Wiring Diagram VW NEW SAGITAR 2016 - Radio - Rear left treble loudspeaker - Rear left bass loudspeaker - Front left treble loudspeaker - Front left bass loudspeaker - Fuse 13 on fuse holder B



Wiring Diagram VW NEW SAGITAR 2016 - Radio - Rear left treble loudspeaker - Rear left bass loudspeaker - Front left treble loudspeaker - Front left bass loudspeaker - Fuse 13 on fuse holder B https://portal-diagnostov.com/license.html
https://portal-diagnostov.com/license.html Automotive Electricians Portal FZCO Automotive Electricians Portal FZCO
Download PDF file
R Radio
R14 Rear left treble loudspeaker
R15 Rear left bass loudspeaker
R20 Front left treble loudspeaker
R21 Front left bass loudspeaker
SB13 Fuse 13 on fuse holder B
T1aqy Single connector
T16d 16-pin connector
T28 28-pin connector
T28b 28-pin connector
  A46 Positive connection (30 - from radio), in dash panel wiring harness
  B101 Connection (positive, front left speaker), in main wiring harness
  B102 Connection (negative, front left speaker), in main wiring harness
*Only models with "Low" equipment (AW0)
*2Only models with "High" equipment (AW1)

Wiring Diagram VW NEW SAGITAR 2016 - Radio - Rear right treble loudspeaker - Rear right bass loudspeaker - Front right treble loudspeaker - Front right bass loudspeaker



Wiring Diagram VW NEW SAGITAR 2016 - Radio - Rear right treble loudspeaker - Rear right bass loudspeaker - Front right treble loudspeaker - Front right bass loudspeaker https://portal-diagnostov.com/license.html
https://portal-diagnostov.com/license.html Automotive Electricians Portal FZCO Automotive Electricians Portal FZCO
Získajte prístup ku všetkým schémam zapojenia automobiluDownload PDF file
R Radio
R16 Rear right treble loudspeaker
R17 Rear right bass loudspeaker
R22 Front right treble loudspeaker
R23 Front right bass loudspeaker
T16d 16-pin connector
T28a 28-pin connector
T28c 28-pin connector
  B103 Connection (positive, front right speaker), in main wiring harness
  B104 Connection (negative, front right speaker), in main wiring harness

Wiring Diagram VW NEW SAGITAR 2016 - Data bus diagnostic interface - Radio - Aerial - Right aerial module - Frequency modulation (FM) frequency filter in negative wire - Frequency modulation (FM) frequency filter in positive wire - Heated rear window



Wiring Diagram VW NEW SAGITAR 2016 - Data bus diagnostic interface - Radio - Aerial - Right aerial module - Frequency modulation (FM) frequency filter in negative wire - Frequency modulation (FM) frequency filter in positive wire - Heated rear window https://portal-diagnostov.com/license.html
https://portal-diagnostov.com/license.html Automotive Electricians Portal FZCO Automotive Electricians Portal FZCO
Získajte prístup ku všetkým schémam zapojenia automobiluDownload PDF file
J9 Heated rear window relay
J533 Data bus diagnostic interface
R Radio
R11 Aerial
R109 Right aerial module
R178 Frequency modulation (FM) frequency filter in negative wire
R179 Frequency modulation (FM) frequency filter in positive wire
T5c 5-pin connector
T16d 16-pin connector
T20 20-pin connector
Z1 Heated rear window
  255 Earth connection 1, in radio wiring harness
  610 Earth point (audio), front below centre console
  657 Earth point 1, on left near rear window
  681 Earth point 1, in rear right side panel
  B180 Connection (heated rear window), in interior wiring harness
  B397 Connection 1 (convenience CAN bus, high), in main wiring harness
  B406 Connection 1 (convenience CAN bus, low), in main wiring harness
  B415 Connection 1 (infotainment CAN bus, high), in main wiring harness
  B421 Connection 1 (infotainment CAN bus, low), in main wiring harness
*According to equipment
