |
G | 12 | Switches and instruments illumination regulator signal input | x | x |
H | 1 | | - | - |
H | 2 | | - | - |
H | 3 | | - | - |
H | 4 | | - | - |
H | 5 | | - | - |
H | 6 | | - | - |
H | 7 | | - | - |
H | 8 | | - | - |
H | 9 | | - | - |
H | 10 | | - | - |
H | 11 | | - | - |
H | 12 | | - | - |
I | 1 | Supply (75a) input | x | x |
I | 2 | Supply (75x) output | x | x |
J | 1 | Washer pump supply input | x | x |
J | 2 | Washer pump motor and rear window wiper motor signal output | x | x |
J | 3 | Horn supply input | x | x |
J | 4 | Washer pump motor and rear window wiper motor signal output | x | x |
J | 5 | Washer pump earth (31) | x | x |
J | 6 | Horn signal output | x | x |
K | 1 | Heated rear window signal output | x | x |
K | 2 | | - | - |
K | 3 | | - | - |
K | 4 | | - | - |
K | 5 | Supply input (30G) | x | x |
K | 6 | Heated rear window supply input | x | x |
K | 7 | | - | - |
K | 8 | | - | - |
K | 9 | | - | - |
K | 10 | Supply output (30G) | x | x |
L | 1 | Interior supply input (15) | x | x |
L | 2 | Interior supply output (15) | x | x |
Connector | Pin | Terminal | Equipment H | Equipment M |
A | 1 | Supply (30), right lights | x | x |
A | 2 | Right dipped beam signal output | x | x |
A | 3 | Right main beam signal output | x | x |
A | 4 | Right fog light signal output | x | - |
A | 5 | Signal output for the activation of the gas discharge headlights on the right | x | - |
A | 6 | Signal output for front right turn signal | x | x |
A | 7 | Front left side light signal output | x | x |
A | 8 | Signal output for left side repeater turn signal | x | x |
A | 9 | Signal earth (31), left lights | x | x |
A | 10 | Fuel pump relay signal output | x | x |
A | 11 | Voltage supply relay (50) signal output | x | x |
B | 1 | Right reversing light signal output | x | x |
B | 2 | | - | - |
B | 3 | | - | - |
B | 4 | Signal output for rear left fog light | x | x |
B | 5 | Right brake and tail light signal output (Altea XL and Freetrack) | x | x |
B | 6 | | - | - |
B | 7 | Footwell light signal output | x | x |
B | 8 | | - | - |
B | 9 | Right brake and tail light signal output (Altea and Toledo), right tail light signal output (Altea XL and Freetrack) | x | x |
B | 10 | Signal output for rear right turn signal | x | x |
B | 11 | Interior lighting signal output, door contact switch | x | x |
B | 12 | Illumination - switches and instruments (58d) signal output | x | x |
C | 1 | Signal output for switching heated seat off | x | x |
C | 2 | Left brake and tail light signal output (Altea XL and Freetrack) | x | x |
C | 3 | Signal output for rear right fog light | x | x |
C | 4 | | - | - |
C | 5 | Left seat backrest switch signal input | x | x |
C | 6 | Right seat backrest switch signal input | x | x |
C | 7 | | - | - |
C | 8 | Number plate light signal output | x | x |
C | 9 | High level brake light signal output | x | x |
C | 10 | Left brake and tail light signal output (Altea and Toledo), left tail light signal output (Altea XL and Freetrack) | x | x |
C | 11 | Left tail light signal output | x | x |
C | 12 | Left reversing light signal output | x | x |
D | 1 | Supply (30), left lights | x | x |
D | 2 | Left fog light signal output | x | - |
D | 3 | Left main beam signal output | x | x |
D | 4 | Left dipped beam signal output | x | x |
D | 5 | Signal earth (31), right lights | x | x |
D | 6 | Signal output for the activation of the gas discharge headlights on the left | x | - |
D | 7 | Supply (15) output signal, engine relay | x | x |
D | 8 | Headlight washer system relay signal output | x | x |
D | 9 | Signal output for right side repeater turn signal | x | x |
D | 10 | Front right side light signal output | x | x |
D | 11 | Signal output for front left turn signal | x | x |
E | 1 | Side light switch signal input | x | x |
E | 2 | Brake light switch signal input | x | x |
E | 3 | Come-Home potentiometer earth | x | x |
E | 4 | Come-Home potentiometer supply | x | x |
E | 5 | | - | - |
E | 6 | Fog light switch signal input | x | - |
E | 7 | Selector lever lock P/N signal input | x | x |
E | 8 | Dipped beam switch input signal | x | x |
E | 9 | | - | - |
E | 10 | | - | - |
E | 11 | | - | - |
E | 12 | Come-Home potentiometer input signal | x | x |
E | 13 | Rear fog light switch signal input | x | x |
E | 14 | Automatic driving lights switch signal input | x | x |
E | 15 | | - | - |
E | 16 | Light switch position "0" signal input | x | x |
F | 1 | Signal input (50), diagnosis | x | x |
F | 2 | Signal input (15), diagnosis engine | x | x |
F | 3 | LIN-Bus | x | x |
F | 4 | Signal (L) alternator | x | x |
F | 5 | Bonnet switch input signal | x | x |
F | 6 | Reversing light switch signal input | x | x |
F | 7 | Input signal for reference voltage (30) | x | x |
F | 8 | Input signal for earth - reference voltage (31) | x | x |
G | 1 | Voltage supply signal input (50) for ignition/starter switch | x | x |
G | 2 | Hazard warning light system warning lamp signal output | x | x |
G | 3 | Heated rear window warning lamp signal output | x | x |
G | 4 | Signal earth for illumination regulators - switches and instruments (31) | x | x |
G | 5 | | - | - |
G | 6 | Heated rear window button input signal | x | x |
G | 7 | Convenience CAN-L | x | x |
G | 8 | Convenience CAN-H | x | x |
G | 9 | Hazard warning light switch signal input | x | x |
G | 10 | Supply for switches and instruments illumination regulator | x | x |
G | 11 | Voltage supply signal input (15) for ignition/starter switch | x | x |
G | 12 | Switches and instruments illumination regulator signal input | x | x |
H | 1 | | - | - |
H | 2 | | - | - |
H | 3 | | - | - |
H | 4 | | - | - |
H | 5 | | - | - |
H | 6 | | - | - |
H | 7 | | - | - |
H | 8 | | - | - |
H | 9 | | - | - |
H | 10 | | - | - |
H | 11 | | - | - |
H | 12 | | - | - |
I | 1 | Supply (75a) input | x | x |
I | 2 | Supply (75x) output | x | x |
J | 1 | Washer pump supply input | x | x |
J | 2 | Washer pump motor and rear window wiper motor signal output | x | x |
J | 3 | Horn supply input | x | x |
J | 4 | Washer pump motor and rear window wiper motor signal output | x | x |
J | 5 | Washer pump earth (31) | x | x |
J | 6 | Horn signal output | x | x |
K | 1 | Heated rear window signal output | x | x |
K | 2 | | - | - |
K | 3 | | - | - |
K | 4 | | - | - |
K | 5 | Supply input (30G) | x | x |
K | 6 | Heated rear window supply input | x | x |
K | 7 | | - | - |
K | 8 | | - | - |
K | 9 | | - | - |
K | 10 | Supply output (30G) | x | x |
L | 1 | Interior supply input (15) | x | x |
L | 2 | Interior supply output (15) | x | x |
No. | | Current Flow Diagram designation | Nominal value | | Function/component | Terminal |
F1 | - | Fuse 1 on fuse holder B -SB1- | 30 A | - | ABS control unit -J104- | 30 |
F2 | - | Fuse 2 on fuse holder B -SB2- | 30 A | - | ABS control unit -J104- | 30 |
F3 | - | Fuse 3 on fuse holder B -SB3- | 25 A | - | Front passenger side windscreen wiper motor -V217- | 30 |
F4 | - | Fuse 4 on fuse holder B -SB4- | 5 A | - | Onboard supply control unit -J519- | 30 |
F5 | - | Fuse 5 on fuse holder B -SB5- | 20 A | - | Treble tone horn -H2- | 30 |
| | | | | Bass tone horn -H7- | |
F6 | - | Fuse 6 on fuse holder B -SB6- | 20 A | - | Ignition transformer -N152- (BGU) | 87 |
| | | 5 A | - | Fuel metering valve -N290- (BLR and BLY) | |
F7 | - | Fuse 7 on fuse holder B -SB7- | 5 A | - | Clutch pedal switch -F36- | 87 |
| | | | | Brake pedal switch -F47- | |
F8 | - | Fuse 8 on fuse holder B -SB8- | 10 A | - | Map-controlled engine cooling system thermostat -F265- (BLR and BLY) | 87 |
| | | | | Exhaust gas recirculation valve -N18- (BGU) | |
| | | | | Activated charcoal filter system solenoid valve 1 -N80- (BGU, BLR and BLY) | |
| | | | | Variable intake manifold change-over valve -N156- (BGU, BLR and BLY) | |
| | | | | Inlet camshaft control valve 1 -N205- (BLR and BLY) | |
| | | | | Radiator fan -V7- | |
| | | | | Intake manifold flap motor -V157- (AZV, BKC and BKD) | |
F9 | - | Fuse 9 on fuse holder B -SB9- | 10 A | - | Fuel pump relay -J17- (AZV, BJB, BKC and BKD) | 87 |
| | | | | Automatic glow period control unit -J179- (AZV, BJB, BKC and BKD) | |
F10 | - | Fuse 10 on fuse holder B -SB10- | 5 A | - | Secondary air pump relay -J299- (BGU) | 87 |
| | | 10 A | - | Exhaust gas recirculation valve -N18- (AZV, BJB, BKC and BKD) | |
| | | | | Charge pressure control solenoid valve -N75- (AZV, BJB, BKC and BKD) | |
| | | | | Exhaust gas recirculation cooler change-over valve -N345- (AZV, BJB, BKC and BKD) | |
| | | | | Lambda probe 1 heater after catalytic converter -Z29- (BLR and BLY) | |
| | | | | Lambda probe 2 heater after catalytic converter -Z30- (BLR) | |
| | | | | Lambda probe 3 heater after catalytic converter -Z64- (BLR) | |
F11 | - | Fuse 11 on fuse holder B -SB11- | 30 A | - | Motronic control unit -J220- (BLR and BLY) | 87 |
| | | 25 A | - | Diesel direct injection system control unit -J248- (AZV, BJB, BKC and BKD) | |
| | | | | Simos control unit -J361- (BGU) | |
F12 | - | Fuse 12 on fuse holder B -SB12- | 15 A | - | Lambda probe heater -Z19- (BLR and BLY) | 87 |
| | | | | Lambda probe 2 heater -Z28- (BLR) | |
F13 | - | Fuse 13 on fuse holder B -SB13- | 15 A | - | Mechatronic unit for dual clutch gearbox -J743- (AZV and BKD) | 30 |
F14 | - | Fuse 14 on fuse holder B -SB14- | - | - | Vacant | |
F15 | - | Fuse 15 on fuse holder B -SB15- | - | - | Vacant | |
F16 | - | Fuse 16 on fuse holder B -SB16- | 15 A | - | Steering column electronics control unit -J527- | 30 |
F17 | - | Fuse 17 on fuse holder B -SB17- | 10 A | - | Control unit in dash panel insert -J285- | 30 |
F18 | - | Fuse 18 on fuse holder B -SB18- | - | - | Vacant | |
F19 | - | Fuse 19 on fuse holder B -SB19- | 15 A | - | Control unit with display for radio and navigation system -J503- | 30 |
| | | | | Radio -R- | |
F20 | - | Fuse 20 on fuse holder B -SB20- | 10 A | - | Mobile telephone operating electronics control unit -J412- | 30 |
| | | | | Telephone transmitter and receiver unit -R36- | |
F21 | - | Fuse 21 on fuse holder B -SB21- | - | - | Vacant | |
F22 | - | Fuse 22 on fuse holder B -SB22- | - | - | Vacant | |
F23 | - | Fuse 23 on fuse holder B -SB23- | - | - | Vacant | |
F24 | - | Fuse 24 on fuse holder B -SB24- | 10 A | - | Data bus diagnostic interface -J533- | 30 |
F25 | - | Fuse 25 on fuse holder B -SB25- | - | - | Vacant | |
F26 | - | Fuse 26 on fuse holder B -SB26- | 5 A | - | Terminal 30 voltage supply relay -J317- (AZV, BJB, BKC and BKD) | 30 |
| | | 10 A | - | Main relay -J271- (BLR and BLY) | |
F27 | - | Fuse 27 on fuse holder B -SB27- | 40 A | - | Secondary air pump motor -V101- (BGU) | 87 |
F28 | - | Fuse 28 on fuse holder B -SB28- | 40 A | - | Secondary air pump motor -V101- (BGU) | 87 |
F29 | - | Fuse 29 on fuse holder B -SB29- | - | - | Vacant | |
F30 | - | Fuse 30 on fuse holder B -SB30- | - | - | Vacant | |
F31 | - | Fuse 31 on fuse holder B -SB31- | 25 A | - | Driver side windscreen wiper motor -V216- | 30 |
F32 | - | Fuse 32 on fuse holder B -SB32- | 10 A | - | Injector, cylinder 1 -N30- (BGU) | 87 |
| | | | | Injector, cylinder 2 -N31- (BGU) | |
| | | | | Injector, cylinder 3 -N32- (BGU) | |
| | | | | Injector, cylinder 4 -N33- (BGU) | |
F33 | - | Fuse 33 on fuse holder B -SB33- | 15 A | - | Fuel system pressurisation pump -G6- (BGU) | 87 |
F34 | - | Fuse 34 on fuse holder B -SB34- | - | - | Vacant | |
F35 | - | Fuse 35 on fuse holder B -SB35- | - | - | Vacant | |
F36 | - | Fuse 36 on fuse holder B -SB36- | - | - | Vacant | |
F37 | - | Fuse 37 on fuse holder B -SB37- | - | - | Vacant | |
F38 | - | Fuse 38 on fuse holder B -SB38- | - | - | Vacant | |
F39 | - | Fuse 39 on fuse holder B -SB39- | - | - | Vacant | |
F40 | - | Fuse 40 on fuse holder B -SB40- | - | - | Vacant | |
F41 | - | Fuse 40 on fuse holder B -SB40- | - | - | Vacant | |
F42 | - | Fuse 42 on fuse holder B -SB42- | - | - | Vacant | |
F43 | - | Fuse 43 on fuse holder B -SB43- | - | - | Vacant | |
F44 | - | Fuse 44 on fuse holder B -SB44- | - | - | Vacant | |
F45 | - | Fuse 45 on fuse holder B -SB45- | 15 A | - | Lambda probe -G39- (BGU) | 87 |
| | | | | Lambda probe after catalytic converter -G130- (BGU) | |
F46 | - | Fuse 46 on fuse holder B -SB46- | - | - | Vacant | |
F47 | - | Fuse 47 on fuse holder B -SB47- | 40 A | - | Onboard supply control unit -J519- (supply illumination, left) | 30 |
F48 | - | Fuse 48 on fuse holder B -SB48- | 40 A | - | Onboard supply control unit -J519- (supply illumination, right) | 30 |
F49 | - | Fuse 49 on fuse holder B -SB49- | 80 A | - | Terminal 15 voltage supply relay 2 -J681- | 30 |
F50 | - | Fuse 50 on fuse holder B -SB50- | - | - | Vacant | |
F51 | - | Fuse 51 on fuse holder B -SB51- | 50 A | - | Automatic glow period control unit -J179- (AZV, BJB, BKC and BKD) | 30 |
F52 | - | Fuse 52 on fuse holder B -SB52- | 50 A | - | Onboard supply control unit -J519- | 75 |
F53 | - | Fuse 53 on fuse holder B -SB53- | 50 A | - | Driver door control unit -J386- | 30 |
| | | | | Front passenger door control unit -J387- | |
| | | | | Rear left door control unit -J388- | |
| | | | | Rear right door control unit -J389- | |
| | | | | Window regulator single fuse -S37- | |
F54 | - | Fuse 54 on fuse holder B -SB54- | 50 A | - | Radiator fan -V7- | 30 |
No. | | Current Flow Diagram designation | Nominal value | | Function/component | Terminal |
F1 | - | Fuse 1 on fuse holder B -SB1- | 30 A | - | Driver side wiper motor control unit, front passenger side -J584- | 30 |
F2 | - | Fuse 2 on fuse holder B -SB2- | 5 A | - | Steering column electronics control unit -J527- | 30 |
F3 | - | Fuse 3 on fuse holder B -SB3- | 5 A | - | Onboard supply control unit -J519- | 30 |
F4 | - | Fuse 4 on fuse holder B -SB4- | 30 A | - | ABS control unit -J104- | 30 |
F5 | - | Fuse 5 on fuse holder B -SB5- | 15 A | - | Mechatronic unit for dual clutch gearbox -J743- (AZV and BKD) | 30 |
F6 | - | Fuse 6 on fuse holder B -SB6- | 5 A | - | Control unit in dash panel insert -J285- | 30 |
F7 | - | Fuse 7 on fuse holder B -SB7- | - | - | Vacant | |
F8 | - | Fuse 8 on fuse holder B -SB8- | 15 A | - | Control unit with display for radio and navigation system -J503- | 30 |
| | | | - | Radio -R- | |
F9 | - | Fuse 9 on fuse holder B -SB9- | 5 A | | Mobile telephone operating electronics control unit -J412- | 30 |
| | | | - | Telephone transmitter and receiver unit -R36- | |
F10 | - | Fuse 10 on fuse holder B -SB10- | 5 A | - | Motronic control unit -J220- (BLR and BLY) | 30 |
| | | | | Main relay -J271- (BLR and BLY) | |
| | | | | Terminal 30 voltage supply relay -J317- (AZV, BJB, BKC, BKD and BLS) | |
F11 | - | Fuse 11 on fuse holder B -SB11- | - | - | Vacant | |
F12 | - | Fuse 12 on fuse holder B -SB12- | 5 A | - | Data bus diagnostic interface -J533- | 30 |
F13 | - | Fuse 13 on fuse holder B -SB13- | 25 A | - | Motronic control unit -J220- (BLR and BLY) | 87 |
| | | | | Simos control unit -J361- (BSE and BSF) | |
| | | 30 A | | Diesel direct injection system control unit -J248- (AZV, BJB, BKC, BKD and BLS) | |
F14 | - | Fuse 14 on fuse holder B -SB14- | 20 A | - | Ignition coil 1 with output stage -N70- (BLR and BLY) | 87 |
| | | | | Ignition coil 2 with output stage -N127- (BLR and BLY) | |
| | | | | Ignition transformer -N152- (BSE and BSF) | |
| | | | | Ignition coil 3 with output stage -N291- (BLR and BLY) | |
