Электросхемы СИСТЕМА КОНДИЦИОНЕРА Ford Fusion SEL 2006

СИСТЕМА КОНДИЦИОНЕРА

Электросхема кондиционера, Единственный Зональный счет (1 из 3) для Ford Fusion SEL 2006

Электросхема кондиционера, Единственный Зональный счет (1 из 3) для Ford Fusion SEL 2006 - Список элементов:

• (3.0l:behind front grille)
• (in main harn, near breakout to c251) s228
• (in steering wheel jumper harness, near breakout to c2999) s201
• Actuators return
• Air bag sliding contact (behind steering wheel assembly)
• Ambient air temperature sensor (3.0l:behind front grille) (2.3l:right side of radiator support)
• Ambient temp sensor
• Battery
• Battery junction box (bjb) (2.3l: left side of engine compt) (3.0l: left front of engine compt)
• Blend fbk
• Blend input
• Blower motor (right side of dash)
• Blower motor relay
• C218a
• C218b
• C228a
• C228b
• Cbp20
• Ch122
• Ch123
• Ch207
• Ch208
• Ch228
• Ch229
• Ch233
• Ch234
• Chs04
• Chs09
• Chs13
• Chs14
• Chs29
• Chs30
• Cmd
• Computer data lines system
• Def request
• Defogger system
• Dr hs request
• Dr hshi
• Dr hslo
• Dr sunload sens
• Electronic automatic temperature control (eatc) module (center of dash)
• Fan+
• Fan-
• Front blower motor speed controller (right side of dash)
• Fuse 40a
• G201 (center of dash)
• G202 (left side of dash)
• Gd116
• Gnd
• Headlights system
• Hot at all times
• Ign feed
• In car temp
• In-vehicle temperature sensor (left side of dash)
• Left steering wheel switch
• Lh111
• Mode actuator fbk
• Mode input
• Motor+
• Motor-
• Ms can +
• Ms can -
• Pass hshi
• Pass request
• Pss hslo
• Recirc ccw
• Recirc cw
• Redundant cc return
• Redundant cc signal
• Rh104
• Rh106
• Rh111
• Run/start
• Sbp07
• Seats system
• Sensor ret 4
• Sunload sensor (right side of dash)
• Vdb06
• Vdb07
• Vh101
• Vh407
• Vh414
• Vh416
• Vh436
• Vh439
• Vh444
• Vpwr
• Vref actuators

Электросхема кондиционера, Единственный Зональный счет (2 из 3) для Ford Fusion SEL 2006

Электросхема кондиционера, Единственный Зональный счет (2 из 3) для Ford Fusion SEL 2006 - Список элементов:

• (in a/c jumper, near breakout to c2295) s204
• Amp
• C2280a
• C2280b
• Fresh/recirculation door actuator (right side of dash)
• Fuse 7.5a
• Harness, near breakout to c251)
• Harness, near breakout to g201)
• Headlamp junction harness, near breakout to battery junction box (bjb))
• Headlamp junction harness, near breakout to battery junction box (bjb)) (3.0l: in dash panel to headlamp junction harness, near breakout to powertrain control module (pcm))
• Hot at all times
• Hot in run or acc
• Hot in start or run
• Mode door actuator (center of dash)
• Passenger temperature blend door actuator (right side of dash)
• Right steering wheel switch
• S206 (in a/c jumper, near breakout to c2295)
• Smart junction box (sjb) (base of left "a" pillar)
• Temp+
• Temp-

Электросхема кондиционера, Единственный Зональный счет (3 из 3) для Ford Fusion SEL 2006

Электросхема кондиционера, Единственный Зональный счет (3 из 3) для Ford Fusion SEL 2006 - Список элементов:

• (in dash panel to headlamp junction harness, near breakout to powertrain control module (pcm)) s124
• A/c clutch field coil (front of a/c compressor)
• A/c clutch relay
• A/c pressure transducer sensor (right front of engine)
• Accr
• Acpt
• Battery junction box (bjb) (2.3l: left side of engine compt) (3.0l: left front of engine compt)
• C-sigrtn
• C-vref
• C175b
• C175e
• Ce302
• Ch302
• Computer data lines system
• E-sigrtn
• Ect
• Engine coolant temperature (ect) sensor (rear of engine)
• Engine cooling fan motor (left front of engine compt)
• Fc-v
• Fuse 10a
• Fuse 15a
• Fuse 40a
• Fuse 60a
• G103 (left front of engine compartment)
• G103 (left front of engine compt)
• Hot at all times
• Hs can+
• Hs can-
• Le424
• Pcm control
• Pcm power relay
• Powertrain control module (pcm) (left rear of engine compt)
• Re405
• Re407
• Red
• S102 (2.3l: in engine control sensor and fuel charge harness, near breakout to c175e) (3.0l: in engine control sensor and fuel charge harness, near breakout to c1450)
• S129 (in dash panel to headlamp junction harness, near breakout to battery junction box (bjb))
• Vdb04
• Vdb05
• Ve716
• Vec03
• Vh433

