AUDI A4 CABRIOLET 2003

Wiring Diagram AUDI A4 CABRIOLET 2003 - Servotronic control unit - Servotronic solenoid valve

D	Ignition/starter switch
J104	ABS with EDL control unit
J236	Servotronic control unit
J285	Control unit with display in dash panel insert
N119	Servotronic solenoid valve
T6b	6-pin connector, black, connector point, A pillar, left
T17b	17-pin connector, green, connector point, A pillar, left
T32a	32-pin connector, green, on dash panel insert
44	Earth point, A pillar, bottom left
81	Earth connection -1-, in dash panel wiring harness
501	Screw connection -2- (30), on relay plate
A2	Positive (+) connection (15), in dash panel wiring harness
A27	Connection (speed signal), in dash panel wiring harness
A32	Positive (+) connection (30), in dash panel wiring harness
*	As of July 2002 no longer fitted
**	Applicable from July 2002 onwards

AUDI A4 CABRIOLET 2003 Control units overview

Control units overview

Получить доступ ко всем электросхемам автомобиля

1 -	Heated windscreen control unit -J505-

q	Location → page 804/4

2 -	CD changer -R41-

q	Location → page 804/12

3 -	Fresh air blower control unit -J126-

q	Location → page 804/7

4 -	Headlight range control, control unit -J431-

q	Location → page 804/7

5 -

Radio -R-

q	not for navigation system

q	Location → page 804/10

5 -	Navigation operating electronics control unit -J402-

q	for navigation system RNS-D only

q	Location → page 804/10

5 -	Control unit with display for radio and navigation system -J503-

q	for navigation system RNS-Low only

q	Location → page 804/12

Audi Cabriolet	Fitting Locations	No. 804 / 2

Получить доступ ко всем электросхемам автомобиля

5 -	Navigation system with CD drive control unit -J401-

q	Location for navigation system NS-Low → page 804/11

q	Location for navigation system RNS-E → page 804/11

6 -	Front passenger side door control unit -J387-

q	Location → page 804/14

7 -	Steering column electronics control unit -J527-

q	Location → page 804/8

8 -	Control unit in dash panel insert -J285-

q	Location → page 804/8

9 -	Telephone and telematics control unit, telematics -J526-

q	Location → page 804/13

10 -	Airbag control unit -J234-

q	Location → page 804/9

11 -	Driver door control unit -J386-

q	Location → page 804/14

12 -	Convenience system central control unit -J393-

q	Location → page 804/13

Audi Cabriolet	Fitting Locations	No. 804 / 3

Получить доступ ко всем электросхемам автомобиля

13 -	Onboard power supply control unit -J519-

q	Location → page 804/9

14 -	Motronic control unit -J220-

14 -	Diesel direct injection system control unit -J248-

q	Location → page 804/4

15 -	Automatic gearbox control unit -J217-

q	not for models with multitronic®

q	Location → page 804/5

16 -	ABS control unit -J104-

q	Location → page 804/6

17 -	Automatic gearbox control unit -J217-

q	for models with multitronic® only

q	Location → page 804/5

18 -	Radiator fan control unit -J293-

q	Location → page 804/6

Audi Cabriolet	Fitting Locations	No. 804 / 4

Heated windscreen control unit -J505-

Location:

On right in plenum chamber, next to battery

AUDI A4 CABRIOLET 2003 Motronic control unit -J220-, diesel direct injection system control unit -J248-

Motronic control unit -J220-, diesel direct injection system control unit -J248-

Получить доступ ко всем электросхемам автомобиля

Location:

On electronics box in plenum chamber

Получить доступ ко всем электросхемам автомобиля

Audi Cabriolet	Fitting Locations	No. 804 / 5

AUDI A4 CABRIOLET 2003 Automatic gearbox control unit -J217-

Automatic gearbox control unit -J217-

not for models with multitronic®

Location:

AUDI A4 CABRIOLET 2003 Automatic gearbox control unit -J217-

Получить доступ ко всем электросхемам автомобиля

In electronics box in plenum chamber

for models with multitronic® only

Location:

