AIR CONDITIONING – Mitsubishi Galant SE 2010 – SYSTEM WIRING DIAGRAMS

AIR CONDITIONING

Automatic A/C Wiring Diagram (1 of 2) for Mitsubishi Galant SE 2010

List of elements for Automatic A/C Wiring Diagram (1 of 2) for Mitsubishi Galant SE 2010:

44

• (behind center of dash)
• (left front of engine compt) condenser fan motor
• (left side of engine compt) g13
• (left side of engine compt) grounding connector a-14
• (not used)
• (on relay box)
• 20a
• A-13
• A/c pressure sensor (right front of engine compt)
• A/c-ecu (behind lower center of dash)
• Air mixing damper control motor & potentiometer (behind center of dash)
• Air thermo sensor (behind lower center of dash)
• Ambient temperature sensor (behind left side of front bumper)
• C-04
• C-15
• C-16
• C-214
• C-23
• C-29
• Condenser fan relay
• Defogger system
• Fan control relay (on engine compt relay box)
• Fuse 10a
• Fuse 7.5a
• Fusible link 2 30a
• Fusible link 26 (in relay box)
• G13
• Hot at all times
• Hot in acc or on
• Hot in on
• Hot w/ taillight relay energized
• Interior lights system
• Interior temperature sensor (lower left side of dash, right of steering column)
• Joint con- nector 2 (behind instrument cluster)
• Joint connector 1 (upper left end of dash)
• Joint connector 2 (behind instrument cluster)
• Junction block (behind left side of dash)
• Mode selection damper control motor & potentiometer (behind left side of dash)
• Nca
• Outside/inside air selection damper control motor (behind right side of dash)
• Radiator fan motor (left front of engine compt)
• Radiator fan relay (on relay box)
• Red
• Relay box (left side of engine compt)

Automatic A/C Wiring Diagram (2 of 2) for Mitsubishi Galant SE 2010

List of elements for Automatic A/C Wiring Diagram (2 of 2) for Mitsubishi Galant SE 2010:

32

• A-13
• A/c compressor assembly
• A/c compressor clutch
• A/c compressor clutch relay (on engine compt relay box)
• A/c refrigerant temperature switch
• B-19
• B-21
• B-22
• Blower motor (below right side of dash)
• Blower relay
• C-211
• C-215
• Connector (under left side of dash)
• Data link
• Engine controls system
• Engine coolant temperature sensor (on left side engine compt)
• Fuse 10a
• Fuse 30a
• Fuse 7.5a
• G12 (left side of engine compt)
• G6 (behind instrument cluster)
• Hot at all times
• Hot in on
• Joint connector 3 (behind instrument cluster)
• Junction block (behind left side of dash)
• Nca
• Off
• Power transistor (behind center of dash)
• Powertrain control module (left front of engine compt)
• Radiator sensor (california) (mounted on radiator shroud)
• Red
• Relay box (left side of engine compt)

Manual A/C Wiring Diagram (1 of 2) for Mitsubishi Galant SE 2010

List of elements for Manual A/C Wiring Diagram (1 of 2) for Mitsubishi Galant SE 2010:

40

• (behind center of dash)
• (left front of engine compt) condenser fan motor
• (left side of engine compt) grounding connector a-14
• 20a
• A-13
• A/c pressure sensor (right front of engine compt)
• A/c-ecu (behind lower center of dash)
• Air mixing damper control motor & potentiometer (behind center of dash)
• Air thermo sensor (behind lower center of dash)
• Ambient temperature sensor (behind left side of front bumper)
• C-15
• C-16
• C-214
• C-23
• C-29
• Condenser fan relay (on relay box)
• Defogger system
• Fan control relay (on engine compt relay box)
• Fuse 10a
• Fuse 7.5a
• Fusible link 2 30a
• Fusible link 26 (in relay box)
• G13
• G13 (left side of engine compt)
• Hot at all times
• Hot in acc or on
• Hot in on
• Hot w/ taillight relay energized
• Interior lights system
• Joint con- nector 2 (behind instrument cluster)
• Joint connector 1 (upper left end of dash)
• Joint connector 2 (behind instrument cluster)
• Junction block (behind left side of dash)
• Mode selection damper control motor & potentiometer (behind left side of dash)
• Nca
• Outside/inside air selection damper control motor (behind right side of dash)
• Radiator fan motor (left front of engine compt)
• Radiator fan relay (on relay box)
• Red
• Relay box (left side of engine compt)

Manual A/C Wiring Diagram (2 of 2) for Mitsubishi Galant SE 2010

List of elements for Manual A/C Wiring Diagram (2 of 2) for Mitsubishi Galant SE 2010:

32

• A-13
• A/c compressor assembly
• A/c compressor clutch
• A/c compressor clutch relay (on engine compt relay box)
• A/c refrigerant temperature switch
• B-19
• B-21
• B-22
• Blower motor (below right side of dash)
• Blower relay
• C-211
• C-215
• Connector (under left side of dash)
• Data link
• Engine controls system
• Engine coolant temperature sensor (on left side engine compt)
• Fuse 10a
• Fuse 30a
• Fuse 7.5a
• G12 (left side of engine compt)
• G6 (behind instrument cluster)
• Hot at all times
• Hot in on
• Joint connector 3 (behind instrument cluster)
• Junction block (behind left side of dash)
• Nca
• Off
• Power transistor (behind center of dash)
• Powertrain control module (left front of engine compt)
• Radiator sensor (mounted on radiator shroud)
• Red
• Relay box (left side of engine compt)
