VW JETTA 2014 – Convenience system, (AW1) . Wiring diagrams, Pin Connector, Location

Wiring Diagram VW JETTA 2014 - Battery - Fuse 1 in fuse holder A - Fuse 4 in fuse holder A - Fuse 25 on fuse holder B - Fuse holder C

A	Battery
C	Alternator
SA1	Fuse 1 in fuse holder A
SA4	Fuse 4 in fuse holder A
SB25	Fuse 25 on fuse holder B
SC	Fuse holder C
SC22	Fuse 22 on fuse holder C
SC36	Fuse 36 on fuse holder C
SC45	Fuse 45 on fuse holder C
SC46	Fuse 46 on fuse holder C
SC48	Fuse 48 on fuse holder C
SC51	Fuse 51 on fuse holder C
508	Threaded connection (30) on E-box
B111	Positive connection 1 (30a), in interior wiring harness
B169	Positive connection 1 (30), in interior wiring harness
B170	Positive connection 2 (30), in interior wiring harness
B171	Positive connection 3 (30), in interior wiring harness
*	Only models with no hybrid drive system
*2	Cross section depends on equipment
*3	see applicable current flow diagram for high-voltage system

Wiring Diagram VW JETTA 2014 - Front left window regulator switch - Rear left window regulator switch - in driver door - Rear right window regulator switch - in driver door - Front right window regulator switch in driver door - Childproof lock button - Driver door control unit

E40	Front left window regulator switch
E53	Rear left window regulator switch, in driver door
E55	Rear right window regulator switch, in driver door
E81	Front right window regulator switch in driver door
E318	Childproof lock button
J386	Driver door control unit
K236	Warning light for activated childproof lock
L76	Button illumination bulb
T10f	10-pin connector
T20a	20-pin connector
T28	28-pin connector, lower part of A-pillar, driver side
T32a	32-pin connector
V147	Driver side window regulator motor
205	Earth connection, in driver door wiring harness
Q38	Positive connection 1 (58b), in window regulator wiring harness
R10	Positive connection 1 (30), in driver door wiring harness
S25	Positive connection (30a), in central locking wiring harness
*	Gradually discontinued

Wiring Diagram VW JETTA 2014 - Rear lid remote release button - Driver side interior locking button for central locking system - Driver door control unit - Central locking SAFELOCK function warning lamp

E233	Rear lid remote release button
E308	Driver side interior locking button for central locking system
J386	Driver door control unit
K133	Central locking SAFELOCK function warning lamp
K174	Driver side interior locking warning lamp
L76	Button illumination bulb
T2z	2-pin connector
T4am	4-pin connector
T4w	4-pin connector
T20a	20-pin connector
T28	28-pin connector, lower part of A-pillar, driver side
T32a	32-pin connector
205	Earth connection, in driver door wiring harness
Q38	Positive connection 1 (58b), in window regulator wiring harness

Wiring Diagram VW JETTA 2014 - Mirror adjustment switch - Mirror adjustment changeover switch - Exterior mirror heater button - Fold-in mirror switch - Fuel tank flap release button - Driver door control unit - Mirror adjustment switch illumination bulb

E43	Mirror adjustment switch
E48	Mirror adjustment changeover switch
E231	Exterior mirror heater button
E263	Fold-in mirror switch
E319	Fuel tank flap release button
J386	Driver door control unit
L76	Button illumination bulb
L78	Mirror adjustment switch illumination bulb
T4ac	4-pin connector
T6al	6-pin connector
T32a	32-pin connector
205	Earth connection, in driver door wiring harness
Q38	Positive connection 1 (58b), in window regulator wiring harness
*	Only for American markets

Wiring Diagram VW JETTA 2014 - Driver door control unit - Driver side exterior mirror - Driver side fold-in mirror motor - Driver side mirror adjustment motor

J386	Driver door control unit
L131	Driver side turn signal repeater bulb
T2sk	2-pin connector, in driver side exterior mirror housing
T2sl	2-pin connector, in driver side exterior mirror housing
T16a	16-pin connector
T20a	20-pin connector
T28	28-pin connector, lower part of A-pillar, driver side
VX4	Driver side exterior mirror
V17	Driver side mirror adjustment motor
V121	Driver side fold-in mirror motor
V149	Driver side mirror adjustment motor
Z4	Heated exterior mirror on driver side
44	Earth point, lower part of left A-pillar
107	Earth connection, in external mirror wiring harness
205	Earth connection, in driver door wiring harness
386	Earth connection 21, in main wiring harness
*	According to equipment
*2	Wiring colour depends on equipment

Wiring Diagram VW JETTA 2014 - Driver door contact switch - Driver side central locking lock unit - Driver door control unit - Driver door central locking motor

