Wiring Diagram VW POLO 2011 - Battery - Starter - Ignition/starter switch - Fuse holder B
A | Battery |
B | Starter |
D | Ignition/starter switch |
SA | Fuse holder A |
SA1 | Fuse 1 in fuse holder A |
SA3 | Fuse 3 in fuse holder A |
SB | Fuse holder B |
SB2 | Fuse 2 on fuse holder B |
SB6 | Fuse 6 on fuse holder B |
SB7 | Fuse 7 on fuse holder B |
SB11 | Fuse 11 on fuse holder B |
SB18 | Fuse 18 on fuse holder B |
SB19 | Fuse 19 on fuse holder B |
SB25 | Fuse 25 on fuse holder B |
SB27 | Fuse 27 on fuse holder B |
SB34 | Fuse 34 on fuse holder B |
SB38 | Fuse 38 on fuse holder B |
T1m | Single connector |
T6ba | 6-pin connector |
A15 | Positive connection (15), in instrument wiring harness |
A40 | Positive connection 1 (30), in dash panel wiring harness |
B141 | Positive connection 1 (56a), in interior wiring harness |
B170 | Positive connection 2 (30), in interior wiring harness |
Wiring Diagram VW POLO 2011 - X-contact relief relay - Dipped beam relay - Fuse holder B
J59 | X-contact relief relay |
J331 | Dipped beam relay |
SB | Fuse holder B |
SB20 | Fuse 20 on fuse holder B |
SB21 | Fuse 21 on fuse holder B |
SB22 | Fuse 22 on fuse holder B |
SB39 | Fuse 39 on fuse holder B |
SB42 | Fuse 42 on fuse holder B |
SB43 | Fuse 43 on fuse holder B |
SB46 | Fuse 46 on fuse holder B |
SB47 | Fuse 47 on fuse holder B |
SB48 | Fuse 48 on fuse holder B |
SB53 | Fuse 53 on fuse holder B |
SB57 | Fuse 57 on fuse holder B |
SB58 | Fuse 58 on fuse holder B |
SB59 | Fuse 59 on fuse holder B |
T6z | 6-pin connector |
A9 | Positive connection (56b), in instruments wiring harness |
A33 | Connection (75), in dash panel wiring harness |
A34 | Connection (75x), in dash panel wiring harness |
A52 | Positive connection 2 (30), in dash panel wiring harness |
* | Gradually discontinued |
*2 | gradual introduction |
*3 | From August 2011 |
Wiring Diagram VW POLO 2011 - Light switch - Front and rear fog light switch - Onboard supply control unit - Light switch illumination bulb
E1 | Light switch |
E23 | Front and rear fog light switch |
J519 | Onboard supply control unit |
L9 | Light switch illumination bulb |
T17 | 17-pin connector |
T73a | 73-pin connector |
T73b | 73-pin connector |
80 | Earth connection 1, in dash panel wiring harness |
B169 | Positive connection 1 (30), in interior wiring harness |
B239 | Positive connection 1 (50), in interior wiring harness |
B583 | Positive connection (58), in interior wiring harness |
* | According to equipment |
*2 | From August 2011 |
Wiring Diagram VW POLO 2011 - Switch and instrument illumination regulator - Onboard supply control unit
E20 | Switch and instrument illumination regulator |
E102 | Headlight range control regulator |
J519 | Onboard supply control unit |
T6aa | 6-pin connector |
T73a | 73-pin connector |
T73b | 73-pin connector |
A3 | Positive connection (58), in dash panel wiring harness |
A19 | Connection (58d), in dash panel wiring harness |
A116 | Connection 2 (58d), in dash panel wiring harness |
A219 | Connection (S contact), in main wiring harness |
B149 | Positive connection 2 (15a), in interior wiring harness |
* | According to equipment |
*2 | Wire colour is white and wire is printed |
*3 | gradual introduction |
*4 | From August 2011 |
Wiring Diagram VW POLO 2011 - Steering column combination switch - Rear lid lock unit - Onboard supply control unit - Windscreen and rear window washer pump - Heated rear window
E22 | Intermittent wiper switch |
E34 | Rear wiper switch |
E38 | Intermittent wiper regulator |
E595 | Steering column combination switch |
