ЦЕНТРАЛЬНЫЙ ЗАМОК

Электросхема центрального замка, Кабриолет для MINI Cooper 2006

Электросхема центрального замка, Кабриолет для MINI Cooper 2006 - Список элементов:

• (left door) x1108
• (left rear of trunk)
• (right side of engine compt)
• Central locking drive, trunk lid/tailgate (center rear of trunk)
• Computer data lines system
• Diode
• Driver's door lock
• Driver's door microwave sensor
• Fuel filler door lock
• Fuse f1 30a
• Fuse f14 10a
• Fuse f19 30a
• Fuse f23 20a
• Fuse f24 5a
• Fuse f4 5a
• Fuse f7 5a
• Fuse fl 12 50a
• Fuse fl 8 50a
• Fuse holder 2 (behind left footwell trim)
• Fuse holder 3 (left side of engine compt)
• General module control unit (behind right footwell)
• Hot at all times
• Hot in accy, run and start
• License plate lights
• Not used
• Passenger's door lock
• Passenger's door microwave sensor
• Rear left microwave sensor
• Rear right microwave sensor
• Red
• Siren w/ tilt alarm sensor
• Switch panel
• Theft ind
• Trunk lid contact switch
• Turn signal/ headlight dimmer switch
• Underhood light switch
• X10200
• X10201
• X10202
• X10206
• X10207
• X1108 (left door)
• X13230 (under left rear seat)
• X151 (right side of right footwell)
• X165
• X165 (right side of engine compt)
• X179 (below right rear seat)
• X253
• X254
• X255
• X332
• X4009
• X4010
• X490
• X490 (left rear of trunk)
• X494 (right rear side of luggage compt)

Электросхема центрального замка, Кабриолет Except для MINI Cooper 2006

Электросхема центрального замка, Кабриолет Except для MINI Cooper 2006 - Список элементов:

• (left door) x1108
• (left rear side of luggage compt)
• (not used)
• (right side of engine compt)
• Central locking drive, trunk lid/tailgate
• Central locking remote control (under front headliner)
• Computer data lines system
• Driver's door lock
• Fuel filler door lock
• Fuse f1 30a
• Fuse f14 10a
• Fuse f19 30a
• Fuse f23 20a
• Fuse f24 5a
• Fuse f4 5a
• Fuse f7 5a
• Fuse fl 12 50a
• Fuse fl 8 50a
• Fuse holder 2 (behind left footwell trim)
• Fuse holder 3 (left side of engine compt)
• General module control unit (behind right footwell)
• Hot at all times
• Hot in accy, run and start
• Interior protection 1 control module (in headliner)
• License plate lights
• Passenger's door lock
• Power distribution system
• Red
• Siren w/ tilt sensor
• Switch panel
• Theft ind
• Turn signal/ headlight dimmer switch
• Underhood light switch
• X10200
• X10201
• X10202
• X10206
• X10207
• X1108 (left door)
• X13230 (left door)
• X151 (right side of right footwell)
• X165
• X165 (right side of engine compt)
• X179 (right door)
• X253
• X254
• X255
• X332
• X4009
• X4010
• X490
• X494 (right rear side of luggage compt)