| | | | | Ignition coil 4 with output stage -N292- (BLR and BLY) | |
F15 | - | Fuse 15 on fuse holder B -SB15- | 5 A | - | Fuel pump relay -J17- (AZV, BJB, BKC, BKD and BLS) | 87 |
| | | | | Automatic glow period control unit -J179- (AZV, BJB, BKC, BKD and BLS) | |
| | | 10 A | - | Lambda probe 1 heater after catalytic converter -Z29- (BLR and BLY) | |
| | | | | Lambda probe 2 heater after catalytic converter -Z30- (BLR) | |
| | | | | Lambda probe 3 heater after catalytic converter -Z64- (BLR) | |
F16 | - | Fuse 16 on fuse holder B -SB16- | 30 A | - | ABS control unit -J104- | 30 |
F17 | - | Fuse 17 on fuse holder B -SB17- | 15 A | - | Onboard supply control unit -J519- | 30 |
F18 | - | Fuse 18 on fuse holder B -SB18- | - | - | Vacant | |
F19 | - | Fuse 19 on fuse holder B -SB19- | 30 A | - | Wiper motor control unit -J400- | 30 |
F20 | - | Fuse 20 on fuse holder B -SB20- | - | - | Vacant | |
F21 | - | Fuse 21 on fuse holder B -SB21- | 15 A | - | Lambda probe heater -Z19- (BLR and BLY) | 87 |
| | | | | Lambda probe 2 heater -Z28- (BLR) | |
| | | | | Lambda probe -G39- (BSE and BSF) | |
| | | | | Lambda probe after catalytic converter -G130- (BSE and BSF) | |
F22 | - | Fuse 22 on fuse holder B -SB22- | 5 A | - | Clutch position sender -G476- | 87 |
| | | | | Brake pedal switch -F47- | |
F23 | - | Fuse 23 on fuse holder B -SB23- | 5 A | - | Secondary air pump relay -J299- (BSE) | 87 |
| | | 10 A | - | Exhaust gas recirculation valve -N18- (AZV, BJB, BKC and BKD) | |
| | | | | Charge pressure control solenoid valve -N75- (AZV, BJB, BKC, BKD and BLS) | |
| | | | | Exhaust gas recirculation cooler change-over valve -N345- (AZV, BJB, BKC, BKD and BLS) | |
| | | 15 A | - | Fuel pressure regulating valve -N276- (BRL and BLS) | |
F24 | - | Fuse 24 on fuse holder B -SB24- | 10 A | - | Map-controlled engine cooling system thermostat -F265- (BRL and BLS) | 87 |
| | | | | Exhaust gas recirculation valve -N18- (BSE and BSF) | |
| | | | | Activated charcoal filter system solenoid valve 1 -N80- (BLR, BLY, BSE and BSF) | |
| | | | | Variable intake manifold change-over valve -N156- (BLR, BLY, BSE and BSF) | |
| | | | | Inlet camshaft control valve 1 -N205- (BLR and BLY) | |
| | | | | Radiator fan -V7- | |
| | | | | Intake manifold flap motor -V157- (AZV, BJB, BKC and BKD) | |
F25 | - | Fuse 25 on fuse holder B -SB25- | 40 A | - | Onboard supply control unit -J519- | 30 |
F26 | - | Fuse 26 on fuse holder B -SB26- | 40 A | - | Onboard supply control unit -J519- | 30 |
F27 | - | Fuse 27 on fuse holder B -SB27- | 40 A | - | Secondary air pump motor -V101- (BSE) | 87 |
| | | 50 A | - | Automatic glow period control unit -J179- (AZV, BJB, BKC, BKD and BLS) | 30 |
F28 | - | Fuse 28 on fuse holder B -SB28- | 40 A | - | Terminal 15 voltage supply relay 2 -J681- | 30 |
F29 | - | Fuse 29 on fuse holder B -SB29- | 30 A | - | Driver door control unit -J386- | 30 |
| | | | | Front passenger door control unit -J387- | |
| | | 50 A | - | Driver door control unit -J386- | |
| | | | | Front passenger door control unit -J387- | |
| | | | | Rear left door control unit -J388- | |
| | | | | Rear right door control unit -J389- | |
F30 | - | Fuse 30 on fuse holder B -SB30- | 40 A | - | X-contact relief relay -J59- | 30 |
No. | | Current Flow Diagram designation | Nominal value | | Function/component | Terminal |
F1 | - | Fuse 1 on fuse holder B -SB1- | 30 A | - | Driver side wiper motor control unit, front passenger side -J584- | 30 |
F2 | - | Fuse 2 on fuse holder B -SB2- | 5 A | - | Steering column electronics control unit -J527- | 30 |
F3 | - | Fuse 3 on fuse holder B -SB3- | 5 A | - | Onboard supply control unit -J519- | 30 |
F4 | - | Fuse 4 on fuse holder B -SB4- | 30 A | - | ABS control unit -J104- | 30 |
F5 | - | Fuse 5 on fuse holder B -SB5- | 15 A | - | Mechatronic unit for dual clutch gearbox -J743- (AZV and BKD) | 30 |
F6 | - | Fuse 6 on fuse holder B -SB6- | 5 A | - | Control unit in dash panel insert -J285- | 30 |
F7 | - | Fuse 7 on fuse holder B -SB7- | - | - | Vacant | |
F8 | - | Fuse 8 on fuse holder B -SB8- | 15 A | - | Control unit with display for radio and navigation system -J503- | 30 |
| | | | - | Radio -R- | |
F9 | - | Fuse 9 on fuse holder B -SB9- | 5 A | | Mobile telephone operating electronics control unit -J412- | 30 |
| | | | - | Telephone transmitter and receiver unit -R36- | |
F10 | - | Fuse 10 on fuse holder B -SB10- | 5 A | - | Motronic control unit -J220- (BVY and BVZ) | 30 |
| | | | | Main relay -J271- (BVY and BVZ) | |
| | | | | Terminal 30 voltage supply relay -J317- (AZV, BJB, BKC, BKD, BLS, BMM, BMN and BXE) | |
F11 | - | Fuse 11 on fuse holder B -SB11- | - | - | Vacant | |
F12 | - | Fuse 12 on fuse holder B -SB12- | 5 A | - | Data bus diagnostic interface -J533- | 30 |
F13 | - | Fuse 13 on fuse holder B -SB13- | 25 A | - | Motronic control unit -J220- (BVY and BVZ) | 87 |
| | | | | Simos control unit -J361- (BSE and BSF) | |
| | | 30 A | | Diesel direct injection system control unit -J248- (AZV, BJB, BKC, BKD, BLS, BMM, BMN and BXE) | |
F14 | - | Fuse 14 on fuse holder B -SB14- | 20 A | - | Ignition coil 1 with output stage -N70- (BVY and BVZ) | 87 |
| | | | | Ignition coil 2 with output stage -N127- (BVY and BVZ) | |
| | | | | Ignition transformer -N152- (BSE and BSF) | |
| | | | | Ignition coil 3 with output stage -N291- (BVY and BVZ) | |
| | | | | Ignition coil 4 with output stage -N292- (BVY and BVZ) | |
F15 | - | Fuse 15 on fuse holder B -SB15- | 5 A | - | Fuel pump relay -J17- (AZV, BJB, BKC, BKD, BLS, BMM, BMN and BXE) | 87 |
| | | | | Automatic glow period control unit -J179- (AZV, BJB, BKC, BKD, BLS, BMM, BMN and BXE) | |
| | | 10 A | - | Lambda probe 1 heater after catalytic converter -Z29- (BVY and BVZ) | |
| | | | | Lambda probe 2 heater after catalytic converter -Z30- (BVY) | |
| | | | | Lambda probe 3 heater after catalytic converter -Z64- (BVY) | |
F16 | - | Fuse 16 on fuse holder B -SB16- | 30 A | - | ABS control unit -J104- | 30 |
F17 | - | Fuse 17 on fuse holder B -SB17- | 15 A | - | Onboard supply control unit -J519- | 30 |
F18 | - | Fuse 18 on fuse holder B -SB18- | - | - | Vacant | |
F19 | - | Fuse 19 on fuse holder B -SB19- | 30 A | - | Wiper motor control unit -J400- | 30 |
F20 | - | Fuse 20 on fuse holder B -SB20- | - | - | Vacant | |
F21 | - | Fuse 21 on fuse holder B -SB21- | 10 A | - | Lambda probe heater -Z19- (BLS, BMM and BMN) | 87 |
| | | 15 A | | Lambda probe heater -Z19- (BVY and BVZ) | |
| | | | | Lambda probe -G39- (BSE and BSF) | |
| | | | | Lambda probe after catalytic converter -G130- (BSE and BSF) | |
F22 | - | Fuse 22 on fuse holder B -SB22- | 5 A | - | Clutch position sender -G476- | 87 |
F23 | - | Fuse 23 on fuse holder B -SB23- | 5 A | - | Secondary air pump relay -J299- (BSE) | 87 |
| | | 10 A | - | Exhaust gas recirculation valve -N18- (AZV, BJB, BKC, BKD and BXE) | |
| | | | | Charge pressure control solenoid valve -N75- (AZV, BJB, BKC, BKD, BLS, BMM, BMN and BXE) | |
| | | | | Intake manifold flap valve -N316- (BMN) | |
| | | | | Exhaust gas recirculation cooler change-over valve -N345- (AZV, BJB, BKC, BKD, BLS, BMM, BMN and BXE) | |
| | | 15 A | - | Fuel pressure regulating valve -N276- (BVY and BVZ) | |
F24 | - | Fuse 24 on fuse holder B -SB24- | 10 A | - | Activated charcoal filter system solenoid valve 1 -N80- (BSE, BSF, BVY and BVZ) | 87 |
| | | | | Variable intake manifold change-over valve -N156- (BSE, BSF, BVY and BVZ) | |
| | | | | Inlet camshaft control valve 1 -N205- (BVY and BVZ) | |
| | | | | Radiator fan -V7- | |
| | | | | Intake manifold flap motor -V157- (AZV, BJB, BKC, BKD and BXE) | |
F25 | - | Fuse 25 on fuse holder B -SB25- | 40 A | - | Onboard supply control unit -J519- | 30 |
F26 | - | Fuse 26 on fuse holder B -SB26- | 40 A | - | Onboard supply control unit -J519- | 30 |
F27 | - | Fuse 27 on fuse holder B -SB27- | 40 A | - | Secondary air pump motor -V101- (BSE) | 87 |
| | | 50 A | - | Automatic glow period control unit -J179- (AZV, BJB, BKC, BKD, BLS, BMM, BMN and BXE) | 30 |
F28 | - | Fuse 28 on fuse holder B -SB28- | 40 A | - | Terminal 15 voltage supply relay 2 -J681- | 30 |
F29 | - | Fuse 29 on fuse holder B -SB29- | 30 A | - | Driver door control unit -J386- | 30 |
| | | | | Front passenger door control unit -J387- | |
| | | 50 A | - | Driver door control unit -J386- | |
| | | | | Front passenger door control unit -J387- | |
| | | | | Rear left door control unit -J388- | |
| | | | | Rear right door control unit -J389- | |
F30 | - | Fuse 30 on fuse holder B -SB30- | 40 A | - | X-contact relief relay -J59- | 30 |
No. | | Current Flow Diagram designation | Nominal value | | Function/component | Terminal |
F1 | - | Fuse 1 on fuse holder B -SB1- | 30 A | - | Driver side wiper motor control unit, front passenger side -J584- | 30 |
F2 | - | Fuse 2 on fuse holder B -SB2- | 5 A | - | Steering column electronics control unit -J527- | 30 |
F3 | - | Fuse 3 on fuse holder B -SB3- | 5 A | - | Onboard supply control unit -J519- (via F/7) | 30 |
F4 | - | Fuse 4 on fuse holder B -SB4- | 30 A | - | ABS control unit -J104- | 30 |
F5 | - | Fuse 5 on fuse holder B -SB5- | 15 A | - | Mechatronic unit for dual clutch gearbox -J743- (AZV, BKD, BMM and BWA) | 30 |
F6 | - | Fuse 6 on fuse holder B -SB6- | 5 A | - | Control unit in dash panel insert -J285- | 30 |
F7 | - | Fuse 7 on fuse holder B -SB7- | - | - | Vacant | |
F8 | - | Fuse 8 on fuse holder B -SB8- | 15 A | - | Control unit with display for radio and navigation system -J503- | 30 |
| | | | - | Radio -R- | |
F9 | - | Fuse 9 on fuse holder B -SB9- | 5 A | | Mobile telephone operating electronics control unit -J412- | 30 |
| | | | - | Telephone transmitter and receiver unit -R36- | |
| | | | | Navigation system interface -R94- (Tom-Tom Navigator) | |
F10 | - | Fuse 10 on fuse holder B -SB10- | 5 A | - | Motronic control unit -J220- (BVY and BVZ) | 30 |
| | | | | Main relay -J271- (BVY and BVZ) | |
| | | | | Terminal 30 voltage supply relay -J317- (AZV, BKC, BKD, BLS, BMM, BMN and BXE) | |
| | | 10 A | | Motronic control unit -J220- (BWA) | |
| | | | | Main relay -J271- (BWA) | |
| | | | | Terminal 30 voltage supply relay -J317- (BXW) | |
| | | | | Catalytic converter monitor 1 -J357- (BXW) | |
F11 | - | Fuse 11 on fuse holder B -SB11- | - | - | Vacant | |
F12 | - | Fuse 12 on fuse holder B -SB12- | 5 A | - | Data bus diagnostic interface -J533- | 30 |
F13 | - | Fuse 13 on fuse holder B -SB13- | 15 A | - | Motronic control unit -J220- (BVY, BVZ and BWA) | 87 |
| | | | | Simos control unit -J361- (BSE and BSF) | |
| | | | | 4LV injection system control unit -J537- (BXW) | |
| | | 30 A | | Diesel direct injection system control unit -J248- (AZV, BKC, BKD, BLS, BMM, BMN and BXE) | |
F14 | - | Fuse 14 on fuse holder B -SB14- | 20 A | - | Ignition coil 1 with output stage -N70- (BVY, BVZ, BWA and BXW) | 87 |
| | | | | Ignition coil 2 with output stage -N127- (BVY, BVZ, BWA and BXW) | |
| | | | | Ignition transformer -N152- (BSE and BSF) | |
| | | | | Ignition coil 3 with output stage -N291- (BVY, BVZ, BWA and BXW) | |
| | | | | Ignition coil 4 with output stage -N292- (BVY, BVZ, BWA and BXW) | |
F15 | - | Fuse 15 on fuse holder B -SB15- | 5 A | - | Fuel pump relay -J17- (AZV, BKC, BKD, BLS, BMM, BMN and BXE) | 87 |
| | | | | Automatic glow period control unit -J179- (AZV, BKC, BKD, BLS, BMM, BMN and BXE) | |
| | | 10 A | - | Injector, cylinder 1 -N30- (BXW) | |
| | | | | Injector, cylinder 2 -N31- (BXW) | |
| | | | | Injector, cylinder 3 -N32- (BXW) | |
| | | | | Injector, cylinder 4 -N33- (BXW) | |
| | | | | Circulation pump relay -J160- (BWA) | |
| | | | | Lambda probe 1 heater after catalytic converter -Z29- (BVY and BVZ) | |
| | | | | Lambda probe 2 heater after catalytic converter -Z30- (BVY) | |
| | | | | Lambda probe 3 heater after catalytic converter -Z64- (BVY) | |
F16 | - | Fuse 16 on fuse holder B -SB16- | 30 A | - | ABS control unit -J104- | 30 |
F17 | - | Fuse 17 on fuse holder B -SB17- | 15 A | - | Onboard supply control unit -J519- (via J/3) | 30 |
F18 | - | Fuse 18 on fuse holder B -SB18- | - | - | Vacant | |
F19 | - | Fuse 19 on fuse holder B -SB19- | 30 A | - | Wiper motor control unit -J400- | 30 |
F20 | - | Fuse 20 on fuse holder B -SB20- | - | - | Vacant | |
F21 | - | Fuse 21 on fuse holder B -SB21- | 10 A | - | Lambda probe heater -Z19- (BLS, BMM and BMN) | 87 |
| | | 15 A | | Lambda probe heater -Z19- (BVY and BVZ) | |
| | | | | Lambda probe -G39- (BSE, BSF and BXW) | |
| | | | | Lambda probe after catalytic converter -G130- (BSE, BSF and BXW) | |
F22 | - | Fuse 22 on fuse holder B -SB22- | 5 A | - | Clutch position sender -G476- | 87 |
F23 | - | Fuse 23 on fuse holder B -SB23- | 5 A | - | Circulation pump relay -J160- (BWA) | 87 |
| | | | | Secondary air pump relay -J299- (BSE) | |
| | | | | Motronic current supply relay -2- -J670- (BWA) | |
| | | 10 A | - | Exhaust gas recirculation valve -N18- (AZV, BKC, BKD and BXE) | |
| | | | | Charge pressure control solenoid valve -N75- (AZV, BKC, BKD, BLS, BMM, BMN and BXE) | |
| | | | | Intake manifold flap valve -N316- (BMN) | |
| | | | | Exhaust gas recirculation cooler change-over valve -N345- (AZV, BKC, BKD, BLS, BMM, BMN and BXE) | |
| | | 15 A | - | Fuel pressure regulating valve -N276- (BVY and BVZ) | |
F24 | - | Fuse 24 on fuse holder B -SB24- | 10 A | - | Activated charcoal filter system solenoid valve 1 -N80- (BSE, BSF, BVY, BVZ and BXW) | 87 |
| | | | | Variable intake manifold change-over valve -N156- (BSE, BSF, BVY and BVZ) | |
| | | | | Inlet camshaft control valve 1 -N205- (BVY, BVZ and BWA) | |
| | | | | Radiator fan -V7- | |
| | | | | Intake manifold flap motor -V157- (AZV, BKC, BKD and BXE) | |
F25 | - | Fuse 25 on fuse holder B -SB25- | 30 A | - | Onboard supply control unit -J519- (via A/1) | 30 |
F26 | - | Fuse 26 on fuse holder B -SB26- | 30 A | - | Onboard supply control unit -J519- (via D/1) | 30 |
F27 | - | Fuse 27 on fuse holder B -SB27- | 40 A | - | Secondary air pump motor -V101- (BSE) | 87 |
| | | 50 A | - | Automatic glow period control unit -J179- (AZV, BKC, BKD, BLS, BMM, BMN and BXE) | 30 |
F28 | - | Fuse 28 on fuse holder B -SB28- | 40 A | - | Terminal 15 voltage supply relay 2 -J681- | 30 |
F29 | - | Fuse 29 on fuse holder B -SB29- | 50 A | - | Driver door control unit -J386- (without Autolock function) | 30 |
| | | | | Front passenger door control unit -J387- (without Autolock function) | |
F30 | - | Fuse 30 on fuse holder B -SB30- | 50 A | - | X-contact relief relay -J59- | 30 |
No. | | Current Flow Diagram designation | Nominal value | | Function/component | Terminal |
F1 | - | Fuse 1 on fuse holder B -SB1- | 30 A | - | Driver side wiper motor control unit, front passenger side -J584- | 30 |
F2 | - | Fuse 2 on fuse holder B -SB2- | 5 A | - | Steering column electronics control unit -J527- | 30 |
F3 | - | Fuse 3 on fuse holder B -SB3- | 5 A | - | Onboard supply control unit -J519- (via F/7) | 30 |
F4 | - | Fuse 4 on fuse holder B -SB4- | 30 A | - | ABS control unit -J104- | 30 |
F5 | - | Fuse 5 on fuse holder B -SB5- | 15 A | - | Mechatronic unit for dual clutch gearbox -J743- (AZV, BKD, BMM and BWA) | 30 |
F6 | - | Fuse 6 on fuse holder B -SB6- | 5 A | - | Control unit in dash panel insert -J285- | 30 |
F7 | - | Fuse 7 on fuse holder B -SB7- | - | - | Vacant | |