In gearbox

Получить доступ ко всем электросхемам автомобиля

Audi Cabriolet	Fitting Locations	No. 804 / 6

AUDI A4 CABRIOLET 2003 ABS control unit -J104-

ABS control unit -J104-

Location:

In engine compartment, on front left hydraulic unit

AUDI A4 CABRIOLET 2003 Radiator fan control unit -J293-

Radiator fan control unit -J293-

Получить доступ ко всем электросхемам автомобиля

Location:

on radiator fan

Получить доступ ко всем электросхемам автомобиля

Audi Cabriolet	Fitting Locations	No. 804 / 7

AUDI A4 CABRIOLET 2003 Fresh air blower control unit -J126-

Fresh air blower control unit -J126-

Location:

Behind the glove box, in fresh air blower

AUDI A4 CABRIOLET 2003 Headlight range control, control unit -J431-

Headlight range control, control unit -J431-

Получить доступ ко всем электросхемам автомобиля

Location:

Behind the glove box

Получить доступ ко всем электросхемам автомобиля

Audi Cabriolet	Fitting Locations	No. 804 / 8

AUDI A4 CABRIOLET 2003 Steering column electronics control unit -J527-

Steering column electronics control unit -J527-

Location:

On steering column

AUDI A4 CABRIOLET 2003 Display control unit in dash panel insert -J285-

Display control unit in dash panel insert -J285-

Получить доступ ко всем электросхемам автомобиля

Location:

In the dash panel behind the display unit

Получить доступ ко всем электросхемам автомобиля

Audi Cabriolet	Fitting Locations	No. 804 / 9

AUDI A4 CABRIOLET 2003 Airbag control unit -J234-

Airbag control unit -J234-

Location:

On centre tunnel, under handbrake lever

AUDI A4 CABRIOLET 2003 Onboard power supply control unit -J519-

Onboard power supply control unit -J519-

Получить доступ ко всем электросхемам автомобиля

Location:

Behind driver's storage compartment

Получить доступ ко всем электросхемам автомобиля

Audi Cabriolet	Fitting Locations	No. 804 / 10

AUDI A4 CABRIOLET 2003 Navigation operating electronics control unit -J402-

Navigation operating electronics control unit -J402-

for navigation system RNS-D only

Location:

in centre console

AUDI A4 CABRIOLET 2003 Navigation operating electronics control unit -J402-

Получить доступ ко всем электросхемам автомобиля

AUDI A4 CABRIOLET 2003 Radio -R-

Radio -R-

not for navigation system

Location:

in centre console

Получить доступ ко всем электросхемам автомобиля

Audi Cabriolet	Fitting Locations	No. 804 / 11

AUDI A4 CABRIOLET 2003 Navigation system with CD drive control unit -J401-

Navigation system with CD drive control unit -J401-

For navigation system NS-Low only

Location:

AUDI A4 CABRIOLET 2003 Navigation system with CD drive control unit -J401-

Получить доступ ко всем электросхемам автомобиля

in centre console

For navigation system RNS-E only

Location:

in centre console

Получить доступ ко всем электросхемам автомобиля

Audi Cabriolet	Fitting Locations	No. 804 / 12

AUDI A4 CABRIOLET 2003 Control unit with display for radio and navigation system -J503-

Control unit with display for radio and navigation system -J503-

for navigation system RNS-Low only

Location:

in centre console

AUDI A4 CABRIOLET 2003 CD changer -R41-

CD changer -R41-

Получить доступ ко всем электросхемам автомобиля

Location:

In glove compartment

Получить доступ ко всем электросхемам автомобиля

Audi Cabriolet	Fitting Locations	No. 804 / 13

AUDI A4 CABRIOLET 2003 Convenience system central control unit -J393-

Convenience system central control unit -J393-

Location:

on sill, front left

AUDI A4 CABRIOLET 2003 Convenience system central control unit -J393-

Получить доступ ко всем электросхемам автомобиля

AUDI A4 CABRIOLET 2003 Telephone and telematics control unit, telematics -J526-

Telephone and telematics control unit, telematics -J526-

For models with telematics only

Location:

in electronics box under front passenger seat

AUDI A4 CABRIOLET 2003 Telephone and telematics control unit, telematics -J526-

Получить доступ ко всем электросхемам автомобиля

Audi Cabriolet	Fitting Locations	No. 804 / 14

AUDI A4 CABRIOLET 2003 Driver door control unit -J386-

Driver door control unit -J386-

Location:

In window regulator motor integrated

AUDI A4 CABRIOLET 2003 Front passenger side door control unit -J387-

Front passenger side door control unit -J387-

Получить доступ ко всем электросхемам автомобиля

Location:

In window regulator motor integrated

Получить доступ ко всем электросхемам автомобиля

AUDI A4 CABRIOLET 2003 Overview of relay

Overview of relay

Получить доступ ко всем электросхемам автомобиля

1 -	Relay carrier (3-pin)

q	Components: -J359-, -J360-

q	Location → page 803/3

2 -	Relay carrier (9-pin) with onboard supply control unit

q	Components: -J4-, -J9-, -J17-, -J53-, -J59-, -J236-, -J569-, -J695-

q	Location up to October 2005 → page 803/4

q	Location from November 2005 → page 803/5

q	Location component -J569- for engine code BNS → page 803/15

q	Location component -J17- for some engine variants ⇒ Item → 4 page → 803/2

3 -	Relay carrier (4-pin) with screw connection

q	Components: -J662-, -J663-, -J610-

q	Location → page 803/6

Audi Cabriolet	Fitting Locations	No. 803 / 2

Получить доступ ко всем электросхемам автомобиля

4 -	Relay carrier (4-pin)

q	Components: -J17-, -J52-, -J60-, -J151-, -J155-, -J179-, -J207-, -J226-, -J271-, -J299-, -J317-, -J434-, -J496-, -J569-, -J757-, -V274-

q	Location for petrol engines, up to October 2005 → page 803/7

q	Location for diesel engines, up to October 2005 → page 803/8

q	Location for engine codes BRC, BPW, BRF, BRE → page 803/9

q	Location for engine codes BKN, ASB, BSG, BPP → page 803/10

q	Location for engine codes BWE, BPG, BWT → page 803/11

q	Location for engine code ALT → Seite 803/12

q	Location for engine codes BFB, BBK, BHF → page 803/13

q	Location for engine codes AUK, BKH → Seite 803/14

q	Location for engine code BNS → Seite 803/15

Audi Cabriolet	Fitting Locations	No. 803 / 3

Position of relays, relay carrier (3-pin)

Location:

Driver side dash panel

Position of relays:

2 -	Low heat output relay -J359-

3 -	High heat output relay -J360-

Получить доступ ко всем электросхемам автомобиля

Audi Cabriolet	Fitting Locations	No. 803 / 4

AUDI A4 CABRIOLET 2003 Position of relays, relay carrier (9-pin) with onboard supply control unit, up to October 2005

Position of relays, relay carrier (9-pin) with onboard supply control unit, up to October 2005

Location:

Driver side dash panel, behind the relay carrier (3-pin)

Position of relays:

1 -	Fuel pump relay -J17-

2 -	Servotronic control unit -J236-

3 -	Dual tone horn relay -J4-

4 -	Brake servo relay -J569-

5 -	Heated rear window relay -J9-

6 -	X-contact relief relay -J59-

AUDI A4 CABRIOLET 2003 Position of relays, relay carrier (9-pin) with onboard supply control unit, up to October 2005

Получить доступ ко всем электросхемам автомобиля

Audi Cabriolet	Fitting Locations	No. 803 / 5

AUDI A4 CABRIOLET 2003 Position of relays, relay carrier (9-pin) with onboard supply control unit, from November 2005

Position of relays, relay carrier (9-pin) with onboard supply control unit, from November 2005

Location:

Driver side dash panel, behind the relay carrier (3-pin)

Position of relays:

1 -	Fuel pump relay -J17-

2 -	Servotronic control unit -J236-

3 -	Starter motor relay 2 ¹) -J695-

4 -	Starter motor relay ¹) -J53-

4 -	Brake servo relay ²) -J569-

5 -	Heated rear window relay -J9-

6 -	X-contact relief relay -J59-

8 -	Dual tone horn relay -J4-

¹) for engine codes AUK, BKH, BNS only

²) not for engine codes AUK, BKH

AUDI A4 CABRIOLET 2003 Position of relays, relay carrier (9-pin) with onboard supply control unit, from November 2005

Получить доступ ко всем электросхемам автомобиля

Audi Cabriolet	Fitting Locations	No. 803 / 6

AUDI A4 CABRIOLET 2003 Position of relays, relay carrier (4-pin) with screw connection

Position of relays, relay carrier (4-pin) with screw connection

Location:

Driver side dash panel

Position of relays:

3 -	Engine power reduction relay 1 (driving school vehicle) -J662-

4 -	Engine power reduction relay 2 (driving school vehicle) -J663-

4 -	Alarm on and hands-free system control unit (taxi) -J610-

AUDI A4 CABRIOLET 2003 Position of relays, relay carrier (4-pin) with screw connection

Получить доступ ко всем электросхемам автомобиля

Audi Cabriolet	Fitting Locations	No. 803 / 7

AUDI A4 CABRIOLET 2003 Position of relays, relay carrier (4-pin), petrol engines, up to October 2005

Position of relays, relay carrier (4-pin), petrol engines, up to October 2005

Location:

In electronics box in plenum chamber

Position of relays:

1 -	Automatic gearbox relay (multitronic) -J60-

1.1 -

Continued coolant circulation relay (V6) -J151-

2 -	Secondary air pump relay -J299-

3 -	Motronic current supply relay -J271-

3 -	Turbocharger coolant pump control unit -J155-

4 -	Starter inhibitor and reversing light relay -J226-

4 -	Starter inhibitor relay, clutch pedal switch -J434-

AUDI A4 CABRIOLET 2003 Position of relays, relay carrier (4-pin), petrol engines, up to October 2005

Получить доступ ко всем электросхемам автомобиля

Audi Cabriolet	Fitting Locations	No. 803 / 8

AUDI A4 CABRIOLET 2003 Position of relays, relay carrier (4-pin), diesel engines, up to October 2005

Position of relays, relay carrier (4-pin), diesel engines, up to October 2005

Location:

In electronics box in plenum chamber

Position of relays:

1 -	Automatic gearbox relay -J60-

1.2 -

Fuel pump relay -J17-

2 -	Glow plug relay -J52-

3 -	Terminal 30 voltage supply relay -J317-

4 -	Starter inhibitor and reversing light relay -J226-

4 -	Starter inhibitor relay, clutch pedal switch -J434-

E -	Fan for control unit -V274-

AUDI A4 CABRIOLET 2003 Position of relays, relay carrier (4-pin), diesel engines, up to October 2005

Получить доступ ко всем электросхемам автомобиля

Audi Cabriolet	Fitting Locations	No. 803 / 9

AUDI A4 CABRIOLET 2003 Position of relays ,relay carrier (4-pin), engine codes BRC, BPW, BRF, BRE, from November 2005

Position of relays ,relay carrier (4-pin), engine codes BRC, BPW, BRF, BRE, from November 2005

Location:

In electronics box in plenum chamber

Position of relays:

1.1 -

Fuel pump relay -J17-

1.2 -

Starter inhibitor relay -J207-

2 -	Terminal 30 voltage supply relay -J317-

3 -	Automatic glow period control unit -J179-

AUDI A4 CABRIOLET 2003 Position of relays ,relay carrier (4-pin), engine codes BRC, BPW, BRF, BRE, from November 2005

Получить доступ ко всем электросхемам автомобиля

Audi Cabriolet	Fitting Locations	No. 803 / 10

AUDI A4 CABRIOLET 2003 Position of relays ,relay carrier (4-pin), engine codes BKN, ASB, BSG, BPP, from November 2005

Position of relays ,relay carrier (4-pin), engine codes BKN, ASB, BSG, BPP, from November 2005

Location:

In electronics box in plenum chamber

Position of relays:

1.1 -

Fuel pump relay -J17-

1.2 -

Starter inhibitor relay -J207-

2 -	Terminal 30 voltage supply relay -J317-

3 -	Automatic glow period control unit -J179-

AUDI A4 CABRIOLET 2003 Position of relays ,relay carrier (4-pin), engine codes BKN, ASB, BSG, BPP, from November 2005

Получить доступ ко всем электросхемам автомобиля

Audi Cabriolet	Fitting Locations	No. 803 / 11

AUDI A4 CABRIOLET 2003 Position of relays, relay carrier (4-pin), engine codes BWE, BPG, BWT, from November 2005

Position of relays, relay carrier (4-pin), engine codes BWE, BPG, BWT, from November 2005

Location:

In electronics box in plenum chamber

Position of relays:

1.2 -

Starter inhibitor relay -J207-

2 -	Motronic current supply relay -J271-

3 -	Engine component current supply relay -J757-

AUDI A4 CABRIOLET 2003 Position of relays, relay carrier (4-pin), engine codes BWE, BPG, BWT, from November 2005

Получить доступ ко всем электросхемам автомобиля

Audi Cabriolet	Fitting Locations	No. 803 / 12

AUDI A4 CABRIOLET 2003 Position of relays, relay carrier (4-pin), engine code ALT, from November 2005

Position of relays, relay carrier (4-pin), engine code ALT, from November 2005

Location:

In electronics box in plenum chamber

Position of relays:

2 -	Motronic current supply relay -J271-

Получить доступ ко всем электросхемам автомобиля

Audi Cabriolet	Fitting Locations	No. 803 / 13

AUDI A4 CABRIOLET 2003 Position of relays, relay carrier (4-pin), engine codes BFB, BBK, BHF, from November 2005

Position of relays, relay carrier (4-pin), engine codes BFB, BBK, BHF, from November 2005

Location:

In electronics box in plenum chamber

Position of relays:

1.1 -

Continued coolant circulation relay -J151-

1.2 -

Starter inhibitor relay -J207-

1.2 -

Starter inhibitor relay, clutch pedal switch ¹) -J434-

2 -	Motronic current supply relay -J271-

3 -	Secondary air pump relay -J299-

¹) For engine codes BBK, BHF only

AUDI A4 CABRIOLET 2003 Position of relays, relay carrier (4-pin), engine codes BFB, BBK, BHF, from November 2005

Получить доступ ко всем электросхемам автомобиля

Audi Cabriolet	Fitting Locations	No. 803 / 14

AUDI A4 CABRIOLET 2003 Position of relays, relay carrier (4-pin), engine codes AUK, BKH, from November 2005

Position of relays, relay carrier (4-pin), engine codes AUK, BKH, from November 2005

Location:

In electronics box in plenum chamber

Position of relays:

1.1 -

Additional coolant pump relay -J496-

2 -	Motronic current supply relay -J271-

3 -	Engine component current supply relay -J757-

AUDI A4 CABRIOLET 2003 Position of relays, relay carrier (4-pin), engine codes AUK, BKH, from November 2005

Получить доступ ко всем электросхемам автомобиля

Audi Cabriolet	Fitting Locations	No. 803 / 15

AUDI A4 CABRIOLET 2003 Position of relays, relay carrier (4-pin), engine code BNS, from November 2005

Position of relays, relay carrier (4-pin), engine code BNS, from November 2005

Location:

In electronics box in plenum chamber

Position of relays:

1.1 -

Continued coolant circulation relay -J151-

1.2 -

Brake servo relay -J569-

2 -	Motronic current supply relay -J271-

3 -	Engine component current supply relay -J757-

4 -	Secondary air pump relay -J299-

AUDI A4 CABRIOLET 2003 Position of relays, relay carrier (4-pin), engine code BNS, from November 2005

