| E165 | Tailgate/boot lid release switch |
| F2 | Door contact switch, driver's side |
| F3 | Door contact switch, front passenger's side |
| F5 | Luggage compartment light switch |
| F120 | Anti-theft alarm system contact switch |
| H8 | Anti-theft alarm system horn |
| J285 | Control unit with display in dash panel insert |
| J393 | Convenience system central control unit |
| R47 | Central locking and anti-theft alarm system |
| T5 | 5-pin connector, brown, in rear lid prewiring wiring harness |
| W3 | Luggage compartment light |
| 12 | Earth point, in engine compartment, left |
| 52 | Earth point, in tailgate/boot lid, left |
| 98 | Earth connection, in tailgate/boot lid wiring harness |
| 179 | Earth connection, in left headlight wiring harness |
| A76 | Connection (diagnosis wire K), in dash panel wiring harness |
| A126 | Connection (tailgate/boot lid contact switch), in dash panel wiring harness |
| B152 | Connection (BL (turn signal, left)), in interior wiring harness |
| B153 | Connection (BR (turn signal, right)), in interior wiring harness |
| B154 | Connection -1- (TK (door contact)), in interior wiring harness |
| B155 | Connection -2- (TK (door contact)), in interior wiring harness |
| J362 | Immobilizer control unit, next to steering column |
| J393 | Convenience system central control unit |
| K133 | Central locking warning lamp -SAFE- |
| R | Radio |
| SB38 | Fuse -38- on fuse box |
| T8 | 8-pin connector |
| T10 | 10-pin connector |
| T15 | 15-pin connector |
| T18 | 18-pin connector, in driver's door |
| T23 | 23-pin connector |
| V69 | Central locking pump with control unit |
| 75 | Earth point, rear pillar, right |
| B6 | Connection (S), in steering column switch wiring harness |
| B133 | Connection (central locking open), in interior wiring harness |
| B134 | Connection (central locking closed), in interior wiring harness |
| R10 | Positive (+) connection -1- (30), in door wiring harness - driver's side |
| Q59 | Connection (country coding), in ATA wiring harness |
| E267 | Interior monitoring deactivation switch |
| G209 | Anti-theft alarm ultra-sonic sensor, rear B-pillar driver's side |
| J393 | Convenience system central control unit |
| T4 | 4-pin connector, on interior monitoring deactivation switch |
| T8 | 8-pin connector |
| T9 | 9-pin connector, near interior light |
| T15 | 15-pin connector |
| T16 | 16-pin connector, self-diagnosis connection |
| T23 | 23-pin connector |
| W | Interior light, front |
| 76 | Earth point, near selector mechanism |
| 105 | Earth connection -1-, in central locking wiring harness |
| 223 | Earth connection -1-, in ATA wiring harness |
| A66 | Connection (30a, central locking/anti-theft alarm system/infra-red remote control), in dash panel wiring harness |
| A76 | Connection (diagnosis wire K), in dash panel wiring harness |
| Q52 | Connection (door contact switch), in ATA wiring harness |
| D | Ignition/starter switch |
| J393 | Convenience system central control unit |
| SB14 | Fuse -14- in fuse box |
| SB22 | Fuse -22- in fuse box |
| SB26 | Fuse -26- in fuse box |
| SB41 | Fuse -41- in fuse box |
| T15 | 15-pin connector |
| T23 | 23-pin connector |
| 500 | Screw connection -1- (30), on relay plate |
| 502 | Screw connection -1- (30a), on relay plate |
| A20 | Connection (15a), in dash panel wiring harness |
| A32 | Positive (+) connection (30), in dash panel wiring harness |
| A52 | Positive (+) connection -2- (30), in dash panel wiring harness |
| A57 | Positive (+) connection -3- (30), in dash panel wiring harness |
| A66 | Connection (30a, central locking/anti-theft alarm system/infra-red remote control), in dash panel wiring harness |
| B235 | Positive (+) connection -4- (15a), in interior wiring harness |
| Q51 | Positive (+) connection (30), in anti-theft alarm system wiring harness |