F8 | - | Fuse 8 on fuse holder B -SB8- | 15 A | - | Control unit with display for radio and navigation system -J503- | 30 |
| | | | - | Radio -R- | |
F9 | - | Fuse 9 on fuse holder B -SB9- | 5 A | | Mobile telephone operating electronics control unit -J412- | 30 |
| | | | - | Telephone transmitter and receiver unit -R36- | |
| | | | | Navigation system interface -R94- (Tom-Tom Navigator) | |
F10 | - | Fuse 10 on fuse holder B -SB10- | 5 A | - | Motronic control unit -J220- (BVY and BVZ) | 30 |
| | | | | Main relay -J271- (BVY and BVZ) | |
| | | | | Terminal 30 voltage supply relay -J317- (AZV, BKC, BKD, BLS, BMM, BMN and BXE) | |
| | | 10 A | | Motronic control unit -J220- (BWA) | |
| | | | | Main relay -J271- (BWA) | |
| | | | | Terminal 30 voltage supply relay -J317- (BXW) | |
| | | | | Catalytic converter monitor 1 -J357- (BXW) | |
F11 | - | Fuse 11 on fuse holder B -SB11- | - | - | Vacant | |
F12 | - | Fuse 12 on fuse holder B -SB12- | 5 A | - | Data bus diagnostic interface -J533- | 30 |
F13 | - | Fuse 13 on fuse holder B -SB13- | 15 A | - | Motronic control unit -J220- (BVY, BVZ and BWA) | 87 |
| | | | | Simos control unit -J361- (BSE and BSF) | |
| | | | | 4LV injection system control unit -J537- (BXW) | |
| | | 30 A | | Diesel direct injection system control unit -J248- (AZV, BKC, BKD, BLS, BMM, BMN and BXE) | |
F14 | - | Fuse 14 on fuse holder B -SB14- | 20 A | - | Ignition coil 1 with output stage -N70- (BVY, BVZ, BWA and BXW) | 87 |
| | | | | Ignition coil 2 with output stage -N127- (BVY, BVZ, BWA and BXW) | |
| | | | | Ignition transformer -N152- (BSE and BSF) | |
| | | | | Ignition coil 3 with output stage -N291- (BVY, BVZ, BWA and BXW) | |
| | | | | Ignition coil 4 with output stage -N292- (BVY, BVZ, BWA and BXW) | |
F15 | - | Fuse 15 on fuse holder B -SB15- | 5 A | - | Fuel pump relay -J17- (AZV, BKC, BKD, BLS, BMM, BMN and BXE) | 87 |
| | | | | Automatic glow period control unit -J179- (AZV, BKC, BKD, BLS, BMM, BMN and BXE) | |
| | | | | Low heat output relay -J359- | |
| | | | | High heat output relay -J360- | |
| | | 10 A | - | Injector, cylinder 1 -N30- (BXW) | |
| | | | | Injector, cylinder 2 -N31- (BXW) | |
| | | | | Injector, cylinder 3 -N32- (BXW) | |
| | | | | Injector, cylinder 4 -N33- (BXW) | |
| | | | | Circulation pump relay -J160- (BWA) | |
| | | | | Lambda probe 1 heater after catalytic converter -Z29- (BVY and BVZ) | |
| | | | | Lambda probe 2 heater after catalytic converter -Z30- (BVY) | |
| | | | | Lambda probe 3 heater after catalytic converter -Z64- (BVY) | |
F16 | - | Fuse 16 on fuse holder B -SB16- | 30 A | - | ABS control unit -J104- | 30 |
F17 | - | Fuse 17 on fuse holder B -SB17- | 15 A | - | Onboard supply control unit -J519- (via J/3) | 30 |
F18 | - | Fuse 18 on fuse holder B -SB18- | - | - | Vacant | |
F19 | - | Fuse 19 on fuse holder B -SB19- | 30 A | - | Wiper motor control unit -J400- | 30 |
F20 | - | Fuse 20 on fuse holder B -SB20- | - | - | Vacant | |
F21 | - | Fuse 21 on fuse holder B -SB21- | 10 A | - | Lambda probe heater -Z19- (BLS, BMM and BMN) | 87 |
| | | 15 A | | Lambda probe heater -Z19- (BVY and BVZ) | |
| | | | | Lambda probe -G39- (BSE, BSF and BXW) | |
| | | | | Lambda probe after catalytic converter -G130- (BSE, BSF and BXW) | |
F22 | - | Fuse 22 on fuse holder B -SB22- | 5 A | - | Clutch position sender -G476- | 87 |
F23 | - | Fuse 23 on fuse holder B -SB23- | 5 A | - | Circulation pump relay -J160- (BWA) | 87 |
| | | | | Secondary air pump relay -J299- (BSE) | |
| | | | | Motronic current supply relay -2- -J670- (BWA) | |
| | | 10 A | - | Exhaust gas recirculation valve -N18- (AZV, BKC, BKD and BXE) | |
| | | | | Charge pressure control solenoid valve -N75- (AZV, BKC, BKD, BLS, BMM, BMN and BXE) | |
| | | | | Intake manifold flap valve -N316- (BMN) | |
| | | | | Exhaust gas recirculation cooler change-over valve -N345- (AZV, BKC, BKD, BLS, BMM, BMN and BXE) | |
| | | 15 A | - | Fuel pressure regulating valve -N276- (BVY and BVZ) | |
F24 | - | Fuse 24 on fuse holder B -SB24- | 10 A | - | Activated charcoal filter system solenoid valve 1 -N80- (BSE, BSF, BVY, BVZ and BXW) | 87 |
| | | | | Variable intake manifold change-over valve -N156- (BSE, BSF, BVY and BVZ) | |
| | | | | Inlet camshaft control valve 1 -N205- (BVY, BVZ and BWA) | |
| | | | | Radiator fan -V7- | |
| | | | | Intake manifold flap motor -V157- (AZV, BKC, BKD and BXE) | |
F25 | - | Fuse 25 on fuse holder B -SB25- | 30 A | - | Onboard supply control unit -J519- (via A/1) | 30 |
F26 | - | Fuse 26 on fuse holder B -SB26- | 30 A | - | Onboard supply control unit -J519- (via D/1) | 30 |
F27 | - | Fuse 27 on fuse holder B -SB27- | 40 A | - | Secondary air pump motor -V101- (BSE) | 87 |
| | | 50 A | - | Automatic glow period control unit -J179- (AZV, BKC, BKD, BLS, BMM, BMN and BXE) | 30 |
F28 | - | Fuse 28 on fuse holder B -SB28- | 40 A | - | Terminal 15 voltage supply relay 2 -J681- | 30 |
F29 | - | Fuse 29 on fuse holder B -SB29- | 50 A | - | Driver door control unit -J386- (without Autolock function) | 30 |
| | | | | Front passenger door control unit -J387- (without Autolock function) | |
F30 | - | Fuse 30 on fuse holder B -SB30- | 50 A | - | X-contact relief relay -J59- | 30 |
No. | | Current Flow Diagram designation | Nominal value | | Function/component | Terminal |
F1 | - | Fuse 1 on fuse holder B -SB1- | 30 A | - | Driver side wiper motor control unit, front passenger side -J584- | 30 |
F2 | - | Fuse 2 on fuse holder B -SB2- | 5 A | - | Steering column electronics control unit -J527- | 30 |
F3 | - | Fuse 3 on fuse holder B -SB3- | 5 A | - | Onboard supply control unit -J519- (via F/7) | 30 |
F4 | - | Fuse 4 on fuse holder B -SB4- | 30 A | - | ABS control unit -J104- | 30 |
F5 | - | Fuse 5 on fuse holder B -SB5- | 15 A | - | Mechatronic unit for dual clutch gearbox -J743- (AZV, BKD, BLS, BMM and BWA) | 30 |
F6 | - | Fuse 6 on fuse holder B -SB6- | 5 A | - | Control unit in dash panel insert -J285- | 30 |
F7 | - | Fuse 7 on fuse holder B -SB7- | - | - | Vacant | |
F8 | - | Fuse 8 on fuse holder B -SB8- | 15 A | - | Control unit with display for radio and navigation system -J503- | 30 |
| | | | - | Radio -R- | |
F9 | - | Fuse 9 on fuse holder B -SB9- | 5 A | - | Telephone transmitter and receiver unit -R36- | 30 |
| | | | | Navigation system interface -R94- (Tom-Tom Navigator) | |
F10 | - | Fuse 10 on fuse holder B -SB10- | 5 A | - | Motronic control unit -J220- (BVY and BVZ) | 30 |
| | | | | Main relay -J271- (BVY and BVZ) | |
| | | | | Terminal 30 voltage supply relay -J317- (AZV, BKC, BKD, BLS, BMM, BMN and BXE) | |
| | | 10 A | | Motronic control unit -J220- (BWA) | |
| | | | | Main relay -J271- (BWA and BZB) | |
| | | | | Terminal 30 voltage supply relay -J317- (BXW) | |
| | | | | Catalytic converter monitor 1 -J357- (BXW) | |
| | | | | Engine control unit -J623- (BZB) | |
F11 | - | Fuse 11 on fuse holder B -SB11- | - | - | Vacant | |
F12 | - | Fuse 12 on fuse holder B -SB12- | 5 A | - | Data bus diagnostic interface -J533- | 30 |
F13 | - | Fuse 13 on fuse holder B -SB13- | 15 A | - | Motronic control unit -J220- (BVY, BVZ and BWA) | 87 |
| | | | | Simos control unit -J361- (BSE and BSF) | |
| | | | | 4LV injection system control unit -J537- (BXW) | |
| | | | | Engine control unit -J623- (BZB) | |
| | | 30 A | | Diesel direct injection system control unit -J248- (AZV, BKC, BKD, BLS, BMM, BMN and BXE) | |
F14 | - | Fuse 14 on fuse holder B -SB14- | 20 A | - | Ignition coil 1 with output stage -N70- (BVY, BVZ, BWA, BXW and BZB) | 87 |
| | | | | Ignition coil 2 with output stage -N127- (BVY, BVZ, BWA, BXW and BZB) | |
| | | | | Ignition transformer -N152- (BSE and BSF) | |
| | | | | Ignition coil 3 with output stage -N291- (BVY, BVZ, BWA, BXW and BZB) | |
| | | | | Ignition coil 4 with output stage -N292- (BVY, BVZ, BWA, BXW and BZB) | |
F15 | - | Fuse 15 on fuse holder B -SB15- | 5 A | - | Fuel pump relay -J17- (AZV, BKC, BKD, BLS, BMM, BMN and BXE) | 87 |
| | | | | Automatic glow period control unit -J179- (AZV, BKC, BKD, BLS, BMM, BMN and BXE) | |
| | | | | Low heat output relay -J359- | |
| | | | | High heat output relay -J360- | |
| | | 10 A | - | Injector, cylinder 1 -N30- (BXW) | |
| | | | | Injector, cylinder 2 -N31- (BXW) | |
| | | | | Injector, cylinder 3 -N32- (BXW) | |
| | | | | Injector, cylinder 4 -N33- (BXW) | |
| | | | | Circulation pump relay -J160- (BWA) | |
| | | | | Lambda probe 1 heater after catalytic converter -Z29- (BVY and BVZ) | |
| | | | | Lambda probe 2 heater after catalytic converter -Z30- (BVY) | |
| | | | | Lambda probe 3 heater after catalytic converter -Z64- (BVY) | |
F16 | - | Fuse 16 on fuse holder B -SB16- | 30 A | - | ABS control unit -J104- | 30 |
F17 | - | Fuse 17 on fuse holder B -SB17- | 15 A | - | Onboard supply control unit -J519- (via J/3) | 30 |
F18 | - | Fuse 18 on fuse holder B -SB18- | - | - | Vacant | |
F19 | - | Fuse 19 on fuse holder B -SB19- | 30 A | - | Wiper motor control unit -J400- | 30 |
F20 | - | Fuse 20 on fuse holder B -SB20- | 20 A | - | Fuel pressure regulating valve -N276- (BZB) | 87 |
F21 | - | Fuse 21 on fuse holder B -SB21- | 10 A | - | Lambda probe heater -Z19- (BLS, BMM and BMN) | 87 |
| | | 15 A | | Lambda probe heater -Z19- (BVY, BVZ and BZB) | |
| | | | | Lambda probe -G39- (BSE, BSF and BXW) | |
| | | | | Lambda probe after catalytic converter -G130- (BSE, BSF and BXW) | |
F22 | - | Fuse 22 on fuse holder B -SB22- | 5 A | - | Clutch position sender -G476- | 87 |
F23 | - | Fuse 23 on fuse holder B -SB23- | 5 A | - | Continued coolant circulation relay -J151- (BZB) | 87 |
| | | | | Circulation pump relay -J160- (BWA) | |
| | | | | Secondary air pump relay -J299- (BSE) | |
| | | | | Motronic current supply relay -2- -J670- (BWA) | |
| | | 10 A | - | Exhaust gas recirculation valve -N18- (AZV, BKC, BKD and BXE) | |
| | | | | Charge pressure control solenoid valve -N75- (AZV, BKC, BKD, BLS, BMM, BMN and BXE) | |
| | | | | Intake manifold flap valve -N316- (BMN) | |
| | | | | Exhaust gas recirculation cooler change-over valve -N345- (AZV, BKC, BKD, BLS, BMM, BMN and BXE) | |
| | | 15 A | - | Fuel pressure regulating valve -N276- (BVY and BVZ) | |
F24 | - | Fuse 24 on fuse holder B -SB24- | 10 A | - | Engine component current supply relay -J757- (BZB) | 87 |
| | | | | Charge pressure control solenoid valve -N75- (BZB) | |
| | | | | Activated charcoal filter system solenoid valve 1 -N80- (BSE, BSF, BVY, BVZ, BXW and BZB) | |
| | | | | Variable intake manifold change-over valve -N156- (BSE, BSF, BVY and BVZ) | |
| | | | | Inlet camshaft control valve 1 -N205- (BVY, BVZ, BWA and BZB) | |
| | | | | Turbocharger air recirculation valve -N249- (BZB) | |
| | | | | Intake manifold flap valve -N316- (BZB) | |
| | | | | Radiator fan -V7- | |
| | | | | Intake manifold flap motor -V157- (AZV, BKC, BKD and BXE) | |
F25 | - | Fuse 25 on fuse holder B -SB25- | 30 A | - | Onboard supply control unit -J519- (via A/1) | 30 |
F26 | - | Fuse 26 on fuse holder B -SB26- | 30 A | - | Onboard supply control unit -J519- (via D/1) | 30 |
F27 | - | Fuse 27 on fuse holder B -SB27- | 40 A | - | Secondary air pump motor -V101- (BSE) | 87 |
| | | 50 A | - | Automatic glow period control unit -J179- (AZV, BKC, BKD, BLS, BMM, BMN and BXE) | 30 |
F28 | - | Fuse 28 on fuse holder B -SB28- | 40 A | - | Terminal 15 voltage supply relay 2 -J681- | 30 |
F29 | - | Fuse 29 on fuse holder B -SB29- | 50 A | - | Driver door control unit -J386- (without Autolock function) | 30 |
| | | | | Front passenger door control unit -J387- (without Autolock function) | |
| | | | | Rear left door control unit -J388- (without Autolock function) | |
| | | | | Rear right door control unit -J389- (without Autolock function) | |
F30 | - | Fuse 30 on fuse holder B -SB30- | 50 A | - | X-contact relief relay -J59- | 30 |
No. | | Current Flow Diagram designation | Nominal value | | Function/component | Terminal |
F1 | - | Fuse 1 on fuse holder B -SB1- | 30 A | - | Driver side wiper motor control unit, front passenger side -J584- | 30 |
F2 | - | Fuse 2 on fuse holder B -SB2- | 5 A | - | Steering column electronics control unit -J527- | 30 |
F3 | - | Fuse 3 on fuse holder B -SB3- | 5 A | - | Onboard supply control unit -J519- (via F/7) | 30 |
F4 | - | Fuse 4 on fuse holder B -SB4- | 30 A | - | ABS control unit -J104- | 30 |
F5 | - | Fuse 5 on fuse holder B -SB5- | 15 A | - | Mechatronic unit for dual clutch gearbox -J743- (AZV, BKD, BLS, BMM and BWA) | 30 |
F6 | - | Fuse 6 on fuse holder B -SB6- | 5 A | - | Control unit in dash panel insert -J285- | 30 |
F7 | - | Fuse 7 on fuse holder B -SB7- | - | - | Vacant | |
F8 | - | Fuse 8 on fuse holder B -SB8- | 15 A | - | Control unit with display for radio and navigation system -J503- | 30 |
| | | | | Radio -R- | |
F9 | - | Fuse 9 on fuse holder B -SB9- | 5 A | - | Telephone transmitter and receiver unit -R36- | 30 |
| | | | | Navigation system interface -R94- (Tom-Tom Navigator) | |
F10 | - | Fuse 10 on fuse holder B -SB10- | 5 A | - | Motronic control unit -J220- (BVY and BVZ) | 30 |
| | | | | Main relay -J271- (BVY, BVZ and CAXC) | |
| | | | | Terminal 30 voltage supply relay -J317- (AZV, BKC, BKD, BLS, BMM, BMN and BXE) | |
| | | | | Engine control unit -J623- (CAXC) | |
| | | 10 A | | Motronic control unit -J220- (BWA) | |
| | | | | Main relay -J271- (BWA and BZB) | |
| | | | | Terminal 30 voltage supply relay -J317- (BXW) | |
| | | | | Catalytic converter monitor 1 -J357- (BXW) | |
| | | | | Engine control unit -J623- (BZB) | |
F11 | - | Fuse 11 on fuse holder B -SB11- | - | - | Vacant | |
F12 | - | Fuse 12 on fuse holder B -SB12- | 5 A | - | Data bus diagnostic interface -J533- | 30 |
F13 | - | Fuse 13 on fuse holder B -SB13- | 15 A | - | Motronic control unit -J220- (BVY, BVZ and BWA) | 87 |
| | | | | Simos control unit -J361- (BSE, BSF and CCSA) | |
| | | | | 4LV injection system control unit -J537- (BXW) | |
| | | | | Engine control unit -J623- (BZB and CAXC) | |
| | | 30 A | - | Diesel direct injection system control unit -J248- (AZV, BKC, BKD, BLS, BMM, BMN and BXE) | |
F14 | - | Fuse 14 on fuse holder B -SB14- | 20 A | - | Ignition coil 1 with output stage -N70- (BVY, BVZ, BWA, BXW, BZB and CAXC) | 87 |
| | | | | Ignition coil 2 with output stage -N127- (BVY, BVZ, BWA, BXW, BZB and CAXC) | |
| | | | | Ignition transformer -N152- (BSE, BSF and CCSA) | |
| | | | | Ignition coil 3 with output stage -N291- (BVY, BVZ, BWA, BXW, BZB and CAXC) | |
| | | | | Ignition coil 4 with output stage -N292- (BVY, BVZ, BWA, BXW, BZB and CAXC) | |
F15 | - | Fuse 15 on fuse holder B -SB15- | 5 A | - | Fuel pump relay -J17- (AZV, BKC, BKD, BLS, BMM, BMN and BXE) | 87 |
| | | | | Automatic glow period control unit -J179- (AZV, BKC, BKD, BLS, BMM, BMN and BXE) | |
| | | | | Low heat output relay -J359- | |
| | | | | High heat output relay -J360- | |
| | | 10 A | - | Injector, cylinder 1 -N30- (BXW) | |
| | | | | Injector, cylinder 2 -N31- (BXW) | |
| | | | | Injector, cylinder 3 -N32- (BXW) | |
| | | | | Injector, cylinder 4 -N33- (BXW) | |
| | | | | Circulation pump relay -J160- (BWA) | |
| | | | | Lambda probe heater -Z19- (CAXC) | |
| | | | | Lambda probe 1 heater after catalytic converter -Z29- (BVY, BVZ and CAXC) | |
| | | | | Lambda probe 2 heater after catalytic converter -Z30- (BVY) | |
