AIR CONDITIONING – Honda Civic del Sol VTEC 1995 – SYSTEM WIRING DIAGRAMS

  1. Home
  2. >HONDA
  3. >Honda 1995
  4. >Honda Civic del Sol VTEC 1995
  5. >Honda Civic del Sol VTEC 1995 - ALL WIRING DIAGRAMS

Download PDF file

AIR CONDITIONING

A/C Wiring Diagram for Honda Civic del Sol VTEC 1995

AC Wiring Diagram for Honda Civic del Sol VTEC 1995 https://portal-diagnostov.com/license.html
https://portal-diagnostov.com/license.html Automotive Electricians Portal FZCO Automotive Electricians Portal FZCO
获取访问所有汽车的接线图Download PDF file

List of elements for A/C Wiring Diagram for Honda Civic del Sol VTEC 1995:

  • (at left
  • (at left kick panel)
  • (at right
  • (behind glove box)
  • (civic)
  • (del sol)
  • (on bracket)
  • (right front corner of engine compartment)
  • (right side of engine) g120
  • 1994,
  • A/c compressor clutch
  • A/c compressor clutch relay (left front of engine compartment)
  • A/c compressor thermal protector
  • A/c diode (left front of engine compartment)
  • A/c pressure switch (left front of engine compartment)
  • A/c switch
  • A/c thermostat (behind glove box)
  • A12
  • A15
  • Bi-lev switch
  • Blower motor
  • Blower motor relay
  • Blower resistor
  • C 1995 vftc
  • C205
  • C206
  • C441
  • Condenser fan motor
  • Condenser fan relay (behind left side of front bumper)
  • Control
  • Defrost switch
  • Dimming circuit
  • Engine
  • Engine coolant temperature switch a (right rear of engine)
  • Fresh
  • Fresh/ recirc switch
  • Fuse 13 7.5a
  • Fuse 33 cooling fan 15a
  • Fuse 35 condenser fan 20a
  • Fuse 37 heater motor 30a
  • G101
  • G101 (right side of engine compartment)
  • G200
  • Heat switch
  • Heat/def switch
  • Heater control panel
  • Heater fan switch
  • High
  • Hot at all times
  • Hot in on
  • Interior lights system
  • Kick panel)
  • Low
  • Mode control motor (below i/p, right of steering column)
  • Module
  • Off
  • Radiator fan motor
  • Radiator fan relay
  • Recirc
  • Recirculation control motor
  • Red
  • Under-dash fuse/relay box
  • Under-hood fuse/relay box
  • Vent switch

Heater Wiring Diagram for Honda Civic del Sol VTEC 1995

Heater Wiring Diagram for Honda Civic del Sol VTEC 1995 https://portal-diagnostov.com/license.html
https://portal-diagnostov.com/license.html Automotive Electricians Portal FZCO Automotive Electricians Portal FZCO
获取访问所有汽车的接线图Download PDF file

List of elements for Heater Wiring Diagram for Honda Civic del Sol VTEC 1995:

  • (at left
  • (at left kick panel)
  • (behind glove box)
  • Bi-lev switch
  • Blower motor
  • Blower motor relay
  • Blower resistor
  • C 1995 vftc
  • C254
  • C441
  • Defrost switch
  • Dimming circuit
  • Fresh
  • Fresh/ recirc switch
  • Fuse 13 7.5a
  • Fuse 37 heater motor 30a
  • G101 (right side of engine compartment)
  • G200
  • Heat switch
  • Heat/def switch
  • Heater control panel
  • Heater fan switch
  • Hot at all times
  • Hot in on
  • Interior lights system
  • Kick panel)
  • Mode control motor (below i/p, right of steering column)
  • Off
  • Recirc
  • Recirculation control motor
  • Red
  • Under-dash fuse/relay box
  • Under-hood fuse/relay box
  • Vent switch