Получить доступ ко всем электросхемам автомобиля

AUDI A4 CABRIOLET 2003 Overview of earth points

Overview of earth points

Получить доступ ко всем электросхемам автомобиля

1 -	Earth point, lower part of right A-pillar -43-

q	Location → page 801/9

2 -	Earth point, on right behind dash panel -33-

q	Location → page 801/8

3 -	Earth point (audio), under centre console, front -610-

q	Location → page 801/10

4 -	Earth point, on left behind dash panel insert -32-

q	Location → page 801/8

5 -	Earth point, airbag control unit -637-

q	on centre tunnel

6 -	Earth point, rear right side panel -663-

q	behind side trim on rear right

7 -	Earth point, on convertible roof box -661-

q	on right in luggage compartment

Audi Cabriolet	Fitting Locations	No. 801 / 2

Получить доступ ко всем электросхемам автомобиля

8 -	Earth point, on right in rear lid -53-

q	on right in rear lid, behind the trim

9 -	Earth point, centre on rear lid -612-

q	centre on rear lid, behind the trim

10 -	Earth point, on left in rear lid -52-

q	on left in rear lid, behind the trim

11 -	Earth point, on left in luggage compartment -50-

q	Location → page 801/11

12 -	Earth point, rear left side panel -662-

q	behind side trim on rear left

13 -	Earth point, near convenience system central control unit -49-

q	Location → page 801/10

14 -	Earth point, lower part of left A-pillar -44-

q	Location → page 801/9

Audi Cabriolet	Fitting Locations	No. 801 / 3

Получить доступ ко всем электросхемам автомобиля

15 -	Earth point, on left in engine compartment -12-

q	not for 2,0 l engine FSI, not for 2,5 l engine TDI, location → page 801/4

q	only for 2.0 l FSI motor, location → page 801/5

q	only for 2,5 l engine TDI, location → page 801/5

15 -	Earth point, near coil -19-

q	Location → page 801/6

15 -	Earth point, on front apron -26-

q	Location → page 801/6

16 -	Earth strap, engine - body -3-

q	between engine and right longitudinal member

17 -	Earth point, in battery box -11-

q	Location → page 801/4

17 -	Earth point, starter battery -624-

q	Location → page 801/7

Audi Cabriolet	Fitting Locations	No. 801 / 4

Earth point, in engine compartment

11	Earth point, in battery box -arrow-

Получить доступ ко всем электросхемам автомобиля

Torque: 20 Nm

12	Earth point, in engine compartment, left -arrow-

on bulkhead

Torque: 9 Nm

not for 2,0 l engine FSI

not for 2,5 l engine TDI

Получить доступ ко всем электросхемам автомобиля

Audi Cabriolet	Fitting Locations	No. 801 / 5

12	Earth point, in engine compartment, left -arrow-

on bulkhead

Torque: 9 Nm

Получить доступ ко всем электросхемам автомобиля

only for 2,0 l engine FSI

12	Earth point, in engine compartment, left -arrow-

on bulkhead

Torque: 9 Nm

only for 2,5 l engine TDI

Получить доступ ко всем электросхемам автомобиля

Audi Cabriolet	Fitting Locations	No. 801 / 6

19	Earth point, near coil -arrow-

Torque: 8 Nm

Получить доступ ко всем электросхемам автомобиля

only for 4.2 l engine

26	Earth point, on front apron -arrow-

Torque: 9 Nm

Получить доступ ко всем электросхемам автомобиля

Audi Cabriolet	Fitting Locations	No. 801 / 7

624	Earth point, starter battery -arrow-

Torque: 7.5 Nm

Получить доступ ко всем электросхемам автомобиля

Audi Cabriolet	Fitting Locations	No. 801 / 8

Earth points, in interior

32	Earth point behind dash panel on left -arrow-

Получить доступ ко всем электросхемам автомобиля

Torque: 9 Nm

33	Earth point behind dash panel on right -arrow-

Torque: 9 Nm

Получить доступ ко всем электросхемам автомобиля

Audi Cabriolet	Fitting Locations	No. 801 / 9

43	Earth point, lower part of right A-pillar -arrow-