| | | | | Lambda probe 3 heater after catalytic converter -Z64- (BVY) | |
F16 | - | Fuse 16 on fuse holder B -SB16- | 30 A | - | ABS control unit -J104- | 30 |
F17 | - | Fuse 17 on fuse holder B -SB17- | 15 A | - | Onboard supply control unit -J519- (via J/3) | 30 |
F18 | - | Fuse 18 on fuse holder B -SB18- | - | - | Vacant | |
F19 | - | Fuse 19 on fuse holder B -SB19- | 30 A | - | Wiper motor control unit -J400- | 30 |
F20 | - | Fuse 20 on fuse holder B -SB20- | 10 A | - | Coolant circulation pump -V50- (CAXC) | 87 |
| | | 20 A | - | Fuel pressure regulating valve -N276- (BZB) | |
F21 | - | Fuse 21 on fuse holder B -SB21- | 10 A | - | Lambda probe heater -Z19- (BLS, BMM and BMN) | 87 |
| | | 15 A | - | Lambda probe heater -Z19- (BVY, BVZ and BZB) | |
| | | | | Lambda probe -G39- (BSE, BSF, BXW and CCSA) | |
| | | | | Lambda probe after catalytic converter -G130- (BSE, BSF, BXW and CCSA) | |
F22 | - | Fuse 22 on fuse holder B -SB22- | 5 A | - | Clutch position sender -G476- | 87 |
F23 | - | Fuse 23 on fuse holder B -SB23- | 5 A | - | Continued coolant circulation relay -J151- (BZB) | 87 |
| | | | | Circulation pump relay -J160- (BWA) | |
| | | | | Secondary air pump relay -J299- (BSE and CCSA) | |
| | | | | Motronic current supply relay -2- -J670- (BWA) | |
| | | 10 A | - | Exhaust gas recirculation valve -N18- (AZV, BKC, BKD and BXE) | |
| | | | | Charge pressure control solenoid valve -N75- (AZV, BKC, BKD, BLS, BMM, BMN and BXE) | |
| | | | | Intake manifold flap valve -N316- (BMN) | |
| | | | | Exhaust gas recirculation cooler change-over valve -N345- (AZV, BKC, BKD, BLS, BMM, BMN and BXE) | |
| | | 15 A | - | Fuel pressure regulating valve -N276- (BVY, BVZ and CAXC) | |
F24 | - | Fuse 24 on fuse holder B -SB24- | 10 A | - | Additional coolant pump relay -J496- (CAXC) | 87 |
| | | | | Engine component current supply relay -J757- (BZB) | |
| | | | | Charge pressure control solenoid valve -N75- (BZB and CAXC) | |
| | | | | Activated charcoal filter system solenoid valve 1 -N80- (BSE, BSF, BVY, BVZ, BXW, BZB, CAXC and CCSA) | |
| | | | | Variable intake manifold change-over valve -N156- (BSE, BSF, BVY, BVZ and CCSA) | |
| | | | | Inlet camshaft control valve 1 -N205- (BVY, BVZ, BWA, BZB and CAXC) | |
| | | | | Turbocharger air recirculation valve -N249- (BZB and CAXC) | |
| | | | | Intake manifold flap valve -N316- (BZB) | |
| | | | | Radiator fan -V7- | |
| | | | | Intake manifold flap motor -V157- (AZV, BKC, BKD and BXE) | |
F25 | - | Fuse 25 on fuse holder B -SB25- | 30 A | - | Onboard supply control unit -J519- (via A/1) | 30 |
F26 | - | Fuse 26 on fuse holder B -SB26- | 30 A | - | Onboard supply control unit -J519- (via D/1) | 30 |
F27 | - | Fuse 27 on fuse holder B -SB27- | 40 A | - | Secondary air pump motor -V101- (BSE and CCSA) | 87 |
| | | 50 A | - | Automatic glow period control unit -J179- (AZV, BKC, BKD, BLS, BMM, BMN and BXE) | 30 |
F28 | - | Fuse 28 on fuse holder B -SB28- | 40 A | - | Terminal 15 voltage supply relay 2 -J681- | 30 |
F29 | - | Fuse 29 on fuse holder B -SB29- | 50 A | - | Driver door control unit -J386- (without Autolock function) | 30 |
| | | | | Front passenger door control unit -J387- (without Autolock function) | |
| | | | | Rear left door control unit -J388- (without Autolock function) | |
| | | | | Rear right door control unit -J389- (without Autolock function) | |
F30 | - | Fuse 30 on fuse holder B -SB30- | 50 A | - | X-contact relief relay -J59- | 30 |
No. | | Current Flow Diagram designation | Nominal value | | Function/component | Terminal |
F1 | - | Fuse 1 on fuse holder B -SB1- | 30 A | - | Driver side wiper motor control unit, front passenger side -J584- | 30 |
F2 | - | Fuse 2 on fuse holder B -SB2- | - | - | Vacant | |
F3 | - | Fuse 3 on fuse holder B -SB3- | 5 A | - | Onboard supply control unit -J519- (via F/7) | 30 |
F4 | - | Fuse 4 on fuse holder B -SB4- | 20 A | - | ABS control unit -J104- | 30 |
F5 | - | Fuse 5 on fuse holder B -SB5- | 15 A | - | Mechatronic unit for dual clutch gearbox -J743- (AZV, BKD, BLS, BMM and BWA) | 30 |
F6 | - | Fuse 6 on fuse holder B -SB6- | 5 A | - | Control unit in dash panel insert -J285- | 30 |
| | | | | Steering column electronics control unit -J527- | |
F7 | - | Fuse 7 on fuse holder B -SB7- | 40 A | - | Terminal 15 voltage supply relay 2 -J681- | 30 |
F8 | - | Fuse 8 on fuse holder B -SB8- | 15 A | - | Control unit with display for radio and navigation system -J503- | 30 |
| | | | | Radio -R- | |
F9 | - | Fuse 9 on fuse holder B -SB9- | 5 A | - | Telephone transmitter and receiver unit -R36- | 30 |
| | | | | Navigation system interface -R94- (Tom-Tom Navigator) | |
F10 | - | Fuse 10 on fuse holder B -SB10- | 5 A | - | Motronic control unit -J220- (BVY and BVZ) | 30 |
| | | | | Main relay -J271- (BVY, BVZ and CAXC) | |
| | | | | Terminal 30 voltage supply relay -J317- (AZV, BKC, BKD, BLS, BMM, BMN and BXE) | |
| | | | | Engine control unit -J623- (CAXC) | |
| | | 10 A | - | Motronic control unit -J220- (BWA) | |
| | | | | Main relay -J271- (BWA and BZB) | |
| | | | | Terminal 30 voltage supply relay -J317- (BXW) | |
| | | | | Catalytic converter monitor 1 -J357- (BXW) | |
| | | | | Engine control unit -J623- (BZB) | |
F11 | - | Fuse 11 on fuse holder B -SB11- | - | - | Vacant | |
F12 | - | Fuse 12 on fuse holder B -SB12- | 5 A | - | Data bus diagnostic interface -J533- | 30 |
F13 | - | Fuse 13 on fuse holder B -SB13- | 15 A | - | Motronic control unit -J220- (BVY, BVZ and BWA) | 87 |
| | | | | Simos control unit -J361- (BSE, BSF and CCSA) | |
| | | | | 4HV injection system control unit -J537- (BXW) | |
| | | | | Engine control unit -J623- (BZB and CAXC) | |
| | | 30 A | - | Diesel direct injection system control unit -J248- (AZV, BKC, BKD, BLS, BMM, BMN and BXE) | |
F14 | - | Fuse 14 on fuse holder B -SB14- | 20 A | - | Ignition coil 1 with output stage -N70- (BVY, BVZ, BWA, BXW, BZB and CAXC) | 87 |
| | | | | Ignition coil 2 with output stage -N127- (BVY, BVZ, BWA, BXW, BZB and CAXC) | |
| | | | | Ignition transformer -N152- (BSE, BSF and CCSA) | |
| | | | | Ignition coil 3 with output stage -N291- (BVY, BVZ, BWA, BXW, BZB and CAXC) | |
| | | | | Ignition coil 4 with output stage -N292- (BVY, BVZ, BWA, BXW, BZB and CAXC) | |
F15 | - | Fuse 15 on fuse holder B -SB15- | 5 A | - | Fuel pump relay -J17- (AZV, BKC, BKD, BLS, BMM, BMN and BXE) | 87 |
| | | | | Automatic glow period control unit -J179- (AZV, BKC, BKD, BLS, BMM, BMN and BXE) | |
| | | | | Low heat output relay -J359- | |
| | | | | High heat output relay -J360- | |
| | | 10 A | - | Injector, cylinder 1 -N30- (BXW) | |
| | | | | Injector, cylinder 2 -N31- (BXW) | |
| | | | | Injector, cylinder 3 -N32- (BXW) | |
| | | | | Injector, cylinder 4 -N33- (BXW) | |
| | | | | Circulation pump relay -J160- (BWA) | |
| | | | | Lambda probe heater -Z19- (CAXC) | |
| | | | | Lambda probe 1 heater after catalytic converter -Z29- (BVY, BVZ and CAXC) | |
| | | | | Lambda probe 2 heater after catalytic converter -Z30- (BVY) | |
| | | | | Lambda probe 3 heater after catalytic converter -Z64- (BVY) | |
F16 | - | Fuse 16 on fuse holder B -SB16- | 30 A | - | ABS control unit -J104- (via A/1) | 30 |
F17 | - | Fuse 17 on fuse holder B -SB17- | 15 A | - | Onboard supply control unit -J519- (via J/3) | 30 |
F18 | - | Fuse 18 on fuse holder B -SB18- | - | - | Vacant | |
F19 | - | Fuse 19 on fuse holder B -SB19- | 30 A | - | Wiper motor control unit -J400- | 30 |
F20 | - | Fuse 20 on fuse holder B -SB20- | 10 A | - | Coolant circulation pump -V50- (CAXC) | 87 |
| | | 20 A | - | Fuel pressure regulating valve -N276- (BZB) | |
F21 | - | Fuse 21 on fuse holder B -SB21- | 10 A | - | Lambda probe heater -Z19- (BLS, BMM and BMN) | 87 |
| | | 15 A | - | Lambda probe heater -Z19- (BVY, BVZ and BZB) | |
| | | | | Lambda probe -G39- (BSE, BSF, BXW and CCSA) | |
| | | | | Lambda probe after catalytic converter -G130- (BSE, BSF, BXW and CCSA) | |
F22 | - | Fuse 22 on fuse holder B -SB22- | 5 A | - | Clutch position sender -G476- | 87 |
F23 | - | Fuse 23 on fuse holder B -SB23- | 5 A | - | Continued coolant circulation relay -J151- (BZB) | 87 |
| | | | | Circulation pump relay -J160- (BWA) | |
| | | | | Secondary air pump relay -J299- (BSE and CCSA) | |
| | | | | Motronic current supply relay -2- -J670- (BWA) | |
| | | 10 A | - | Exhaust gas recirculation valve -N18- (AZV, BKC, BKD and BXE) | |
| | | | | Charge pressure control solenoid valve -N75- (AZV, BKC, BKD, BLS, BMM, BMN and BXE) | |
| | | | | Intake manifold flap valve -N316- (BMN) | |
| | | | | Exhaust gas recirculation cooler change-over valve -N345- (AZV, BKC, BKD, BLS, BMM, BMN and BXE) | |
| | | 15 A | - | Fuel pressure regulating valve -N276- (BVY, BVZ and CAXC) | |
F24 | - | Fuse 24 on fuse holder B -SB24- | 10 A | - | Additional coolant pump relay -J496- (CAXC) | 87 |
| | | | | Engine component current supply relay -J757- (BZB) | |
| | | | | Charge pressure control solenoid valve -N75- (BZB and CAXC) | |
| | | | | Activated charcoal filter system solenoid valve 1 -N80- (BSE, BSF, BVY, BVZ, BXW, BZB, CAXC and CCSA) | |
| | | | | Variable intake manifold change-over valve -N156- (BSE, BSF, BVY, BVZ and CCSA) | |
| | | | | Inlet camshaft control valve 1 -N205- (BVY, BVZ, BWA, BZB and CAXC) | |
| | | | | Turbocharger air recirculation valve -N249- (BZB and CAXC) | |
| | | | | Intake manifold flap valve -N316- (BZB) | |
| | | | | Radiator fan -V7- | |
| | | | | Intake manifold flap motor -V157- (AZV, BKC, BKD and BXE) | |
F25 | - | Fuse 25 on fuse holder B -SB25- | 40 A | - | ABS control unit -J104- | 30 |
F26 | - | Fuse 26 on fuse holder B -SB26- | 30 A | - | Onboard supply control unit -J519- (via D/1) | 30 |
F27 | - | Fuse 27 on fuse holder B -SB27- | 40 A | - | Secondary air pump motor -V101- (BSE and CCSA) | 87 |
| | | 50 A | - | Automatic glow period control unit -J179- (AZV, BKC, BKD, BLS, BMM, BMN and BXE) | 30 |
F28 | - | Fuse 28 on fuse holder B -SB28- | - | - | Vacant | |
F29 | - | Fuse 29 on fuse holder B -SB29- | 50 A | - | Driver door control unit -J386- (without Autolock function) | 30 |
| | | | | Front passenger door control unit -J387- (without Autolock function) | |
| | | | | Rear left door control unit -J388- (without Autolock function) | |
| | | | | Rear right door control unit -J389- (without Autolock function) | |
F30 | - | Fuse 30 on fuse holder B -SB30- | 50 A | - | X-contact relief relay -J59- | 30 |
No. | | Current Flow Diagram designation | Nominal value | | Function/component | Terminal |
1 | - | Fuse 1 on fuse holder C -SC1- | 5 A | - | Mobile telephone operating electronics control unit -J412- | 15 |
| | | | | Automatic anti-dazzle interior mirror -Y7- | |
2 | - | Fuse 2 on fuse holder C -SC2- | 5 A | - | Trailer detector control unit -J345- | 15 |
3 | - | Fuse 3 on fuse holder C -SC3- | 10 A | - | Heater/heat output switch -E16- | 15 |
| | | | | TCS and ESP button -E256- | |
| | | | | Reversing light switch -F4- | |
| | | | | High pressure sender -G65- | |
| | | | | Heated driver seat control unit -J131- | |
| | | | | Heated front passenger seat control unit -J132- | |
| | | | | Climatronic control unit -J255- | |
4 | - | | 10 A | - | Current supply relay for Simos control unit -J363- (BGU) | 15 |
| | | | | Fuel pump control unit -J538- (BLR and BLY) | |
| | | | | Diagnosis connection -U31- (T16/1) | |
5 | - | Fuse 5 on fuse holder C -SC5- | - | - | Vacant | |
6 | - | Fuse 6 on fuse holder C -SC6- | 5 A | - | Heated windscreen -Z2- | 15 |
7 | - | Fuse 7 on fuse holder C -SC7- | 5 A | - | Heater/heat output switch -E16- | 75 |
| | | | | Climatronic control unit -J255- | |
| | | | | Air conditioning system control unit -J301- | |
8 | - | Fuse 8 on fuse holder C -SC8- | 5 A | - | Left washer jet heater element -Z20- | 75 |
| | | | | Right washer jet heater element -Z21- | |
9 | - | Fuse 9 on fuse holder C -SC9- | 5 A | - | Airbag control unit -J234- | 15 |
| | | | | Front passenger side airbag deactivated warning lamp -K145- | |
10 | - | Fuse 10 on fuse holder C -SC10- | - | - | Vacant | |
11 | - | Fuse 11 on fuse holder C -SC11- | 10 A | - | Selector lever -E313- (AZV and BKD) | 15 |
| | | | | Tiptronic switch -F189- (BLR and BLY) | |
| | | | | Engine control unit -J623- | |
| | | | | Terminal 30 voltage supply relay -J317- (BGU) | |
| | | | | Power steering control unit -J500- | |
| | | | | Data bus diagnostic interface -J533- | |
| | | | | Selector lever sensors control unit -J587- (AZV and BKD) | |
| | | | | Mechatronic unit for dual clutch gearbox -J743- (AZV and BKD) | |
12 | - | Fuse 12 on fuse holder C -SC12- | 5 A | - | Headlight range control regulator -E102- | 15 |
| | | | | Left headlight range control motor -V48- | |
| | | | | Right headlight range control motor -V49- | |
13 | - | Fuse 13 on fuse holder C -SC13- | 10 A | - | Air mass meter -G70- | 15 |
14 | - | Fuse 14 on fuse holder C -SC14- | 5 A | - | ABS control unit -J104- | 15 |
15 | - | Fuse 15 on fuse holder C -SC15- | - | - | Vacant | |
16 | - | Fuse 16 on fuse holder C -SC16- | 10 A | - | Intake manifold preheating heater element -N51- | 15 |
17 | - | Fuse 17 on fuse holder C -SC17- | - | - | Vacant | |
18 | - | Fuse 18 on fuse holder C -SC18- | - | - | Vacant | |
19 | - | Fuse 19 on fuse holder C -SC19- | - | - | Vacant | |
20 | - | Fuse 20 on fuse holder C -SC20- | 5 A | - | Parking aid control unit -J446- | 30 |
21 | - | Fuse 21 on fuse holder C -SC21- | 5 A | - | Selector lever -E313- (AZV, BKD, BLR and BLY) | 30 |
| - | | | | Selector lever sensors control unit -J587- (AZV, BKD, BLR and BLY) | |
22 | - | Fuse 22 on fuse holder C -SC22- | - | - | Vacant | |
23 | - | Fuse 23 on fuse holder C -SC23- | 10 A | - | Brake light switch -F- | 30 |
24 | - | Fuse 24 on fuse holder C -SC24- | 10 A | - | Light switch -E1- | 30 |
| | | | | Heater/heat output switch -E16- | |
| | | | | Climatronic control unit -J255- | |
| | | | | Air conditioning system control unit -J301- | |
| | | | | Diagnosis connection -U31- (T16/16) | |
25 | - | Fuse 25 on fuse holder C -SC25- | 20 A | - | Ignition coil 1 with output stage -N70- (BLR and BLY) | 15 |
| | | | | Ignition coil 2 with output stage -N127- (BLR and BLY) | |
| | | | | Ignition coil 3 with output stage -N291- (BLR and BLY) | |
| | | | | Ignition coil 4 with output stage -N292- (BLR and BLY) | |
26 | - | Fuse 26 on fuse holder C -SC26- | 20 A | - | Multifunction switch -F125- (BLR and BLY) | 15 |
| | | | | Automatic gearbox control unit -J217- (BLR and BLY) | |
27 | - | Fuse 27 on fuse holder C -SC27- | 20 A | - | Vacuum pump relay -J57- (BLR and BLY) | 15 |
28 | - | Fuse 28 on fuse holder C -SC28- | 5 A | - | Light switch -E1- | 75 |
29 | - | Fuse 29 on fuse holder C -SC29- | 15 A | - | Rear window wiper motor -V12- | 75 |
30 | - | Fuse 30 on fuse holder C -SC30- | - | - | Vacant | |
31 | - | Fuse 31 on fuse holder C -SC31- | - | - | Vacant | |
32 | - | Fuse 32 on fuse holder C -SC32- | 15 A | - | Onboard supply control unit -J519- | 75 |
33 | - | Fuse 33 on fuse holder C -SC33- | - | - | Vacant | |
34 | - | Fuse 34 on fuse holder C -SC34- | - | - | Vacant | |
35 | - | Fuse 35 on fuse holder C -SC35- | 40 A | - | Fresh air blower -V2- (not for Climatronic) | 75 |
36 | - | Fuse 36 on fuse holder C -SC36- | 40 A | - | Terminal 50 voltage supply relay -J682- | 15 |
37 | - | Fuse 37 on fuse holder C -SC37- | - | - | Vacant | |