F256 | Rear lid lock unit |
J519 | Onboard supply control unit |
T2er | 2-pin connector |
T4ag | 4-pin connector |
T41 | 41-pin connector |
T73a | 73-pin connector |
T73b | 73-pin connector |
V59 | Windscreen and rear window washer pump |
Z1 | Heated rear window |
98 | Earth connection, in rear lid wiring harness |
354 | Earth connection 6, in dash panel wiring harness |
A156 | Connection (53c), in dash panel wiring harness |
* | From August 2011 |
Wiring Diagram VW POLO 2011 - Turn signal switch - Parking light switch - Steering column combination switch - Airbag coil connector and return ring with slip ring - Horn plate - Side light relay - Onboard supply control unit - Windscreen wiper motor
E2 | Turn signal switch |
E4 | Headlight dipper and flasher switch |
E19 | Parking light switch |
E595 | Steering column combination switch |
F138 | Airbag coil connector and return ring with slip ring |
H | Horn plate |
J3 | Side light relay |
J519 | Onboard supply control unit |
T4i | 4-pin connector |
T10y | 10-pin connector |
T12g | 12-pin connector |
T41 | 41-pin connector |
T73a | 73-pin connector |
T73b | 73-pin connector |
V | Windscreen wiper motor |
135 | Earth connection 2, in dash panel wiring harness |
335 | Earth connection 5, in dash panel wiring harness |
B143 | Positive connection (58R), in interior wiring harness |
B144 | Positive connection (58L), in interior wiring harness |
Wiring Diagram VW POLO 2011 - Hazard warning lights button - Heated rear window button - Reversing light switch - Bonnet contact switch - Onboard supply control unit
E229 | Hazard warning lights button |
E230 | Heated rear window button |
F4 | Reversing light switch |
F266 | Bonnet contact switch |
J519 | Onboard supply control unit |
K10 | Heated rear window warning lamp |
L76 | Button illumination bulb |
T2a | 2-pin connector |
T2eq | 2-pin connector, on lock carrier, right, near headlight |
T6al | 6-pin connector |
T6am | 6-pin connector |
T73a | 73-pin connector |
T73b | 73-pin connector |
110 | Earth connection 2, in dash panel wiring harness |
415 | Earth connection, in selector lever wiring harness |
439 | Earth connection 3, in dash panel wiring harness |
B182 | Connection (RL), in interior wiring harness |
* | According to equipment |
*2 | From August 2011 |
Wiring Diagram VW POLO 2011 - Onboard supply control unit - Front left headlight - Left turn signal repeater bulb - Left headlight range control motor
J519 | Onboard supply control unit |
M1 | Left side light bulb |
MX1 | Front left headlight |
M5 | Front left turn signal bulb |
M18 | Left turn signal repeater bulb |
M29 | Left headlight dipped beam bulb |
M30 | Left headlight main beam bulb |
T2fy | 2-pin connector |
T2ga | 2-pin connector |
T2gc | 2-pin connector |
T3ar | 3-pin connector |
T3as | 3-pin connector |
T73b | 73-pin connector |
V48 | Left headlight range control motor |
179 | Earth connection, in left headlight wiring harness |
201 | Earth connection 5, in engine compartment wiring harness |
A6 | Positive connection (left turn signal), in dash panel wiring harness |
A84 | Connection (58L), in dash panel wiring harness |
B142 | Positive connection 2 (56a), in interior wiring harness |
D96 | Connection (headlight range control), in engine compartment wiring harness |
Wiring Diagram VW POLO 2011 - Onboard supply control unit - Front right headlight - Right turn signal repeater bulb - Right headlight range control motor
J519 | Onboard supply control unit |
MX2 | Front right headlight |
M3 | Right side light bulb |
M7 | Front right turn signal bulb |
