| D | Ignition/starter switch |
| J59 | X contact relief relay |
| J234 | Airbag control unit |
| J285 | Control unit with display in dash panel insert |
| K1 | Main beam warning lamp |
| K13 | Rear fog light warning lamp |
| L10 | Dash panel insert light bulb |
| SB43 | Fuse -43- on relay plate fuse holder |
| T32 | 32-pin connector, blue, on dash panel insert |
| 277 | Earth connection -3-, in interior wiring harness |
| 278 | Earth connection -4-, in interior wiring harness |
| 501 | Screw connection -2- (30), on relay plate |
| B138 | Positive connection (X), in interior wiring harness |
| B173 | Positive connection -2- (X), in interior wiring harness |
| D | Ignition/starter switch |
| E1 | Lighting switch |
| E18 | Rear fog light switch |
| L9 | Lighting switch light bulb |
| T17 | 17-pin connector, black, on lighting switch¹) |
| 76 | Earth point, near selector mechanism |
| 238 | Earth connection -1-, in interior wiring harness |
| 278 | Earth connection -4-, in interior wiring harness |
| 502 | Screw connection -3- (30), on relay plate |
| A83 | Connection (day driving lights), in dash panel wiring harness |
| B102 | Earth connection, in front left interior wiring harness |
| B110 | Connection (30, electric windows), in interior wiring harness |
| B145 | Positive connection (58b), in interior wiring harness |
| L20 | Rear fog light bulb |
| M2 | Tail light bulb, right |
| M4 | Tail light bulb, left |
| M6 | Turn signal bulb, rear left |
| M8 | Turn signal bulb, rear right |
| M9 | Brake light bulb, left |
| M10 | Brake light bulb, right |
| M16 | Reversing light bulb, left |
| M17 | Reversing light bulb, right |
| M25 | High level brake light bulb |
| T2g | 2-pin connector, black, in tailgate wiring harness |
| T5c | 5-pin connector, black, in tailgate feeder wiring harness¹) |
| T6b | 6-pin connector, black, left on tail light |
| T6c | 6-pin connector, black, right on tail light |
| 59 | Earth point, near left tail light |
| 277 | Earth connection -3-, in interior wiring harness |
| 287 | Earth connection, in tailgate/boot lid wiring harness |
| B109 | Earth connection, in rear left interior wiring harness |
| B131 | Connection (54), in interior wiring harness |
| B152 | Connection (BL), in interior wiring harness |
| B153 | Connection (BR), in interior wiring harness |
| D | Ignition/starter switch |
| E2 | Turn signal switch |
| E4 | Headlight dipper/flasher switch |
| E19 | Parking light switch |
| J1 | Turn signal relay |
| M1 | Side light bulb, left |
| L1 | Twin filament bulb/sealed beam insert, left |
| SB4 | Fuse -49- on relay plate fuse holder |
| SB12 | Fuse -12- on relay plate fuse holder |
| SB13 | Fuse -13- in relay plate fuse holder |
| SB44 | Fuse -44- in relay plate fuse holder |
| SB45 | Fuse -45- in relay plate fuse holder |
| T5 | 5-pin connector, black, behind steering column switch trim |
| T7 | 7-pin connector, red, behind steering column switch trim |
| T8c | 8-pin connector, black, on hazard warning light switch |
| T8e | 8-pin connector, black, on left headlight |
| T10b | 10-pin connector, black, coupling station under relay carrier¹) |
| T10c | 10-pin connector, blue, coupling station under relay carrier¹) |
| 167 | Earth connection -4-, in engine compartment wiring harness |
| B152 | Connection (BL), in interior wiring harness |
| B153 | Connection (BR), in interior wiring harness |
| D152 | Positive connection -1- (56b), in engine compartment wiring harness |
| L2 | Twin filament bulb/sealed beam insert, right |
| M3 | Side light bulb, right |
| SB5 | Fuse -5- on relay plate fuse holder |
| T8f | 8-pin connector, black, near right headlight |
| T10c | 10-pin connector, blue, coupling station under relay carrier¹) |
| 131 | Earth connection -2-, in engine compartment wiring harness |
| 167 | Earth connection -4-, in engine compartment wiring harness |
| D153 | Positive connection -2- (56b), in engine compartment wiring harness |
| * | For petrol engines only |
| ** | For diesel engines only |
| E20 | Switches and instruments - lighting control |
| E102 | Headlight range control adjuster |
| L54 | Headlight range control adjuster light bulb |
| L105 | Illumination control switch illumination |
| SB2 | Fuse -2- relay plate fuse holder |
| SB9 | Fuse -9- relay plate fuse holder |
| T8e | 8-pin connector, black, near left headlight |
| T8f | 8-pin connector, black, near right headlight |
| T10c | 10-pin connector, blue, coupling station under relay carrier |
| V48 | Headlight range control motor, left |
| V49 | Headlight range control motor, right |
| X | Number plate light |
| 131 | Earth connection -2-, in engine compartment wiring harness |
| B102 | Earth connection, in front left interior wiring harness |
| B109 | Earth connection, in rear left interior wiring harness |
| B117 | Connection (58d, right), in interior wiring harness |