Электросхема кондиционера с ручный управлением (1 из 2) для Ford Fusion SEL 2006

Электросхема кондиционера с ручный управлением (1 из 2) для Ford Fusion SEL 2006 - Список элементов:

• (center of dash)
• (in a/c jumper, near breakout to c2295) s204
• (in a/c jumper, near breakout to c2295) s206
• (in a/c jumper, near breakout to c298) s205
• A/c req
• Ac req
• Amp
• Backlighting
• Batt power
• Battery junction box (bjb) (2.3l: left side of engine compt) (3.0l: left front of engine compt)
• Blend input
• Blower motor (right side of dash)
• Blower motor relay
• Blower relay
• C2280a
• C2280b
• C2357a
• C2357b
• Cbp20
• Ch122
• Ch123
• Ch207
• Ch208
• Ch228
• Ch229
• Ch233
• Ch234
• Ch428
• Ch429
• Ch430
• Ch434
• Computer data lines system
• Defogger system
• Defrost req
• Fresh/recirculation door actuator (right side of dash)
• Front blower motor resistor assembly (right side of dash)
• Fuse 40a
• Fuse 7.5a
• G201
• G202 (left side of dash)
• Gd115
• Gd116
• Gnd
• High
• Hot at all times
• Hot in run or acc
• Hot in start or run
• Hs can+
• Hs can-
• Ign feed
• Instrument cluster
• Interior lights system
• Lh111
• Manual climate control module (center of dash)
• Mid high
• Mid low
• Mode act fdbk
• Mode door actuator (center of dash)
• Mode input
• Pass temp fdbk
• Passenger temperature blend door actuator (right side of dash)
• R/s
• Recir door ccw
• Recir door cw
• Rh111
• S127 (2.3l: in dash panel to headlamp junction harness, near breakout to battery junction box (bjb)) (3.0l: in dash panel to headlamp junction harness, near breakout to powertrain control module (pcm))
• S131 (in dash panel to headlamp junction harness, near breakout to battery junction box (bjb))
• S227 (in main harness, near breakout to c251)
• S229 (in main harness, near breakout to g201)
• Sbp07
• Smart junction box (sjb) (base of left "a" pillar)
• Vh436
• Vh439
• Vln04
• Vref act (5v)
• Vref ret act

Электросхема кондиционера с ручный управлением (2 из 2) для Ford Fusion SEL 2006

Электросхема кондиционера с ручный управлением (2 из 2) для Ford Fusion SEL 2006 - Список элементов:

• (in dash panel to headlamp junction harness, near breakout to powertrain control module (pcm)) s124
• A/c clutch field coil (front of a/c compressor)
• A/c clutch relay
• A/c pressure transducer sensor (right front of engine)
• Accr
• Acpt
• Battery junction box (bjb) (2.3l: left side of engine compt) (3.0l: left front of engine compt)
• C-sigrtn
• C-vref
• C175b
• C175e
• Ce302
• Ch302
• Computer data lines system
• E-sigrtn
• Ect
• Engine coolant temperature (ect) sensor (rear of engine)
• Engine cooling fan motor (left front of engine compt)
• Fc-v
• Fuse 10a
• Fuse 15a
• Fuse 40a
• Fuse 60a
• G103 (left front of engine compartment)
• G103 (left front of engine compt)
• Hot at all times
• Hs can+
• Hs can-
• Le424
• Pcm control
• Pcm power relay
• Powertrain control module (pcm) (left rear of engine compt)
• Re405
• Re407
• Red
• S102 (2.3l: in engine control sensor and fuel charge harness, near breakout to c175e) (3.0l: in engine control sensor and fuel charge harness, near breakout to c1450)
• S129 (in dash panel to headlamp junction harness, near breakout to battery junction box (bjb))
• Vdb04
• Vdb05
• Ve716
• Vec03
• Vh433