M19 | Right turn signal repeater bulb |
M31 | Right headlight dipped beam bulb |
M32 | Right headlight main beam bulb |
T2fz | 2-pin connector |
T2gb | 2-pin connector |
T2gd | 2-pin connector |
T3aq | 3-pin connector |
T3at | 3-pin connector |
T73b | 73-pin connector |
V49 | Right headlight range control motor |
176 | Earth connection, in right headlight wiring harness |
A5 | Positive connection (right turn signal), in dash panel wiring harness |
A85 | Connection (58R), in dash panel wiring harness |
* | From August 2011 |
Wiring Diagram VW POLO 2011 - Onboard supply control unit - Left tail light - Right tail light - High-level brake light bulb - Left number plate light - Right number plate light
J519 | Onboard supply control unit |
L47 | Rear right fog light bulb |
M2 | Right tail light bulb |
MX3 | Left tail light |
MX4 | Right tail light |
M4 | Left tail light bulb |
M6 | Rear left turn signal bulb |
M8 | Rear right turn signal bulb |
M9 | Left brake light bulb |
M10 | Right brake light bulb |
M16 | Left reversing light bulb |
M25 | High-level brake light bulb |
T2dx | 2-pin connector |
T2dy | 2-pin connector |
T2fa | 2-pin connector |
T5b | 5-pin connector |
T5c | 5-pin connector |
T73b | 73-pin connector |
X4 | Left number plate light |
X5 | Right number plate light |
86 | Earth connection 1, in rear wiring harness |
A18 | Connection (54), in dash panel wiring harness |
A88 | Connection (RFL), in dash panel wiring harness |
* | According to equipment |
*2 | Only models with rear fog light |
*3 | Wire colour is white and wire is printed |
*4 | gradual introduction |
Wiring Diagram VW POLO 2011 - Rear lid remote release button - Driver side interior locking button for central locking system - Driver side central locking lock unit - Onboard supply control unit - Central locking SAFELOCK function warning lamp - Tank filler flap locking motor
E233 | Rear lid remote release button |
E308 | Driver side interior locking button for central locking system |
F2 | Driver door contact switch |
F220 | Driver side central locking lock unit |
J519 | Onboard supply control unit |
K133 | Central locking SAFELOCK function warning lamp |
L99 | Interior lock switch illumination bulb |
T2dz | 2-pin connector |
T2ea | 2-pin connector |
T4aa | 4-pin connector |
T4bb | 4-pin connector |
T8f | 8-pin connector |
T28a | 28-pin connector |
T73a | 73-pin connector |
V56 | Driver door central locking motor |
V155 | Tank filler flap locking motor |
205 | Earth connection, in driver door wiring harness |
B216 | Connection 3 (central locking), in interior wiring harness |
R81 | Connection 1 (58d), in driver side door wiring harness |
Wiring Diagram VW POLO 2011 - Operating unit for window regulator in driver door - Driver door control unit - Onboard supply control unit - Driver side window regulator motor
E39 | Rear window regulator isolation switch |
E40 | Front left window regulator switch, in driver door |
E41 | Front right window regulator switch, in driver door |
E53 | Rear left window regulator switch, in driver door |
E55 | Rear right window regulator switch, in driver door |
E512 | Operating unit for window regulator in driver door |
J386 | Driver door control unit |
J519 | Onboard supply control unit |
L53 | Window regulator switch illumination bulb |
SB50 | Fuse 50 on fuse holder B |
T10j | 10-pin connector |
T16g | 16-pin connector |
T28a | 28-pin connector |
T73b | 73-pin connector |
V147 | Driver side window regulator motor |
267 | Earth connection 2, in drive side door wiring harness |
