Wiring Diagram SEAT VARIO 2000 - Control unit for ABS with EDS - button for TCS/ESP



Wiring Diagram SEAT VARIO 2000 - Control unit for ABS with EDS - button for TCS/ESP https://portal-diagnostov.com/license.html
https://portal-diagnostov.com/license.html Automotive Electricians Portal FZCO Automotive Electricians Portal FZCO
获取访问所有汽车的接线图Download PDF file
ABattery (00532)
E1Lighting switch
E256Button for TCS/ESP
J59Relief relay for x contact
J104Control unit for ABS with EDS
J220Control unit for motronic
J248Control unit for Diesel direct injection system
J361Simos control unit
SA7Fuse -7- on battery fuse holder
SA8Fuse -8- on battery fuse holder
SB18Fuse -18- on fuse holder
T3a3 pin connector, black, on the battery
T5q5 pin connector
T6i6 pin connector, black, in the coupling distributor
T6j6 pin connector, black, on the relay holder bracket
T10j10 pin connector, pink, on the relay holder bracket
T1717 pin connector, black, light switch
T2525 pin connector, black, on the left side of the engine housing
T8080 pin connector, black
T121121 pin connector, black
  135 Earth connection -2-, in dash panel wiring loom
  A4 Positive (+) connection (58b), in dash panel wiring loom
  A61 Positive connection (X), in instrument panel wiring loom
*Only with ALD, ANV, AKK or ANW engine distinctive lettering
**Only vehicles with ASR
***Only with APE or AQQ engine distinctive lettering
****Only with AKL or AEH engine distinctive lettering
*****Only with AGP, AQM, AGR, ALH or ASK engine distinctive lettering

Wiring Diagram SEAT VARIO 2000 - Control unit for ABS with EDS - valve 1 for differential lock - valve 2 for differential lock - ABS inlet valve - rear right - ABS inlet valve - rear left



Wiring Diagram SEAT VARIO 2000 - Control unit for ABS with EDS - valve 1 for differential lock - valve 2 for differential lock - ABS inlet valve - rear right - ABS inlet valve - rear left https://portal-diagnostov.com/license.html
https://portal-diagnostov.com/license.html Automotive Electricians Portal FZCO Automotive Electricians Portal FZCO
获取访问所有汽车的接线图Download PDF file
FBrake light switch (00526-2131)
J104Control unit for ABS with EDS
J285Control unit with display unit in dash panel insert (01317)
N125Valve 1 for differential lock (00279-1223)
N126Valve 2 for differential lock (00280-1224)
N133ABS inlet valve, rear right (00273-1211)
N134ABS inlet valve, rear left (00274-1212)
N135ABS outlet valve, rear right (00275-1213)
N136ABS outlet valve, rear left (00276-1214)
T22 pin connector
T33 pin connector, black, in the brake
T6i6 pin connector, black, in the coupling distributor
T10g10 pin connector, green, in the coupling distributor
T10i10 pin connector, red, in the coupling distributor
T10j10 pin connector, pink, on the relay holder bracket
T1616 pin connector, self-diagnosis connection
T2525 pin connector, black, on the left side of the engine housing
T3232 pin connector, blue, dashboard
T32a32 pin connector, green, dashboard
V64ABS hydraulic pump (01276-4133)
  A76 Connection (diagnosis wire K), in dash panel wiring loom
*Only vehicles with EDS
**Only vehicles with ASR

Wiring Diagram SEAT VARIO 2000 - Control unit for ABS with EDS - rear right speed sensor - front right speed sensor



Wiring Diagram SEAT VARIO 2000 - Control unit for ABS with EDS - rear right speed sensor - front right speed sensor https://portal-diagnostov.com/license.html
https://portal-diagnostov.com/license.html Automotive Electricians Portal FZCO Automotive Electricians Portal FZCO
获取访问所有汽车的接线图Download PDF file
G44Rear right speed sensor (00287-1243)
G45Front right speed sensor (00285-1241)
G46Rear left speed sensor (00290-1311)
G47Front left speed sensor (00283-1233)
J104Control unit for ABS with EDS
N99Inlet valve ABS front right (00259-1114)
N100Outlet valve ABS front right (00267-1134)
N101Inlet valve ABS front left (00257-1112)
N102Outlet valve ABS front left (00265-1132)
T2e2 pin connector, in the front right ABS sensor
T2f2 pin connector, in the rear left ABS sensor
T2g2 pin connector, in the rear right ABS sensor
T2h2 pin connector, in the front left ABS sensor
T2525 pin connector, black, on the left side of the engine housing
  114 Earth connection in automatic gearbox wiring loom
