Wiring Diagram SEAT TOLEDO 2000 - 12 V socket
D | Ignition/starter switch |
S235 | Fuse in fuse box |
U5 | 12 V socket |
T3i | 3 pin connector, in the socket |
T6h | 6 pin conn., left side of baggage compartment |
50 | Earth point, luggage boot, left |
86 | Earth connection -1-, in rear wiring loom |
501 | Screw connection -2- (30), on relay plate |
A32 | Positive connection (30), in dash panel wiring loom |
B150 | Positive connection -2- (30a), in interior wiring harness |
* | Only in vehicles with Caravan |