303 | Earth connection 3, in drive side door wiring harness |
B528 | Connection 1 (LIN bus) in main wiring harness |
Wiring Diagram VW POLO 2011 - Window regulator switch in front passenger door - Front passenger side central locking lock unit - Front passenger door control unit - Onboard supply control unit - Front passenger side window regulator motor
E107 | Window regulator switch in front passenger door |
F3 | Front passenger door contact switch |
F221 | Front passenger side central locking lock unit |
J387 | Front passenger door control unit |
J519 | Onboard supply control unit |
L53 | Window regulator switch illumination bulb |
SB51 | Fuse 51 on fuse holder B |
T4ae | 4-pin connector |
T8i | 8-pin connector |
T16l | 16-pin connector |
T28 | 28-pin connector |
T73a | 73-pin connector |
V57 | Front passenger seat central locking motor |
V148 | Front passenger side window regulator motor |
206 | Earth connection, in front passenger door wiring harness |
268 | Earth connection 2, in front passenger side door wiring harness |
B175 | Connection (central locking), in interior wiring harness |
Wiring Diagram VW POLO 2011 - Rear left window regulator switch - in door - Rear left central locking lock unit - Rear left door control unit - Onboard supply control unit - Rear left window regulator motor
E52 | Rear left window regulator switch, in door |
F222 | Rear left central locking lock unit |
J388 | Rear left door control unit |
J519 | Onboard supply control unit |
L53 | Window regulator switch illumination bulb |
SB52 | Fuse 52 on fuse holder B |
T4ae | 4-pin connector |
T8g | 8-pin connector |
T16j | 16-pin connector |
T28b | 28-pin connector |
T73a | 73-pin connector |
V26 | Rear left window regulator motor |
207 | Earth connection, in rear left door wiring harness |
B110 | Connection (30, window regulators), in interior wiring harness |
B215 | Connection 2 (central locking), in interior wiring harness |
Wiring Diagram VW POLO 2011 - Rear right window regulator switch - in door - Rear right central locking lock unit - Rear right door control unit - Onboard supply control unit - Rear right window regulator motor
E54 | Rear right window regulator switch, in door |
F223 | Rear right central locking lock unit |
J389 | Rear right door control unit |
J519 | Onboard supply control unit |
L53 | Window regulator switch illumination bulb |
T4ad | 4-pin connector |
T8h | 8-pin connector |
T16k | 16-pin connector |
T28c | 28-pin connector |
T73a | 73-pin connector |
V27 | Rear right window regulator motor |
208 | Earth connection, in rear right door wiring harness |
Wiring Diagram VW POLO 2011 - Interior monitoring deactivation switch - Onboard supply control unit - Front passenger reading light - Rear centre reading light
E267 | Interior monitoring deactivation switch |
J519 | Onboard supply control unit |
T2ee | 2-pin connector |
T3am | 3-pin connector |
T3an | 3-pin connector |
T4ak | 4-pin connector |
T73a | 73-pin connector |
W13 | Front passenger reading light |
W15 | Interior light with switch-off delay |
W19 | Driver side reading light |
W35 | Right luggage compartment light |
W44 | Rear centre reading light |
A23 | Connection (30al), in dash panel wiring harness |
A29 | Connection (interior light), in dash panel wiring harness |
B128 | Connection (luggage compartment light), in interior wiring harness |
Wiring Diagram VW POLO 2011 - Onboard supply control unit - Cigarette lighter illumination bulb - Cigarette lighter
J519 | Onboard supply control unit |
L28 | Cigarette lighter illumination bulb |
T3ad | 3-pin connector |
