Wiring Diagram VW POLO 2000 - Mirror adjustment switch - mirror adjustment motor (driver's side) - heated exterior mirror (driver's side)
E15 | Heated rear window switch |
E43 | Mirror adjustment switch |
L78 | Mirror adjustment switch illumination |
S224 | Fuse in fuse holder |
T5c | 5-pin connector, black, in tailgate wiring harness - feeder |
T5h | 5-pin connector, black, in driver's door |
T6h | pin connector, black, left on lower A-pillar |
V17 | Mirror adjustment motor, driver's side |
Z1 | Heated rear window |
Z4 | Heated exterior mirror, driver's side |
59 | Earth point, near left-hand tail light |
205 | Earth connection, in driver's door wiring harness |
277 | Earth connection -3-, in interior wiring harness |
503 | Screw connection (75x), on relay plate |
A80 | Connection -1- (X), in dash panel wiring harness |
A82 | Connection (windscreen heater), in dash panel wiring harness |
A96 | Connection (53a), in dash panel wiring harness |
R27 | Connection (mirror adjustment), in driver's door wiring harness |
* | 2.5 mm² cross section from model year 1998 |
Wiring Diagram VW POLO 2000 - Mirror adjustment change-over switch - mirror adjustment motor (passenger's side) - heated exterior mirror (passenger's side)
E1 | Lighting switch |
E48 | Mirror adjustment change-over switch |
L78 | Mirror adjustment switch illumination |
T5i | 5-pin connector, black, in passenger's door |
T6h | pin connector, black, left on lower A-pillar |
T6k | Single connector, black, right on lower A-pillar |
V25 | Mirror adjustment motor, front passenger side |
Z5 | Heated exterior mirror, front passenger's side |
76 | Earth point, near selector mechanism |
278 | Earth connection -4-, in interior wiring harness |
A3 | Positive (+) connection (58), in dash panel wiring harness |
A82 | Connection (windscreen heater), in dash panel wiring harness |
R27 | Connection (mirror adjustment), in driver's door wiring harness |
