| D | Ignition/starter switch |
| E9 | Fresh air blower switch |
| J59 | X contact relief relay |
| J285 | Control unit with display in dash panel insert |
| K1 | Main beam warning lamp |
| K4 | Side light warning lamp |
| K13 | Rear fog light warning lamp |
| SB43 | Fuse -43- on fuse box |
| T32 | 32-pin connector, blue |
| 76 | Earth point, near selector mechanism |
| 81 | Earth connection -1-, in dash panel wiring harness |
| 500 | Screw connection -1- (30), on relay plate |
| A34 | Connection (75x), in dash panel wiring harness |
| B102 | Earth connection, in interior wiring harness, front left |
| B115 | Positive (+) connection (30, central electrics), in interior wiring harness |
| D | Ignition/starter switch |
| E1 | Lighting switch |
| E20 | Switches and instruments, lighting control |
| E23 | Front and rear fog light switch |
| J39 | Headlight washer system relay |
| K4 | Side light warning lamp |
| L9 | Lighting switch light bulb |
| T10a | 10-pin connector, green, near relay station |
| T10b | 10-pin connector, black, near relay station |
| T17 | 17-pin connector, , black |
| A4 | Positive (+) connection (58b), in dash panel wiring harness |
| A88 | Connection (rear fog light), in dash panel wiring harness |
| F4 | Reversing light switch |
| L20 | Rear fog light bulb |
| M2 | Tail light bulb, right |
| M4 | Tail light bulb, left |
| M6 | Turn signal bulb, rear left |
| M8 | Turn signal bulb, rear right |
| M9 | Brake light bulb, left |
| M10 | Brake light bulb, right |
| M17 | Reversing light bulb, right |
| M25 | High level brake light bulb |
| T5a | 5-pin connector, black |
| T5b | 5-pin connector, black |
| T5c | 5-pin connector, black, in rear lid prewiring wiring harness |
| T5f | 5-pin connector, black, in tailgate/boot lid |
| T10d | 10-pin connector, red, near relay station |
| 59 | Earth point, near left tail light |
| 287 | Earth connection, in rear lid prewiring wiring harness |
| A87 | Connection (RL), in dash panel wiring harness |
| B109 | Earth connection, in interior wiring harness, rear left |
| B131 | Connection (54), in interior wiring harness |
| B152 | Connection (BL (turn signal, left)), in interior wiring harness |
| B153 | Connection (BR (turn signal, right)), in interior wiring harness |
| D | Ignition/starter switch |
| E2 | Turn signal switch |
| E4 | Headlight dipper/flasher switch |
| E19 | Parking light switch |
| J1 | Turn signal relay |
| SB12 | Fuse -12- on fuse box |
| SB13 | Fuse -13- on fuse box |
| SB44 | Fuse -44- on fuse box |
| SB45 | Fuse -45- on fuse box |
| T5 | 5-pin connector, black, behind steering column switch trim |
| T7 | 7-pin connector, red, behind steering column switch trim |
| T7c | 7-pin connector, black |
| T10b | 10-pin connector, black, near relay station |
| T10c | 10-pin connector, blue, near relay station |
| T10d | 10-pin connector, red, near relay station |
| B152 | Connection (BL (turn signal, left)), in interior wiring harness |
| B153 | Connection (BR (turn signal, right)), in interior wiring harness |
| B166 | Connection (56a), in interior wiring harness |
| B167 | Connection (56b), in interior wiring harness |
| L1 | Twin filament bulb for headlight, left |
| L2 | Twin filament bulb for headlight, right |
| M1 | Side light bulb, left |
| M3 | Side light bulb, right |
| SB4 | Fuse -4- on fuse box |
| SB5 | Fuse -5- on fuse box |
| T8e | 8-pin connector, black, near headlight, left |
| T8f | 8-pin connector, black, near headlight, right |
| T10c | 10-pin connector, blue, near relay station |
| 12 | Earth point, in engine compartment, left |
| 82 | Earth connection -1-, in front left wiring harness |
| A84 | Connection (58L), in dash panel wiring harness |
| A85 | Connection (58R), in dash panel wiring harness |
| B143 | Positive (+) connection (58R), in interior wiring harness |
| B144 | Positive (+) connection (58L), in interior wiring harness |
| D | Ignition/starter switch |
| E20 | Switches and instruments - lighting control |
| E102 | Headlight range control adjuster |
| L54 | Headlight range control adjuster light bulb |
| L105 | Illumination control switch illumination |
| SB9 | Fuse -9- on fuse box |
| SB33 | Fuse -33- on fuse box |
| T8e | 8-pin connector, black, near headlight, left |
| T8f | 8-pin connector, black, near headlight, right |
| T10c | 10-pin connector, blue, near relay station |
| T10s | 10-pin connector, green, near relay station |
| V48 | Headlight range control motor, left |
| V49 | Headlight range control motor, right |
| 12 | Earth point, in engine compartment, left |
| 131 | Earth connection -2-, in engine compartment wiring harness |
| A114 | Connection (headlight range control), in dash panel wiring harness |
| B135 | Connection -1- (15a), in interior wiring harness |
| B149 | Positive (+) connection -2- (15a), in interior wiring harness |
| D52 | Positive (+) connection (15a), in engine compartment wiring harness |
| L22 | Fog light bulb, left |
| L23 | Fog light bulb, right |
| SB2 | Fuse -2- in relay plate fuse box |
| X | Number plate light |
| 12 | Earth point, in engine compartment, left |
| 59 | Earth point, near left tail light |
| 82 | Earth connection -1-, in front left wiring harness |
| B8 | Positive (+) connection (58), in light switch wiring harness |
| B109 | Earth connection, in interior wiring harness, rear left |
| C25 | Connection (fog light), in front lighting wiring harness |
| W27 | Positive (+) connection (58), in tail light wiring harness |