T73a | 73-pin connector |
U1 | Cigarette lighter |
81 | Earth connection 1, in dash panel wiring harness |
199 | Earth connection 3, in dash panel wiring harness |
* | According to equipment |
Wiring Diagram VW POLO 2011 - Treble horn - Bass horn - Onboard supply control unit - Engine control unit
F | Brake light switch |
F47 | Brake pedal switch |
H2 | Treble horn |
H7 | Bass horn |
J104 | ABS control unit |
J519 | Onboard supply control unit |
J623 | Engine control unit |
SB33 | Fuse 33 on fuse holder B |
T2fc | 2-pin connector |
T2fd | 2-pin connector |
T4e | 4-pin connector |
T38 | 38-pin connector |
T73a | 73-pin connector |
T80 | 80-pin connector |
T94 | 94-pin connector |
124 | Earth connection, in right side engine compartment wiring harness |
C13 | Positive connection in dual tone horn wiring harness |
D73 | Positive connection (54), in engine compartment wiring harness |
D183 | Connection 4 (87a) in engine compartment wiring harness |
* | see applicable current flow diagram for engine |
Wiring Diagram VW POLO 2011 - Onboard supply control unit - Diagnostic connection
J217 | Automatic gearbox control unit |
J234 | Airbag control unit |
J301 | Air conditioning system control unit |
J519 | Onboard supply control unit |
T16b | 16-pin connector |
T16h | 16-pin connector |
T50 | 50-pin connector |
T52 | 52-pin connector |
T73b | 73-pin connector |
U31 | Diagnostic connection |
A20 | Positive connection (15a), in dash panel wiring harness |
A76 | Connection (K-diagnosis wire), in dash panel wiring harness |
B150 | Positive connection 2 (30a), in interior wiring harness |
* | According to equipment |
*2 | gradual introduction |
*3 | Gradually discontinued |
Wiring Diagram VW POLO 2011 - Immobiliser reader coil - Control unit in dash panel insert - Power steering control unit - Dash panel insert
D2 | Immobiliser reader coil |
J285 | Control unit in dash panel insert |
J500 | Power steering control unit |
K | Dash panel insert |
K1 | Main beam warning lamp |
K2 | Alternator warning lamp |
K13 | Rear fog light warning lamp |
K19 | Seat belt warning system warning lamp |
K43 | Coolant temperature warning lamp (too cold) |
K105 | Reserve fuel warning lamp |
K149 | Engine electronics warning lamp |
K166 | Door open warning lamp |
K261 | Warning lamp for left turn signal |
K262 | Warning lamp for right turn signal |
T2fl | 2-pin connector |
T3s | 3-pin connector |
T32 | 32-pin connector |
B383 | Connection 1 (powertrain CAN bus, high), in main wiring harness |
B390 | Connection 1 (powertrain CAN bus, low), in main wiring harness |
Wiring Diagram VW POLO 2011 - Brake fluid level warning contact - Parking brake contact switch - Ambient temperature sensor - Control unit in dash panel insert - Dash panel insert
F34 | Brake fluid level warning contact |
F321 | Parking brake contact switch |
G17 | Ambient temperature sensor |
J285 | Control unit in dash panel insert |
K | Dash panel insert |
K118 | Brake system warning lamp |
T2cx | 2-pin connector |
T2de | 2-pin connector |
T2fm | 2-pin connector |
T32 | 32-pin connector |
131 | Earth connection 2, in engine compartment wiring harness |
132 | Earth connection 3, in engine compartment wiring harness |
269 | Earth connection (sender earth) 1, in dash panel wiring harness |
* | From August 2011 |
VW POLO 2011 Overview of fuse and relay holders
Overview of fuse and relay holders, left-hand and right-hand drive models |
Note:
Illustration shows left-hand drive model. Point 1 and 2 can be found on the right-hand side in right-hand drive vehicles |
