AIR CONDITIONING – Ford Bronco 1995 – SYSTEM WIRING DIAGRAMS

AIR CONDITIONING

A/C Wiring Diagram for Ford Bronco 1995

List of elements for A/C Wiring Diagram for Ford Bronco 1995:

28

• (left front of engine compartment)
• (not used)
• 15a
• A/c clutch cycling pressure switch (right rear of engine compartment on accumulator)
• A/c clutch diode
• A/c compressor clutch
• A/c high pressure cut out switch (left side engine compartment)
• A/c-heater control assembly
• Blower motor
• Blower motor resistors (right side of safety wall, on plenum)
• Blower motor switch
• C 1995 vftc
• Def
• Floor
• Fuse 1 30a
• Fuse 6
• Fuse panel
• G108
• G200 (behind bottom of left cowl panel)
• Hot in accy or run
• Hot in run
• Instrument cluster
• Max
• Mix
• Norm
• Off
• Power- train control module (left side of safety wall)
• Vent

Heater Wiring Diagram for Ford Bronco 1995

List of elements for Heater Wiring Diagram for Ford Bronco 1995:

19

• (not used)
• (right side of safety wall, on plenum)
• 15a
• Blower motor
• Blower motor resistors
• Blower motor switch
• C 1995 vftc
• Def
• Floor
• Fuse 1 30a
• Fuse 6
• Fuse panel
• G200 (behind bottom of left cowl panel)
• Heater control assembly
• Hot in accy or run
• Hot in run
• Mix
• Off
• Vent