F2	Driver door contact switch
F220	Driver side central locking lock unit
J386	Driver door control unit
T8f	8-pin connector
T20a	20-pin connector
V56	Driver door central locking motor
V161	Driver door central locking SAFELOCK function motor
44	Earth point, lower part of left A-pillar
367	Earth connection 2, in main wiring harness
605	Earth point, on top end of steering column
*	Not for American markets

Wiring Diagram VW JETTA 2014 - Window regulator switch in front passenger door - Front passenger door contact switch - Front passenger side central locking lock unit - Front passenger door control unit - Front passenger seat central locking motor - Front passenger side window regulator motor

E107	Window regulator switch in front passenger door
F3	Front passenger door contact switch
F221	Front passenger side central locking lock unit
J387	Front passenger door control unit
L76	Button illumination bulb
T4ak	4-pin connector
T8h	8-pin connector
T20b	20-pin connector
T28a	28-pin connector, lower part of A-pillar, front passenger side
T32b	32-pin connector
V57	Front passenger seat central locking motor
V148	Front passenger side window regulator motor
V162	Front passenger door central locking SAFELOCK function motor
206	Earth connection, in front passenger door wiring harness
R16	Positive connection 1 (30), in front passenger door wiring harness
*	Not for American markets

Wiring Diagram VW JETTA 2014 - Front passenger door control unit - Front passenger side exterior mirror - Front passenger side fold-in mirror motor - Front passenger side mirror adjustment motor

J387	Front passenger door control unit
L132	Front passenger side turn signal repeater bulb
T2sm	2-pin connector, in front passenger side exterior mirror housing
T2sr	2-pin connector, in front passenger side exterior mirror housing
T16b	16-pin connector
VX5	Front passenger side exterior mirror
V25	Front passenger side mirror adjustment motor
V122	Front passenger side fold-in mirror motor
V150	Front passenger side mirror adjustment motor
Z5	Heated exterior mirror on front passenger side
801	Earth connection 2, in external mirror wiring harness, in right door, near exterior mirror
*	According to equipment
*2	Wiring colour depends on equipment

Wiring Diagram VW JETTA 2014 - Interior monitoring deactivation switch - Front passenger side interior locking button for central locking system - Deactivation button for vehicle inclination sender - Front passenger door control unit - Onboard supply control unit - Front interior light

E267	Interior monitoring deactivation switch
E309	Front passenger side interior locking button for central locking system
E360	Deactivation button for vehicle inclination sender
J387	Front passenger door control unit
J519	Onboard supply control unit
L76	Button illumination bulb
T4an	4-pin connector
T4br	4-pin connector
T6b	6-pin connector
T32b	32-pin connector
T52a	52-pin connector
T52b	52-pin connector
T52c	52-pin connector
W1	Front interior light
B154	Connection 1 (DCt), in interior wiring harness
B250	Positive connection, in roof wiring harness
*	According to equipment

Wiring Diagram VW JETTA 2014 - Rear lid handle release button - Luggage compartment light switch - Rear lid lock unit - Onboard supply control unit - Tank filler flap locking motor - Rear lid electric opener motor - Luggage compartment light

E234	Rear lid handle release button
F5	Luggage compartment light switch
F256	Rear lid lock unit
J519	Onboard supply control unit
T2aq	2-pin connector
T2t	2-pin connector
T2x	2-pin connector
T4u	4-pin connector
T52a	52-pin connector
T52b	52-pin connector
V155	Tank filler flap locking motor
V254	Rear lid electric opener motor
W3	Luggage compartment light
86	Earth connection 1, in rear wiring harness
391	Earth connection 26, in main wiring harness
662	Earth point, rear left side panel
B128	Connection (luggage compartment light), in interior wiring harness
B722	Connection 3 (central locking), in main wiring harness
*	gradual introduction
*2	Gradually discontinued

Wiring Diagram VW JETTA 2014 - Interior monitoring sensor - Vehicle inclination sender - Alarm horn - Onboard supply control unit

G273	Interior monitoring sensor
G384	Vehicle inclination sender
H12	Alarm horn
H18	Alarm system horn
J519	Onboard supply control unit
J682	Terminal 50 voltage supply relay
T2ah	2-pin connector
T3f	3-pin connector
T4j	4-pin connector
T9c	9-pin connector
T52b	52-pin connector
T52c	52-pin connector
347	Earth connection, in roof wiring harness
389	Earth connection 24, in main wiring harness
A32	Positive connection (30), in dash panel wiring harness
A57	Positive connection 3 (30), in dash panel wiring harness
B321	Positive connection 7 (30a) in main wiring harness
B549	Connection 2 (LIN bus) in main wiring harness
*	Not for American markets
*2	Only for American markets
*3	Cross section depends on equipment