1 - | Fuse holder B -SB- |
q | Fitting location: under the steering wheel |
q | Fuse assignment, from August 2010 |
q | Fuse assignment, from August 2011 |
q | Fuse assignment, from August 2015 |
2 - | Relay and fuse carrier 1 -SR1- |
t | Side light relay -J3- |
t | Fuel pump relay -J17- |
t | Air conditioning system relay -J32- |
t | X-contact relief relay -J59- |
t | Heated exterior mirror relay -J99- |
t | Starter inhibitor relay -J207- |
t | Main relay -J271- |
t | Terminal 30 voltage supply relay -J317- |
t | Dipped beam relay -J331- |
t | Fuel supply relay -J643- |
q | Relay and fuse assignment, from August 2010 |
q | Relay and fuse assignment, from November 2010 |
q | Relay and fuse assignment, from August 2011 |
q | Relay and fuse assignment, from May 2012 |
q | Relay and fuse assignment, left-hand drive models, from August 2012 |
q | Relay and fuse assignment, right-hand drive models, from August 2012 |
q | Relay and fuse assignment, left-hand drive models, from August 2015 |
q | Relay and fuse assignment, right-hand drive models, from August 2015 |
3 - | Fuse holder A -SA- |
q | Fitting location |
q | Fuse assignment |
q | Fuse assignment, from August 2015 |
Fuse holder C -SC- |
q | Fitting location |
q | Fuse assignment |
q | Fuse assignment, from August 2015 |
Fuse holder on the battery |
t | Automatic glow period control unit -J179- |
t | Additional coolant pump relay -J496- |
Fitting location |
Fuse holder on the battery |
3 - | Automatic glow period control unit -J179- |
q | Only models with diesel engine |
3 - | Additional coolant pump relay -J496- |
q | According to equipment |
|
|
|
No. | Current Flow Diagram designation | Nominal value | Function/component | Terminal | ||
-SA1- | - | Fuse 1 on fuse holder A | 150A | - | Alternator -C- | 30 |
-SA2- | - | Fuse 2 on fuse holder A | - | Not assigned | ||
-SA3- | - | Fuse 3 on fuse holder A | 110A | - | Ignition/starter switch -D- Light switch -E1- Steering column combination switch -E595- X-contact relief relay -J59- Fuel pump relay -J17- Fuel supply relay -J643- Dipped beam relay -J331- Fuse 20 on fuse holder B -SB20- Side light relay -J3- Terminal 30 voltage supply relay -J317- Fuse 3 on fuse holder B -SB3- | 30 |
-SA4- | - | Fuse 4 on fuse holder A | 50A | - | Power steering control unit -J500- | 30 |
-SA5- | - | Fuse 5 on fuse holder A | 40A | - | ABS control unit -J104- | 30 |
-SA6- | - | Fuse 6 on fuse holder A | 40A | - | Radiator fan control unit -J293-1) Radiator fan -V7-1) | 30 |
-SA7- | - | Fuse 7 on fuse holder A | 50A | - | Automatic glow period control unit -J179- | 30 |
-SC1- | - | Fuse 1 on fuse holder C | 25A | - | ABS control unit -J104- | 30 |
-SC2- | - | Fuse 2 on fuse holder C | 30A | - | Radiator fan control unit -J293-2) Radiator fan -V7-2) | 30 |
-SC3- | - | Fuse 3 on fuse holder C | - | - | Not assigned | |
-SC4- | - | Fuse 4 on fuse holder C | 10A | - | ABS control unit -J104- | 30 |
-SC5- | - | Fuse 5 on fuse holder C | 5A | - | Onboard supply control unit -J519- (T73b/59) | 30 |
-SC6- | - | Fuse 6 on fuse holder C | - | - | Not assigned | - |
|
|
No. | Current Flow Diagram designation | Nominal value | Function/component | Terminal | ||
-SA1- | - | Fuse 1 on fuse holder A | - | Not assigned | 30 | |
-SA2- | - | Fuse 2 on fuse holder A | - | Not assigned | ||
-SA3- | - | Fuse 3 on fuse holder A | 110 A | - | Ignition/starter switch -D- Light switch -E1- Steering column combination switch -E595- X-contact relief relay -J59- Fuel pump relay -J17- Fuel supply relay -J643- Dipped beam relay -J331- Fuse 20 on fuse holder B -SB20- Side light relay -J3- Terminal 30 voltage supply relay -J317- Fuse 3 on fuse holder B -SB3- | 30 |
