Wiring Diagram - WIRING FOR MINIBAR - Fiat DUCATO 2.8 JTD 8V fino a 02/05
Components - WIRING FOR MINIBAR - Fiat DUCATO 2.8 JTD 8V fino a 02/05
| Component code | Description | Reference to the assembly |
| B001 | JUNCTION UNIT | |
| B002 | JUNCTION UNIT UNDER DASHBOARD | - |
| B099 | MAXI FUSE BOX ON BATTERY | - |
| B101 | OPTIONAL JUNCTION UNIT UNDER THE DASHBOARD | - |
| D160 | DASHBOARD/OPTIONAL DASHBOARD COUPLING | - |
| D164 | OPTIONAL DASHBOARD/REFRIGERATOR COUPLING | - |
| D179 | PREPARATION FOR REFRIGERATOR | - |
| H001 | IGNITION SWITCH | |
| - |
Location Components - WIRING FOR MINIBAR - Fiat DUCATO 2.8 JTD 8V fino a 02/05
| Component code | Description | Reference to the assembly |
| B001 | JUNCTION UNIT | |
| B002 | JUNCTION UNIT UNDER DASHBOARD | - |
| B099 | MAXI FUSE BOX ON BATTERY | - |
| B101 | OPTIONAL JUNCTION UNIT UNDER THE DASHBOARD | - |
| D160 | DASHBOARD/OPTIONAL DASHBOARD COUPLING | - |
| D164 | OPTIONAL DASHBOARD/REFRIGERATOR COUPLING | - |
| D179 | PREPARATION FOR REFRIGERATOR | - |
| H001 | IGNITION SWITCH | |
| - |
Description - WIRING FOR MINIBAR - Fiat DUCATO 2.8 JTD 8V fino a 02/05
The minibar fridge predisposition system operates with the key ON (INT). It is controlled by a dedicated relay located in the optional junction unit under the instrument facia.The power line from the above relay comes directly from the battery and is protected by a dedicated fuse, also housed in the optional junction unit.The key-operated line is protected by two dedicated fuses, one housed in the engine bay junction unit and the other in the junction unit under the instrument facia.
Operational Description - WIRING FOR MINIBAR - Fiat DUCATO 2.8 JTD 8V fino a 02/05
When the key is turned to MAR (INT), a power supply reaches relay T29, housed in the optional underfacia junction unit B101, via a line protected by fuse F27, housed in underfacia junction unit B002. When the relay is supplied, it closes the internal contact to supply junction D079 with power directly from the battery via a line protected by fuse F59, housed in optional junction unit B101.The ignition-operated power supply is protected by fuse F27, housed in underfacia junction unit B002.Pin 2 of junction D079 is connected to earth C020.