Wiring Diagram VW JETTA 2014 - Rear left window regulator switch - in door - Rear left door control unit - Onboard supply control unit - Rear left window regulator motor

E52	Rear left window regulator switch, in door
J388	Rear left door control unit
J519	Onboard supply control unit
L76	Button illumination bulb
T4aq	4-pin connector
T20f	20-pin connector
T28b	28-pin connector, on left B-pillar
V26	Rear left window regulator motor
207	Earth connection, in rear left door wiring harness
A62	Connection (window regulators), in dash panel wiring harness
Q40	Positive connection 3 (58b), in window regulator wiring harness
R19	Positive connection 1 (30), in rear left door wiring harness

Wiring Diagram VW JETTA 2014 - Rear central switch for interior locking - Rear left door contact switch - Rear left central locking lock unit - Rear left door control unit - Onboard supply control unit - Rear left door central locking motor - lock

E286	Rear central switch for interior locking
F10	Rear left door contact switch
F222	Rear left central locking lock unit
J388	Rear left door control unit
J519	Onboard supply control unit
L76	Button illumination bulb
T4bz	4-pin connector
T8s	8-pin connector
T20f	20-pin connector
T28b	28-pin connector, on left B-pillar
V214	Rear left door central locking motor, lock
43	Earth point, lower part of right A-pillar
207	Earth connection, in rear left door wiring harness
366	Earth connection 1, in main wiring harness
388	Earth connection 23, in main wiring harness
*	Not for American markets

Wiring Diagram VW JETTA 2014 - Rear right window regulator switch - in door - Rear right door control unit - Onboard supply control unit - Rear right window regulator motor

E54	Rear right window regulator switch, in door
J389	Rear right door control unit
J519	Onboard supply control unit
L76	Button illumination bulb
T4ar	4-pin connector
T20g	20-pin connector
T28c	28-pin connector, on right B-pillar
V27	Rear right window regulator motor
208	Earth connection, in rear right door wiring harness
Q41	Positive connection 4 (58b), in window regulator wiring harness
R23	Positive connection 1 (30), in rear right door wiring harness

Wiring Diagram VW JETTA 2014 - Rear right door contact switch - Rear right central locking lock unit - Rear right door control unit - Onboard supply control unit - Rear right door central locking motor - lock

F11	Rear right door contact switch
F223	Rear right central locking lock unit
J389	Rear right door control unit
J519	Onboard supply control unit
T8t	8-pin connector
T20g	20-pin connector
T28c	28-pin connector, on right B-pillar
V215	Rear right door central locking motor, lock
43	Earth point, lower part of right A-pillar
81	Earth connection 1, in dash panel wiring harness
208	Earth connection, in rear right door wiring harness
*	Not for American markets

Wiring Diagram VW JETTA 2014 - Sliding sunroof adjustment regulator - Button 1 for tilting roof - Sliding sunroof adjustment control unit - Onboard supply control unit - Sliding sunroof motor

E1	Light switch
E139	Sliding sunroof adjustment regulator
E582	Button 1 for tilting roof
J245	Sliding sunroof adjustment control unit
J519	Onboard supply control unit
J533	Data bus diagnostic interface
T4ad	4-pin connector
T10e	10-pin connector
T10h	10-pin connector
T20	20-pin connector
T52b	52-pin connector
V1	Sliding sunroof motor
B340	Connection 1 (58d), in main wiring harness

Wiring Diagram VW JETTA 2014 - Bonnet contact switch - Onboard supply control unit - Terminal 15 voltage supply relay 2 - Automatic anti-dazzle interior mirror

F266	Bonnet contact switch
J519	Onboard supply control unit
J681	Terminal 15 voltage supply relay 2
SC13	Fuse 13 on fuse holder C
T2n	2-pin connector
T6b	6-pin connector
T6d	6-pin connector
T9f	9-pin connector
T52a	52-pin connector
T52b	52-pin connector
T52c	52-pin connector
W1	Front interior light
Y7	Automatic anti-dazzle interior mirror
132	Earth connection 3, in engine compartment wiring harness
167	Earth connection 4, in engine compartment wiring harness
376	Earth connection 11, in main wiring harness
655	Earth point, on left headlight
A87	Connection (RL), in dash panel wiring harness
A184	Connection (bonnet contact switch), in dash panel wiring harness
A217	Positive connection 8 (15a) in dash panel wiring harness
B163	Positive connection 1 (15), in interior wiring harness
*	Gradually discontinued

Wiring Diagram VW JETTA 2014 - Onboard supply control unit

J519	Onboard supply control unit
J533	Data bus diagnostic interface
T20	20-pin connector
T52c	52-pin connector
B397	Connection 1 (convenience CAN bus, high), in main wiring harness
B406	Connection 1 (convenience CAN bus, low), in main wiring harness
