| A | Battery |
| B | Starter |
| C | Alternator |
| C1 | Voltage regulator |
| T2bo | 2-pin connector, on alternator |
| T2v | 2-pin connector, near battery |
| T6e | 6-pin connector, (brown) next to relay plate |
| 1 | Earth strap, battery body |
| 49 | Earth point, near battery |
| 500 | Screw connection -1- (30), on relay plate |
| 501 | Screw connection -2- (30), on relay plate |
| D26 | Positive connection (B+), in alternator wiring harness |
| P1 | Positive connection (30), in fuse holder/battery |
| E2 | Turn signal switch |
| E3 | Emergency Flasher Switch |
| E4 | Headlight Dimmer/Flasher Switch |
| S8 | Fuse |
| T2bv | 2-pin connector on number plate light |
| T2bw | 2-pin connector on number plate light |
| T5b | 5-pin connector, on headlight dipper/flasher switch |
| T6d | 6-pin connector, (black) next to relay plate |
| T6k | 6-pin connector, (lilac) next to relay plate |
| T7b | 7-pin connector, on turn signal switch |
| T8j | 8-pin connector, on hazard warning light switch |
| X | License Plate Light |
| 218 | Earth connection -1-, in rear lid wiring harness |
| A1 | Positive connection (30a), in dash panel wiring harness wiring harness |
| A5 | Positive connection (right turn signal), in dash panel wiring harness |
| A6 | Positive connection (left turn signal), in dash panel wiring harness |
| A9 | Positive connection (56 b), in instruments wiring harness |
| A157 | Connection (49a), in dash panel wiring harness |
| W11 | Connection (58), in rear lid wiring harness |
| L123 | Left Low Beam Lamp |
| L124 | Right Low Beam Lamp |
| L125 | Left High Beam Lamp |
| L126 | Right High Beam Lamp |
| M1 | Left Parking Light |
| M2 | Right Tail Light |
| M3 | Right Parking Light |
| M4 | Left Tail Light |
| S2 | Fuse |
| S5 | Fuse |
| S7 | Fuse |
| S15 | Fuse |
| S16 | Fuse |
| S20 | Fuse |
| S230 | Fuse in fuse holder |
| T1aa | Single connector, on main beam bulb, left |
| T1ab | Single connector, on main beam bulb, right |
| T2bh | 2-pin connector, on dipped beam bulb, left |
| T2bi | 2-pin connector, on dipped beam bulb, right |
| T2cb | 2-pin connector behind tailgate, near left wheel |
| T5l | 5-pin connector, on tail light, left |
| T5m | 5-pin connector, on tail light, right |
| T10c | 10-pin connector, near headlight, left |
| T10d | 10-pin connector, near headlight, right |
| 44 | Earth point, lower part of left A-pillar |
| 108 | Earth connection -2-, in front left wiring harness |
| 196 | Earth connection -3-, in rear wiring harness |
| 197 | Earth connection -4-, in rear wiring harness |
| 333 | Earth connection -5-, in rear wiring harness |
| E481 | Loading Area Illumination Switch |
| L28 | Cigarette Lighter Light |
| L42 | Socket Light Bulb |
| M53 | Loading Area Illumination Lamp |
| S12 | Fuse |
| S19 | Fuse |
| S225 | Fuse in fuse holder |
| T1b | Single connector, on cigarette lighter light bulb |
| T1at | Single connector, on socket light bulb |
| T2cw | 2-pin connector, on 12 V socket |
| T2d | 2-pin connector, on cigarette lighter |
| T3aa | 3-pin connector, on loading area illumination lamp |
| T6j | 6-pin connector, (green) next to relay plate |
| T6y | 6-pin connector, on Loading Area Illumination Switch |
| U1 | Cigarette Lighter |
| U5 | 12 V Socket |
| 43 | Earth point, lower part of right A-pillar |
| 199 | Earth connection -3-, in dash panel wiring harness |
| A37 | Connection (58a), in dash panel wiring harness |
| J285 | Control module with indicator unit in instrument panel insert |
| K | Instrument Cluster |
| K1 | Headlight High Beam Indicator Light |
| K2 | Generator (GEN) Warning Light |
| K4 | Park Light Indicator Light |
| L16 | Fresh Air Control Lever Light |
| T2a | 2-pin connector, behind dash panel, centre |
| T2bm, | 2-pin connector, on fresh air blower |
| T5t | 5-pin connector, on fresh air blower switch |
| T7d | 7-pin connector, on air conditioning system control unit |
| T8k | 8-pin connector, behind dash panel, centre |
| T32a | 32-pin connector, on dash panel insert |
| V2 | Fresh Air Blower |
| 44 | Earth point, lower part of left A-pillar |
| 81 | Earth connection -1-, in dash panel wiring harness |
| 97 | Earth connection -1-, in air conditioner wiring harness |
| A4 | Positive connection (58b), in dash panel wiring harness |
