| A | Battery |
| B | Starter |
| C | Alternator |
| C1 | Voltage regulator |
| K | Dash panel insert |
| T1ag | Single connector, on starter |
| T2bo | 2-pin connector, on alternator |
| T2v | 2-pin connector, near battery |
| T6e | 6-pin connector, (brown) next to relay plate |
| T32a | 32-pin connector, on dash panel insert |
| 1 | Earth strap, battery body |
| 49 | Earth point, near battery |
| 500 | Screw connection -1- (30), on relay plate |
| 501 | Screw connection -2- (30), on relay plate |
| D26 | Positive connection (B+), in alternator wiring harness |
| P1 | Positive connection (30), in fuse holder/battery |
| E22 | Intermittent wiper switch |
| J30 | Rear window wiper/washer relay |
| J31 | Automatic intermittent wash/wipe relay |
| S223 | Fuse in fuse holder |
| T2am | 2-pin connector, on rear window wiper |
| T2dm | 2-pin connector, behind rear left side panel trim, near wheel arch |
| T2s | 2-pin connector, on windscreen and rear |
| T4c | 4-pin connector, on intermittent wiper switch |
| T5a | 5-pin connector, on intermittent wiper switch |
| T6d | 6-pin connector, (black) next to relay plate |
| V12 | Rear window wiper motor |
| V59 | Windscreen and rear window washer pump |
| A158 | Connection (T), in dash panel wiring harness |
| A159 | Connection (L), in dash panel wiring harness |
| E1 | Light switch |
| E15 | Heated rear window switch |
| L39 | Heated rear window switch bulb |
| S17 | Fuse in relay plate fuse box |
| S230 | Fuse in fuse holder |
| S231 | Fuse in fuse holder |
| T1ac | Single connector, on heated rear window switch |
| T1ad | Single connector, on heated rear window switch |
| T2dl | 2-pin connector, behind rear left side panel trim, near wheel arch |
| T4d | 4-pin connector, on heated rear window switch |
| T5k | 5-pin connector, on windscreen wiper motor |
| T6i | 6-pin connector, (blue) next to relay plate |
| T17a | 17-pin connector, on light switch |
| V | Windscreen wiper motor |
| Z1 | Heated rear window |
| 43 | Earth point, lower part of right A-pillar |
| 44 | Earth point, left A-pillar, bottom |
| 51 | Earth point, on right in luggage compartment |
| 82 | Earth connection -1-, in front left wiring harness |
| 213 | Earth connection, in dash panel wiring harness |
| 218 | Earth connection -1-, in rear lid wiring harness |
| 333 | Earth connection -5-, in rear wiring harness |
| A37 | Connection (58a), in dash panel wiring harness |
| A82 | Connection (windscreen heater), in dash panel wiring harness |