38 | - | Fuse 38 on fuse holder C -SC38- | - | - | Vacant | |
39 | - | Fuse 39 on fuse holder C -SC39- | 15 A | - | Trailer detector control unit -J345- | 30 |
40 | - | Fuse 40 on fuse holder C -SC40- | 20 A | - | Trailer detector control unit -J345- | 30 |
41 | - | Fuse 41 on fuse holder C -SC41- | 20 A | - | Trailer detector control unit -J345- | 30 |
42 | - | Fuse 42 on fuse holder C -SC42- | 15 A | - | 12 V socket -U5- | 30 |
| | | 30 A | - | 12 V socket -U5- | |
| | | | | 12 V socket 2 -U18- | |
43 | - | Fuse 43 on fuse holder C -SC43- | 15 A | - | Fuel pump control unit -J538- (BLR and BLY) | 30 |
| | | | | Fuel pump relay -J17- (AZV, BGU, BJB, BKC and BKD) | |
| | | | | Fuel system pressurisation pump -G6- | |
44 | - | Fuse 44 on fuse holder C -SC44- | 5 A | - | Interior monitoring sensor -G273- | 30 |
| | | | | Alarm horn -H12- | |
45 | - | Fuse 45 on fuse holder C -SC45- | - | - | Vacant | |
46 | - | Fuse 46 on fuse holder C -SC46- | 7,5 A | - | Onboard supply control unit -J519- | 30 |
47 | - | Fuse 47 on fuse holder C -SC47- | 25 A | - | Cigarette lighter -U1- | 30 |
48 | - | Fuse 48 on fuse holder C -SC48- | 20 A | - | Headlight washer system relay -J39- | 30 |
| | | | | Headlight washer system pump -V11- | |
49 | - | Fuse 49 on fuse holder C -SC49- | 10 A | - | Driver door control unit -J386- | 30 |
| | | | | Front passenger door control unit -J387- | |
50 | - | Fuse 50 on fuse holder C -SC50- | 30 A | - | Heated driver seat control unit -J131- | 30 |
| | | | | Heated front passenger seat control unit -J132- | |
51 | - | Fuse 51 on fuse holder C -SC51- | 20 A | - | Sliding sunroof adjustment control unit -J245- | 30 |
52 | - | Fuse 52 on fuse holder C -SC52- | 25 A | - | Heated rear window -Z1- | 30 |
53 | - | Fuse 53 on fuse holder C -SC53- | 25 A | - | Convenience system central control unit -J393- | 30 |
54 | - | Fuse 54 on fuse holder C -SC54- | 5 A | - | ABS control unit -J104- (BLR and BLY) | 30 |
| | | | | Automatic gearbox control unit -J217- (BLR and BLY) | |
55 | - | Fuse 55 on fuse holder C -SC55- | - | - | Vacant | |
56 | - | Fuse 56 on fuse holder C -SC56- | 40 A | - | Fresh air blower -V2- (Climatronic only) | 30 |
57 | - | Fuse 57 on fuse holder C -SC57- | - | - | Vacant | |
58 | - | Fuse 58 on fuse holder C -SC58- | - | - | Vacant | |
No. | | Current Flow Diagram designation | Nominal value | | Function/component | Terminal |
1 | - | Fuse 1 on fuse holder C -SC1- | 5 A | - | Automatic anti-dazzle interior mirror -Y7- | 15 |
2 | - | Fuse 2 on fuse holder C -SC2- | 5 A | - | Motronic control unit -J220- | 15 |
| | | | | Diesel direct injection system control unit -J248- | |
| | | | | Terminal 30 voltage supply relay -J317- | |
| | | | | Simos control unit -J361- | |
| | | | | Current supply relay for Simos control unit -J363- | |
| | | | | Data bus diagnostic interface -J533- | |
3 | - | Fuse 3 on fuse holder C -SC3- | 5 A | - | Headlight range control regulator -E102- | 15 |
| | | | | Headlight range control, control unit -J431- | |
| | | | | Left headlight range control motor -V48- | |
| | | | | Right headlight range control motor -V49- | |
4 | - | | 5 A | - | Mobile telephone operating electronics control unit -J412- | 15 |
5 | - | Fuse 5 on fuse holder C -SC5- | 10 A | - | Air mass meter -G70- | 15 |
| | | | | Intake manifold preheating heater element -N51- | |
6 | - | Fuse 6 on fuse holder C -SC6- | 5 A | - | Airbag control unit -J234- | 15 |
| | | | | Front passenger side airbag deactivated warning lamp -K145- | |
7 | - | Fuse 7 on fuse holder C -SC7- | - | - | Vacant | |
8 | - | Fuse 8 on fuse holder C -SC8- | - | - | Vacant | |
9 | - | Fuse 9 on fuse holder C -SC9- | 10 A | - | Power steering control unit -J500- | 15 |
10 | - | Fuse 10 on fuse holder C -SC10- | 10 A | - | Diagnosis connection -U31- (T16/16) | 15 |
| | | | | Reversing light switch -F4- | |
11 | - | Fuse 11 on fuse holder C -SC11- | 5 A | - | Heated windscreen -Z2- | 15 |
12 | - | Fuse 12 on fuse holder C -SC12- | 10 A | - | Fuel pump control unit -J538- | 15 |
13 | - | Fuse 13 on fuse holder C -SC13- | 5 A | - | Trailer detector control unit -J345- | 15 |
14 | - | Fuse 14 on fuse holder C -SC14- | 5 A | - | Tyre pressure monitor button -E226- | 15 |
| | | | | TCS and ESP button -E256- | |
| | | | | ABS control unit -J104- | |
15 | - | Fuse 15 on fuse holder C -SC15- | 5 A | - | Selector lever -E313- (AZV and BKD) | 15 |
| | | | | Tiptronic switch -F189- (BLR and BLY) | |
| | | | | Mechatronic unit for dual clutch gearbox -J743- | |
16 | - | Fuse 16 on fuse holder C -SC16- | 10 A | - | Heater/heat output switch -E16- | 15 |
| | | | | High pressure sender -G65- | |
| | | | | Heated driver seat control unit -J131- | |
| | | | | Heated front passenger seat control unit -J132- | |
| | | | | Climatronic control unit -J255- | |
| | | | | Dash panel insert -K- | |
17 | - | Fuse 17 on fuse holder C -SC17- | - | - | Vacant | |
18 | - | Fuse 18 on fuse holder C -SC18- | - | - | Vacant | |
19 | - | Fuse 19 on fuse holder C -SC19- | - | - | Vacant | |
20 | - | Fuse 20 on fuse holder C -SC20- | 5 A | - | ABS control unit -J104- (BLR and BLY) | 30 |
| | | | | Automatic gearbox control unit -J217- (BLR and BLY) | |
21 | - | Fuse 21 on fuse holder C -SC21- | 5 A | - | Selector lever -E313- (AZV and BKD) | 30 |
| - | | | | Selector lever sensors control unit -J587- (BLR and BLY) | |
22 | - | Fuse 22 on fuse holder C -SC22- | - | - | Vacant | |
23 | - | Fuse 23 on fuse holder C -SC23- | 10 A | - | Brake light switch -F- | 30 |
24 | - | Fuse 24 on fuse holder C -SC24- | 10 A | - | Diagnosis connection -U31- (T16/16) | 30 |
| | | | | Light switch -E1- | |
| | | | | Heater/heat output switch -E16- | |
| | | | | Climatronic control unit -J255- | |
| | | | | Air conditioning system control unit -J301- | |
| | | | | Rain and light detector sensor -G397- | |
25 | - | Fuse 25 on fuse holder C -SC25- | 20 A | - | Vacuum pump relay -J57- (BLR and BLY) | 15 |
26 | - | Fuse 26 on fuse holder C -SC26- | 10 A | - | Injector, cylinder 1 -N30- (BSE and BSF) | 15 |
| | | | | Injector, cylinder 2 -N31- (BSE and BSF) | |
| | | | | Injector, cylinder 3 -N32- (BSE and BSF) | |
| | | | | Injector, cylinder 4 -N33- (BSE and BSF) | |
27 | - | Fuse 27 on fuse holder C -SC27- | 20 A | - | Multifunction switch -F125- (BLR and BLY) | 15 |
| | | | | Automatic gearbox control unit -J217- (BLR and BLY) | |
28 | - | Fuse 28 on fuse holder C -SC28- | 5 A | - | Light switch -E1- | 75 |
29 | - | Fuse 29 on fuse holder C -SC29- | 15 A | - | Rear window wiper motor -V12- | 75 |
30 | - | Fuse 30 on fuse holder C -SC30- | 5 A | - | Heater/heat output switch -E16- | 75 |
| | | | | Climatronic control unit -J255- | |
| | | | | Air conditioning system control unit -J301- | |
31 | - | Fuse 31 on fuse holder C -SC31- | 15 A | - | Onboard supply control unit -J519- | 75 |
32 | - | Fuse 32 on fuse holder C -SC32- | 5 A | - | Left washer jet heater element -Z20- | 75 |
| | | | | Right washer jet heater element -Z21- | |
33 | - | Fuse 33 on fuse holder C -SC33- | 40 A | - | Heater/heat output switch -E16- | 75 |
34 | - | Fuse 34 on fuse holder C -SC34- | - | - | Vacant | |
35 | - | Fuse 35 on fuse holder C -SC35- | - | - | Vacant | |
36 | - | Fuse 36 on fuse holder C -SC36- | - | - | Vacant | |
37 | - | Fuse 37 on fuse holder C -SC37- | - | - | Vacant | |
38 | - | Fuse 38 on fuse holder C -SC38- | - | - | Vacant | |
39 | - | Fuse 39 on fuse holder C -SC39- | 15 A | - | Trailer detector control unit -J345- | 30 |
40 | - | Fuse 40 on fuse holder C -SC40- | 20 A | - | Trailer detector control unit -J345- | 30 |
41 | - | Fuse 41 on fuse holder C -SC41- | 20 A | - | Trailer detector control unit -J345- | 30 |
42 | - | Fuse 42 on fuse holder C -SC42- | 15 A | - | 12 V socket -U5- | 30 |
| | | 30 A | - | 12 V socket -U5- | |
| | | | | 12 V socket 2 -U18- | |
43 | - | Fuse 43 on fuse holder C -SC43- | 15 A | - | Fuel pump relay -J17- (AZV, BJB, BKC, BKD, BLS, BSE and BSF) | 30 |
| | | | | Current supply relay for Simos control unit -J363- (BSE and BSF) | |
| | | | | Fuel pump control unit -J538- (BLR and BLY) | |
44 | - | Fuse 44 on fuse holder C -SC44- | 5 A | - | Interior monitoring sensor -G273- | 30 |
| | | | | Alarm horn -H12- | |
45 | - | Fuse 45 on fuse holder C -SC45- | 15 A | - | Taxi meter -G41- | 30 |
46 | - | Fuse 46 on fuse holder C -SC46- | 7,5 A | - | Onboard supply control unit -J519- | 30 |
47 | - | Fuse 47 on fuse holder C -SC47- | 25 A | - | Cigarette lighter -U1- | 30 |
48 | - | Fuse 48 on fuse holder C -SC48- | 30 A | - | Heated driver seat control unit -J131- | 30 |
| | | | | Heated front passenger seat control unit -J132- | |
49 | - | Fuse 49 on fuse holder C -SC49- | 10 A | - | Driver door control unit -J386- | 30 |
| | | | | Front passenger door control unit -J387- | |
50 | - | Fuse 50 on fuse holder C -SC50- | 25 A | - | Convenience system central control unit -J393- | 30 |
51 | - | Fuse 51 on fuse holder C -SC51- | 20 A | - | Sliding sunroof adjustment control unit -J245- | 30 |
52 | - | Fuse 52 on fuse holder C -SC52- | 25 A | - | Onboard supply control unit -J519- | 30 |
53 | - | Fuse 53 on fuse holder C -SC53- | 20 A | - | Headlight washer system relay -J39- | 30 |
54 | - | Fuse 54 on fuse holder C -SC54- | 5 A | - | Parking aid control unit -J446- | 30 |
55 | - | Fuse 55 on fuse holder C -SC55- | 5 A | - | Two-way radio socket -U4- | 30 |
56 | - | Fuse 56 on fuse holder C -SC56- | 40 A | - | Fresh air blower -V2- (Climatronic only) | 30 |
57 | - | Fuse 57 on fuse holder C -SC57- | 30 A | - | Driver door control unit -J386- | 30 |
| | | | | Front passenger door control unit -J387- | |
58 | - | Fuse 58 on fuse holder C -SC58- | 30 A | - | Rear left door control unit -J388- | 30 |
| | | | | Rear right door control unit -J389- | |
No. | | Current Flow Diagram designation | Nominal value | | Function/component | Terminal |
1 | - | Fuse 1 on fuse holder C -SC1- | 5 A | - | Automatic anti-dazzle interior mirror -Y7- | 15 |
2 | - | Fuse 2 on fuse holder C -SC2- | 5 A | - | Motronic control unit -J220- | 15 |
| | | | | Diesel direct injection system control unit -J248- | |
| | | | | Terminal 30 voltage supply relay -J317- | |
| | | | | Simos control unit -J361- | |
| | | | | Current supply relay for Simos control unit -J363- | |
| | | | | Data bus diagnostic interface -J533- | |
3 | - | Fuse 3 on fuse holder C -SC3- | 5 A | - | Headlight range control regulator -E102- | 15 |
| | | | | Headlight range control, control unit -J431- | |
| | | | | Left headlight range control motor -V48- | |
| | | | | Right headlight range control motor -V49- | |
4 | - | | 5 A | - | Mobile telephone operating electronics control unit -J412- | 15 |
5 | - | Fuse 5 on fuse holder C -SC5- | 10 A | - | Air mass meter -G70- | 15 |
| | | | | Intake manifold preheating heater element -N51- | |
6 | - | Fuse 6 on fuse holder C -SC6- | 5 A | - | Airbag control unit -J234- | 15 |
| | | | | Front passenger side airbag deactivated warning lamp -K145- | |
7 | - | Fuse 7 on fuse holder C -SC7- | - | - | Vacant | |
8 | - | Fuse 8 on fuse holder C -SC8- | - | - | Vacant | |
9 | - | Fuse 9 on fuse holder C -SC9- | 10 A | - | Power steering control unit -J500- | 15 |
10 | - | Fuse 10 on fuse holder C -SC10- | 10 A | - | Diagnosis connection -U31- (T16/16) | 15 |
| | | | | Reversing light switch -F4- | |
11 | - | Fuse 11 on fuse holder C -SC11- | 5 A | - | Heated windscreen -Z2- | 15 |
12 | - | Fuse 12 on fuse holder C -SC12- | 10 A | - | Fuel pump control unit -J538- | 15 |
13 | - | Fuse 13 on fuse holder C -SC13- | 5 A | - | Trailer detector control unit -J345- | 15 |
14 | - | Fuse 14 on fuse holder C -SC14- | 5 A | - | Tyre pressure monitor button -E226- | 15 |
| | | | | TCS and ESP button -E256- | |
| | | | | Brake light switch -F- | |
| | | | | ABS control unit -J104- | |
15 | - | Fuse 15 on fuse holder C -SC15- | 5 A | - | Selector lever -E313- (AZV and BKD) | 15 |
| | | | | Tiptronic switch -F189- (BVY and BVZ) | |
| | | | | Mechatronic unit for dual clutch gearbox -J743- | |
16 | - | Fuse 16 on fuse holder C -SC16- | 10 A | - | Heater/heat output switch -E16- | 15 |
| | | | | High pressure sender -G65- | |
| | | | | Heated driver seat control unit -J131- | |
| | | | | Heated front passenger seat control unit -J132- | |
| | | | | Climatronic control unit -J255- | |
| | | | | Dash panel insert -K- | |
17 | - | Fuse 17 on fuse holder C -SC17- | - | - | Vacant | |
18 | - | Fuse 18 on fuse holder C -SC18- | - | - | Vacant | |
19 | - | Fuse 19 on fuse holder C -SC19- | - | - | Vacant | |
20 | - | Fuse 20 on fuse holder C -SC20- | 5 A | - | ABS control unit -J104- (BVY and BVZ) | 30 |
| | | | | Automatic gearbox control unit -J217- (BVY and BVZ) | |
21 | - | Fuse 21 on fuse holder C -SC21- | 5 A | - | Selector lever -E313- (AZV and BKD) | 30 |
| - | | | | Tiptronic switch -F189- (BVY and BVZ) | |
22 | - | Fuse 22 on fuse holder C -SC22- | - | - | Vacant | |
23 | - | Fuse 23 on fuse holder C -SC23- | - | - | Vacant | |
24 | - | Fuse 24 on fuse holder C -SC24- | 10 A | - | Diagnosis connection -U31- (T16/16) | 30 |
| | | | | Light switch -E1- | |
| | | | | Heater/heat output switch -E16- | |
| | | | | Climatronic control unit -J255- | |
| | | | | Air conditioning system control unit -J301- | |
| | | | | Rain and light detector sensor -G397- | |
25 | - | Fuse 25 on fuse holder C -SC25- | 20 A | - | Vacuum pump relay -J57- (BVY and BVZ) | 15 |
26 | - | Fuse 26 on fuse holder C -SC26- | 10 A | - | Injector, cylinder 1 -N30- (BSE and BSF) | 15 |
| | | | | Injector, cylinder 2 -N31- (BSE and BSF) | |
| | | | | Injector, cylinder 3 -N32- (BSE and BSF) | |
| | | | | Injector, cylinder 4 -N33- (BSE and BSF) | |
27 | - | Fuse 27 on fuse holder C -SC27- | 20 A | - | Multifunction switch -F125- (BVY and BVZ) | 15 |
| | | | | Automatic gearbox control unit -J217- (BVY and BVZ) | |
28 | - | Fuse 28 on fuse holder C -SC28- | 5 A | - | Light switch -E1- | 75 |
29 | - | Fuse 29 on fuse holder C -SC29- | 15 A | - | Rear window wiper motor -V12- | 75 |
30 | - | Fuse 30 on fuse holder C -SC30- | 5 A | - | Heater/heat output switch -E16- | 75 |
| | | | | Climatronic control unit -J255- | |
| | | | | Air conditioning system control unit -J301- | |
31 | - | Fuse 31 on fuse holder C -SC31- | 15 A | - | Onboard supply control unit -J519- | 75 |
32 | - | Fuse 32 on fuse holder C -SC32- | 5 A | - | Left washer jet heater element -Z20- | 75 |
| | | | | Right washer jet heater element -Z21- | |
33 | - | Fuse 33 on fuse holder C -SC33- | 40 A | - | Heater/heat output switch -E16- | 75 |
34 | - | Fuse 34 on fuse holder C -SC34- | - | - | Vacant | |
35 | - | Fuse 35 on fuse holder C -SC35- | - | - | Vacant | |
36 | - | Fuse 36 on fuse holder C -SC36- | - | - | Vacant | |
37 | - | Fuse 37 on fuse holder C -SC37- | - | - | Vacant | |
38 | - | Fuse 38 on fuse holder C -SC38- | - | - | Vacant | |
39 | - | Fuse 39 on fuse holder C -SC39- | 15 A | - | Trailer detector control unit -J345- | 30 |
40 | - | Fuse 40 on fuse holder C -SC40- | 20 A | - | Trailer detector control unit -J345- | 30 |
41 | - | Fuse 41 on fuse holder C -SC41- | 20 A | - | Trailer detector control unit -J345- | 30 |
42 | - | Fuse 42 on fuse holder C -SC42- | 15 A | - | 12 V socket -U5- | 30 |
