Электросхемы ЦЕНТРАЛЬНЫЙ ЗАМОК Ford Fusion SEL 2006

ЦЕНТРАЛЬНЫЙ ЗАМОК

Электросхема центрального замка (1 из 2) для Ford Fusion SEL 2006

https://portal-diagnostov.com/license.html
https://portal-diagnostov.com/license.html Automotive Electricians Portal FZCO Automotive Electricians Portal FZCO

Электросхема центрального замка (1 из 2) для Ford Fusion SEL 2006 - Список элементов:

• (in body main harness, near breakout to c316)
• (in body main harness, near breakout to smart junction box (sjb)) s347
• (power seats harness, near breakout to smart junction box (sjb)) s324
• (power seats harness, near breakout to smart junction box (sjb)) s325
• Battery junction box (bjb) (2.3l: left side of engine compt) (3.0l: left front of engine compt)
• C2280c
• C2280e
• C2280f
• Driver side door lock switch
• Fuse 15a
• Fuse 60a
• Fuse 7.5a
• G203 (base of right "a" pillar)
• G300 (center of left floor pan)
• Hot at all times
• Hot w/ accessory delay relay energized
• Left rear door lock actuator (in left rear door)
• Lock
• Lock all relay
• Logic
• Lr door ajar
• Pass door ajar
• Passenger side door lock switch
• Right front door lock actuator (in right front door)
• Right rear door lock actuator (in right rear door)
• Rr door ajar
• S328
• S342
• S500
• S601
• Smart junction box (sjb) (base of left "a" pillar)
• Trim lock
• Trim unlock
• Unlock
• Unlock all relay
• Unlock driver relay

Электросхема центрального замка (2 из 2) для Ford Fusion SEL 2006

https://portal-diagnostov.com/license.html
https://portal-diagnostov.com/license.html Automotive Electricians Portal FZCO Automotive Electricians Portal FZCO

Get access to all wiring diagrams of the car

Электросхема центрального замка (2 из 2) для Ford Fusion SEL 2006 - Список элементов:

• Anti-theft hood switch (left front radiator support)
• C2280a
• C2280c
• Disarm request
• Door reset sw
• Driver door ajar
• G104 (2.3l: in front of right strut tower) (3.0l: right front of engine compt)
• G300 (center of left floor pan)
• G400 (center rear of trunk compartment)
• Hood ajar
• Keypad a
• Keypad b
• Keypad c
• Keypad illum
• Keypad switch assembly
• Left front door lock actuator
• Logic
• Luggage compartment disarm switch (center rear of luggage compartment)
• Reset
• S500
• Set
• Smart junction box (sjb) (base of left "a" pillar)
