AIR CONDITIONING – Jeep Grand Cherokee Limited 2010 – SYSTEM WIRING DIAGRAMS

  1. Home
  2. >JEEP
  3. >Jeep 2010
  4. >Jeep Grand Cherokee Limited 2010
  5. >Jeep Grand Cherokee Limited 2010 - ALL WIRING DIAGRAMS

Download PDF file

AIR CONDITIONING

Automatic A/C Wiring Diagram (1 of 3) for Jeep Grand Cherokee Limited 2010

Automatic AC Wiring Diagram (1 of 3) for Jeep Grand Cherokee Limited 2010 https://portal-diagnostov.com/license.html
https://portal-diagnostov.com/license.html Automotive Electricians Portal FZCO Automotive Electricians Portal FZCO
Download PDF file

List of elements for Automatic A/C Wiring Diagram (1 of 3) for Jeep Grand Cherokee Limited 2010:

  • (left rear of engine compt) g100
  • A/c heater control
  • A114
  • Act temp
  • Blower motor relay
  • C115
  • C121
  • C153
  • C161
  • C200
  • C21
  • C210
  • C255
  • C266
  • C268
  • C53
  • C55
  • C56
  • C61
  • C66
  • C68
  • Can b bus (+)
  • Can b bus (-)
  • Computer data lines system
  • D54
  • D55
  • Defogger rly ctrl
  • Drv temp rtn
  • Evaporator temp sens sig
  • Evaporator temperature sensor (left side of hvac unit)
  • F921
  • Front blower control
  • Front blower ctrl
  • Front blower power module (right side of hvac unit)
  • Front mode door common drv
  • Front mode door drv
  • Ft blw fd
  • Fuse 10 10a
  • Fuse 11 40a
  • Fused b (+)
  • Fused run rly out
  • G139
  • G200 (near breakout to data link connector)
  • G39
  • G939
  • Ground
  • Hot at all times
  • Hot w/ run relay energized
  • Interior lights system
  • Junction block (left side of dash)
  • Left blend door common drv
  • Left blend door drv
  • Panel lmp drv
  • Power distribution center (left side of engine compt)
  • Rear mode door actuator (center of hvac unit)
  • Rear mode door common drv
  • Rear mode door drv
  • Rear window defogger relay
  • Recirculation door common drv
  • Recirculation door drv
  • Red
  • Right blend door actuator (center of hvac unit)
  • Right blend door common drv
  • Right blend door drv
  • Rr mode mtr a
  • Rr mode mtr b
  • S136
  • S204
  • Sens gnd
  • Sun sens 1 sig
  • Sun sens 2 sig
  • Sun sens rtn
  • Sun sensor (top center of dash)
  • Z134
  • Z906

Automatic A/C Wiring Diagram (2 of 3) for Jeep Grand Cherokee Limited 2010

Automatic AC Wiring Diagram (2 of 3) for Jeep Grand Cherokee Limited 2010 https://portal-diagnostov.com/license.html
https://portal-diagnostov.com/license.html Automotive Electricians Portal FZCO Automotive Electricians Portal FZCO
Get access to all wiring diagrams of the carDownload PDF file

List of elements for Automatic A/C Wiring Diagram (2 of 3) for Jeep Grand Cherokee Limited 2010:

  • (left rear of engine compt) g100
  • (left side of engine compt) g102
  • (left side of engine compt) integrated power module
  • A/c clutch fd
  • A/c clutch relay
  • A/c compressor clutch (3.7l: top front of engine) (5.7l: lower left front of engine)
  • A/c press sens return
  • A/c pressure sig
  • A/c pressure transducer (right front of engine compt)
  • A916
  • Abmt temp/fcm ssr rtn1
  • Ambient air temperature sensor (front center of engine compt)
  • C104
  • C18
  • Can c bus (+)
  • Can c bus (-)
  • Clk wse
  • Cntr clk wse
  • Computer data lines system
  • D64
  • D65
  • F891
  • Fan spd sig
  • Front control module
  • Front mode door actuator (left side of hvac unit)
  • Fuse 10a
  • Fuse 15a
  • Fuse 20a
  • Fuse 50a
  • Fused b (+)
  • G31
  • Gnd
  • Gp31
  • Ground
  • High speed fan rly out
  • Hot at all times
  • Hot in on or start
  • Hydraulic cooling fan module (5.7l) (left side of engine compt)
  • Junction block (left side of dash)
  • K173
  • Left blend door actuator (left side of hvac unit)
  • Low speed fan rly out
  • Lt clk wse
  • Lt cntr clk wse
  • N23
  • N24
  • Power distribution center (left side of engine compt)
  • Radiator fan ctrl
  • Radiator fan high relay
  • Radiator fan low relay
  • Radiator fan/motor assembly (3.7l) (behind radiator)
  • Recirculation door actuator (right side of hvac unit)
  • Red
  • S106
  • S127
  • S128
  • S202
  • Sens abmt temp sig
  • Z823

Automatic A/C Wiring Diagram (3 of 3) for Jeep Grand Cherokee Limited 2010

Automatic AC Wiring Diagram (3 of 3) for Jeep Grand Cherokee Limited 2010 https://portal-diagnostov.com/license.html
https://portal-diagnostov.com/license.html Automotive Electricians Portal FZCO Automotive Electricians Portal FZCO
Get access to all wiring diagrams of the carDownload PDF file

