Wiring Diagram VW CADDY 2017 - Steering motor speed sender - Power steering control unit - Fuse holder A - Fuse 13 on fuse holder C - Electromechanical power steering motor
G269 | Steering moment sender |
G577 | Steering motor speed sender |
J500 | Power steering control unit, on front axle carrier |
SA | Fuse holder A |
SA2 | Fuse 2 in fuse holder A |
SC13 | Fuse 13 on fuse holder C |
T2b | 2-pin connector, black |
T3o | 3-pin connector, black |
T5s | 5-pin connector, black |
T5t | 5-pin connector |
T6z | 6-pin connector, near left headlight, black |
T10s | 10-pin connector, near left headlight, black |
V187 | Electromechanical power steering motor |
508 | Threaded connection (30) on E-box |
A199 | Positive connection 4 (15a) in dash panel wiring harness |
B383 | Connection 1 (powertrain CAN bus, high), in main wiring harness |
B390 | Connection 1 (powertrain CAN bus, low), in main wiring harness |
* | Only models with diesel engine |
*2 | Only models with Euro 6 emission standard |
*3 | According to equipment |
Wiring Diagram VW CADDY 2017 - Steering angle sender - Control unit in dash panel insert - Onboard supply control unit - Steering column electronics control unit - Data bus diagnostic interface - Electromechanical power steering warning lamp - Diagnostic connection
G85 | Steering angle sender |
J285 | Control unit in dash panel insert |
J519 | Onboard supply control unit |
J527 | Steering column electronics control unit |
J533 | Data bus diagnostic interface |
J623 | Engine control unit |
K161 | Electromechanical power steering warning lamp |
T16 | 16-pin connector, purple |
T16a | 16-pin connector, black |
T20 | 20-pin connector, red |
T32 | 32-pin connector, blue |
T52c | 52-pin connector, brown |
U31 | Diagnostic connection |
B273 | Positive connection (15), in main wiring harness |
B383 | Connection 1 (powertrain CAN bus, high), in main wiring harness |
B390 | Connection 1 (powertrain CAN bus, low), in main wiring harness |
B397 | Connection 1 (convenience CAN bus, high), in main wiring harness |
B406 | Connection 1 (convenience CAN bus, low), in main wiring harness |
* | Only models with no start/stop system |
*2 | Only models with start/stop system |
VW CADDY 2017 Overview of fuses
Overview of fuses |
1 - | Fuses (SA) on fuse holder A |
q | Fuse assignment, from June 2015 |
2 - | Fuses (SB) on fuse holder B |
q | Fuse assignment, from June 2015 |
3 - | Fuses (SC) on fuse holder C |
q | Fitting location right-hand drive |
q | Fuse assignment, from June 2015 |
|
1 - | Fuse holder A -SA- |
Fuse colours for MIDI strip fuse: |
t | 200 A - purple |
t | 150 A - grey |
t | 125 A - pink |
t | 100 A - blue |
t | 80 A - white / transparent |
t | 70 A - brown |
t | 60 A - yellow |
t | 50 A - red |
t | 40 A - green |
t | 30 A - orange |
Note:
|
Fuses (SB) on fuse holder B |
Fitting location of fuse holder B -SB- |
On left in engine compartment, on E-box. |
1 - | Fuse holder B -SB- |
Fuse colours for ATO flat fuse: |
t | 40 A - orange |
t | 35 A - green-blue |
t | 30 A - light green |
t | 25 A - transparent |
t | 20 A - yellow |
t | 15 A - light blue |
t | 10 A - red |
t | 7.5 A - brown |
t | 5 A - light brown |
t | 1 A - black |
Fuse colours for Maxi ATO flat fuse: |
t | 60 A - blue |
t | 50 A - red |
t | 40 A - orange |
t | 30 A - light green |
t | 20 A - yellow |
|
Fuses (SC) on fuse holder C |
Fitting location, fuse holder C -SC- , left-hand drive |
under dash panel on left. |
1 - | Fuse holder C -SC- |
Fuse colours for ATO flat fuse: |
t | 40 A - orange |
t | 35 A - green-blue |
t | 30 A - light green |
t | 25 A - transparent |
t | 20 A - yellow |
t | 15 A - light blue |
t | 10 A - red |
t | 7.5 A - brown |
t | 5 A - light brown |
t | 1 A - black |
|
1 - | Fuse holder C -SC- |
Fuse colours for ATO flat fuse: |
t | 40 A - orange |
t | 35 A - green-blue |
t | 30 A - light green |
t | 25 A - transparent |
t | 20 A - yellow |
t | 15 A - light blue |
t | 10 A - red |
t | 7.5 A - brown |
t | 5 A - light brown |
t | 1 A - black |
|
