| J285 | Control unit with display in dash panel insert |
| K1 | Main beam warning lamp |
| K65 | Left turn signal warning lamp |
| K94 | Right turn signal warning lamp |
| L1 | Twin filament bulb for headlight, left |
| M1 | Side light bulb, left |
| M5 | Turn signal bulb, front left |
| M18 | Side turn signal bulb, left |
| SB13 | Fuse -13- on fuse box |
| SB44 | Fuse -44- on fuse box |
| T4a | 4-pin connector, in headlight, left |
| T10b | 10-pin connector, white, in protective housing for connectors |
| T32 | 32-pin connector, blue |
| 12 | Earth point, in engine compartment, left |
| 179 | Earth connection, in left headlight wiring harness |
| A5 | Positive (+) connection (right turn signal), in dash panel wiring harness |
| A6 | Positive (+) connection (left turn signal), in dash panel wiring harness |
| B167 | Connection (56b), in interior wiring harness |
| C20 | Connection (turn signal, left), in headlight wiring harness |
| D | Ignition/starter switch |
| E2 | Turn signal switch |
| E3 | Hazard warning light switch |
| E4 | Headlight dipper/flasher switch |
| E19 | Parking light switch |
| L2 | Twin filament bulb for headlight, right |
| M3 | Side light bulb, right |
| M6 | Turn signal bulb, rear left |
| M7 | Turn signal bulb, front right |
| M8 | Turn signal bulb, rear right |
| M19 | Side turn signal bulb, right |
| SB12 | Fuse -12- on fuse box |
| SB45 | Fuse -45- on fuse box |
| T4 | 4-pin connector, in headlight, right |
| T5e | 5-pin connector |
| T7g | 7-pin connector |
| T8 | 8-pin connector |
| T10b | 10-pin connector, white, in protective housing for connectors |
| T10h | 10-pin connector, green, in protective housing for connectors |
| TV2 | Terminal 30 junction box |
| 179 | Earth connection, in left headlight wiring harness |
| A5 | Positive (+) connection (right turn signal), in dash panel wiring harness |
| A6 | Positive (+) connection (left turn signal), in dash panel wiring harness |
| A32 | Positive (+) connection (30), in dash panel wiring harness |
| B167 | Connection (56b), in interior wiring harness |
| C19 | Connection -1- (turn signal, right), in headlight wiring harness |
| D | Ignition/starter switch |
| E1 | Lighting switch |
| L9 | Lighting switch light bulb |
| TV2 | Terminal 30 junction box |
| T17 | 17-pin connector |
| 43 | Earth point, lower part of right A-pillar |
| 80 | Earth connection -1-, in instruments wiring harness |
| 199 | Earth connection -3-, in dash panel wiring harness |
| A4 | Positive (+) connection (58b), in dash panel wiring harness |
| A32 | Positive (+) connection (30), in dash panel wiring harness |
| A80 | Connection -1- (X), in dash panel wiring harness |
| A83 | Connection (daytime driving lights), in dash panel wiring harness |
| M21 | Brake and tail light bulb, left |
| M22 | Brake and tail light bulb, right |
| SB4 | Fuse -4- on fuse box |
| SB5 | Fuse -5- on fuse box |
| T5a | 5-pin connector |
| T5b | 5-pin connector |
| T6e | 6-pin connector, on left C-pillar |
| T6n | 6-pin connector |
| T6p | 6-pin connector |
| T10h | 10-pin connector, green, in protective housing for connectors |
| 50 | Earth point, in left luggage compartment |
| 51 | Earth point, in right luggage compartment |
| 86 | Earth connection -1-, in rear wiring harness |
| 87 | Earth connection -2-, in rear wiring harness |
| A83 | Connection (daytime driving lights), in dash panel wiring harness |
| A84 | Connection (58L), in dash panel wiring harness |
| A85 | Connection (58R), in dash panel wiring harness |
| * | Only models Polo Classic |
| Only models Polo Variant |
| SB2 | Fuse -2- on fuse box |
| T5k | 5-pin connector, black, in C pillar, right |
| T5q | 5-pin connector, black, in tailgate/bootlid, rear right |
| T6d | 6-pin connector, in tailgate/bootlid |
| T6e | 6-pin connector, on left C-pillar |
| T10h | 10-pin connector, green, in protective housing for connectors |
| X | Number plate light |
| 53 | Earth point, in tailgate/bootlid, left |
| 98 | Earth connection, in tailgate/bootlid wiring harness |
| 287 | Earth connection, in wiring harness for tailgate/bootlid |
| A61 | Positive (+) connection (X), in instruments wiring harness |
| A83 | Connection (daytime driving lights), in dash panel wiring harness |
| W11 | Connection (58), in tailgate/bootlid wiring harness |
| * | Only models Polo Classic |
| Only models Polo Variant |
