Все схемы для электропроводки Chevrolet Camaro Z28 1999 модели

Автомтическая коробка Передач (АКПП) Полная привод (4WD) Блокировка Дифференциала

3.8L

3.8L ВИН К, Электросхема автоматической коробки передач АКПП для Chevrolet Camaro Z28 1999

3.8L ВИН К, Электросхема автоматической коробки передач АКПП для Chevrolet Camaro Z28 1999 - Список элементов:

93

(fwd lamp harn, approx 5 cm from underhood electrical center 1 breakout)
(i/p harn, approc 5 cm from bcm breakout) s234
(left side of dash)
(partial) (under dash to right of steering column)
1-2 shift solenoid valve
1-2 ss valve ctrl
2-3 shift solenoid valve
2-3 ss valve ctrl
2nd gear ind ctrl
2nd gear start in
3-2 shift solenoid valve assembly
3-2 ss valve ctrl
Air conditioning system
Automatic transmission (4l60-e)
Automatic transmission fluid pressure manual valve position switch
Batt (+)
Brake pedal switch
Brake sw sig in
Bulb test hot in run, or start
Class ii serial data
Data link connector
Daytime running lamps module
Ect sens gnd
Ect sens sig in
Eng ctrl fuse 15a
Eng sen fuse 20a
Engine controls system
Engine coolant temperature sensor (under throttle body)
Evap canister purge solenoid valve & electronic ignition control module
Evap canister vent solenoid valve
G119 (bolted to pulley above a/c clutch connector)
Gages fuse 9 10a
Hot at all times
Hot in run
Hot in run, bulb test or start
Hot in run, or start
I/p fuse block
Ign (run/start)
Illumination lamp
Instrument cluster
Interior lights system
Malfunction indicator lamp
Mass airflow sensor & heated oxygen sensors
Mil ctrl
Park/neutral position switch
Park/neutral position switch (near shift control lever)
Pc sol valve hi
Pc sol valve low
Pcm bat fuse 10a
Pcm gnd
Pcm ign fuse 15a
Pnk
Pnp sw sig in
Powertrain control module (pcm) (in engine compt, behind right strut tower)
Pressure control solenoid valve
Red
Rev
S104
S107
S110
S117
S121
S182
S184
S206
S207
S215
Second gear start ind
Second gear start switch
Sens gnd
Shift interlock system & hatch release circuit
Tan
Tcc pwm sol ctrl
Tcc sol ctrl
Tcc/shift interrupt switch
Tft sens sig in
Throttle position sensor (mounted to side of throttle body)
Torque converter clutch pulse width modulation solenoid valve
Torque converter clutch solenoid valve
Tps 5v ref
Tps gnd
Tps sig in
Trans range a in
Trans range b in
Trans range c in
Transmission fluid temperature sensor
Turn b/u fuse 2 20a
Uart serial data
Underhood electrical center 1 (left front corner of engine compt)
Underhood electrical center 2 (left front corner of engine compt)
Vehicle speed sensor (left rear of transmission)
Vss hi
Vss lo

5.7L

5.7L ВИН Г, Электросхема автоматической коробки передач АКПП для Chevrolet Camaro Z28 1999

5.7L ВИН Г, Электросхема автоматической коробки передач АКПП для Chevrolet Camaro Z28 1999 - Список элементов:

83

1-2 shift solenoid valve
1-2 ss valve
2-3 shift solenoid valve
2-3 ss valve
3-2 shift solenoid valve assembly
3-2 ss valve
Anti-lock brakes system
Automatic transmission (4l60-e)
Automatic transmission fluid pressure manual valve position switch
Batt (+)
Body control module, brake malfunction indicator lamp, driver module, daytime running lights module & instrument cluster
Brake sw in
Cyl head)
Data link connector (partial) (under dash to right of steering column)
Ect sens gnd
Ect sens in
Eng ctrl fuse 15a
Eng sens fuse 20a
Engine coolant temperature sensor (left side of engine above generator)
Engine wiring harness junction block 1 (left front corner of eng compt)
Engine wiring harness junction block 2 (left front corner of engine compt)
Evap canister purge solenoid valve
Evap canister vent solenoid valve
G114 (rear of
G114 (rear of left cylinder head)
Gages fuse 9 10a
Gnd
Hot at all times
Hot in run, bulb test or start
I/p fuse block (left side of dash)
Ignition
Instrument cluster
Malfunction indicator lamp
Mass air- flow sensor, ho2 sensors
Mil ctrl
Park/neutral position switch (near shift control lever)
Pc sol hi
Pc sol low
Pcm bat fuse 10a
Pcm ign fuse 15a
Pnk
Pnp sw in
Powertrain control module (pcm) (in engine compt, behind right strut tower)
Pressure control solenoid valve
Red
Rev
S104
S106
S107
S110
S116
S116: eng harn, approx 9 cm from map sensor breakout
S118
S118: eng harn, approx 15 cm from map sensor breakout
S119
S119: eng harn, approx 9 cm from automatic transmission breakout
S182
S206
S215
S234 (dash harn, approx 5cm from bcm breakout)
Sens gnd
Serial data
Shift interlock system & hatch release circuit
Splice pack sp200
Stoplamp/ tcc switch
Tan
Tcc pwm sol
Tcc sol ctrl
Tcc/shift interrupt switch
Tft sens sig
Throttle position sensor (on throttle body)
Torque converter clutch pulse width modulation solenoid valve
Torque converter clutch solenoid valve
Tps 5v ref
Tps gnd
Tps sig in
Transmission fluid temperature sensor
Trs a
Trs b
Trs c
Vehicle speed sensor (left rear of transmission)
Vss hi (signal)
Vss lo (ground)

5.7L ВИН Г, схема M/T для Chevrolet Camaro Z28 1999

5.7L ВИН Г, схема M/T для Chevrolet Camaro Z28 1999 - Список элементов:

21

Body control module, brake malfunction indicator lamp, driver module, daytime running lights module & instrument cluster
Data link connector (partial) (under dash to right of steering column)
Eng sens fuse 20a
Engine wiring harness junction block 2 (left front corner of engine compt)
Gages fuse 9 10a
Hot in run, bulb test or start
I/p fuse block (left side of dash)
Instrument cluster
Manual transmission
Mass airflow sensor & heated oxygen sensors
Pnk
Powertrain control module (in engine compt, behind right strut tower)
Reverse inhibit solenoid
Reverse inhibit solenoid ctrl
S104
S206
Serial data
Skip shift ind
Skip shift solenoid
Skip shift solenoid ctrl
Splice pack sp200

БАГАЖНИК ЗАДНЯЯ ДВЕРЬ ЛЮЧОК ТОПЛИВНОГО БАКА

Электросхема привода багажника и лючка топливного бака для Chevrolet Camaro Z28 1999

Электросхема привода багажника и лючка топливного бака для Chevrolet Camaro Z28 1999 - Список элементов:

33

A/t
Battery
Body control module (under right side of dash, near blower motor)
Courtesy fuse 8 20a
Daytime running lamps (drl) module (mounted behind radio & hvac controls, left of glove box)
Engine controls system
G114 (5.7l engine) (left rear of engine)
G119 (3.8l engine) (right front of engine)
G200 (left kick panel)
G407 (hatch release bracket)
Hot at all times
I/p fuse block
Instru- ment cluster system
Isolation diode
Lid release sig
Lid rly ctrl
M/t
Nca
Park brake switch
Park/neutral position switch (under console near shift control lever)
Pwr accy fuse 7 15a
Rear compartment lid release actuator (in cargo compt)
Rear compartment lid release relay (behind left side of dash)
Rear compartment lid release switch
S211
S215
S216
S228 (i/p harn, main branch, approx 20 cm from rear compt lid release relay breakout)
S234 (i/p harn, main branch, approx 5 cm from body control module breakout)
S237 (in i/p harn, main branch, approx 6cm from bcm breakout)
S239 (i/p harn, main branch, approx 1 cm from bcm breakout)
S470
Shift interlock system

БЛОК ПРЕДОХРАНИТЕЛЕЙ И РЕЛЕ

Электросхема блока предохранителей и реле (1 из 4) для Chevrolet Camaro Z28 1999

Электросхема блока предохранителей и реле (1 из 4) для Chevrolet Camaro Z28 1999 - Список элементов:

57

(1999)
(2000/2001)
(eng harn, near powertrain control module) s106
(forward lamp harn, 25 cm from underhood electrical center 1 breakout)
(forward lamp harn, 4 cm from ign switch) breakout) s203
(forward lamp harn, 8 cm from underhood electrical center 1 breakout) s168
30a
A10
Abs bat 1 fuse 40a
Abs bat 2 fuse 50a
Abs bat fuse 25a
Accelerator & servo control module
Air pump fuse 25a
Air pump relay (vin g)
Air solenoid relay (1999 w/vin g)
Battery
Blower motor relay
Body control module (bcm)
Bottom underhood fuse block
Cool fan fuse 10a
Cool fan fuse 40a
Cooling fan 1 relay
Cooling fan 2 relay
Cooling fan 3 relay
Electronic brake control module (ebcm)
Eng ctrl fuse 50a
Fuel pump fuse 20a
Fuel pump relay
Generator
Headlamp opening door actuator control module
Headlamp switch
Hl door-horn fuse 50a
Horn fuse 20a
Horn relay
I/p 1 fuse 40a
I/p 2 fuse 40a
Ign fuse 50a
L hdlp door fuse 15a
Nca
Pcm bat fuse 10a
Powertrain control module (pcm)
R hdlp door fuse 15a
Red
S169 (forward lamp harn, 6 cm from underhood electrical center 1 breakout)
S177 (forward lamp harn, 5 cm from underhood electrical center breakout)
S179
Secondary air injection (air) solenoid (2000/2001 vin g)
Starter solenoid
Tcs bat fuse 20a
Throttle actuator control (tac) module
To cigar accy fuse (diagram 3 of 4)
To ignition switch pin b (diagram 2 of 4)
To radio accy fuse (diagram 3 of 4)
To tail lts fuse (diagram 3 of 4)
Top underhood fuse block
Vin g
Vin k

Электросхема блока предохранителей и реле (2 из 4) для Chevrolet Camaro Z28 1999

Электросхема блока предохранителей и реле (2 из 4) для Chevrolet Camaro Z28 1999 - Список элементов:

76

(1999) (2000-01)
(chevy) b
(eng harn, 7 cm from pcm breakout) s107
(forward lamp harn, 11 cm from engine wiring harness junction block 1 breakout) s164
(forward lamp harn, 15 cm from underhood electrical center 1 breakout) s182
(forward lamp harn, 20 cm from underhood electrical center 1 breakout) s181
(forward lamp harn, near left radiator support)
(i/p harn, 2 cm from drl module breakout) s248
(pont) a
(vin g w/nw9)
A/c compressor relay
A/c cruise fuse 15a
A/t
Abs ign fuse 10a
Acc
Accelerator & servo control module (asm)
Automatic transmission
Back-up lamp switch (m/t)
Body control module (bcm)
Bottom underhood fuse block
Bulb test
C c
C1 c4
C101
Clutch pedal position switch
Clutch pedal positon (cpp) switch
Cruise control module (vin g)
Cruise control release switch
Cruise control switches
D10
Daytime running lamps (drl) control module
Electronic brake control module (ebcm)
Electronic traction control switch (1999 w/vin g)
Eng ctrl fuse 15a
Etc fuse 10a
Evaporative emission (evap) canister purge solenoid
Evaporative emission (evap) canister vent solenoid
From ign fuse (diagram 1 of 4)
G109 (top right of radiator)
Hvac control assembly
Hvac control selector switch
Hvac fuse 6 20a
I/p fuse block
Ignition control module (icm) (vin k)
Ignition relay
Ignition switch
Instrument panel cluster
Lock
M/t
Multifunction turn signal lever
Nca
Off
Park/ neutral position switch
Park/ neutral position switch (a/t)
Pcm ign fuse 15a
Pnk
Powertrain control module (pcm)
Powertrain control module (pcm) (vin k)
Rear defogger switch
Rear defogger timer/ relay
Red
Run
S112
S165 (forward lamp harn, 7 cm from underhood electrical center 2 breakout)
S183 (forward lamp harn, 10 cm from engine wiring harness junction block 1 breakout)
S185 (forward lamp harn, at engine wiring harness junction block 1 breakout)
S254 (i/p harn, behind left side of dash)
Second gear start switch (1999 chevy w/vin k)
Start
Strtr fuse 15a
Throttle actuator control (tac) module (vin k)
To air bag fuse (diagram 3 of 4)
To eng sen fuse (diagram 4 of 4)
To wiper/ wash fuse (diagram 4 of 4)
Turn b/u fuse 2 20a
Turn signal lamp flasher module

Электросхема блока предохранителей и реле (3 из 4) для Chevrolet Camaro Z28 1999

Электросхема блока предохранителей и реле (3 из 4) для Chevrolet Camaro Z28 1999 - Список элементов:

63

(chev)
(dash harn, at rear compt lid release relay breakout) s206
(i/p harn, 7 cm from rear compt release breakout)
(ip harn, 7 cm into ip fuse block breakout) s255
(not used)
(pont)
(seat jumper harn, under driver's seat) s320
A10
Air bag fuse 10 15a
Audio amplifier
Auxiliary power outlet
Body control module (bcm)
Cigar accy fuse 11 25a
Cigar lighter
Convertible: (i/p harn, near g200 breakout)
Courtesy fuse 8 20a
Data link connector (dlc)
Daytime running lamps control module
Defog/seats circuit breaker 30a
Driver's seat assembly
E11
E12
From fusible link e (diagram 1 of 4)
From fusible link f (diagram 1 of 4)
From i/p 2 fuse (diagram 1 of 4)
From s185 (diagram 2 of 4)
G200 (left kick panel)
Gauges fuse 9 10a
Hazard flasher module
Headlamp switch
Hvac control assembly
I/p fuse block
Inflatable restraint sensing & diagnostic module (sdm)
Instrument panel cluster
Lumbar adjust switch
Nca
Outside rear view mirror switch
Passenger's seat assembly
Pnk
Pontiac, w/ dual power seat
Power seat cushion air control module
Power seat inflator switch
Power seat switch
Pwr accy fuse 7 15a
Radio
Radio accy fuse 4 25a
Radio power antenna
Rear compt lid release relay
Rear defogger timer/ relay
Red
Remote playback device cd player
S211
S217
S333
Shock sensor
Stop/hazard fuse 1 20a
Stoplamp switch
Tail lts fuse 5 20a
Theft deterrent relay
Traction control switch (or second gear start switch) (2000-01)
W/ single power seat
W/ uz7, u59, w53, w54, w55
W/ w53, u62 w/o uz7, w54, w55

Электросхема блока предохранителей и реле (4 из 4) для Chevrolet Camaro Z28 1999

Электросхема блока предохранителей и реле (4 из 4) для Chevrolet Camaro Z28 1999 - Список элементов:

59

(cross car harn, near window control module breakout) s208
(eng harn, 14 cm from pcm breakout) s104
(eng harn, 7 cm from oil presure sender breakout) s102
(eng harn, 8 cm from fuel inj 4 breakout) s109
(engine jumper harness) s122
(engine jumper harness) s124
(i/p harn, 7 cm from park brake switch breakout) s253
Body control module (bcm)
Bottom underhood fuse block
C100
Convertible
Driver window switch
Eng sen fuse 20a
Folding top relay
Folding top switch
From ignition switch pin e (diagram 2 of 4)
From inj 2 fuse h (diagram 4 of 4)
From s164 (diagram 2 of 4)
Front passenger window switch
Fuel injector
Fuel injector (vin g)
Fuel injector (vin k)
Heated oxygen sensor (ho2s) bank 1 sensor 1
Heated oxygen sensor (ho2s) bank 1 sensor 2 (1999 vin g & 2000-01 all)
Heated oxygen sensor (ho2s) bank 1 sensor 3 (1999 vin k)
Heated oxygen sensor (ho2s) bank 2 sensor 1
Heated oxygen sensor (ho2s) bank 2 sensor 2 (vin g)
I/p fuse block
Ignition coil/ module 1 (2000- 01)
Ignition coil/ module 2 (2000- 01)
Ignition coil/ module 3 (2000- 01)
Ignition coil/ module 4 (2000- 01)
Ignition coil/ module 5 (2000- 01)
Ignition coil/ module 6 (2000- 01)
Ignition coil/ module 7 (2000- 01)
Ignition coil/ module 8 (2000- 01)
Inflatable restraint steering wheel module coil
Inj 1 fuse 15a
Inj 2 fuse 15a
Left electronic ignition control module (icm) (vin g) (1999)
Mass airflow (maf) sensor
Nca
Pnk
Radio
Radio fuse 17 15a
Reverse inhibit solenoid (m/t)
Right electronic ignition control module (icm) (1999)
S218 (i/p harn 4 cm from instrument cluster breakout)
Skip shift solenoid (m/t)
Steering wheel controls
Stg whl cntrl fuse 3 1a
Stoplamp switch (a/t)
To inj 1 fuse (diagram 4 of 4)
Vin g only
Window control module
Windows circuit breaker 30a
Windshield wiper motor
Windshield wiper/ washer switch
Wiper/wash fuse 14 25a

БЛОК УПРАВЛЕНИЯ КУЗОВОМ

Электросхема блока управления кузовом для Chevrolet Camaro Z28 1999

Электросхема блока управления кузовом для Chevrolet Camaro Z28 1999 - Список элементов:

84

"low coolant" latching ind control
(1999)
(ua6)
Accy
Anti-theft system
Battery
Body control module (under right side of dash, near blower motor)
Bulb test
C10
C11
C12
C13
C14
C15
C16
Courtesy fuse 8 20a
D10
D11
D12
D13
D14
D15
D16
Door locks system
Driver door
Engine controls system
Exterior lights system
Fasten seat belt ind light control
Fuel enable
G200 (left kick panel)
Gages fuse 9 10a
Ground
Hatch ajar input
Horn relay control
Horns system
Hot at all times
Hot in acc, run or w/ rap energized
Hot in run, bulb test or start
I/p fuse block
Ign key resistor feed
Ign key resistor return
Ignition
Ignition switch
Instrument cluster system
Interior lights command input
Interior lights feed
Interior lights return
Interior lights system
Key ignition signal
Lock
Lock all doors output
Lock input
Off
Park lights feed
Passenger door
Pnk
Power distribution system
Power distribution system (rap relay)
Program input
Radio fuse 17 15a
Rear compt lid release signal
Rear compt release relay control
Red
Retained accessory power (rap)
Run
S206
S217
S218
S254
Seat belt switch signal
Security indicator light control
Security led control
Shock sensor "shock" input
Shock sensor "tamper" input
Start
Starter enable
Tan
Theft deterrent relay control
Trunk, tailgate, fuel doors system
Unlock driver's door output
Unlock input
Unlock passenger's door output
Vss input
Warning systems

БЛОКИРОВКИ СЕЛЕКТОРА СТОЯНОЧНЫЙ ТОРМОЗ

Электросхема блокировки селектора для Chevrolet Camaro Z28 1999

Электросхема блокировки селектора для Chevrolet Camaro Z28 1999 - Список элементов:

26

(1998)
(1999-01)
(3.8l)
(i/p harn, approx 1 cm from bcm breakout)
(i/p harn, approx 5 cm from bcm breakout) s234
(i/p harn, approx 6 cm from bcm breakout)
(opens w/ brake pedal depressed)
(right front of engine) g119
(sealed in harn, approx 6 cm from bcm breakout)
A/t shift lock control actuator solenoid (in console, forward of shift control lever)
Brake transmission shift interlock switch
G114 (5.7l)
Gauges fuse 9 10a
Hatch release relay
Hot in run, bulb test or start
I/p fuse block
Isolation diode (btsi) (1 amp)
Park/neutral position switch (under console, near shift ctrl lever)
Pnk
Power tops
Powertrain control module (pcm)
S206
S215
S236
S239
Stoplamp/tcc switch assembly (mounted on brake pedal bracket)

ВНЕШНЕЕ ОСВЕЩЕНИЕ

Электросхема заднего хода для Chevrolet Camaro Z28 1999

Электросхема заднего хода для Chevrolet Camaro Z28 1999 - Список элементов:

13

A/t
Back-up lamp switch (on side of transmission)
G407 (on hatch release bracket)
Hot in run
I/p fuse block (behind left side of dash)
Left back-up lamp
M/t
Park/ neutral position switch (under console, near shift control lever)
Right back-up lamp
S207
S405 (rear body harn, left quarter panel, near rear lamps harness pass-through grommet)
S410
Turn b/u fuse 2 20a

Электросхема внешнего освещения для Chevrolet Camaro Z28 1999

Электросхема внешнего освещения для Chevrolet Camaro Z28 1999 - Список элементов:

