Электросхемы Автомтическая коробка Передач (АКПП) Полная привод (4WD) Блокировка Дифференциала Isuzu Trooper LS 2002

Автомтическая коробка Передач (АКПП) Полная привод (4WD) Блокировка Дифференциала

Электросхема Полного привода 4WD, перейдите на лету для Isuzu Trooper LS 2002

Электросхема Полного привода 4WD, перейдите на лету для Isuzu Trooper LS 2002 - Список элементов:

• (under side of vehicle, center of front axle)
• 4wd actuator assembly (on rear of transfer case)
• 4wd control unit (behind front console)
• 4wd ind
• 4wd ind ctrl
• 4wd mtr ctrl
• 4wd out
• 4wd switch
• 4wd transfer switch (on top right of transfer case)
• Anti-lock brakes system
• Axle engaged
• C-10 meter gauge fuse 10a
• C-16 (rear of left front fender)
• C-4 elec ig fuse 15a
• Dash fuse box (behind left kick panel)
• Front axle switch (under side of vehicle, center of front axle)
• Front axle vacuum solenoid valve (c) (gray)
• Frt axle vsv
• Gnd
• High/4l in
• Hot in on or start
• I-9
• Ign
• Illum
• Interior lights system
• M-11
• M-12
• Meter assembly
• Off
• On/off in
• Pnk
• Red
• Trans complete

Электросхема Полного привода 4WD, крутящий момент по требованию для Isuzu Trooper LS 2002

Электросхема Полного привода 4WD, крутящий момент по требованию для Isuzu Trooper LS 2002 - Список элементов:

• (11)
• (12)
• (13)
• (14)
• (15)
• (16)
• (17)
• (18)
• (19)
• (20)
• (22)
• (23)
• (29)
• (30)
• (31)
• (32)
• (33)
• (34)
• (36)
• (37)
• (4)
• (40)
• (42)
• (44)
• (45)
• (46)
• (47)
• (6)
• (8)
• (except s models)
• (left side of dash, above engine hood release lever) data link connector
• (not used)
• (on top rear of transfer case) transfer front speed sensor
• (s models)
• (top right rear of engine) e-30
• 1 ind
• 2 ind
• 3 ind
• 4 h/l transfer switch assembly (bottom front of transfer case)
• 4h switch
• 4l switch
• 4wd engage out
• 4wd switch
• 4wd switch on
• Abs active in
• Anti-lock brakes system
• Auto ind
• B-48
• B-49
• Brake switch
• Brake switch (on brake pedal support)
• C-10 meter gauge fuse 10a
• C-14 stoplight a/t cont fuse 15a
• C-16 (rear of left front fender)
• C-4 elec ign fuse 15a
• Check ind
• Clutch sol
• Dash fuse box (behind left kick panel)
• Dlc
• E-30 (top right rear of engine)
• Engine controls
• Exterior lights
• Front axle switch (on underside of vehicle, center of front axle)
• Front axle vacuum solenoid valve (gray) (on underside of vehicle, center of front axle)
• Frt axle in
• Frt axle vsv
• Frt transfer spd
• Ground
• Hot at all times
• Hot in on or start
• I-9
• Ind
• Interior lights
• Interior lights system
• Lights on
• M-27
• Meter assembly
• P-15 (top of transfer case, on shift lever bracket)
• Pin numbers in parenthesis may be used for testing purposes
• Pnk
• Power
• Rear transfer spd
• Red
• Rr ind
• Torque on demand control unit (beneath front passenger's seat)
• Tp sensor
• Transfer rear speed sensor (on lower rear of transfer case)
• Transfer clutch solenoid (in transfer case)
• Transfer spd

Электросхема автоматической коробки передач АКПП для Isuzu Trooper LS 2002

Электросхема автоматической коробки передач АКПП для Isuzu Trooper LS 2002 - Список элементов:

• (+)
• (-)
• (below rear of center console) b-26
• (front left side of transmission) automatic transmission mode switch
• (left side of dash, above hood release lever) data link connector
• A/c compr rly
• A/c sys
• A/t oil temp warning ind
• Anti-lock brakes
• Automatic transmission
• Battery
• Brake input
• Brake switch (on brake pedal support)
• C-10 meter gauge fuse 10a
• C-14 stoplight a/t cont fuse 15a
• C-3 back/turn fuse 15a
• C-39 (right rear corner of engine compt, on inner fender panel)
• C-8 engine fuse 15a
• Check trans ind
• Chk trans ind
• Dash fuse box
• E-21
• E-22
• E-28 (top left rear of engine)
• E-30 (top right rear of engine)
• Ect input
• Engine coolant temperature sensor (right front of engine)
• Etc grd
• Exterior lights
• F19
• F20
• F32
• F39
• F40
• F41
• F43
• F45
• F47
• F53
• F57
• F58
• F61
• F65
• F74
• F75
• F76
• F77
• F78
• F79
• Fl3 fuse 30a
• Fuse/ relay box
• Ground
• Hot at all times
• Hot in on or start
• I-9
• Ignition
• Instrument cluster (a/t shift indicator control unit)
• Interior lights
• M-6
• M-7
• Meter assembly
• Oil temp ind
• Other models
• Pcm main relay
• Pnk
• Power
• Power drive ind
• Power/ winter switch
• Powertrain control module (right side of engine compt)
• Pressure control solenoid
• Pwr drv ind
• Pwr sw input
• R or l range
• Red
• Ref volt
• S models
• S10
• S20
• S22
• S23
• S29
• S31
• S32
• S33
• S38
• S40
• S43
• S45
• S46
• S47
• S49
• S51
• S53
• S55
• S66
• S72
• S76
• Send grd
• Serial data
• Shift sol a
• Shift sol b
• Shift solenoid a
• Shift solenoid b
• Tcc
• Tft sens
• Throttle position sensor 1
• Throttle position sensor 2
• Throttle valve assembly (top front of engine)
• Torque converter clutch pwm solenoid
• Tps1
• Tps1 grd
• Tps2 grd
• Tps2 sig
• Trans fluid temperature sensor
• Trans pos in
• Trans spd sens
• Transmission speed sensor (on top rear of transmission)
• Win drv ind
• Win sw input
• Winter
• Winter drive ind