| | | 30 A | - | 12 V socket -U5- | |
| | | | | 12 V socket 2 -U18- | |
43 | - | Fuse 43 on fuse holder C -SC43- | 15 A | - | Fuel pump relay -J17- (AZV, BJB, BKC, BKD, BLS, BMM, BMN, BSE, BSF and BXE) | 30 |
| | | | | Current supply relay for Simos control unit -J363- (BSE and BSF) | |
| | | | | Fuel pump control unit -J538- (BVY and BVZ) | |
44 | - | Fuse 44 on fuse holder C -SC44- | 5 A | - | Interior monitoring sensor -G273- | 30 |
| | | | | Alarm horn -H12- | |
45 | - | Fuse 45 on fuse holder C -SC45- | 15 A | - | Taxi meter -G41- | 30 |
46 | - | Fuse 46 on fuse holder C -SC46- | 7,5 A | - | Onboard supply control unit -J519- | 30 |
47 | - | Fuse 47 on fuse holder C -SC47- | 25 A | - | Cigarette lighter -U1- | 30 |
48 | - | Fuse 48 on fuse holder C -SC48- | 30 A | - | Heated driver seat control unit -J131- | 30 |
| | | | | Heated front passenger seat control unit -J132- | |
49 | - | Fuse 49 on fuse holder C -SC49- | 10 A | - | Driver door control unit -J386- | 30 |
| | | | | Front passenger door control unit -J387- | |
50 | - | Fuse 50 on fuse holder C -SC50- | 25 A | - | Convenience system central control unit -J393- | 30 |
51 | - | Fuse 51 on fuse holder C -SC51- | 20 A | - | Sliding sunroof adjustment control unit -J245- | 30 |
52 | - | Fuse 52 on fuse holder C -SC52- | 25 A | - | Onboard supply control unit -J519- | 30 |
53 | - | Fuse 53 on fuse holder C -SC53- | 20 A | - | Headlight washer system relay -J39- | 30 |
54 | - | Fuse 54 on fuse holder C -SC54- | 5 A | - | Parking aid control unit -J446- | 30 |
55 | - | Fuse 55 on fuse holder C -SC55- | 5 A | - | Two-way radio socket -U4- | 30 |
56 | - | Fuse 56 on fuse holder C -SC56- | 40 A | - | Fresh air blower -V2- (Climatronic only) | 30 |
57 | - | Fuse 57 on fuse holder C -SC57- | 30 A | - | Driver door control unit -J386- | 30 |
| | | | | Front passenger door control unit -J387- | |
58 | - | Fuse 58 on fuse holder C -SC58- | 30 A | - | Rear left door control unit -J388- | 30 |
| | | | | Rear right door control unit -J389- | |
No. | | Current Flow Diagram designation | Nominal value | | Function/component | Terminal |
1 | - | Fuse 1 on fuse holder C -SC1- | - | - | Vacant | |
2 | - | Fuse 2 on fuse holder C -SC2- | - | - | Vacant | |
3 | - | Fuse 3 on fuse holder C -SC3- | - | - | Vacant | |
4 | - | Fuse 4 on fuse holder C -SC4- | - | - | Vacant | |
5 | - | Fuse 5 on fuse holder C -SC5- | - | - | Vacant | |
6 | - | Fuse 6 on fuse holder C -SC6- | - | - | Vacant | |
7 | - | Fuse 7 on fuse holder C -SC7- | - | - | Vacant | |
8 | - | Fuse 8 on fuse holder C -SC8- | - | - | Vacant | |
9 | - | Fuse 9 on fuse holder C -SC9- | 5 A | - | Airbag control unit -J234- | 15 |
| | | | | Front passenger side airbag deactivated warning lamp -K145- | |
10 | - | Fuse 10 on fuse holder C -SC10- | - | - | Vacant | |
11 | - | Fuse 11 on fuse holder C -SC11- | - | - | Vacant | |
12 | - | Fuse 12 on fuse holder C -SC12- | 10 A | - | Power output module for left headlight -J667- | 15 |
13 | - | Fuse 13 on fuse holder C -SC13- | 5 A | - | Heater/heat output switch -E16- | 15 |
| | | | | Tyre pressure monitor button -E226- | |
| | | | | TCS and ESP button -E256- | |
| | | | | Reversing light switch -F4- | |
| | | | | High pressure sender -G65- | |
| | | | | Climatronic control unit -J255- | |
| | | | | Air conditioning system control unit -J301- | |
| | | | | Mobile telephone operating electronics control unit -J412- | |
| | | | | Navigation system interface -R94- | |
| | | | | Automatic anti-dazzle interior mirror -Y7- | |
| | | | | Left washer jet heater element -Z20- | |
| | | | | Right washer jet heater element -Z21- | |
14 | - | Fuse 14 on fuse holder C -SC14- | 10 A | - | Light switch -E1- | 15 |
| | | | | Brake light switch -F- | |
| | | | | Tiptronic switch -F189- (BVY and BVZ) | |
| | | | | ABS control unit -J104- | |
| | | | | Motronic control unit -J220- (BVY, BVZ and BWA) | |
| | | | | Diesel direct injection system control unit -J248- (AZV, BKC, BKD, BLS, BMM, BMN and BXE) | |
| | | | | Terminal 30 voltage supply relay -J317- (BSE and BSF) | |
| | | | | Trailer detector control unit -J345- | |
| | | | | Simos control unit -J361- (BSE and BSF) | |
| | | | | Current supply relay for Simos control unit -J363- (BSE and BSF) | |
| | | | | Power steering control unit -J500- | |
| | | | | Data bus diagnostic interface -J533- | |
| | | | | 4HV injection system control unit -J537- (BXW) | |
| | | | | Fuel pump control unit -J538- (BVY, BVZ and BWA) | |
| | | | | Selector lever sensors control unit -J587- (AZV, BKD, BMM and BWA) | |
| | | | | Fuel supply relay -J643- (BXW) | |
| | | | | Mechatronic unit for dual clutch gearbox -J743- (AZV, BKD, BMM and BWA) | |
| | | | | Dash panel insert -K- | |
| | | | | Left headlight range control motor -V48- | |
| | | | | Right headlight range control motor -V49- | |
15 | - | Fuse 15 on fuse holder C -SC15- | 10 A | - | Diagnosis connection -U31- (T16/16) | 15 |
| | | | | Headlight range control regulator -E102- | |
| | | | | Air mass meter -G70- (AZV, BKC, BKD, BLS, BMM, BMN, BWA and BXE) | |
| | | | | Headlight range control, control unit -J431- | |
| | | | | Cornering light and headlight range control unit -J745- | |
| | | | | Intake manifold preheating heater element -N51- (AZV, BKC, BKD, BLS, BMM, BMN, BSE, BSF and BXE) | |
| | | | | Heater element for crankcase breather -N79- (BXW) | |
| | | | | Heated windscreen -Z2- | |
16 | - | Fuse 16 on fuse holder C -SC16- | 10 A | - | Power output module for right headlight -J668- | 15 |
17 | - | Fuse 17 on fuse holder C -SC17- | 10 A | - | Fuel pressure regulating valve -N276- (BWA) | 87 |
18 | - | Fuse 18 on fuse holder C -SC18- | - | - | Vacant | |
19 | - | Fuse 19 on fuse holder C -SC19- | - | - | Vacant | |
20 | - | Fuse 20 on fuse holder C -SC20- | 10 A | - | Heater/heat output switch -E16- | 30 |
| | | | | Tiptronic switch -F189- (BVY and BVZ) | |
| | | | | ABS control unit -J104- (BVY and BVZ) | |
| | | | | Automatic gearbox control unit -J217- (BVY and BVZ) | |
| | | | | Climatronic control unit -J255- | |
| | | | | Air conditioning system control unit -J301- | |
| | | | | Parking aid control unit -J446- | |
| | | | | Selector lever sensors control unit -J587- (AZV, BKD, BMM and BWA) | |
21 | - | Fuse 21 on fuse holder C -SC21- | 7,5 A | - | Onboard supply control unit -J519- (via K/5) | 30 |
22 | - | Fuse 22 on fuse holder C -SC22- | 5 A | - | Interior monitoring sensor -G273- | 30 |
| | | | | Alarm horn -H12- | |
23 | - | Fuse 23 on fuse holder C -SC23- | 10 A | - | Diagnosis connection -U31- (T16/16) | 30 |
| | | | | Light switch -E1- | |
| | | | | Rain and light detector sensor -G397- | |
24 | - | Fuse 24 on fuse holder C -SC24- | - | - | Vacant | |
25 | - | Fuse 25 on fuse holder C -SC25- | 20 A | - | Multifunction switch -F125- (BVY and BVZ) | 15 |
| | | | | Automatic gearbox control unit -J217- (BVY and BVZ) | |
26 | - | Fuse 26 on fuse holder C -SC26- | 20 A | - | Vacuum pump relay -J57- (BVY and BVZ) | 15 |
27 | - | Fuse 27 on fuse holder C -SC27- | - | - | Vacant | |
28 | - | Fuse 28 on fuse holder C -SC28- | 20 A | - | Onboard supply control unit -J519- (via J/1) | 75 |
| | | | | Rear window wiper motor -V12- | |
29 | - | Fuse 29 on fuse holder C -SC29- | - | - | Vacant | |
30 | - | Fuse 30 on fuse holder C -SC30- | 20 A | - | Cigarette lighter -U1- | 75 |
| | | | | 12 V socket -U5- | |
| | | | | 12 V socket 2 -U18- | |
31 | - | Fuse 31 on fuse holder C -SC31- | - | - | Vacant | |
32 | - | Fuse 32 on fuse holder C -SC32- | - | - | Vacant | |
33 | - | Fuse 33 on fuse holder C -SC33- | 40 A | - | Heater/heat output switch -E16- | 75 |
| | | | | Air conditioning system control unit -J301- | |
34 | - | Fuse 34 on fuse holder C -SC34- | - | - | Vacant | |
35 | - | Fuse 35 on fuse holder C -SC35- | - | - | Vacant | |
36 | - | Fuse 36 on fuse holder C -SC36- | 10 A | - | Lambda probe 1 heater after catalytic converter -Z29- (BWA) | 87 |
37 | - | Fuse 37 on fuse holder C -SC37- | 10 A | - | Lambda probe heater -Z19- (BWA) | 87 |
38 | - | Fuse 38 on fuse holder C -SC38- | 10 A | - | Charge pressure control solenoid valve -N75- (BWA) | 87 |
| | | | | Activated charcoal filter system solenoid valve 1 -N80- (BWA) | |
| | | | | Turbocharger air recirculation valve -N249- (BWA) | |
39 | - | Fuse 39 on fuse holder C -SC39- | 15 A | - | Trailer detector control unit -J345- | 30 |
40 | - | Fuse 40 on fuse holder C -SC40- | 20 A | - | Trailer detector control unit -J345- | 30 |
41 | - | Fuse 41 on fuse holder C -SC41- | 20 A | - | Trailer detector control unit -J345- | 30 |
42 | - | Fuse 42 on fuse holder C -SC42- | - | - | Vacant | |
43 | - | Fuse 43 on fuse holder C -SC43- | - | - | Vacant | |
44 | - | Fuse 44 on fuse holder C -SC44- | 25 A | - | Onboard supply control unit -J519- (via K/6) | 30 |
45 | - | Fuse 45 on fuse holder C -SC45- | 30 A | - | Driver door control unit -J386- | 30 |
| | | | | Front passenger door control unit -J387- | |
46 | - | Fuse 46 on fuse holder C -SC46- | 30 A | - | Rear left door control unit -J388- | 30 |
| | | | | Rear right door control unit -J389- | |
47 | - | Fuse 47 on fuse holder C -SC47- | 15 A | - | Fuel pump relay -J17- (AZV, BKC, BKD, BLS, BMM, BMN, BSE, BSF, BXE and BXW) | 30 |
| | | | | Current supply relay for Simos control unit -J363- (BSE and BSF) | |
| | | | | Fuel pump control unit -J538- (BVY, BVZ and BWA) | |
| | | | | Fuel supply relay -J643- (BXW) | |
| | | | | Motronic current supply relay -2- -J670- (BWA) | |
48 | - | Fuse 48 on fuse holder C -SC48- | 20 A | - | Convenience system central control unit -J393- | 30 |
49 | - | Fuse 49 on fuse holder C -SC49- | 40 A | - | Fresh air blower -V2- (Climatronic only) | 30 |
50 | - | Fuse 50 on fuse holder C -SC50- | 30 A | - | Heated front seats control unit -J774- | 30 |
51 | - | Fuse 51 on fuse holder C -SC51- | 20 A | - | Sliding sunroof adjustment control unit -J245- | 30 |
52 | - | Fuse 52 on fuse holder C -SC52- | 20 A | - | Headlight washer system relay -J39- | 30 |
53 | - | Fuse 53 on fuse holder C -SC53- | - | - | Vacant | |
54 | - | Fuse 54 on fuse holder C -SC54- | 5 A | - | Taxi meter -G41- | 30 |
55 | - | Fuse 55 on fuse holder C -SC55- | - | - | Vacant | |
56 | - | Fuse 56 on fuse holder C -SC56- | 15 A | - | Two-way radio socket -U4- | 30 |
57 | - | Fuse 57 on fuse holder C -SC57- | - | - | Vacant | |
58 | - | Fuse 58 on fuse holder C -SC58- | 30 A | - | Driver door control unit -J386- | 30 |
| | | | | Front passenger door control unit -J387- | |
| | | | | Convenience system central control unit -J393- | |
No. | | Current Flow Diagram designation | Nominal value | | Function/component | Terminal |
1 | - | Fuse 1 on fuse holder C -SC1- | - | - | Vacant | |
2 | - | Fuse 2 on fuse holder C -SC2- | - | - | Vacant | |
3 | - | Fuse 3 on fuse holder C -SC3- | - | - | Vacant | |
4 | - | Fuse 4 on fuse holder C -SC4- | - | - | Vacant | |
5 | - | Fuse 5 on fuse holder C -SC5- | - | - | Vacant | |
6 | - | Fuse 6 on fuse holder C -SC6- | - | - | Vacant | |
7 | - | Fuse 7 on fuse holder C -SC7- | - | - | Vacant | |
8 | - | Fuse 8 on fuse holder C -SC8- | - | - | Vacant | |
9 | - | Fuse 9 on fuse holder C -SC9- | 5 A | - | Airbag control unit -J234- | 15 |
| | | | | Front passenger side airbag deactivated warning lamp -K145- | |
10 | - | Fuse 10 on fuse holder C -SC10- | - | - | Vacant | |
11 | - | Fuse 11 on fuse holder C -SC11- | - | - | Vacant | |
12 | - | Fuse 12 on fuse holder C -SC12- | 10 A | - | Power output module for left headlight -J667- | 15 |
13 | - | Fuse 13 on fuse holder C -SC13- | 5 A | - | Heater/heat output switch -E16- | 15 |
| | | | | Tyre pressure monitor button -E226- | |
| | | | | TCS and ESP button -E256- | |
| | | | | Reversing light switch -F4- | |
| | | | | High pressure sender -G65- | |
| | | | | Climatronic control unit -J255- | |
| | | | | Air conditioning system control unit -J301- | |
| | | | | Mobile telephone operating electronics control unit -J412- | |
| | | | | Navigation system interface -R94- | |
| | | | | Automatic anti-dazzle interior mirror -Y7- | |
| | | | | Left washer jet heater element -Z20- | |
| | | | | Right washer jet heater element -Z21- | |
14 | - | Fuse 14 on fuse holder C -SC14- | 10 A | - | Light switch -E1- | 15 |
| | | | | Brake light switch -F- | |
| | | | | Tiptronic switch -F189- (BVY and BVZ) | |
| | | | | ABS control unit -J104- | |
| | | | | Motronic control unit -J220- (BVY, BVZ and BWA) | |
| | | | | Diesel direct injection system control unit -J248- (AZV, BKC, BKD, BLS, BMM, BMN and BXE) | |
| | | | | Terminal 30 voltage supply relay -J317- (BSE and BSF) | |
| | | | | Trailer detector control unit -J345- | |
| | | | | Simos control unit -J361- (BSE and BSF) | |
| | | | | Current supply relay for Simos control unit -J363- (BSE and BSF) | |
| | | | | Power steering control unit -J500- | |
| | | | | Data bus diagnostic interface -J533- | |
| | | | | 4HV injection system control unit -J537- (BXW) | |
| | | | | Fuel pump control unit -J538- (BVY, BVZ and BWA) | |
| | | | | Selector lever sensors control unit -J587- (AZV, BKD, BMM and BWA) | |
| | | | | Fuel supply relay -J643- (BXW) | |
| | | | | Mechatronic unit for dual clutch gearbox -J743- (AZV, BKD, BMM and BWA) | |
| | | | | Dash panel insert -K- | |
| | | | | Left headlight range control motor -V48- | |
| | | | | Right headlight range control motor -V49- | |
15 | - | Fuse 15 on fuse holder C -SC15- | 10 A | - | Diagnosis connection -U31- (T16/11) | 15 |
| | | | | Headlight range control regulator -E102- | |
| | | | | Air mass meter -G70- (AZV, BKC, BKD, BLS, BMM, BMN, BWA and BXE) | |
| | | | | Headlight range control, control unit -J431- | |
| | | | | Cornering light and headlight range control unit -J745- | |
| | | | | Intake manifold preheating heater element -N51- (AZV, BKC, BKD, BLS, BMM, BMN, BSE, BSF and BXE) | |
| | | | | Heater element for crankcase breather -N79- (BXW) | |
| | | | | Heated windscreen -Z2- | |
16 | - | Fuse 16 on fuse holder C -SC16- | 10 A | - | Power output module for right headlight -J668- | 15 |
17 | - | Fuse 17 on fuse holder C -SC17- | 10 A | - | Fuel pressure regulating valve -N276- (BWA) | 87 |
18 | - | Fuse 18 on fuse holder C -SC18- | - | - | Vacant | |
19 | - | Fuse 19 on fuse holder C -SC19- | - | - | Vacant | |
20 | - | Fuse 20 on fuse holder C -SC20- | 10 A | - | Heater/heat output switch -E16- | 30 |
| | | | | Tiptronic switch -F189- (BVY and BVZ) | |
| | | | | ABS control unit -J104- (BVY and BVZ) | |
| | | | | Automatic gearbox control unit -J217- (BVY and BVZ) | |
| | | | | Climatronic control unit -J255- | |
| | | | | Air conditioning system control unit -J301- | |
| | | | | Parking aid control unit -J446- | |
| | | | | Selector lever sensors control unit -J587- (AZV, BKD, BMM and BWA) | |
21 | - | Fuse 21 on fuse holder C -SC21- | 7,5 A | - | Onboard supply control unit -J519- (via K/5) | 30 |
22 | - | Fuse 22 on fuse holder C -SC22- | 5 A | - | Interior monitoring sensor -G273- | 30 |
| | | | | Alarm horn -H12- | |
23 | - | Fuse 23 on fuse holder C -SC23- | 10 A | - | Diagnosis connection -U31- (T16/16) | 30 |
| | | | | Light switch -E1- | |
| | | | | Rain and light detector sensor -G397- | |
24 | - | Fuse 24 on fuse holder C -SC24- | - | - | Vacant | |