73

(chmsl jumper harness, 30 cm from chmsl bulbs) s460
(dash harn, near headlamp switch and cluster breakouts) s226
(forward lamps harn, 16 cm from washer pump breakout)
(not used)
(on hatch release bracket)
(rear body harness, left quarter panel, near rear lamps pass-through grommet)
(rear body harness, left quarter panel, near rear lamps pass-through grommet) s403
A12
B10
B11
Body control module (bcm) (under right side of dash, near blower motor)
Breakout)
Center high mounted stop light
Cruise control system
D15
Daytime running lamps (drl) module (behind radio, left side of glove box)
G108 (left radiator support)
G109 (right radiator support)
G200 (left kick panel)
G407
G909 (center rear of roof)
Hazard
Hazard lamp flasher (behind dash, left of steering column)
Head
Headlamp switch
Headlights system
Hot at all times
Hot in run
I/p fuse block (behind left side of dash)
Instrument cluster
Instrument cluster system
Interior lights system
Left front park/ turn lamp
Left front side marker lamp
Left tail lamp
Left tail/ stop lamp
Left tail/ stop/ turn lamp
Left turn indic
License lamp
Normal
Off
Optional
Orn
Park
Pwr accy fuse 7 15a
Right front park/ turn lamp
Right front side marker lamp
Right tail lamp
Right tail/ stop lamp
Right tail/ stop turn lamp
Right turn indic
S112
S113
S150
S207
S211
S216
S243 (dash harn, 9 cm from g200)
S400
S410
S420
S450
Solid state
Sound systems
Stop/ hazard fuse 1 20a
Stoplamp/ tcc switch (on brake pedal bracket)
Tail lts fuse 5 20a
Theft deterrent relay (attached to inflatable restraint module bracket)
Turn b/u fuse 2 20a
Turn left
Turn right
Turn signal lamp flasher (behind dash, right of steering column)
Turn/ hazard switch assembly

ВНУТРЕННЕЕ ОСВЕЩЕНИЕ

Электросхема подсветки, Кабриолет для Chevrolet Camaro Z28 1999

Электросхема подсветки, Кабриолет для Chevrolet Camaro Z28 1999 - Список элементов:

38

(hatch release bracket)
(left kick panel)
Body control module (bcm) (under right side of dash)
Courtesy fuse 8 20a
Courtesy lamps power feed
Courtesy lamps return
Courtesy reading lamps
D11
D12
D13
Driver door ajar
G200
G407
Ground
Hot at all times
I/p compartment lamp
I/p dimmer switch
I/p fuse block (behind left side of dash)
Inside rearview mirror
Instrument cluster system
Interior lamps command
Left front side door lock
Left rear courtesy lamp
Passenger door ajar
Power (battery)
Rear compartment lamp
Rear compartment lid ajar indication switch
Rear compt lid ajar
Right front side door lock
Right rear courtesy lamp
S216
S217
S220
S241 (i/p harn, approx 4 cm from antenna cable breakout)
S246
S247 (i/p harn approx 16 cm from left kick panel ground)
S317 (i/p harn, approx 40 cm from left rear courtesy lamp breakout)
S470

Электросхема подсветки, Купе для Chevrolet Camaro Z28 1999

Электросхема подсветки, Купе для Chevrolet Camaro Z28 1999 - Список элементов:

35

(hatch release bracket)
(left kick panel)
Body control module (bcm) (under right side of dash)
Courtesy fuse 8 20a
Courtesy lamps power feed
Courtesy lamps return
Courtesy reading lamps
D11
D12
D13
Dome lamp
Driver door ajar
G200
G407
Ground
Hot at all times
I/p compartment lamp
I/p dimmer switch
I/p fuse block (behind left side of dash)
Inside rearview mirror
Instrument cluster system
Interior lamps command
Left front side door lock
Passenger door ajar
Power (battery)
Rear compartment lid ajar indication switch
Rear compt lid ajar
Right front side door lock
S216
S217
S220
S241 (i/p harn, 4 cm from antenna cable breakout)
S246
S247 (i/p harn, approx 16 cm from left kick panel ground)
S470

Электросхема подсветки приборов для Chevrolet Camaro Z28 1999

Электросхема подсветки приборов для Chevrolet Camaro Z28 1999 - Список элементов:

57

(1999)
(2000-01)
(5 bulbs)
(chevy) b g
(cross car harn, approx 11 cm from inside rearview mirror breakout)
(i/p harn, approx 17 cm from instrument cluster breakout) s224
(pont)
(pont) f c (chevy)
A/t
Ashtray lamp
B11
Courtesy lamps circuit
Daytime running lamps (drl) module (mounted behind radio & hvac controls, left of glove box) (w/drl)
Electronic traction control switch or second gear start switch
Exterior lights system
Fog lamp switch
Folding top switch
G130 (attached to rear of cylinder head) (v8 vin g)
G134 (front of engine, bolted to pulley above a/c clutch connector) (v6 vin k)
G200 (left kick panel)
G407 (hatch release bracket)
Gauges fuse 9 10a
Head
Headlight switch
Hot at all times
Hot in run, bulb test or start
Hot with lamps on
Hvac control
I/p dimmer fuse 16 5a
I/p dimmer switch
I/p fuse block (behind left side of dash)
Inflatable restraint steering wheel module coil
Instrument cluster
Left door illumination lamp
M/t
Max
Min
Nca
Off
Park
Park lights relay
Pnk
Prndl illumination lamp
Radio
Radio (1999) steering wheel controls
Right door illumination lamp
S206
S215
S216
S217
S220
S226 (i/p harn, approx 7 cm into headlamp switch breakout)
S260 s260 (cross car harn, behind left side of dash)
S470
Solid state
Stg whl cntrl fuse 13 1a
Tail lts fuse 5 20a

ЗАЗЕМЛЕНИЕ ПОДКЛЮЧЕНИЕ МАССЫ

Электросхема подключение массы заземления (1 из 3) для Chevrolet Camaro Z28 1999

Электросхема подключение массы заземления (1 из 3) для Chevrolet Camaro Z28 1999 - Список элементов:

70

(eng harn, 15 cm from pcm breakout)
(eng harn, near trans connector breakout) s108
(forward lamp harn, near right frt shock tower)
3.8l (vin k)
5.7l (vin g)
A/c clutch diode
A/c compressor clutch
A18
Accelerator and servo control
Accelerator and servo control module (asm)
B10
B15
Battery
Braided
C high nca
C low nca
Camaro
Connector breakout)
Cruise control (clutch) switch a
Cruise control module
Cruise control/ clutch anticipate switch
Data link connector (dlc)
Electronic brake control module (ebcm)
Electronic ignition control module (icm)
Engine coolant level indicator module (5.7l)
Engine oil level sensor
Engine oil pressure switch
Firebird
Fuel pump relay
G102 (left front shock tower)
G103 (right front shock tower)
G109 (top right of radiator support)
G110 (left front of engine)
G112 (lower left side of engine)
G113 (left front frame rail)
G114 (left rear of engine)
G119 (right front of engine)
G120 (right side of engine block)
G302 (below center console)
Heated oxygen sensor (ho2s) bank 1 sensor 1
Heated oxygen sensor (ho2s) bank 1 sensor 2
Heated oxygen sensor (ho2s) bank 1 sensor 3
Heated oxygen sensor (ho2s) bank 2 sensor 1
Heated oxygen sensor (ho2s) bank 2 sensor 2
Horn
Ignition control coils/module bank 1
Ignition control coils/module bank 2
Ignition relay
Inflatable restraint sensing and diagnostic module (sdm)
Instrument cluster
Mass air flow (maf) sensor
Nca
Park/ neutral position switch
Powertrain control module (pcm)
Right front fog lamp
Right front park/turn lamp
Right front side marker lamp
Right headlamp opening door
Right headlight
Right high beam headlamp
Right low beam headlamp
S100
S101
S108 (engine harn, near trans connector breakout)
S110 (engine harness, 20 cm from pcm breakout)
S115 (eng harn, side of eng, near a/c comp)
S115 (engine harness, side of engine, near a/c comp)
S215 (i/p harness, 11 cm from antenna cable breakout)
Second gear start switch (chevy)
Throttle actuator control (tac) module

Электросхема подключение массы заземления (2 из 3) для Chevrolet Camaro Z28 1999

Электросхема подключение массы заземления (2 из 3) для Chevrolet Camaro Z28 1999 - Список элементов:

72

(forward lamp harn, 27 cm from electronic throttle control module breakout)
(forward lamp harn, 7 cm from electronic throttle control module breakout)
A (firebird) (camaro)
A/t
Abs brake modulator
Amplifier
Ashtray lamp
Auxiliary accessory (wire taped to i/p harness)
B10
B11
Blower motor relay
Body control module (bcm)
Brake fluid level indicator sensor
C high
C low
Camaro
Cigar lighter
Coolant fan 3 relay
Courtesy/ reading lamps
Data link connector (drl)
Daytime running lamps (drl) module
Firebird
Fog lamp switch
G108 (top left of radiator support)
G200 (left kick panel)
Headlamp opening actuator control module
Headlamp switch
Hvac control
Hvac control (firebird)
Hvac illumination lamps
I/p compartment lamp
I/p dimmer switch
Ignition key warning switch
Inside rearview mirror
Instrument cluster
Left door illumination lamp
Left front fog lamp
Left front park/turn lamp
Left front side door lock
Left front side marker lamp
Left headlamp
Left headlamp opening door
Left high beam headlamp
Left low beam headlamp
Left power door lock switch
Left power window switch
M/t
Nca
Outside rear view mirror switch
Prndl illumination lamp
Radio
Radio power antenna
Radio steering wheel controls (firebird w/ uk3)
Rear compartment lid release switch
Rear defogger switch
Rear defogger timer/ relay
Right door illumination lamp
Right engine coolant fan
Right front side door lock
Right power door lock switch
S113
S155
S216 (i/p harness, near instrument cluster)
S217 (i/p harness, 14 cm from bcm breakout)
Seat belt switch
Secondary air inject- ion pump (5.7l)
Secondary injection bleed valve solenoid (5.7l)
Security indicator led
Sir coil assembly
Theft deterrent shock sensor
Windshield washer pump
Windshield wiper motor

Электросхема подключение массы заземления (3 из 3) для Chevrolet Camaro Z28 1999

Электросхема подключение массы заземления (3 из 3) для Chevrolet Camaro Z28 1999 - Список элементов:

50

Blower motor
Camaro
Center high mounted stop lamp
Convertible only
Coupe
Firebird
Firebird w/ aq9
Folding top relay
Folding top switch
Folding top top switch (pontiac)
From hatch release actuator)
From rear compt lid release actuator)
Fuel tank unit
G203 (right kick panel)
G300 (below left front seat)
G407 (hatch release bracket)
G407 (on hatch release bracket)
G909 (convertible only) (near left of dome light)
G909 (coupe only) (center rear of roof)
Left back up lamp
Left inboard tail/stop/ turn lamp
Left outboard tail/stop/ turn lamp
Left tail lamp
Left tail- lamp
Left tail/stop lamp
Left turn/stop lamp
License lamp
Nca
Power seat control module
Power seat switch
Rear compartment lid ajar indicator switch
Rear compartment lid release actuator
Rear defogger grid
Right back up lamp
Right inboard tail/stop/ turn lamp
Right outboard tail/stop/ turn lamp
Right tail lamp
Right tail/stop lamp
Right turn/stop lamp
S335
S410 (rear body harness, near right tail lamp)
S420 (hatch harness, main branch, rear center of roof, near dome lamp)
S430 (rear facia harn, 12 cm from license lamp breakout)
S430 (rear fascia harness, 12 cm from license lamp breakout)
S450 (center high mounted stop light harn, near center high mounted stop lights)
S470 (i/p harness, 6 cm from hatch release actuator)
S470 (i/p harness, 6 cm from rear compt lid release actuator)
W/ ag1
W/ eta
W/o eta