List of elements for Automatic A/C Wiring Diagram (3 of 3) for Jeep Grand Cherokee Limited 2010:

  • A/c clutch relay control
  • A209
  • C104
  • C13
  • Can bus (+)
  • Can bus (-)
  • Computer data lines system
  • D64
  • D65
  • Ect signal
  • Engine controls system
  • Engine coolant temperature sensor (3.7l: top front of engine) (5.7l: left front of engine)
  • Fuse 20a
  • Fused b (+)
  • Hot at all times
  • K900
  • Power distribution center (left side of engine compt)
  • Powertrain control module (right rear of engine compt)
  • Red
  • S141 (right side of engine)
  • S167
  • Sensor rtn

Manual A/C Wiring Diagram (1 of 2) for Jeep Grand Cherokee Limited 2010

Manual AC Wiring Diagram (1 of 2) for Jeep Grand Cherokee Limited 2010 https://portal-diagnostov.com/license.html
https://portal-diagnostov.com/license.html Automotive Electricians Portal FZCO Automotive Electricians Portal FZCO
Get access to all wiring diagrams of the carDownload PDF file

List of elements for Manual A/C Wiring Diagram (1 of 2) for Jeep Grand Cherokee Limited 2010:

  • (in headlamp & dash harness) s198
  • (left rear
  • A/c heater control
  • A/c sw sense
  • A/c sw sns
  • Blower high speed
  • Blower low speed
  • Blower m1 speed
  • Blower m2 speed
  • Blower motor (right side of hvac unit)
  • Blower motor relay
  • Blower motor resistor (right side of hvac unit)
  • Blower rtn
  • Blower sw position sig
  • Blw hi
  • C115
  • C121
  • C139
  • C200
  • C21
  • C210
  • C221
  • C255
  • C266
  • C268
  • C53
  • C55
  • C66
  • C68
  • C70
  • C71
  • C72
  • C73
  • C850
  • Clk wse
  • Cluster
  • Cntr clk wse
  • Defogger rly ctrl
  • Dim sig sel
  • Dimmer hvac
  • E16
  • Evaporator temp sens sig
  • Evaporator temperature sensor (left side of hvac unit)
  • F921
  • Front mode door common drv
  • Front mode door drv
  • Fuse 10 10a
  • Fuse 11 40a
  • Fused run rly out
  • G200 (near breakout to data link connector)
  • Ground
  • Hot at all times
  • Hot w/ run relay energized
  • Interior lights system
  • Junction block (left side of dash)
  • Left blend door common drv
  • Left blend door drv
  • Of engine compt) g100
  • Power distribution center (left side of engine compt)
  • Rear defogger window relay
  • Rear mode door common drv
  • Rear mode door drv
  • Recirculation door actuator (right side of hvac unit)
  • Recirculation door common drv
  • Recirculation door drv
  • Red
  • S136
  • S204
  • Sens rtn
  • Spd
  • Z134
  • Z906

Manual A/C Wiring Diagram (2 of 2) for Jeep Grand Cherokee Limited 2010

Manual AC Wiring Diagram (2 of 2) for Jeep Grand Cherokee Limited 2010 https://portal-diagnostov.com/license.html
https://portal-diagnostov.com/license.html Automotive Electricians Portal FZCO Automotive Electricians Portal FZCO
Get access to all wiring diagrams of the carDownload PDF file

List of elements for Manual A/C Wiring Diagram (2 of 2) for Jeep Grand Cherokee Limited 2010:

  • (3.7l: right side of engine) (5.7l: right rear of engine) s141
  • (left rear of engine compt) g100
  • A/c clutch fd
  • A/c clutch relay
  • A/c clutch relay control
  • A/c compressor clutch (3.7l: top front of engine) (5.7l: lower left front of engine)
  • A916
  • Aat sig
  • Ambient air temperature sensor (front center of engine compt)
  • C104
  • C13
  • Can bus (+)
  • Can bus (-)
  • Clk wse
  • Cntr clk wse
  • Computer data lines system
  • D64
  • D65
  • Ect signal
  • Engine controls system
  • Engine coolant temperature sensor (3.7l: top front of engine) (5.7l: left front of engine)
  • Fan rly ctrl
  • Front control module
  • Front mode door actuator (left side of hvac unit)
  • Fuse 10a
  • Fuse 20a
  • Fuse 20a red
  • Fuse 50a
  • Fused b (+)
  • G102 (left side of engine compt)
  • G31
  • G931
  • Gnd
  • Ground
  • High speed fan rly out
  • Hot at all times
  • Hot in on or start
  • Hydraulic cooling fan module (5.7l) (left side of engine compt)
  • Integrated power module (left side of engine compt)
  • Junction block (left side of dash)
  • K173
  • K900
  • Left blend door actuator (left side of hvac unit)
  • Low speed fan rly out
  • Lt clk wse
  • Lt cntr clk wse
  • N23
  • N24
  • Power distribution center (left side of engine compt)
  • Powertrain control module (right rear of engine compt)
  • Radiator fan high relay
  • Radiator fan low relay
  • Radiator fan sol ctrl
  • Radiator fan solenoid ctrl
  • Radiator fan/motor assembly (3.7l) (behind radiator)
  • Rear mode door actuator (center of hvac unit)
  • Red
  • Rr mode mtr a
  • Rr mode mtr b
  • S106
  • S127
  • S128
  • Sens gnd
  • Sensor rtn
  • Z823