25 | - | Fuse 25 on fuse holder C -SC25- | 20 A | - | Multifunction switch -F125- (BVY and BVZ) | 15 |
| | | | | Automatic gearbox control unit -J217- (BVY and BVZ) | |
26 | - | Fuse 26 on fuse holder C -SC26- | 20 A | - | Vacuum pump relay -J57- (BVY and BVZ) | 15 |
27 | - | Fuse 27 on fuse holder C -SC27- | - | - | Vacant | |
28 | - | Fuse 28 on fuse holder C -SC28- | 20 A | - | Onboard supply control unit -J519- (via J/1) | 75 |
| | | | | Rear window wiper motor -V12- | |
29 | - | Fuse 29 on fuse holder C -SC29- | - | - | Vacant | |
30 | - | Fuse 30 on fuse holder C -SC30- | 20 A | - | Cigarette lighter -U1- | 75 |
| | | | | 12 V socket -U5- | |
| | | | | 12 V socket 2 -U18- | |
31 | - | Fuse 31 on fuse holder C -SC31- | - | - | Vacant | |
32 | - | Fuse 32 on fuse holder C -SC32- | - | - | Vacant | |
33 | - | Fuse 33 on fuse holder C -SC33- | 40 A | - | Heater/heat output switch -E16- | 75 |
| | | | | Air conditioning system control unit -J301- | |
34 | - | Fuse 34 on fuse holder C -SC34- | - | - | Vacant | |
35 | - | Fuse 35 on fuse holder C -SC35- | - | - | Vacant | |
36 | - | Fuse 36 on fuse holder C -SC36- | 10 A | - | Lambda probe 1 heater after catalytic converter -Z29- (BWA) | 87 |
37 | - | Fuse 37 on fuse holder C -SC37- | 10 A | - | Lambda probe heater -Z19- (BWA) | 87 |
38 | - | Fuse 38 on fuse holder C -SC38- | 10 A | - | Charge pressure control solenoid valve -N75- (BWA) | 87 |
| | | | | Activated charcoal filter system solenoid valve 1 -N80- (BWA) | |
| | | | | Turbocharger air recirculation valve -N249- (BWA) | |
39 | - | Fuse 39 on fuse holder C -SC39- | 15 A | - | Trailer detector control unit -J345- | 30 |
40 | - | Fuse 40 on fuse holder C -SC40- | 20 A | - | Trailer detector control unit -J345- | 30 |
41 | - | Fuse 41 on fuse holder C -SC41- | 20 A | - | Trailer detector control unit -J345- | 30 |
42 | - | Fuse 42 on fuse holder C -SC42- | - | - | Vacant | |
43 | - | Fuse 43 on fuse holder C -SC43- | 40 A | - | Trailer detector control unit -J345- | 30 |
44 | - | Fuse 44 on fuse holder C -SC44- | 25 A | - | Onboard supply control unit -J519- (via K/6) | 30 |
45 | - | Fuse 45 on fuse holder C -SC45- | 30 A | - | Driver door control unit -J386- | 30 |
| | | | | Front passenger door control unit -J387- | |
46 | - | Fuse 46 on fuse holder C -SC46- | 30 A | - | Rear left door control unit -J388- | 30 |
| | | | | Rear right door control unit -J389- | |
47 | - | Fuse 47 on fuse holder C -SC47- | 15 A | - | Fuel pump relay -J17- (AZV, BKC, BKD, BLS, BMM, BMN, BSE, BSF, BXE and BXW) | 30 |
| | | | | Current supply relay for Simos control unit -J363- (BSE and BSF) | |
| | | | | Fuel pump control unit -J538- (BVY, BVZ and BWA) | |
| | | | | Fuel supply relay -J643- (BXW) | |
| | | | | Motronic current supply relay -2- -J670- (BWA) | |
48 | - | Fuse 48 on fuse holder C -SC48- | 20 A | - | Convenience system central control unit -J393- | 30 |
49 | - | Fuse 49 on fuse holder C -SC49- | 40 A | - | Fresh air blower -V2- (Climatronic only) | 30 |
50 | - | Fuse 50 on fuse holder C -SC50- | 30 A | - | Heated front seats control unit -J774- | 30 |
51 | - | Fuse 51 on fuse holder C -SC51- | 20 A | - | Sliding sunroof adjustment control unit -J245- | 30 |
52 | - | Fuse 52 on fuse holder C -SC52- | 20 A | - | Headlight washer system relay -J39- | 30 |
53 | - | Fuse 53 on fuse holder C -SC53- | - | - | Vacant | |
54 | - | Fuse 54 on fuse holder C -SC54- | 5 A | - | Taxi meter -G41- | 30 |
55 | - | Fuse 55 on fuse holder C -SC55- | - | - | Vacant | |
56 | - | Fuse 56 on fuse holder C -SC56- | 15 A | - | Two-way radio socket -U4- | 30 |
57 | - | Fuse 57 on fuse holder C -SC57- | - | - | Vacant | |
58 | - | Fuse 58 on fuse holder C -SC58- | 30 A | - | Driver door control unit -J386- | 30 |
| | | | | Front passenger door control unit -J387- | |
| | | | | Convenience system central control unit -J393- | |
No. | | Current Flow Diagram designation | Nominal value | | Function/component | Terminal |
1 | - | Fuse 1 on fuse holder C -SC1- | - | - | Vacant | |
2 | - | Fuse 2 on fuse holder C -SC2- | - | - | Vacant | |
3 | - | Fuse 3 on fuse holder C -SC3- | - | - | Vacant | |
4 | - | Fuse 4 on fuse holder C -SC4- | - | - | Vacant | |
5 | - | Fuse 5 on fuse holder C -SC5- | - | - | Vacant | |
6 | - | Fuse 6 on fuse holder C -SC6- | - | - | Vacant | |
7 | - | Fuse 7 on fuse holder C -SC7- | - | - | Vacant | |
8 | - | Fuse 8 on fuse holder C -SC8- | - | - | Vacant | |
9 | - | Fuse 9 on fuse holder C -SC9- | 5 A | - | Airbag control unit -J234- | 15 |
| | | | | Front passenger side airbag deactivated warning lamp -K145- | |
10 | - | Fuse 10 on fuse holder C -SC10- | 10 A | - | Roof display unit -J702- (rear seats) | 15 |
11 | - | Fuse 11 on fuse holder C -SC11- | - | - | Vacant | |
12 | - | Fuse 12 on fuse holder C -SC12- | 10 A | - | Power output module for left headlight -J667- | 15 |
13 | - | Fuse 13 on fuse holder C -SC13- | 5 A | - | Heater/heat output switch -E16- | 15 |
| | | | | Tyre pressure monitor button -E226- | |
| | | | | TCS and ESP button -E256- | |
| | | | | Reversing light switch -F4- | |
| | | | | High pressure sender -G65- | |
| | | | | Climatronic control unit -J255- | |
| | | | | Air conditioning system control unit -J301- | |
| | | | | Navigation system interface -R94- (Tom-Tom Navigator) | |
| | | | | Automatic anti-dazzle interior mirror -Y7- | |
| | | | | Left washer jet heater element -Z20- | |
| | | | | Right washer jet heater element -Z21- | |
14 | - | Fuse 14 on fuse holder C -SC14- | 10 A | - | Light switch -E1- | 15 |
| | | | | Brake light switch -F- | |
| | | | | Tiptronic switch -F189- (BVY and BVZ) | |
| | | | | ABS control unit -J104- | |
| | | | | Motronic control unit -J220- (BVY, BVZ and BWA) | |
| | | | | Diesel direct injection system control unit -J248- (AZV, BKC, BKD, BLS, BMM, BMN and BXE) | |
| | | | | Terminal 30 voltage supply relay -J317- (BSE and BSF) | |
| | | | | Trailer detector control unit -J345- | |
| | | | | Simos control unit -J361- (BSE and BSF) | |
| | | | | Current supply relay for Simos control unit -J363- (BSE and BSF) | |
| | | | | Four-wheel drive control unit -J492- | |
| | | | | Power steering control unit -J500- | |
| | | | | Data bus diagnostic interface -J533- | |
| | | | | 4HV injection system control unit -J537- (BXW) | |
| | | | | Fuel pump control unit -J538- (BVY, BVZ, BWA and BZB) | |
| | | | | Selector lever sensors control unit -J587- (AZV, BKD, BLS, BMM and BWA) | |
| | | | | Engine control unit -J623- (BZB) | |
| | | | | Fuel supply relay -J643- (BXW) | |
| | | | | Mechatronic unit for dual clutch gearbox -J743- (AZV, BKD, BLS, BMM and BWA) | |
| | | | | Dash panel insert -K- | |
| | | | | Left headlight range control motor -V48- | |
| | | | | Right headlight range control motor -V49- | |
15 | - | Fuse 15 on fuse holder C -SC15- | 10 A | - | Diagnosis connection -U31- (T16/1) | 15 |
| | | | | Headlight range control regulator -E102- | |
| | | | | Air mass meter -G70- (AZV, BKC, BKD, BLS, BMM, BMN, BWA, BXE and BZB) | |
| | | | | Headlight range control, control unit -J431- | |
| | | | | Cornering light and headlight range control unit -J745- | |
| | | | | Intake manifold preheating heater element -N51- (AZV, BKC, BKD, BLS, BMM, BMN, BSE, BSF and BXE) | |
| | | | | Heater element for crankcase breather -N79- (BXW) | |
| | | | | Heated windscreen -Z2- | |
16 | - | Fuse 16 on fuse holder C -SC16- | 10 A | - | Power output module for right headlight -J668- | 15 |
17 | - | Fuse 17 on fuse holder C -SC17- | 10 A | - | Fuel pressure regulating valve -N276- (BWA) | 87 |
18 | - | Fuse 18 on fuse holder C -SC18- | - | - | Vacant | |
19 | - | Fuse 19 on fuse holder C -SC19- | - | - | Vacant | |
20 | - | Fuse 20 on fuse holder C -SC20- | 10 A | - | Heater/heat output switch -E16- | 30 |
| | | | | Tiptronic switch -F189- (BVY and BVZ) | |
| | | | | ABS control unit -J104- (BVY and BVZ) | |
| | | | | Automatic gearbox control unit -J217- (BVY and BVZ) | |
| | | | | Climatronic control unit -J255- | |
| | | | | Air conditioning system control unit -J301- | |
| | | | | Parking aid control unit -J446- | |
| | | | | Selector lever sensors control unit -J587- (AZV, BKD, BLS, BMM and BWA) | |
21 | - | Fuse 21 on fuse holder C -SC21- | 7,5 A | - | Onboard supply control unit -J519- (via K/5) | 30 |
22 | - | Fuse 22 on fuse holder C -SC22- | 5 A | - | Interior monitoring sensor -G273- | 30 |
| | | | | Alarm horn -H12- | |
23 | - | Fuse 23 on fuse holder C -SC23- | 10 A | - | Diagnosis connection -U31- (T16/16) | 30 |
| | | | | Light switch -E1- | |
| | | | | Rain and light detector sensor -G397- | |
24 | - | Fuse 24 on fuse holder C -SC24- | - | - | Vacant | |
25 | - | Fuse 25 on fuse holder C -SC25- | 20 A | - | Multifunction switch -F125- (BVY and BVZ) | 15 |
| | | | | Automatic gearbox control unit -J217- (BVY and BVZ) | |
26 | - | Fuse 26 on fuse holder C -SC26- | 20 A | - | Vacuum pump relay -J57- (BVY and BVZ) | 15 |
27 | - | Fuse 27 on fuse holder C -SC27- | - | - | Vacant | |
28 | - | Fuse 28 on fuse holder C -SC28- | 20 A | - | Onboard supply control unit -J519- (via J/1) | 75 |
| | | | | Rear window wiper motor -V12- | |
29 | - | Fuse 29 on fuse holder C -SC29- | - | - | Vacant | |
30 | - | Fuse 30 on fuse holder C -SC30- | 20 A | - | Cigarette lighter -U1- | 75 |
| | | | | 12 V socket -U5- | |
| | | | | 12 V socket 2 -U18- | |
31 | - | Fuse 31 on fuse holder C -SC31- | - | - | Vacant | |
32 | - | Fuse 32 on fuse holder C -SC32- | - | - | Vacant | |
33 | - | Fuse 33 on fuse holder C -SC33- | 40 A | - | Heater/heat output switch -E16- | 75 |
| | | | | Air conditioning system control unit -J301- | |
34 | - | Fuse 34 on fuse holder C -SC34- | - | - | Vacant | |
35 | - | Fuse 35 on fuse holder C -SC35- | - | - | Vacant | |
36 | - | Fuse 36 on fuse holder C -SC36- | 10 A | - | Lambda probe 1 heater after catalytic converter -Z29- (BWA) | 87 |
37 | - | Fuse 37 on fuse holder C -SC37- | 10 A | - | Lambda probe heater -Z19- (BWA) | 87 |
38 | - | Fuse 38 on fuse holder C -SC38- | 10 A | - | Charge pressure control solenoid valve -N75- (BWA) | 87 |
| | | | | Activated charcoal filter system solenoid valve 1 -N80- (BWA) | |
| | | | | Turbocharger air recirculation valve -N249- (BWA) | |
39 | - | Fuse 39 on fuse holder C -SC39- | 15 A | - | Trailer detector control unit -J345- | 30 |
40 | - | Fuse 40 on fuse holder C -SC40- | 20 A | - | Trailer detector control unit -J345- | 30 |
41 | - | Fuse 41 on fuse holder C -SC41- | 20 A | - | Trailer detector control unit -J345- | 30 |
42 | - | Fuse 42 on fuse holder C -SC42- | 10 A | - | Roof display unit -J702- (rear seats) | 30 |
43 | - | Fuse 43 on fuse holder C -SC43- | 40 A | - | Trailer detector control unit -J345- | 30 |
44 | - | Fuse 44 on fuse holder C -SC44- | 25 A | - | Onboard supply control unit -J519- (via K/6) | 30 |
45 | - | Fuse 45 on fuse holder C -SC45- | 30 A | - | Driver door control unit -J386- | 30 |
| | | | | Front passenger door control unit -J387- | |
46 | - | Fuse 46 on fuse holder C -SC46- | 30 A | - | Rear left door control unit -J388- | 30 |
| | | | | Rear right door control unit -J389- | |
47 | - | Fuse 47 on fuse holder C -SC47- | 15 A | - | Fuel pump relay -J17- (AZV, BKC, BKD, BLS, BMM, BMN, BSE, BSF, BXE and BXW) | 30 |
| | | | | Current supply relay for Simos control unit -J363- (BSE and BSF) | |
| | | | | Fuel pump control unit -J538- (BVY, BVZ, BWA and BZB) | |
| | | | | Fuel supply relay -J643- (BXW) | |
| | | | | Motronic current supply relay -2- -J670- (BWA) | |
48 | - | Fuse 48 on fuse holder C -SC48- | 20 A | - | Convenience system central control unit -J393- (without Autolock function) | 30 |
49 | - | Fuse 49 on fuse holder C -SC49- | 40 A | - | Fresh air blower -V2- (Climatronic only) | 30 |
50 | - | Fuse 50 on fuse holder C -SC50- | 30 A | - | Heated front seats control unit -J774- | 30 |
51 | - | Fuse 51 on fuse holder C -SC51- | 20 A | - | Sliding sunroof adjustment control unit -J245- | 30 |
52 | - | Fuse 52 on fuse holder C -SC52- | 20 A | - | Headlight washer system relay -J39- | 30 |
53 | - | Fuse 53 on fuse holder C -SC53- | - | - | Vacant | |
54 | - | Fuse 54 on fuse holder C -SC54- | 5 A | - | Taxi meter -G41- | 30 |
55 | - | Fuse 55 on fuse holder C -SC55- | - | - | Vacant | |
56 | - | Fuse 56 on fuse holder C -SC56- | 15 A | - | Two-way radio socket -U4- | 30 |
57 | - | Fuse 57 on fuse holder C -SC57- | - | - | Vacant | |
58 | - | Fuse 58 on fuse holder C -SC58- | 30 A | - | Driver door control unit -J386- | 30 |
| | | | | Front passenger door control unit -J387- | |
| | | | | Rear left door control unit -J388- | |
| | | | | Rear right door control unit -J389- | |
| | | | | Convenience system central control unit -J393- (with Autolock function) | |
No. | | Current Flow Diagram designation | Nominal value | | Function/component | Terminal |
1 | - | Fuse 1 on fuse holder C -SC1- | - | - | Vacant | |
2 | - | Fuse 2 on fuse holder C -SC2- | - | - | Vacant | |
3 | - | Fuse 3 on fuse holder C -SC3- | - | - | Vacant | |
4 | - | Fuse 4 on fuse holder C -SC4- | - | - | Vacant | |
5 | - | Fuse 5 on fuse holder C -SC5- | - | - | Vacant | |
6 | - | Fuse 6 on fuse holder C -SC6- | - | - | Vacant | |
7 | - | Fuse 7 on fuse holder C -SC7- | - | - | Vacant | |
8 | - | Fuse 8 on fuse holder C -SC8- | - | - | Vacant | |
9 | - | Fuse 9 on fuse holder C -SC9- | 5 A | - | Airbag control unit -J234- | 15 |
| | | | | Front passenger side airbag deactivated warning lamp -K145- | |
10 | - | Fuse 10 on fuse holder C -SC10- | 10 A | - | Roof display unit -J702- (rear seats) | 15 |
11 | - | Fuse 11 on fuse holder C -SC11- | - | - | Vacant | |
12 | - | Fuse 12 on fuse holder C -SC12- | 10 A | - | Power output module for left headlight -J667- | 15 |
13 | - | Fuse 13 on fuse holder C -SC13- | 5 A | - | Heater/heat output switch -E16- | 15 |
| | | | | Tyre pressure monitor button -E226- | |
| | | | | TCS and ESP button -E256- | |
| | | | | Reversing light switch -F4- | |
| | | | | High pressure sender -G65- | |
| | | | | Oil level and oil temperature sender -G266- (CAXC) | |
| | | | | Climatronic control unit -J255- | |
| | | | | Air conditioning system control unit -J301- | |
| | | | | Navigation system interface -R94- | |
| | | | | Automatic anti-dazzle interior mirror -Y7- | |
| | | | | Left washer jet heater element -Z20- | |
| | | | | Right washer jet heater element -Z21- | |
14 | - | Fuse 14 on fuse holder C -SC14- | 10 A | - | Light switch -E1- | 15 |
| | | | | Brake light switch -F- | |
| | | | | Tiptronic switch -F189- (BVY and BVZ) | |
| | | | | ABS control unit -J104- | |
| | | | | Motronic control unit -J220- (BVY, BVZ and BWA) | |
| | | | | Diesel direct injection system control unit -J248- (AZV, BKC, BKD, BLS, BMM, BMN and BXE) | |
| | | | | Terminal 30 voltage supply relay -J317- (BSE, BSF and CCSA) | |
| | | | | Trailer detector control unit -J345- | |
| | | | | Simos control unit -J361- (BSE, BSF and CCSA) | |
| | | | | Current supply relay for Simos control unit -J363- (BSE, BSF and CCSA) | |
| | | | | Four-wheel drive control unit -J492- | |
| | | | | Power steering control unit -J500- | |
| | | | | Data bus diagnostic interface -J533- | |
| | | | | 4HV injection system control unit -J537- (BXW) | |
| | | | | Fuel pump control unit -J538- (BVY, BVZ, BWA, BZB and CAXC) | |