Звуковой сигнал Гудок

Электросхема звукового сигнал Гудка для Chevrolet Camaro Z28 1999

Электросхема звукового сигнал Гудка для Chevrolet Camaro Z28 1999 - Список элементов:

18

Body control module (under right side of dash, near blower motor)
Chevy
G109 (top right side of radiator support)
Horn (below right front headlamp)
Horn minifuse 20a
Horn relay
Hot at all times
Nca
Pontiac
Red
S112
S168
Slip ring
Spring
Steering wheel
Top underhood fuse block
Top underhood fuse block (left front corner of engine compt)
W/ anti- theft

Магнитола Мультимедия

Электросхемы магнитолы, С усилитель для Chevrolet Camaro Z28 1999

Электросхемы магнитолы, С усилитель для Chevrolet Camaro Z28 1999 - Список элементов:

69

Antenna
Audio amplifier (behind right rear quarter inner trim panel)
Audio return
Bare
Batt
Battery
Cd changer-remote playback device (if equipped)
Dimming input
Drain
E10
E11
E12
E13
E14
E15
E16
Engine controls system
F10
F11
F12
F13
F14
F15
F16
G200 (left kick panel)
Ground
Hot at all times
I/p fuse block (behind left side of dash)
Ign input
Illumination
Interior lights system
Left audio sig
Left front speaker assembly
Left rear extended range speaker
Left rear subwoofer speaker
Lf (+)
Lf (-)
Lr (+)
Lr (-)
Midrange
Midrange (+)
Midrange (-)
Nca
Power
Pwr accy fuse 4 25a
Pwr accy fuse 7 15a
Radio
Radio fuse 17 15a
Red
Rf (+)
Rf (-)
Rf(-)
Right audio sig
Right front speaker assembly
Right rear extended range speaker
Right rear subwoofer speaker
Rr (+)
Rr (-)
S211
S216
S218
S333
System on
System pwr on
Tan
Tweeter
Tweeter (+)
Tweeter (-)
Vss signal

Электросхемы магнитолы, без усилитель для Chevrolet Camaro Z28 1999

Электросхемы магнитолы, без усилитель для Chevrolet Camaro Z28 1999 - Список элементов:

59

Antenna
Antenna enable
Audio return
Bare
Battery
C217
Cd changer-remote playback device (if equipped)
Dimming input
Drain
G200 (left kick panel)
Ground
Hot at all times
Hot in run, acc or rap
I/p fuse block (behind left side of dash)
Ign input
Illumination
Interior lights system
Left audio sig
Left front speaker
Left rear speaker
Left steering wheel controls
Lf (+)
Lf (-)
Lr (+)
Lr (-)
Nca
Pnk
Pontiac only (if equipped)
Power
Power antenna system (pontiac)
Pwr accy fuse 4 25a
Pwr accy fuse 7 15a
Radio
Radio fuse 17 15a
Rf (+)
Rf(-)
Right audio sig
Right front speaker
Right rear speaker
Right steering wheel controls
Rr (+)
Rr (-)
S211
S216
S218
Sir coil assembly
Stg whl cntrl fuse 3 1a
Strg whl ctlr
Sw1
Sw2
Sw3
Sw4
Sw5
Sw6
Sw7
Sw8
System on
System pwr on
Tan

Подогрев стекол и зеркал

Электросхема подогрева стекол и зеркал для Chevrolet Camaro Z28 1999

Электросхема подогрева стекол и зеркал для Chevrolet Camaro Z28 1999 - Список элементов:

22

"on"
(coupe)
(left kick panel) g200
(near left of dome light) g909 (convertible)
Defog enable
Defog/seats circuit breaker 30a
Gnd
Hot at all times
Hot in run
Hvac control assembly
Hvac fuse 6 20a
I/p fuse block
Ign
On/off input
Pnk
Rear window defogger grid
Rear window defogger switch
Rear window defogger timer/ relay
S216
S248
S252
S420

ПОДУШКИ БЕЗОПАСНОСТИ AIR BAG

Электросхема подушек безопасности SRS AirBag для Chevrolet Camaro Z28 1999

Электросхема подушек безопасности SRS AirBag для Chevrolet Camaro Z28 1999 - Список элементов:

44

(dash harn, at rear compt lid release relay breakout)
(i/p harn, 14 cm from bcm breakout)
A10
A11
A12
A13
A14
A15
A16
A17
A18
Air bag fuse 10 15a
Air bag indicator
Bar
Body control module (bcm) (under right dash, near blower motor)
C13
Connector (dlc) (under dash, to right of steering column)
Data link
Driver high
Driver low
G200 (left kick panel)
G302 (under center console)
Gages fuse 9 10a
Ground
Hot in run, bulb test or start
I/p fuse block (behind left side of dash)
Ign pos volt
Inflatable restraint instrument panel module (upper right side of dash)
Inflatable restraint sensing and diagnostic module (sdm) (below rear of console)
Inflatable restraint steering wheel module (on front of steering wheel)
Inflatable restraint steering wheel module coil
Instrument cluster
Nca
Pass high
Pass low
Pnk
S206
S217
S222 (i/p harn, near breakout to sdm)
Seat belt sig
Seat belt switch
Serial data
Shorting
Star connector (under left side of dash)

ПРЕДУПРЕЖДАЮЩИЕ СИСТЕМЫ

Электросхема предупреждающей системы для Chevrolet Camaro Z28 1999

Электросхема предупреждающей системы для Chevrolet Camaro Z28 1999 - Список элементов:

42

A13
B11
Battery (b+)
Belt indic ctrl
Body control module (bcm) (under right side of dash, near blower motor)
C13
C14
Courtesy fuse 8 20a
D11
D12
D15
Exterior lights system
Fasten seat belt ind
G200 (left kick panel)
Gages fuse 9 10a
Ground
Head
Headlamp switch
Hot at all times
Hot in run, bulb test or start
I/p fuse block
Ignition key warning switch (inside steering column)
Ignition power
Instrument cluster
Key-in-ign in
Left front side door lock
Lft door sw in
Lights on in
Nca
Off
Park
Pnk
Right front side door lock
Rt door sw in
S206
S216
S217
S220
S222 (i/p harn, approx 6 cm from ground g302 breakout, in in inflatable restraint sdm breakout)
S226 (i/p harn, in headlamp switch breakout)
Seat belt switch (in driver's seat belt buckle)
Seat blt sw in

ПРИБОРНАЯ ПАНЕЛЬ

Электросхема панели приборов для Chevrolet Camaro Z28 1999

Электросхема панели приборов для Chevrolet Camaro Z28 1999 - Список элементов:

126

(1999 vin g only)
(5 bulbs)
(i/p harn, approx 20 cm from rear compt lid release relay breakout)
(on hatch release bracket)
(on rear side of transmission)
(pont) (chev)
(right front of eng) (left rear of eng)
(top right of radiator support)
(vin k)
3.8l vin k
5.7l vin g
A10
A11
A12
A13
A14
A15
A16
A17
Abs inop ind
Air bag ind
Anti-theft system
B10
B11
B12
B13
B14
B15
B16
B17
Body control module (under right side of dash, near blower motor)
Brake fluid level switch (in master cylinder)
Brake ind
C15
Change oil
Check gauges ind
Class 2 data
Cluster illum
Coolant temp gauge
Crank input
Cruise control module (in eng compt, on left frame rail forward of wheelwell)
D13
Data link connector (under dash, to right of steering column)
Daytime running lights module (behind radio & hvac contrls, left of glove box)
Electronic brake control module (top of left front frame rail)
Engine controls system
Engine coolant level indicator module (5.7l only) (mounted on upper right side of radiator)
Engine oil pressure sensor (3.8l: lower right front of engine) (5.7l: on top rear b
Engine speed
Exterior lights system
Fasten seat belt ind
Fuel gauge
G108 (top left of radiator support)
G109
G114
G119
G200 (left kick panel)
G407
Gauges fuse 9 10a
Gnd
Hatch ajar
Headlights system
Hi beam ind
Hot at all times
Hot in run, bulb test or start
Hot in start
Hot with lamps on
I/p dimmer fuse 16 5a
I/p fuse block (behind left side of dash)
Ind ctrl
Inflatable restraint sensing & diagnostic module (sdm) (below rear of console)
Instrument cluster
Interior lights system
Left turn ind
Low coolant
Low coolant ind (1999 w/vin g)
Low oil ind
Low trac ind
M/t
Odometer
Odometer lamp
Of eng, near left cylinder head)
Oil press gauge
Park brake switch (at base of parking brake lever)
Pnk
Power
Powertrain control module (in engine compt, behind right strut tower)
Pwr accy fuse 7 15a
Radio (chevrolet w/ vin g)
Rear compartment lid ajar indicator switch
Rear compt lid ajar input
Reduced engine
Right turn ind
S110
S112
S155
S170
S206
S211
S215
S216
S219 (i/p harn, approx 13 cm from rear compt lid release relay breakout)
S224
S228
S242 (i/p harn, approx 4 cm from data link connector breakout)
S246 (i/p harn, approx 3 cm from antenna cable breakout)
Security ind
Service engine soon ind (mil)
Service vehicle
Skip shift ind (vin g)
Slice pack sp200 (left side of dash, near dlc)
Solid state logic
Speedo- meter
Strtr minifuse 15a
Tacho- meter
Tan
Tcs off asr off ind
Trunk, tailgate, fuel doors system
Underhood fuse block (bottom) (in left front corner of eng compt)
Vehicle speed sensor
Volt- meter
Vss hi input
Vss in
Vss lo input
Vss output 4000 p/m
Warning system

ПРИВОД ЗЕРКАЛ

Электросхема привода зеркал для Chevrolet Camaro Z28 1999

Электросхема привода зеркал для Chevrolet Camaro Z28 1999 - Список элементов:

23

(cross car harness, approx 4 cm from left outside rearview mirror breakout)
(cross car harness, approx 7 cm from right outside rearview mirror breakout)
(left kick panel) g200
Down
Driver outside rearview mirror
Front passenger outside rearview mirror
Hot at all times
I/p fuse block (behind left side of dash)
Left
Mirror position switch
Mirror select switch
Nca
Nca b
Nca g
Outside rearview mirror switch
Pwr accy fuse 7 15a
Right
Right/left motor
S211
S220
S501
S610
Up/down motor