Получить доступ ко всем электросхемам автомобиля

Torque: 9 Nm

44	Earth point, lower part of left A-pillar -arrow-

Torque: 9 Nm

Получить доступ ко всем электросхемам автомобиля

Audi Cabriolet	Fitting Locations	No. 801 / 10

49	Earth point, near convenience system central control unit -arrow-

Получить доступ ко всем электросхемам автомобиля

Torque: 9 Nm

610	Earth point (audio), under centre console, front -arrow-

Torque: 9 Nm

Получить доступ ко всем электросхемам автомобиля

Audi Cabriolet	Fitting Locations	No. 801 / 11

Earth point, in luggage compartment

50	Earth point, on left in luggage compartment -arrow-

Torque: 9 Nm

Получить доступ ко всем электросхемам автомобиля

AUDI A4 CABRIOLET 2003 — Servotronic . Wiring diagrams, Pin Connector, Location

Wiring Diagram AUDI A4 CABRIOLET 2003 - Servotronic control unit - Servotronic solenoid valve

AUDI A4 CABRIOLET 2003 Control units overview

AUDI A4 CABRIOLET 2003 Motronic control unit -J220-, diesel direct injection system control unit -J248-

AUDI A4 CABRIOLET 2003 Automatic gearbox control unit -J217-

AUDI A4 CABRIOLET 2003 ABS control unit -J104-

AUDI A4 CABRIOLET 2003 Radiator fan control unit -J293-

AUDI A4 CABRIOLET 2003 Fresh air blower control unit -J126-

AUDI A4 CABRIOLET 2003 Headlight range control, control unit -J431-

AUDI A4 CABRIOLET 2003 Steering column electronics control unit -J527-

AUDI A4 CABRIOLET 2003 Display control unit in dash panel insert -J285-

AUDI A4 CABRIOLET 2003 Airbag control unit -J234-

AUDI A4 CABRIOLET 2003 Onboard power supply control unit -J519-

AUDI A4 CABRIOLET 2003 Navigation operating electronics control unit -J402-

AUDI A4 CABRIOLET 2003 Radio -R-

AUDI A4 CABRIOLET 2003 Navigation system with CD drive control unit -J401-

AUDI A4 CABRIOLET 2003 Control unit with display for radio and navigation system -J503-

AUDI A4 CABRIOLET 2003 CD changer -R41-

AUDI A4 CABRIOLET 2003 Convenience system central control unit -J393-

AUDI A4 CABRIOLET 2003 Telephone and telematics control unit, telematics -J526-

AUDI A4 CABRIOLET 2003 Driver door control unit -J386-

AUDI A4 CABRIOLET 2003 Front passenger side door control unit -J387-

AUDI A4 CABRIOLET 2003 Overview of relay

AUDI A4 CABRIOLET 2003 Position of relays, relay carrier (9-pin) with onboard supply control unit, up to October 2005

AUDI A4 CABRIOLET 2003 Position of relays, relay carrier (9-pin) with onboard supply control unit, from November 2005

AUDI A4 CABRIOLET 2003 Position of relays, relay carrier (4-pin) with screw connection

AUDI A4 CABRIOLET 2003 Position of relays, relay carrier (4-pin), petrol engines, up to October 2005

AUDI A4 CABRIOLET 2003 Position of relays, relay carrier (4-pin), diesel engines, up to October 2005

AUDI A4 CABRIOLET 2003 Position of relays ,relay carrier (4-pin), engine codes BRC, BPW, BRF, BRE, from November 2005

AUDI A4 CABRIOLET 2003 Position of relays ,relay carrier (4-pin), engine codes BKN, ASB, BSG, BPP, from November 2005

AUDI A4 CABRIOLET 2003 Position of relays, relay carrier (4-pin), engine codes BWE, BPG, BWT, from November 2005

AUDI A4 CABRIOLET 2003 Position of relays, relay carrier (4-pin), engine code ALT, from November 2005

AUDI A4 CABRIOLET 2003 Position of relays, relay carrier (4-pin), engine codes BFB, BBK, BHF, from November 2005

AUDI A4 CABRIOLET 2003 Position of relays, relay carrier (4-pin), engine codes AUK, BKH, from November 2005

AUDI A4 CABRIOLET 2003 Position of relays, relay carrier (4-pin), engine code BNS, from November 2005

AUDI A4 CABRIOLET 2003

AUDI A4 CABRIOLET 2003 Overview of earth points

Войти

Регистрация

Получить новый пароль
