DEFOGGERS – Jeep Wrangler S 1993 – SYSTEM WIRING DIAGRAMS

    HomeJEEPJeep 1993Jeep Wrangler S 1993Jeep Wrangler S 1993 - ALL WIRING DIAGRAMS

DEFOGGERS

Defogger Wiring Diagram for Jeep Wrangler S 1993

Defogger Wiring Diagram for Jeep Wrangler S 1993

List of elements for Defogger Wiring Diagram for Jeep Wrangler S 1993:

12
  • (body ground)
  • Fuse 15a
  • Fuse 25a
  • Fuse block
  • Heated rear window relay (behind parking brake pedal)
  • Heated rear window switch
  • Heated rear window grid
  • Hot at all times
  • Hot in run or start
  • Liftgate support strut
  • On indicator
  • Timer