ПРИВОД ЛЮКА И КРЫШИ

Электросхемы привода люка или крыши для Chevrolet Camaro Z28 1999

Электросхемы привода люка или крыши для Chevrolet Camaro Z28 1999 - Список элементов:

27

(hatch release bracket) g407
(i/p harness, main branch approx 1-7 cm from body control module (bcm) breakout)
(left rear of engine) g114 (5.7l engine)
(right front of engine) (3.8l engine) g119
(right kick panel) g203
A/t shift lock control actuator diode (in dash harness, near breakout to body control module)
Down
Ecb
Folding top pump (left side rear compartment, behind carpeting)
Folding top relay (behind right side of dash)
Folding top switch
Hot in accy, run or during retained accessory power (rap)
I/p fuse block (behind left side of dash)
Illum- ination lamp
Interior lights system
Nca
Park/neutral position switch (under console, near shift control lever)
S215
S232 (i/p harness, approximately 7 cm from park brake switch breakout)
S234 (i/p harness, main branch, approx 6 cm from body control module (bcm) breakout)
S237
S239
S253
S470
W/eta
W/o eta
Windows ckt breaker 30a

ПРИВОД СТЕКЛОПОДЪЕМНИКОВ

Электросхема стеклоподъемников для Chevrolet Camaro Z28 1999

Электросхема стеклоподъемников для Chevrolet Camaro Z28 1999 - Список элементов:

17

(left kick panel) g200
Driver window motor
Driver window switch
Ecb
Front passenger window motor
Front passenger window switch
Hot in accy, run or with rap energized
I/p fuse block (behind left side of dash)
Left window switch
Right window switch
S208
S220
S263
Solid state (express down relay)
Tan
Window control module (mounted to center of dash mat, above floor tunnel)
Windows circuit breaker 30a

Противоугонная система Сигнализация

Электросхема противоугонной сигнализации для Chevrolet Camaro Z28 1999

Электросхема противоугонной сигнализации для Chevrolet Camaro Z28 1999 - Список элементов:

71

(3.8l)
(5.7l)
(i/p harn, near rear compartment lid release relay) s211
(left kick panel)
(ua6)
A10
Accy
Body control module (under right side of dash, near blower motor)
Bulb test
C11
C12
C16
C2 e
Courtesy fuse 8 20a
D11
D12
D13
D14
Driver door lock
Driver dr open
Front passenger door lock
Fuel enable
G200
G200 (left kick panel)
G407 (on hatch release bracket)
Gages fuse 9 10a
Grd
Hatch ajar in
Horn rly ctrl
Horns system
Hot at all times
Hot in run, bulb test or start
I/p fuse block
Ign
Ignition key
Ignition key lock cylinder
Ignition switch
Ind ctrl
Instrument cluster system
Instrument panel cluster
Lock
Nca
Off
Pass dr open
Pnk
Powertrain control module (behind right strut tower)
Pwr accy fuse 7 15a
Rear compartment lid ajar indication switch
Red
Relay ctrl
Resistor fd
Resistor pellet
Resistor ret
Run
S206
S217
S220
S254
S470
Sec led ctrl
Security indicator
Security indicator led (top center of dash)
Shock
Shock in
Start
Start rly ctrl
Starting system
System lights exterior
Tamper
Theft deterrent relay (on inflatable restraint dash module bracket)
Theft deterrent shock sensor (ua6) (in right rear quarter panel)

СИСТЕМА АНТИБЛОКИРОВОЧНОЙ ТОРМОЗНОЙ СИСТЕМЫ ABS

3.8L

3.8L ВИН К, Электросхема антиблокировочной тормозной системы АБС (ABS), С регулирование тягового усилия для Chevrolet Camaro Z28 1999

3.8L ВИН К, Электросхема антиблокировочной тормозной системы АБС (ABS), С регулирование тягового усилия для Chevrolet Camaro Z28 1999 - Список элементов:

62

(on brake pedal bracket)
(rear of left cylinder head) g114
(right front shock tower) g103
Abs batt 1 maxi fuse 40a
Abs batt mini fuse 25a
Abs ign mini fuse 10a
Abs inop ind
Asr (chevrolet) tcs off (pontiac)
B c1
Battery
Brake pressure modulator valve
Brake warning ind
Breakout)
C 1995 vftc
C1 req tor
C2 tach out
Del tor
Del torque
Electronic brake and traction control module (top of left front frame rail)
G108 (left radiator support)
Gauges fuse 9 10a
Ground
Hot at all times
Hot in run
Hot in run, bulb test and start
I/p fuse block
Ignition
Instrument cluster
Instrument cluster system
Interior lights system
Left front wheel speed sensor
Lf whl spd
Low trac ind
Lr whl spd
Nca
Pnk
Powertrain control module (behind right strut tower)
Pump motor
Pump mtr ctrl
Rear wheel speed sensor
Red
Req torque sig
Rf whl spd
Right front wheel speed sensor
S113
S206
S207
S215
Serial data
Solid state
Star connector
Stop lamp switch
Stop lp fd
Stop/hazard fuse 1 20a
Tach signal
Tan
Tcs ind
Tcs switch
Traction control switch
Turn b/u fuse 2 20a
Underhood electrical center 1
Underhood electrical center 2

Электросхема антиблокировочной тормозной системы АБС (ABS), без Регулирование тягового усилия для Chevrolet Camaro Z28 1999

Электросхема антиблокировочной тормозной системы АБС (ABS), без Регулирование тягового усилия для Chevrolet Camaro Z28 1999 - Список элементов:

44

(on brake pedal bracket)
(right front shock tower) g103
(top left radiator support) g108
Abs batt 1 maxi fuse 40a
Abs batt mini fuse 25a
Abs ign mini fuse 10a
Abs inop ind
B c1
Battery
Brake pressure modulator valve
Brake warning ind
C 1995 vftc
Electronic brake control module (top of left front frame rail)
Engine wiring harness junction block 1
Engine wiring harness junction block 2
Gauges fuse 9 10a
Ground
Hot at all times
Hot in run, bulb test or start
I/p fuse block
Ignition
Instrument cluster
Instrument cluster system
Left front wheel speed sensor
Lf whl spd
Low trac ind
Nca
Pnk
Pump motor
Pump mtr ctrl
Rear wheel speed sensor
Rear whl spd
Red
Rf whl spd
Right front wheel speed sensor
S113
S154 (fwd lamp harn, near left front front wheel speed sensor breakout)
S206
Serial data
Splice pack sp200
Stop lp fd
Stop/hazard fuse 1 20a
Stoplamp/ tcc switch
Tan

5.7L

5.7L ВИН Г, Электросхема антиблокировочной тормозной системы АБС (ABS), С регулирование тягового усилия для Chevrolet Camaro Z28 1999

5.7L ВИН Г, Электросхема антиблокировочной тормозной системы АБС (ABS), С регулирование тягового усилия для Chevrolet Camaro Z28 1999 - Список элементов:

91

(engine harn, near map sensor breakout)
(engine harn, near vss breakout)
(fwd lamp harn, near bulkhead connector)
(on brake pedal bracket)
(rear of left cylinder head) g114
(right front shock tower) g103
+5v ref
Abs batt 1 maxi fuse 40a
Abs batt mini fuse 25a
Abs ign mini fuse 10a
Abs inop ind
Acc crtl
Acc ctrl
Accelerator & servo control module (under left side of dash)
Accelerator control & adjuster (forward of right front wheelwell)
Asr (chevrolet) tcs off (pontiac)
B c1
Battery
Brake pressure modulator valve
Brake warning ind
Breakout)
C 1995 vftc
C1 +5v
C2 spk rtd
Electronic brake & traction control module (top of left front frame rail)
G101 (front of right front wheelhouse)
G108 (left radiator support)
Gauges fuse 9 10a
Ground
Hot at all times
Hot in run
Hot in run, bulb test and start
I/p fuse block
Ign retard
Ignition
Instrument cluster
Instrument cluster system
Interior lights system
Left front wheel speed sensor
Left rear wheel speed sensor
Lf whl spd
Low trac ind
Lr whl spd
Nca
Note: unused pins not shown
Pnk
Powertrain control module (behind right strut tower)
Pump motor
Pump mtr ctrl
Red
Req tps sig
Rf whl spd
Right front wheel speed sensor
Right rear wheel speed sensor
Rr whl spd
S113
S116
S118
S119
S181
S203
S204
S205
S206
S207
S209
S215
Sens gnd
Serial data
Solid state
Star connector
Stop lamp switch
Stop lp fd
Stop/hazard fuse 1 20a
Tach out
Tach signal
Tan
Tcs batt mini fuse 20a
Tcs ind
Tcs signal
Tcs switch
Throttle position sensor (front of throttle body)
Torque del
Torque req
Tp sens
Tps ret
Tps sig
Traction control switch
Turn b/u fuse 2 20a
Underhood electrical center 1
Underhood electrical center 2

Электросхема антиблокировочной тормозной системы АБС (ABS), без Регулирование тягового усилия для Chevrolet Camaro Z28 1999

Электросхема антиблокировочной тормозной системы АБС (ABS), без Регулирование тягового усилия для Chevrolet Camaro Z28 1999 - Список элементов:

44

(on brake pedal bracket)
(right front shock tower) g103
(top left radiator support) g108
Abs batt 1 maxi fuse 40a
Abs batt mini fuse 25a
Abs ign mini fuse 10a
Abs inop ind
B c1
Battery
Brake pressure modulator valve
Brake warning ind
C 1995 vftc
Electronic brake control module (top of left front frame rail)
Engine wiring harness junction block 1
Engine wiring harness junction block 2
Gauges fuse 9 10a
Ground
Hot at all times
Hot in run, bulb test or start
I/p fuse block
Ignition
Instrument cluster
Instrument cluster system
Left front wheel speed sensor
Lf whl spd
Low trac ind
Nca
Pnk
Pump motor
Pump mtr ctrl
Rear wheel speed sensor
Rear whl spd
Red
Rf whl spd
Right front wheel speed sensor
S113
S154 (fwd lamp harn, near left front front wheel speed sensor breakout)
S206
Serial data
Splice pack sp200
Stop lp fd
Stop/hazard fuse 1 20a
Stoplamp/ tcc switch
Tan

СИСТЕМА КОНДИЦИОНЕРА

3.8L

3.8L ВИН К, Электросхема компрессора для Chevrolet Camaro Z28 1999

3.8L ВИН К, Электросхема компрессора для Chevrolet Camaro Z28 1999 - Список элементов:

40

(eng harn 3 cm from inj 2 breakout)
(eng harn near generator breakout)
(eng harn, at a/c refrigerant pressure sensor breakout)
(forward comploc harn, 7 cm from underhood electrical center 2 breakout)
+5v
A/c clutch diode (1 amp)
A/c compressor clutch
A/c compressor relay (in underhood electrical center 2)
A/c refrigerant pressure sensor (above right front wheelwell, on refrigerant line)
A/c request
A/c-cruise fuse (mini) 15a
Bi-lv
Blend
Center 2
Clutch status
Compressor ctrl
D10
Def
G112 (left side of engine)
Hot in run
Hot in run, bulb test or start
Htr/ def
Hvac control
Hvac fuse 6 20a
I/p fuse block
Max
Nca
Norm
Off
Pnk
Powertrain control module (in engine compt, rear of right strut tower)
S105
S114 (eng harn, 3 cm back from generator breakout)
S115
S165 pnk
Selector switch
Sensor ground
Sensor sig
Underhood electrical
Vent

3.8L ВИН К, Электросхема кондиционера с ручный управлением для Chevrolet Camaro Z28 1999

3.8L ВИН К, Электросхема кондиционера с ручный управлением для Chevrolet Camaro Z28 1999 - Список элементов:

78

(eng harn, at a/c refrigerant pressure sensor breakout)
(engine harn, 3 cm back from generator breakout)
(engine harn, 3 cm from inj 2 breakout)
(engine harn, at generator breakout)
(forward lamp harn)
(forward lamp harn, near right radiator support)
(in underhood electrical center 1)
(near top left side of the radiator support)
+5v
0.31 ohm total
0.61 ohm
1.85 ohm
A/c clutch diode (1 amp)
A/c compressor clutch
A/c compressor relay (in underhood electrical center 2)
A/c refrigerant pressure sensor (above right front wheelwell, on refrigerant line)
A/c request
A/c-cruise fuse (mini) 15a
Bi-lv
Blend
Blower motor
Blower motor relay (on inflatable restraint dash module bracket)
Blower resistor (in hvac module)
Blower switch
C 1995 vftc
C tan
Center 2
Clutch status
Compressor ctrl
Cool fan fuse (maxi) 40a
Cooling fan fuse (mini) 10a
D10
Def
Engine cooling fan relay 1
Engine cooling fan relay 2 (in underhood electrical center 1)
Engine cooling fan relay 3 (in underhood electrical center 1)
Fan rly 1 control
Fan rly 2 & 3 control
G106
G112 (left side of engine)
G200 (left kick panel)
G201 (right kick panel)
Hot at all times
Hot in run
Hot in run, bulb test or start
Htr
Htr/ def
Htr/def
Hvac control (blower switch contacts are make before break contacts)
Hvac fuse 6 20a
I/p 1 fuse (maxi) 40a
I/p fuse block
Interior lights system
Left engine cooling fan
Max
Nca
Norm
Off
Pnk
Powertrain control module (in engine compt, rear of right strut tower)
Red
Right engine cooling fan
S105
S114
S115
S165 (forward lamp harn, 7cm from pnk underhood electrical center 2 breakout)
S166
S169 (forward lamp harn, 6 cm into underhood electrical center 1 breakout)
S179
S216 (i/p harn, 10 cm from i/p cluster breakout)
S248 (i/p harn, 2 cm from radio connectors breakout)
Selector switch
Sensor ground
Sensor sig
Tan
Underhood electrical
Underhood electrical center 1
Vent

5.7L

5.7L ВИН Г, Электросхема компрессора для Chevrolet Camaro Z28 1999

5.7L ВИН Г, Электросхема компрессора для Chevrolet Camaro Z28 1999 - Список элементов:

39

(eng harn, 17 cm back from a/c comp clutch connector)
(eng harn, 20 cm back from a/c clutch breakout)
(forward lamp harn, 7 cm from underhood electrical center 2 breakout)
+5v
A/c clutch diode (1 amp)
A/c compressor clutch
A/c compressor relay (in underhood electrical center 2)
A/c refrigerant pressure sensor (above right front wheelwell, on refrigerant line)
A/c request
A/c-cruise fuse (mini) 15a
Bi-lv
Blend
C10
Center 2
Clutch status
Compressor ctrl
D10
Def
G112 (left side of engine)
Hot in run
Hot in run, bulb test or start
Htr/ def
Hvac control
Hvac fuse 6 20a
I/p fuse block
Max
Nca
Norm
Off
Pnk
Powertrain control module (in engine compt, rear of right strut tower)
S114 (eng harn, 17 cm back from a/c compressor clutch breakout)
S115
S165 pnk
Selector switch
Sensor ground
Sensor sig
Underhood electrical
Vent

5.7L ВИН Г, Электросхема кондиционера с ручный управлением для Chevrolet Camaro Z28 1999

5.7L ВИН Г, Электросхема кондиционера с ручный управлением для Chevrolet Camaro Z28 1999 - Список элементов:

75

(engine harn 20 cm back from a/c clutch breakout)
(engine harn, 17 cm back from a/c comp clutch connector)
(engine harn, 17 cm back from a/c compressor clutch conn)
(forward lamp harn)
(forward lamp harn, near right radiator support)
(in underhood electrical center 1)
(near top left side of the radiator support)
+5v
0.31 ohm total
0.61 ohm
1.85 ohm
A/c clutch diode (1 amp)
A/c compressor clutch
A/c compressor relay (in underhood electrical center 2)
A/c refrigerant pressure sensor (above right front wheelhouse, on refrigerant line)
A/c request
A/c-cruise fuse (mini) 15a
Bi-lv
Blend
Blower motor
Blower motor relay (on inflatable restraint dash module bracket)
Blower resistor (in hvac module)
Blower switch
C 1995 vftc
C tan
Center 2
Compressor ctrl
Cool fan fuse (maxi) 40a
Cooling fan fuse (mini) 10a
D10
Def
Engine cooling fan relay 1
Engine cooling fan relay 2 (in underhood electrical center 1)
Engine cooling fan relay 3 (in underhood electrical center 1)
Fan rly 1 control
Fan rly 2 & 3 control
G106
G112 (left side of engine)
G200 (left kick panel)
G201 (right kick panel)
Hot at all times
Hot in run
Hot in run, bulb test or start
Htr
Htr/ def
Htr/def
Hvac control (blower switch contacts are make before break contacts)
Hvac fuse 6 20a
I/p 1 fuse (maxi) 40a
I/p fuse block
Interior lights system
Left engine cooling fan
Max
Nca
Norm
Off
Pnk
Powertrain control module (in engine compt, rear of right strut tower)
Red
Right engine cooling fan
S114
S115
S165 (forward lamp harn, 7cm from pnk underhood electrical center 2 breakout)
S166
S169 (forward lamp harn, 6 cm into underhood electrical center 1 breakout)
S179
S216 (i/p harn, 10 cm from i/p cluster breakout)
S248 (i/p harn, 2 cm from radio connectors breakout)
Selector switch
Sensor ground
Sensor sig
Tan
Underhood electrical
Underhood electrical center 1
Vent

СИСТЕМА КРУИЗКОНТРОЛЯ

Электросхема системы круизконтроля для Chevrolet Camaro Z28 1999

Электросхема системы круизконтроля для Chevrolet Camaro Z28 1999 - Список элементов:

41

4000 pulses/mile
A c1
A/c-cruise fuse 15a
A/t
B c1
Bottom underhood fuse block (left front corner of engine compt)
Brake input
Clutch pedal position (cpp) switch (on clutch pedal bracket)
Cruise control module (engine compt, on left frame rail)
Cruise control release/tcc brake switch (on brake pedal bracket)
Cruise engaged
Cruise inhibit
Cruise status
Cruise switch
Engine control system
G113 (left front frame rail)
Ground
Hot at all times
Hot in run, bulb test or start
I/p fuse block (behind left side of dash)
Ignition input
M/t
Multi-function turn signal lever
Nca
Off
On/off input
Pnk
Powertrain control module (pcm) (in engine compt, behind right stut tower)
R/a
Resume/accel input
S154 (fwd lamp harness, near left front wheel speed sensor breakout)
S165
S242 (i/p harness, near breakout of data link connector)
Set/ coast sw
Set/coast input
Stop/hazard fuse 1 20a
Stoplight switch (on brake pedal bracket)
Vehicle speed sensor (rear side of transmission)
Vss inpt hi
Vss input
Vss input lo

СИСТЕМА ОХЛАЖДЕНИЯ

Электросхема системы охлаждения для Chevrolet Camaro Z28 1999

Электросхема системы охлаждения для Chevrolet Camaro Z28 1999 - Список элементов:

27

(in underhood electrical center 1)
(near top left side of
+5v
3.8l
5.7l
A/c refrigerant pressure sensor (above right front wheelhouse, on refrigerant line)
C 1995 vftc
Cool fan fuse (maxi) 40a
Cooling fan fuse (mini) 10a
Engine cooling fan relay 1
Engine cooling fan relay 2 (in underhood electrical center 1)
Engine cooling fan relay 3 (in underhood electrical center 1)
Fan rly 1 control
Fan rly 2 & 3 control
G106
Hot at all times
Left engine cooling fan
Powertrain control module (in engine compt, rear of right strut tower)
Red
Right engine cooling fan
S166 (forward lamp harn, near right radiator support)
S169 (forward lamp harn, 6 cm into underhood electrical center 1 breakout)
S179 (forward lamp harness)
Sensor ground
Sensor sig
The radiator support)
Underhood electrical center 1

СИСТЕМА ПЕРЕДАЧИ ДАННЫХ

Электросхема компьютерной линии передачи данных CAN для Chevrolet Camaro Z28 1999

Электросхема компьютерной линии передачи данных CAN для Chevrolet Camaro Z28 1999 - Список элементов:

23

(1999)
(2000-01)
(right front of engine) (3.8l only) g119 g114 (5.7l only) (left rear of engine)
(under left
2000-01 5.7l only
All except 2000-01 5.7l
Cigar/accy fuse 11 25a
Data link connector (dlc) (under dash, to right of steering column)
Electronic brake & traction control module (ebtcm) (on top of left front frame rail)
G200 (left kick panel)
Hot at all times
I/p fuse block
Inflatable restraint sensing & diagnostic module (sdm) (below rear of console)
Instrument panel cluster (ipc)
Near dlc)
Powertrain control module (pcm) (in engine compt, behind right strut tower)
S215
S217
S240
Serial data
Side of dash,
Splice pack sp200
Star connector

СИСТЕМА УПРАВЛЕНИЯ ДВИГАТЕЛЯ

3.8L

3.8L ВИН К, Электросхема системы управления двигателя (1 из 4) для Chevrolet Camaro Z28 1999

3.8L ВИН К, Электросхема системы управления двигателя (1 из 4) для Chevrolet Camaro Z28 1999 - Список элементов:

84

(front of engine) g125
(left side of cyl block) knock sensor (ks) bank 1
1-2 shift sol control
18x ref
18x reference
2-3 shift sol control
2nd gear ind ctrl
3x ref
3x reference
Bank 1 ks input
Bank 2 ks input
Battery
Body control module
Bypass
Ckp 18x sig
Ckp sync sig
Cmp input
Cmp output
Cmp signal
Cooling fan system
Cruise module, radio & inst cluster
Data link connector (under dash, to the right of steering column)
Ect sensor ground
Egr control ground
Egr pos sensor ground
Electronic brake & traction control module
Electronic ignition control module (icm) (at front end of left cylinder head)
Eng ctrl fuse 15a
Evap purge valve cont
Evaporative emissions (evap) canister purge solenoid valve (right front of eng, next to inj 2)
Fuel inj 1 control
Fuel inj 2 control
Fuel inj 4 control
Fuel inj 5 control
Fuel inj 6 control
G114 (rear of left cylinder head)
G125 (front of engine)
Ground
Hi speed cool fan cont
Ho2s 1 low
Ho2s 2 low
Hot at all times
Hot in run and start
Hot in run, bulb test and start
Iat sensor ground
Ign
Ign control
Ign voltage
Ignition
Ignition control
Instrument cluster system (tach signal)
Knock sensor (ks) bank 2 (right side of cyl block)
Lo speed cool fan cont
Maf sensor input
Map sensor ground
Mass air flow (maf) sensor (in air duct, front of int manifold)
Pcm batt fuse 10a
Pcm ground
Pcm ign fuse 15a
Pnk
Pnk a
Powertrain control module (pcm) (in eng compt, behind right strut tower)
Ref low
Reference low
Requested torque in
S107
S108
S110
S182
Serial data (class 2)
Signal
Star connector
Stoplamp/ tcc switch (on brake pedal support) c2
Tac serial data
Tan
Tcc switch input
Theft deter fuel enable
Trans range a input
Underhood electrical center 1 (left front of eng compt)
Underhood electrical center 2 (left front of eng compt)
Vehicle speed sensor (vss) (on rear side of transmission)
Vss high
Vss low
Vss output

3.8L ВИН К, Электросхема системы управления двигателя (2 из 4) для Chevrolet Camaro Z28 1999

3.8L ВИН К, Электросхема системы управления двигателя (2 из 4) для Chevrolet Camaro Z28 1999 - Список элементов:

34

(eng harn, approx 2 cm from inj 3 breakout)
(under console near shift control lever) park/neutral position (pnp) switch
1-2 shift sol
2-3 shift sol
2nd gear ind
3-2 shift sol
A/t fluid pressure manual valve position switch
A/t fluid temp sensor
Automatic transaxle
Camshaft position sensor (cmp) (engine front cover)
Control solenoid
Crankshaft position sensor (ckp) (lower front of eng)
Fuel injectors
G125 (front of eng)
G125 (front of engine)
Hot in run
Hot in run, bulb test and start
I/p fuse block
Inj 1 fuse 15a
Pnk
Pressure a
Red
Rev
S102 pnk
S144 (eng harn, approx 4 cm from inj 3 breakout)
S145
S207
S215
Second gear start switch
Tan
Tcc pwm sol
Tcc sol
Turn b/u fuse 2 20a
Underhood electrical center 2 (left front of eng compt)

3.8L ВИН К, Электросхема системы управления двигателя (3 из 4) для Chevrolet Camaro Z28 1999

3.8L ВИН К, Электросхема системы управления двигателя (3 из 4) для Chevrolet Camaro Z28 1999 - Список элементов:

40

(eng harn, approx 3 cm from inj 5 breakout)
(eng harn, approx 8 cm from pcm breakout)
(i/p harn, coupe: 40 cm conv: 46 cm from i/p pass through in-line connector that is forward of rear axle)
(on air intake duct, forward of intake manifold) intake air temperature (iat) sensor
(top right of engine) evaporative emissions canister vent solenoid valve
A10
B10
Exhaust gas recirculation (egr) valve (left front of engine)
Fuel level sensor
Fuel pump
Fuel pump fuse 15a
Fuel pump relay
Fuel tank pressure sensor (in fuel tank)
Fuel tank unit
G125 (front of engine)
G309 (left door sill)
Hot at all times
Manifold absolute pressure (map) sensor (right side of intake manifold)
Motor driver
Mtr drive hi
Mtr drive lo
Nca
Pnk
Red
S117
S121
S171
S244
Tac srl data
Tan
Throttle actuator control
Throttle actuator control module
Tps1 5v ref
Tps1 gnd
Tps1 sig
Tps2 5v ref
Tps2 gnd
Tps2 sig
Underhood electrical center 1
Underhood electrical center 2

3.8L ВИН К, Электросхема системы управления двигателя (4 из 4) для Chevrolet Camaro Z28 1999

3.8L ВИН К, Электросхема системы управления двигателя (4 из 4) для Chevrolet Camaro Z28 1999 - Список элементов:

76

(front of engine)
(front of engine) g125
(in underhood electrical center no2)
(w/ nc1)
2nd gear start sig
3-2 sol control
5 volt reference a
5 volt reference b
A/c comp relay control
A/c ref press sensor in
A/c refrigerent pressure sensor (above right front wheelwell, attached to refrigerent line)
A/c request
A/c system
A/t fluid temp input
Air pump relay
Air pump rly ctrl (if equipped)
Charging system
Clutch anticipate sig
Cruise control system
Cruise control/ clutch anticipate switch (on clutch pedal bracket)
Cruise ctrl release sig
Delivered torque out
Ect sensor input
Egr pintel position input
Egr valve control
Electronic brake & traction control module
Eng oil level sw input
Eng sen fuse 20a
Eng speed out
Engine coolant temperature (ect) sensor (below throttle body, at front of eng)
Engine oil level switch (inside of oil pan)
Evap solenoid control
Fuel inj 3 control
Fuel level input
Fuel pump relay control
Fuel tank press sensor
G114 (rear of left cylinder head)
G125
Gauges fuse 9 10a
Gen term l control
Heated oxygen sensor bank 1 sensor 1 (on left exhaust manifold)
Heated oxygen sensor bank 2 sensor 1 (on right exhaust manifold)
Heated oxygen sensor bank sensor 3 (rear of cat converter)
Ho2s 1 input
Ho2s 2 input
Hot in run, bulb test and start
Hot in start
I/p fuse block
Iat sensor input
Ignition
Instrument cluster
Low oil control
Map sensor input
Mil control
Mil ind
Nca
Pnk
Powertrain control module (pcm) (in eng compt, behind right strut tower)
Press sol high control
Press sol low control
Red
S104
S108
S110
S111
S170
S206
Sensor ground
Strtr fuse 15a
Tan
Tcc pwm sol control
Tcc sol control
Trans range b input
Trans range c input
Trans range sw p input
Underhood electrical center 2 (left front of eng compt)

5.7L

5.7L ВИН Г, Электросхема системы управления двигателя (1 из 4) для Chevrolet Camaro Z28 1999

5.7L ВИН Г, Электросхема системы управления двигателя (1 из 4) для Chevrolet Camaro Z28 1999 - Список элементов:

95

(587)
(eng harn, a/t: approx 8 cm from a/t breakout, m/t: approx 9 cm from vss breakout)
(eng harn, approx 15 cm from map sensor breakout)
(eng harn, approx 9 cm from map sensor breakout) s116
(pin 13-16 not used)
(pin 38-39 not used)
(pin 49-50 not used)
(pin 5-7 not used)
(pin 62-64 not used)
(pin 9-10 not used)
(rear of left cylinder head) g114
5v feed
A/c refrig press 5v ref
A/c system
Anti-lock brakes system
Bank 1 lf ho2s hi
Bank 1 lf ho2s lo
Bank 1 lr ho2s hi
Bank 1 lr ho2s lo
Bank 1 sensor 1 heated oxygen sensor (in left exhaust manifold)
Bank 1 sensor 2 heated oxygen sensor (rear of left catalytic converter)
Bank 2 rf ho2s hi
Bank 2 rf ho2s lo
Bank 2 rr ho2s hi
Bank 2 rr ho2s lo
Batt
Camshaft position sensor (top center rear of eng)
Ckp sen sig
Clutch anticipate sw sig
Cmp sen sig in
Cooling fan 1 rly ctrl
Cooling fans system
Crankshaft position sensor (right rear of eng, behind starter)
Cruise control/ clutch anticipate switch (on clutch pedal bracket)
Data link connector (under dash, right of steering column)
Ect sen gnd
Ect sen sig
Egr sen gnd
Egr sig
Engine coolant temperature sensor (left side of eng, above generator)
Front ks sig
Fuel gnd
Fuel inj driver no1
Fuel inj driver no2
Fuel inj driver no3
Fuel inj driver no4
Fuel inj driver no5
Fuel inj driver no6
Fuel inj driver no7
Fuel inj driver no8
Fuel injectors
Hot in run, bulb test and start
Hot in run, bulb test or start
Ign
Ign feed
Inj1 fuse 15a
Inj2 fuse 15a
Knock sensor (front) (center of eng, below manifold)
Knock sensor (rear) (center of eng, below manifold)
Manifold absolute pressure sensor (rear of intake manifold)
Map 5v ref
Map sen gnd
Nca
Oil level switch in
Pcm bat fuse 10a
Pcm gnd
Pcm ign fuse 15a
Pnk
Pnk a
Pnk d
Pnk s109
Pnp sw sig
Powertrain control module (in eng compt, behind right strut tower)
Rear ks sig
Red
Red c
Ref low
S102
S106
S110
S118
S119
S215
Sen gnd
Serial data
Skip shift sol ctrl (m/t) 3-2 ss valve ctrl (a/t)
Star connector
Tan
Tcc/cruise brake sw in
Throttle position sensor (on throttle body)
Tps 5v ref
Trans range "b" in
Trans range "c" in
Under- hood electrical center 1
Underhood electrical center 2

5.7L ВИН Г, Электросхема системы управления двигателя (2 из 4) для Chevrolet Camaro Z28 1999

5.7L ВИН Г, Электросхема системы управления двигателя (2 из 4) для Chevrolet Camaro Z28 1999 - Список элементов:

48

(fwd lamp harn, 8 cm into solenoid breakout)
(on brake pedal bracket) stop lamp switch
(top left side of radiator support)
1-2 shift solenoid
2-3 shift solenoid
3-2 shift solenoid
A/t
Air pump relay
Air sol relay
Automatic transmission
Automatic transmission fluid pressure
B pnk
Bank 2 sensor 1 heated oxygen sensor (in right exhaust manifold)
Bank 2 sensor 2 heated oxygen sensor (rear of right catalytic converter)
D2 sw
D3 sw
D4 sw
E11
Eng sen fuse 20a
F11
G108
G114 (rear of left cylinder head)
Hot w/ ign 1 relay energized
Lo sw
M/t
Manual transmission
Manual valve position switch
Mass air flow sensor (in air duct, in front of intake manifold)
Nca
Pnk
Pressure control solenoid valve
Red
Red a
Rev sw
Reverse inhibit solenoid
S104
S108
S110
S159
S177
Secondary air injection bleed valve solenoid (on right front frame rail)
Secondary air injection pump (on right front frame rail)
Skip shift solenoid
Tan
Tcc pwm solenoid
Tcc solenoid
Transmission fluid temp sensor
Underhood electrical center 2

5.7L ВИН Г, Электросхема системы управления двигателя (3 из 4) для Chevrolet Camaro Z28 1999

5.7L ВИН Г, Электросхема системы управления двигателя (3 из 4) для Chevrolet Camaro Z28 1999 - Список элементов:

39

(eng jumper harn)
(i/p harn, 5 cm from bcm breakout)
(rear of left cylinder head)
A10
Air pump fuse 25a
B10
Engine oil level switch (in side of oil pan)
Exhaust gas recirculation valve (upper right front corner of eng)
Fuel level sensor
Fuel pump
Fuel pump fuse 20a
Fuel pump relay
Fuel tank pressure sensor
Fuel tank unit
G114
G114 (rear of left cylinder head)
G316 (left door sill)
Gnd
Hot at all times
Ign
Ign ctrl sig
Ignition coil/ module (at top of cylinder)
Nca
Park/neutral position switch (under console, near shift control lever)
Plug spark
Pnk
Red
Red e
Ref lo
S100
S110
S122
S123
S126
S234
S244 (i/p harn, near dash pass- through in-line connector)
Spark plug
Under- hood electrical center 1
Underhood electrical center 2

5.7L ВИН Г, Электросхема системы управления двигателя (4 из 4) для Chevrolet Camaro Z28 1999

5.7L ВИН Г, Электросхема системы управления двигателя (4 из 4) для Chevrolet Camaro Z28 1999 - Список элементов:

101

(eng jumper harn)
(left side of eng, on intake manifold)
(mil)
(pin 11-12 not used)
(pin 22-23 not used)
(pin 55-56 not used)
(pin 58-59 not used)
(pin 70-75 not used)
(rear side of transmission) vehicle speed sensor
(under floor pan, fwd of fuel tank) evaporative emission canister vent valve
(w/ traction control only)
1-3 ss valve ctrl
2-3 ss valve ctrl
A pnk
A/c clutch rly ctrl
A/c clutch status
A/c refrig press sen sig
A/c request
A/c system
Air pump rly ctrl
Air solenoid rly ctrl
Anti-lock brakes system
Body control module
Cool fans 2 & 3 rly ctrl
Cooling fans system
Cruise control system
Cruise control, sound (camaro) & instrument cluster systems
Cruise ctrl enable sig
Cruise ctrl inhibit
Egr valve ctrl
Egr valve gnd
Electronic brake control module
Eng ctrl fuse 15a
Evap can purge valve ctrl
Evap can vent valve ctrl
Evaporative emission canister purge solenoid valve
Fuel level in
Fuel pump rly ctrl
Fuel tank pressure
G114 (rear of left cylinder head)
Generator term "l" out
Gnd
Hot w/ ign 1 relay energized
Iac coil "a" hi
Iac coil "a" lo
Iac coil "b" hi
Iac coil "b" lo
Iat sen in
Idle air control valve (on throttle body)
Ign
Ign ctrl no1
Ign ctrl no2
Ign ctrl no3
Ign ctrl no4
Ign ctrl no5
Ign ctrl no6
Ign ctrl no7
Ign ctrl no8
Ign ctrl sig
Ign feed
Ignition coil/ module (at top of cylinder)
Instrument cluster
Intake air temperature sensor (on air intake duck, fwd of intake manifold)
Maf sen sig
Malfunction indicator lamp
Map sen sig
Mil ctrl
Nca
Pc sol valve hi
Pc sol valve lo
Plug spark
Pnk
Powertrain control module (in eng compt, behind right strut tower)
Red
Ref lo
Ref low
Reverse inhibit sol ctrl
S107
S110
S124
S125
S127
S128
S182
S215
Sen gnd
Spark plug
Starting/ charging system
Tach out
Tan
Tcc pwm sol valve ctrl
Tcc sol valve ctrl
Tcs spark retard sig
Tft sen sig
Theft deter fuel enable
Tp sen sig
Trans range "a" in
Underhood electrical center 2
Vss hi
Vss lo
Vss out

Система Фар

Электросхема фар для Chevrolet Camaro Z28 1999

Электросхема фар для Chevrolet Camaro Z28 1999 - Список элементов:

65

(forward lamp harn, approx 13cm from left front wheel speed sensor breakout) s153
(forward lamp harn, approx 16cm from windshield washer pump breakout)
(forward lamp harn, approx 4cm from cruise control module) s160
(i/p harn, approx 14cm into headlamp switch breakout) s227
(i/p harn, approx 7cm into headlamp switch breakout)
A11
Al sens
Ambient light sensor (top of dash)
Circuit breaker
Daytime running lamps module (mounted behind radio and hvac controls)
Exterior lights system
F11
Fog lamp relay (under- hood electrical center 2)
Fog lamp switch
G108 (top left of radiator support)
G109 (top right of radiator)
G200 (left kick panel)
Gages fuse 9 10a
Ground
Head
Head- lamp dimmer switch
Headlamp switch
Headlight relay
High beam indicator
Hl on in
Hot at all times
Hot in run
Hot in run, bulb test or start
I/p fuse block (behind left side of dash)
Ignition
Instrument cluster
Instrument cluster system
Interior lights system
Left front fog lamp
Left high beam head- lamp
Left low beam head- lamp
Left turn relay
Lt turn in
Off
On indicator
Park
Park brake switch
Park light relay
Pnk
Prk brake
Red
Right front fog lamp
Right high beam head- lamp
Right low beam head- lamp
Right turn relay
Rly ctrl
Rt turn in
S112
S150
S155
S206
S207
S214 (i/p harn, approx 8cm from cluster breakout)
S216
S226
Si52 (forward lamp harn, approx 7cm from left front whl spd sens breakout)
Sw illum
Tail lts fuse 5 20a
Tan
Turn b-u fuse 2 20a

СИСТЕМЫ СИДЕНИЙ

Электросхема привода сидений с 6 путями для Chevrolet Camaro Z28 1999

Электросхема привода сидений с 6 путями для Chevrolet Camaro Z28 1999 - Список элементов:

21

Back
Defog/seats circuit breaker 12 30a
Down
Driver's seat assembly
E tan a
Entire seat
For- ward
Forward/ back motor
Front height
Front height motor
G300 (below left front
Hot at all times
I/p fuse block
Nca
Power seat actuator assembly
Power seat switch
Rear height
Rear height motor
S252
S321 (aq9)
Seat)

Электросхема регулировки поясницы для Chevrolet Camaro Z28 1999

Электросхема регулировки поясницы для Chevrolet Camaro Z28 1999 - Список элементов:

24

Deflate
Deflate relay
Defog/seats circuit breaker 12 30a
Driver's seat assembly
G300 (below left front seat)
Hot at all times
I/p fuse block
Inflate
Lumbar adjust switch
Passenger's seat assembly
Pnk
Power seat cushion air control module (under passenger's seat)
Pressure switch
Ptc inflate relay
Red
S320
S321
S330
S331
Seat inflator pump
Solenoid 1
Solenoid 2
Solenoid 3
Solenoid 4

Стартер Генератор

Электросхема Генератора для Chevrolet Camaro Z28 1999

Электросхема Генератора для Chevrolet Camaro Z28 1999 - Список элементов:

13

Battery
Charging indicator
Clamp 15 cruise fuse 15 15a
Fuse block
G101 (left front of engine compt)
G110 (below power steering pump)
Gauge cluster
Generator
Hot in on or start
Power distribution system
Red
S200
Starter motor switch

Электросхема стартера для Chevrolet Camaro Z28 1999

Электросхема стартера для Chevrolet Camaro Z28 1999 - Список элементов:

35

(left front shock tower)
(right side of engine block)
(under right side of of dash, near kick panel)
A/t
Accy
Battery
Battery junction block
Body control module (bcm)
Bulb test
C11
Clutch pedal position switch (on clutch pedal bracket)
G102
G120
Generator
Hold- in coil
Ign maxi fuse 50a
Ignition switch
Instrument cluster
Lock
M/t
Off
Park/neutral position switch (under console, near shift control lever)
Powertrain control module (behind right strut tower)
Pull- in coil
Red
Run
S170
S183
Start
Starter motor
Starter relay
Starter relay control
Starter solenoid
Strtr minifuse 15a
Underhood electrical center 2 (left front corner of engine compt)

Стеклоочистители и Стеклоомыватели Дворники

Электросхема стеклоочистителя, дворников и омывателя для Chevrolet Camaro Z28 1999

Электросхема стеклоочистителя, дворников и омывателя для Chevrolet Camaro Z28 1999 - Список элементов:

24

24k
End of sweep switch
G108 (top left of radiator support)
Hot in acc or run
I/p fuse block (left side of dash)
Low speed relay
Mist
Nca
Nca e
Nca h
Off
Park relay
Park switch
Pnk
Pulse
Red
S155
Washer switch
Wind- shield washer pump (fwrd of rad suppt)
Wind- shield wiper motor
Wiper isolation diode (in fwd lts hrn base of steeering column)
Wiper switch
Wiper/ wash fuse 14 25a
Wiper/ washer switch

ЦЕНТРАЛЬНЫЙ ЗАМОК

Электросхема центрального замка для Chevrolet Camaro Z28 1999

Электросхема центрального замка для Chevrolet Camaro Z28 1999 - Список элементов:

36

(cross-car harness, 39cm from power window control module breakout) s267
(cross-car harness,11cm from left power mirror control switch harness breakout) s504
All doors lock
Bat
Body control module (bcm) (under right side of dash, near blower motor)
Courtesy fuse 8 20a
D11
D12
Driver door lock
Driver door lock actuator
Driver door lock switch
Driver dr jamb sw
Driver dr unlock
Front passenger door lock
Front passenger door lock actuator
Front passenger door lock switch
G200 (left kick panel)
Ground
Hot at all times
I/p fuse block
Interior lts feed
Interior lights system
Interior lts return
Lock
Lock input
Pass dr jamb sw
Pass dr unlock
S217
S220
S268 (cross-car harn, 45cm from power window control module breakout)
Tan
Trunk rel rly ctrl
Trunk rel sig
Trunk/tailgate/ fuel doors system
Unlock
Unlock input
