Wiring Diagram VW POLO 2002 - Automatic intermittent wash/wipe relay - automatic anti-dazzle interior mirror - rain sensor
D | Ignition/starter switch |
F4 | Reversing light switch |
G213 | Rain sensor |
J31 | Automatic intermittent wash/wipe relay, on relay plate |
SB26 | Fuse -26- in fuse box |
T4 | 4-pin connector, near front interior light |
T6 | 6-pin connector, near interior light, front |
T9 | 9-pin connector, near interior light, front |
T9a | 9-pin connector, on automatic intermittent wash/wipe relay |
T10d | 10-pin connector, red, near relay station |
Y7 | Automatic anti-dazzle interior mirror |
76 | Earth point, near selector mechanism |
81 | Earth connection -1-, in dash panel wiring harness |
303 | Earth connection -rain sensor/mirror-, in interior wiring harness |
A20 | Connection (15a), in dash panel wiring harness |
A87 | Connection (RL), in dash panel wiring harness |
B102 | Earth connection, in interior wiring harness, front left |
B235 | Positive (+) connection -4- (15), in interior wiring harness |
Wiring Diagram VW POLO 2002 - Intermittent wiper switch - windscreen wiper motor - windscreen and rear window washer pump - automatic intermittent wash/wipe relay
E22 | Intermittent wiper switch |
E34 | Rear wiper switch |
J31 | Automatic intermittent wash/wipe relay |
SB50 | Fuse -50- in fuse box |
T4a | 4-pin connector, black, behind steering column switch trim |
T5c | 5-pin connector, black, in rear lid pre-wiring wiring harness |
T5d | 5-pin connector |
T5e | 5-pin connector |
T9a | 9-pin connector, on automatic intermittent wash/wipe relay |
T10 | 10-pin connector, white, near relay station |
T10a | 10-pin connector, green, near relay station |
T10b | 10-pin connector, black, near relay station |
T10c | 10-pin connector, blue, near relay station |
T10d | 10-pin connector, red |
V | Windscreen wiper motor |
V59 | Windscreen and rear window washer pump |
81 | Earth connection -1-, in dash panel wiring harness |
B162 | Connection (75a), in interior wiring harness |
Q44 | Connection -2-, in tailgate/bootlid wiring harness |
* | Not with headlight washer system |
Wiring Diagram VW POLO 2002 - Rear window wiper motor
SB6 | Fuse -6- in fuse box/relay plate |
T3a | 3-pin connector, black, in tailgate/bootlid, near wiper motor |
T5c | 5-pin connector, black, in rear lid pre-wiring wiring harness |
T5f | 5-pin connector, black, in tailgate/bootlid |
V12 | Rear window wiper motor |
59 | Earth point, near left tail light |
287 | Earth connection, in rear lid pre-wiring wiring harness |
A96 | Connection (53a), in dash panel wiring harness |