| | | | | Selector lever sensors control unit -J587- (AZV, BKD, BLS, BMM and BWA) | |
| | | | | Engine control unit -J623- (BZB and CAXC) | |
| | | | | Fuel supply relay -J643- (BXW) | |
| | | | | Mechatronic unit for dual clutch gearbox -J743- (AZV, BKD, BLS, BMM and BWA) | |
| | | | | Dash panel insert -K- | |
| | | | | Left headlight range control motor -V48- | |
| | | | | Right headlight range control motor -V49- | |
15 | - | Fuse 15 on fuse holder C -SC15- | 10 A | - | Diagnosis connection -U31- (T16/1) | 15 |
| | | | | Headlight range control regulator -E102- | |
| | | | | Air mass meter -G70- (AZV, BKC, BKD, BLS, BMM, BMN, BWA, BXE and BZB) | |
| | | | | Headlight range control, control unit -J431- | |
| | | | | Cornering light and headlight range control unit -J745- | |
| | | | | Intake manifold preheating heater element -N51- (AZV, BKC, BKD, BLS, BMM, BMN, BSE, BSF, BXE and CCSA) | |
| | | | | Heater element for crankcase breather -N79- (BXW) | |
| | | | | Heated windscreen -Z2- | |
16 | - | Fuse 16 on fuse holder C -SC16- | 10 A | - | Power output module for right headlight -J668- | 15 |
17 | - | Fuse 17 on fuse holder C -SC17- | 10 A | - | Fuel pressure regulating valve -N276- (BWA) | 87 |
18 | - | Fuse 18 on fuse holder C -SC18- | - | - | Vacant | |
19 | - | Fuse 19 on fuse holder C -SC19- | - | - | Vacant | |
20 | - | Fuse 20 on fuse holder C -SC20- | 10 A | - | Heater/heat output switch -E16- | 30 |
| | | | | Tiptronic switch -F189- (BVY and BVZ) | |
| | | | | ABS control unit -J104- (BVY and BVZ) | |
| | | | | Automatic gearbox control unit -J217- (BVY and BVZ) | |
| | | | | Climatronic control unit -J255- | |
| | | | | Air conditioning system control unit -J301- | |
| | | | | Parking aid control unit -J446- | |
| | | | | Selector lever sensors control unit -J587- (AZV, BKD, BLS, BMM and BWA) | |
21 | - | Fuse 21 on fuse holder C -SC21- | 7,5 A | - | Onboard supply control unit -J519- (via K/5) | 30 |
22 | - | Fuse 22 on fuse holder C -SC22- | 5 A | - | Interior monitoring sensor -G273- | 30 |
| | | | | Alarm horn -H12- | |
23 | - | Fuse 23 on fuse holder C -SC23- | 10 A | - | Diagnosis connection -U31- (T16/16) | 30 |
| | | | | Light switch -E1- | |
| | | | | Rain and light detector sensor -G397- | |
24 | - | Fuse 24 on fuse holder C -SC24- | - | - | Vacant | |
25 | - | Fuse 25 on fuse holder C -SC25- | 20 A | - | Multifunction switch -F125- (BVY and BVZ) | 15 |
| | | | | Automatic gearbox control unit -J217- (BVY and BVZ) | |
26 | - | Fuse 26 on fuse holder C -SC26- | 20 A | - | Vacuum pump relay -J57- (BVY and BVZ) | 15 |
27 | - | Fuse 27 on fuse holder C -SC27- | 10 A | - | Roof display unit -J702- (rear seats) | 15 |
28 | - | Fuse 28 on fuse holder C -SC28- | 20 A | - | Onboard supply control unit -J519- (via J/1) | 75 |
| | | | | Rear window wiper motor -V12- | |
29 | - | Fuse 29 on fuse holder C -SC29- | - | - | Vacant | |
30 | - | Fuse 30 on fuse holder C -SC30- | 20 A | - | Cigarette lighter -U1- | 75 |
| | | | | 12 V socket -U5- | |
| | | | | 12 V socket 2 -U18- | |
31 | - | Fuse 31 on fuse holder C -SC31- | - | - | Vacant | |
32 | - | Fuse 32 on fuse holder C -SC32- | - | - | Vacant | |
33 | - | Fuse 33 on fuse holder C -SC33- | 40 A | - | Heater/heat output switch -E16- | 75 |
| | | | | Air conditioning system control unit -J301- | |
34 | - | Fuse 34 on fuse holder C -SC34- | - | - | Vacant | |
35 | - | Fuse 35 on fuse holder C -SC35- | - | - | Vacant | |
36 | - | Fuse 36 on fuse holder C -SC36- | 10 A | - | Lambda probe 1 heater after catalytic converter -Z29- (BWA) | 87 |
37 | - | Fuse 37 on fuse holder C -SC37- | 10 A | - | Lambda probe heater -Z19- (BWA) | 87 |
38 | - | Fuse 38 on fuse holder C -SC38- | 10 A | - | Charge pressure control solenoid valve -N75- (BWA) | 87 |
| | | | | Activated charcoal filter system solenoid valve 1 -N80- (BWA) | |
| | | | | Turbocharger air recirculation valve -N249- (BWA) | |
39 | - | Fuse 39 on fuse holder C -SC39- | 15 A | - | Trailer detector control unit -J345- | 30 |
40 | - | Fuse 40 on fuse holder C -SC40- | 20 A | - | Trailer detector control unit -J345- | 30 |
41 | - | Fuse 41 on fuse holder C -SC41- | 20 A | - | Trailer detector control unit -J345- | 30 |
42 | - | Fuse 42 on fuse holder C -SC42- | - | - | Vacant | |
43 | - | Fuse 43 on fuse holder C -SC43- | 40 A | - | Trailer detector control unit -J345- | 30 |
44 | - | Fuse 44 on fuse holder C -SC44- | 25 A | - | Onboard supply control unit -J519- (via K/6) | 30 |
45 | - | Fuse 45 on fuse holder C -SC45- | 30 A | - | Driver door control unit -J386- | 30 |
| | | | | Front passenger door control unit -J387- | |
46 | - | Fuse 46 on fuse holder C -SC46- | 30 A | - | Rear left door control unit -J388- | 30 |
| | | | | Rear right door control unit -J389- | |
47 | - | Fuse 47 on fuse holder C -SC47- | 15 A | - | Fuel pump relay -J17- (AZV, BKC, BKD, BLS, BMM, BMN, BSE, BSF, BXE, BXW and CCSA) | 30 |
| | | | | Current supply relay for Simos control unit -J363- (BSE, BSF and CCSA) | |
| | | | | Fuel pump control unit -J538- (BVY, BVZ, BWA, BZB and CAXC) | |
| | | | | Fuel supply relay -J643- (BXW) | |
| | | | | Motronic current supply relay -2- -J670- (BWA) | |
48 | - | Fuse 48 on fuse holder C -SC48- | 20 A | - | Convenience system central control unit -J393- (without Autolock function) | 30 |
49 | - | Fuse 49 on fuse holder C -SC49- | 40 A | - | Fresh air blower -V2- (Climatronic only) | 30 |
50 | - | Fuse 50 on fuse holder C -SC50- | 30 A | - | Heated front seats control unit -J774- | 30 |
51 | - | Fuse 51 on fuse holder C -SC51- | 20 A | - | Sliding sunroof adjustment control unit -J245- | 30 |
52 | - | Fuse 52 on fuse holder C -SC52- | 20 A | - | Headlight washer system relay -J39- | 30 |
53 | - | Fuse 53 on fuse holder C -SC53- | - | - | Vacant | |
54 | - | Fuse 54 on fuse holder C -SC54- | 5 A | - | Taxi meter -G41- | 30 |
55 | - | Fuse 55 on fuse holder C -SC55- | - | - | Vacant | |
56 | - | Fuse 56 on fuse holder C -SC56- | 15 A | - | Two-way radio socket -U4- | 30 |
57 | - | Fuse 57 on fuse holder C -SC57- | - | - | Vacant | |
58 | - | Fuse 58 on fuse holder C -SC58- | 30 A | - | Driver door control unit -J386- | 30 |
| | | | | Front passenger door control unit -J387- | |
| | | | | Rear left door control unit -J388- | |
| | | | | Rear right door control unit -J389- | |
| | | | | Convenience system central control unit -J393- (with Autolock function) | |
No. | | Current Flow Diagram designation | Nominal value | | Function/component | Terminal |
1 | - | Fuse 1 on fuse holder C -SC1- | - | - | Vacant | |
2 | - | Fuse 2 on fuse holder C -SC2- | - | - | Vacant | |
3 | - | Fuse 3 on fuse holder C -SC3- | - | - | Vacant | |
4 | - | Fuse 4 on fuse holder C -SC4- | - | - | Vacant | |
5 | - | Fuse 5 on fuse holder C -SC5- | - | - | Vacant | |
6 | - | Fuse 6 on fuse holder C -SC6- | - | - | Vacant | |
7 | - | Fuse 7 on fuse holder C -SC7- | - | - | Vacant | |
8 | - | Fuse 8 on fuse holder C -SC8- | - | - | Vacant | |
9 | - | Fuse 9 on fuse holder C -SC9- | 5 A | - | Airbag control unit -J234- | 15 |
| | | | | Front passenger side airbag deactivated warning lamp -K145- | |
10 | - | Fuse 10 on fuse holder C -SC10- | 10 A | - | Roof display unit -J702- (rear seats) | 15 |
11 | - | Fuse 11 on fuse holder C -SC11- | - | - | Vacant | |
12 | - | Fuse 12 on fuse holder C -SC12- | 10 A | - | Power output module for left headlight -J667- | 15 |
13 | - | Fuse 13 on fuse holder C -SC13- | 5 A | - | Heater/heat output switch -E16- | 15 |
| | | | | Tyre pressure monitor button -E226- | |
| | | | | TCS and ESP button -E256- | |
| | | | | Reversing light switch -F4- | |
| | | | | High pressure sender -G65- | |
| | | | | Oil level and oil temperature sender -G266- (CAXC) | |
| | | | | Climatronic control unit -J255- | |
| | | | | Air conditioning system control unit -J301- | |
| | | | | Navigation system interface -R94- (Tom-Tom Navigator) | |
| | | | | Automatic anti-dazzle interior mirror -Y7- | |
| | | | | Left washer jet heater element -Z20- | |
| | | | | Right washer jet heater element -Z21- | |
14 | - | Fuse 14 on fuse holder C -SC14- | 10 A | - | Light switch -E1- | 15 |
| | | | | Brake light switch -F- | |
| | | | | Tiptronic switch -F189- (BVY and BVZ) | |
| | | | | ABS control unit -J104- | |
| | | | | Motronic control unit -J220- (BVY, BVZ and BWA) | |
| | | | | Diesel direct injection system control unit -J248- (AZV, BKC, BKD, BLS, BMM, BMN and BXE) | |
| | | | | Terminal 30 voltage supply relay -J317- (BSE, BSF and CCSA) | |
| | | | | Trailer detector control unit -J345- | |
| | | | | Simos control unit -J361- (BSE, BSF and CCSA) | |
| | | | | Current supply relay for Simos control unit -J363- (BSE, BSF and CCSA) | |
| | | | | Parking aid control unit -J446- | |
| | | | | Four-wheel drive control unit -J492- | |
| | | | | Power steering control unit -J500- | |
| | | | | Data bus diagnostic interface -J533- | |
| | | | | 4HV injection system control unit -J537- (BXW) | |
| | | | | Fuel pump control unit -J538- (BVY, BVZ, BWA, BZB and CAXC) | |
| | | | | Selector lever sensors control unit -J587- (AZV, BKD, BLS, BMM and BWA) | |
| | | | | Engine control unit -J623- (BZB and CAXC) | |
| | | | | Fuel supply relay -J643- (BXW) | |
| | | | | Mechatronic unit for dual clutch gearbox -J743- (AZV, BKD, BLS, BMM and BWA) | |
| | | | | Dash panel insert -K- | |
| | | | | Left headlight range control motor -V48- | |
| | | | | Right headlight range control motor -V49- | |
15 | - | Fuse 15 on fuse holder C -SC15- | 10 A | - | Diagnosis connection -U31- (T16/1) | 15 |
| | | | | Headlight range control regulator -E102- | |
| | | | | Air mass meter -G70- (AZV, BKC, BKD, BLS, BMM, BMN, BWA, BXE and BZB) | |
| | | | | Cornering light and headlight range control unit -J745- | |
| | | | | Intake manifold preheating heater element -N51- (AZV, BKC, BKD, BLS, BMM, BMN, BSE, BSF, BXE and CCSA) | |
| | | | | Heater element for crankcase breather -N79- (BXW) | |
| | | | | Heated windscreen -Z2- | |
16 | - | Fuse 16 on fuse holder C -SC16- | 10 A | - | Power output module for right headlight -J668- | 15 |
17 | - | Fuse 17 on fuse holder C -SC17- | 10 A | - | Fuel pressure regulating valve -N276- (BWA) | 87 |
18 | - | Fuse 18 on fuse holder C -SC18- | - | - | Vacant | |
19 | - | Fuse 19 on fuse holder C -SC19- | - | - | Vacant | |
20 | - | Fuse 20 on fuse holder C -SC20- | 10 A | - | Heater/heat output switch -E16- | 30 |
| | | | | Tiptronic switch -F189- (BVY and BVZ) | |
| | | | | Automatic gearbox control unit -J217- (BVY and BVZ) | |
| | | | | Climatronic control unit -J255- | |
| | | | | Air conditioning system control unit -J301- | |
| | | | | Selector lever sensors control unit -J587- (AZV, BKD, BLS, BMM and BWA) | |
21 | - | Fuse 21 on fuse holder C -SC21- | 7,5 A | - | Onboard supply control unit -J519- (via K/5) | 30 |
22 | - | Fuse 22 on fuse holder C -SC22- | 5 A | - | Interior monitoring sensor -G273- | 30 |
| | | | | Alarm horn -H12- | |
23 | - | Fuse 23 on fuse holder C -SC23- | 10 A | - | Diagnosis connection -U31- (T16/16) | 30 |
| | | | | Light switch -E1- | |
| | | | | Rain and light detector sensor -G397- | |
24 | - | Fuse 24 on fuse holder C -SC24- | - | - | Vacant | |
25 | - | Fuse 25 on fuse holder C -SC25- | 20 A | - | Multifunction switch -F125- (BVY and BVZ) | 15 |
| | | | | Automatic gearbox control unit -J217- (BVY and BVZ) | |
26 | - | Fuse 26 on fuse holder C -SC26- | 20 A | - | Vacuum pump relay -J57- (BVY and BVZ) | 15 |
27 | - | Fuse 27 on fuse holder C -SC27- | 10 A | - | Roof display unit -J702- (rear seats) | 15 |
28 | - | Fuse 28 on fuse holder C -SC28- | 20 A | - | Onboard supply control unit -J519- (via J/1) | 75 |
| | | | | Rear window wiper motor -V12- | |
29 | - | Fuse 29 on fuse holder C -SC29- | - | - | Vacant | |
30 | - | Fuse 30 on fuse holder C -SC30- | 20 A | - | Cigarette lighter -U1- | 75 |
| | | | | 12 V socket -U5- | |
| | | | | 12 V socket 2 -U18- | |
31 | - | Fuse 31 on fuse holder C -SC31- | - | - | Vacant | |
32 | - | Fuse 32 on fuse holder C -SC32- | - | - | Vacant | |
33 | - | Fuse 33 on fuse holder C -SC33- | 40 A | - | Heater/heat output switch -E16- | 75 |
| | | | | Air conditioning system control unit -J301- | |
34 | - | Fuse 34 on fuse holder C -SC34- | - | - | Vacant | |
35 | - | Fuse 35 on fuse holder C -SC35- | - | - | Vacant | |
36 | - | Fuse 36 on fuse holder C -SC36- | 10 A | - | Lambda probe 1 heater after catalytic converter -Z29- (BWA) | 87 |
37 | - | Fuse 37 on fuse holder C -SC37- | 10 A | - | Lambda probe heater -Z19- (BWA) | 87 |
38 | - | Fuse 38 on fuse holder C -SC38- | 10 A | - | Charge pressure control solenoid valve -N75- (BWA) | 87 |
| | | | | Activated charcoal filter system solenoid valve 1 -N80- (BWA) | |
| | | | | Turbocharger air recirculation valve -N249- (BWA) | |
39 | - | Fuse 39 on fuse holder C -SC39- | 15 A | - | Trailer detector control unit -J345- | 30 |
40 | - | Fuse 40 on fuse holder C -SC40- | 20 A | - | Trailer detector control unit -J345- | 30 |
41 | - | Fuse 41 on fuse holder C -SC41- | 20 A | - | Trailer detector control unit -J345- | 30 |
42 | - | Fuse 42 on fuse holder C -SC42- | - | - | Vacant | |
43 | - | Fuse 43 on fuse holder C -SC43- | 40 A | - | Trailer detector control unit -J345- | 30 |
44 | - | Fuse 44 on fuse holder C -SC44- | 25 A | - | Onboard supply control unit -J519- (via K/6) | 30 |
45 | - | Fuse 45 on fuse holder C -SC45- | 30 A | - | Driver door control unit -J386- | 30 |
| | | | | Front passenger door control unit -J387- | |
46 | - | Fuse 46 on fuse holder C -SC46- | 30 A | - | Rear left door control unit -J388- | 30 |
| | | | | Rear right door control unit -J389- | |
47 | - | Fuse 47 on fuse holder C -SC47- | 15 A | - | Fuel pump relay -J17- (AZV, BKC, BKD, BLS, BMM, BMN, BSE, BSF, BXE, BXW and CCSA) | 30 |
| | | | | Current supply relay for Simos control unit -J363- (BSE, BSF and CCSA) | |
| | | | | Fuel pump control unit -J538- (BVY, BVZ, BWA, BZB and CAXC) | |
| | | | | Fuel supply relay -J643- (BXW) | |
| | | | | Motronic current supply relay -2- -J670- (BWA) | |
48 | - | Fuse 48 on fuse holder C -SC48- | 20 A | - | Convenience system central control unit -J393- (without Autolock function) | 30 |
49 | - | Fuse 49 on fuse holder C -SC49- | 40 A | - | Fresh air blower -V2- (Climatronic only) | 30 |
50 | - | Fuse 50 on fuse holder C -SC50- | 30 A | - | Heated front seats control unit -J774- | 30 |
51 | - | Fuse 51 on fuse holder C -SC51- | 20 A | - | Sliding sunroof adjustment control unit -J245- | 30 |
52 | - | Fuse 52 on fuse holder C -SC52- | 20 A | - | Headlight washer system relay -J39- | 30 |
53 | - | Fuse 53 on fuse holder C -SC53- | - | - | Vacant | |
54 | - | Fuse 54 on fuse holder C -SC54- | 5 A | - | Taxi meter -G41- | 30 |
55 | - | Fuse 55 on fuse holder C -SC55- | - | - | Vacant | |
56 | - | Fuse 56 on fuse holder C -SC56- | 15 A | - | Two-way radio socket -U4- | 30 |
57 | - | Fuse 57 on fuse holder C -SC57- | - | - | Vacant | |
58 | - | Fuse 58 on fuse holder C -SC58- | 30 A | - | Driver door control unit -J386- | 30 |
| | | | | Front passenger door control unit -J387- | |
| | | | | Rear left door control unit -J388- | |
| | | | | Rear right door control unit -J389- | |
| | | | | Convenience system central control unit -J393- (with Autolock function) | |
