| D | Ignition/starter switch |
| E1 | Lighting switch |
| E4 | Headlight dipper/flasher switch |
| E20 | Switches and instruments - lighting control |
| E23 | Front and rear fog light switch |
| J285 | Control unit with display in dash panel insert |
| K4 | Side light warning lamp |
| K13 | Rear fog light warning lamp |
| L9 | Lighting switch light bulb |
| T5 | 5-pin connector, black, behind steering column switch trim |
| T10b | 10-pin connector, black, near relay station |
| T32a | 32-pin connector, blue, on dash panel insert |
| 76 | Earth point, near selector mechanism |
| A3 | Positive (+) connection (58), in dash panel wiring harness |
| B102 | Earth connection, in front left interior wiring harness |
| B115 | Positive connection (30, central electrics), in interior wiring harness |
| * | Resistance wire |
| E19 | Parking light switch |
| F4 | Reversing light switch |
| L20 | Rear fogl ight bulb |
| M2 | Tail light bulb, right |
| M4 | Tail light bulb, left |
| M6 | Turn signal bulb, rear left |
| M8 | Turn signal bulb, rear right |
| M9 | Brake light bulb, left |
| M10 | Brake light bulb, right |
| M17 | Reversing light bulb, right |
| S16 | Fuse in relay plate fuse box |
| S17 | Fuse in relay plate fuse box |
| T5a | 5-pin connector, black, right on tail light |
| T5b | 5-pin connector, black, left on tail light |
| T10d | 10-pin connector, red, near relay station |
| 59 | Earth point, near left-hand tail light |
| B109 | Earth connection, in rear left interior wiring harness |
| B131 | Connection (54), in interior wiring harness |
| B152 | Connection (BL), in interior wiring harness |
| B153 | Connection (BR), in interior wiring harness |
| S231 | Fuse in fuse holder |
| T19 | 19-pin connector, black, front left in engine compartment |
| X | Number plate light |
| 85 | Earth connection -1-, in engine compartment wiring harness |
| 119 | Earth connection -1-, in headlight wiring harness |
| 120 | Earth connection -2-, in headlight wiring harness |
| 131 | Earth connection -3-, in engine compartment wiring harness |
| 167 | Earth connection -4-, in engine compartment wiring harness |
| B109 | Earth connection, in rear left interior wiring harness |
| W27 | Positive connection (58), in tail light wiring harness |
| * | For petrol engine only |
| ** | For diesel engine only |
| For petrol engine with automatic gearbox only |
| For petrol engine with manual gearbox only |
| L22 | Rear fog light bulb |
| L23 | Rear fog light bulb |
| S19 | Fuse in relay plate fuse box |
| T19 | 19-pin connector, black, front left in engine compartment |
| 12 | Earth point, in engine compartment, left |
| 85 | Earth connection -1-, in engine compartment wiring harness |
| 120 | Earth connection -2-, in headlight wiring harness |
| 131 | Earth connection -3-, in engine compartment wiring harness |
| 167 | Earth connection -4-, in engine compartment wiring harness |
| A80 | Connection -1- (X), in dash panel wiring harness |
| C25 | Connection (fog light), in front lighting wiring harness |
| * | For petrol engine with manual gearbox only |
| ** | For engine codes AGD and AHG only |
| *** | For engine code AEF only |
| For petrol engine with automatic gearbox only |
| E102 | Headlight range control adjuster |
| K1 | Main beam warning lamp |
| L1 | Twin filament bulb/sealed beam insert, left |
| L2 | Twin filament bulb/sealed beam insert, right |
| M1 | Side light bulb, left |
| M3 | Side light bulb, right |
| S12 | Fuse in relay plate fuse box |
| S13 | Fuse in relay plate fuse box |
| S14 | Fuse in relay plate fuse box |
| S15 | Fuse in relay plate fuse box |
| T7a | 7-pin connector, black, near left headlight |
| T7b | 7-pin connector, black, near right headlight |
| T10b | 10-pin connector, black, near relay station |
| T10c | 10-pin connector, blue, near relay station |
| T19 | 19-pin connector, black, front left in engine compartment |
| V48 | Headlight range control motor, left |
| V49 | Headlight range control motor, right |
| 119 | Earth connection -1-, in headlight wiring harness |
| C28 | Connection -1- (56b), in headlight wiring harness |
| C29 | Connection -2- (56b), in headlight wiring harness |
| * | Resistance wire |