-SA4- | - | Fuse 4 on fuse holder A | 50 A | - | Power steering control unit -J500- | 30 |
-SA5- | - | Fuse 5 on fuse holder A | 40 A | - | ABS control unit -J104- | 30 |
-SA6- | - | Fuse 6 on fuse holder A | 40 A | - | Radiator fan control unit -J293-Radiator fan -V7- | 30 |
-SA7- | - | Fuse 7 on fuse holder A | 50 A | - | Automatic glow period control unit -J179- | 30 |
-SC1- | - | Fuse 1 on fuse holder C | 25 A | - | ABS control unit -J104- | 30 |
-SC2- | - | Fuse 2 on fuse holder C | 30 A | - | Radiator fan control unit -J293- Radiator fan thermal switch -F18- | 30 |
-SC3- | - | Fuse 3 on fuse holder C | - | Not assigned | ||
-SC4- | - | Fuse 4 on fuse holder C | - | Not assigned | 30 | |
-SC5- | - | Fuse 5 on fuse holder C | 10 A | - | Onboard supply control unit -J519- | 30 |
-SC6- | - | Fuse 6 on fuse holder C | 25 A | - | Automatic gearbox control unit -J217- | - |
|
No. | Current Flow Diagram designation | Nominal value | Function/component | Terminal | ||||||||||||||||
1 | - | Fuse 1 on fuse holder B -SB1- | - | Not assigned | ||||||||||||||||
2 | - | Fuse 2 on fuse holder B -SB2- | 10A | - | Steering column combination switch -E595- Rear window wiper motor -V12- Windscreen and rear window washer pump -V59- | 15 | ||||||||||||||
3 | - | Fuse 3 on fuse holder B -SB3- | 5A | - | Fuel pump relay -J17- Engine control unit -J623- | 15 | ||||||||||||||
4 | - | Fuse 4 on fuse holder B -SB4- | 2A | - | Steering column combination switch -E595-1) Multifunction steering wheel control unit -J453-1) | 15 | ||||||||||||||
5 | - | Fuse 5 on fuse holder B -SB5- | - | Not assigned | ||||||||||||||||
6 | - | Fuse 6 on fuse holder B -SB6- | 5A | - | Control unit in dash panel insert -J285- | 15 | ||||||||||||||
7 | - | Fuse 7 on fuse holder B -SB7- | 5A | - | Headlight range control regulator -E102- Left number plate light -X4- Right number plate light -X5- Switch and instrument illumination regulator -E20-1) | 58 | ||||||||||||||
8 | - | Fuse 8 on fuse holder B -SB8- | 10A | - | Injector, cylinder 1 -N30- Injector, cylinder 2 -N31- Injector, cylinder 3 -N32- Injector, cylinder 4 -N33- | 87 | ||||||||||||||
9 | - | Fuse 9 on fuse holder B -SB9- | 5A 7.5A 1) | - | ABS control unit -J104- TCS and ESP button -E256-1) Steering column combination switch -E595-1) | 15 | ||||||||||||||
10 | - | Fuse 10 on fuse holder B -SB10- | 5A | - | Vehicle speed sender -G68- Onboard supply control unit -J519- (T73a/44)
| 15 | ||||||||||||||
11 | - | Fuse 11 on fuse holder B -SB11- | 5A | - | Headlight range control regulator -E102- Left headlight range control motor -V48- Right headlight range control motor -V49- Steering column combination switch -E595-1) | 15 | ||||||||||||||
12 | - | Fuse 12 on fuse holder B -SB12- | 5A | - | Mirror adjustment switch -E43- | 15 | ||||||||||||||
13 | - | Fuse 13 on fuse holder B -SB13- | 15A | - | Automatic gearbox control unit -J217- Multifunction switch -F125- Selector lever -E313- | 15 | ||||||||||||||
14 | - | Fuse 14 on fuse holder B -SB14- | 5A | - | Airbag control unit -J234- Front passenger airbag deactivated warning lamp -K145-1) | 15 | ||||||||||||||
15 | - | Fuse 15 on fuse holder B -SB15- | - | Not assigned | ||||||||||||||||
16 | - | Fuse 16 on fuse holder B -SB16- | - | Not assigned | ||||||||||||||||
17 | - | Fuse 17 on fuse holder B -SB17- | 10A | - | Lambda probe heater -Z19- Lambda probe 1 heater after catalytic converter -Z29- Activated charcoal filter solenoid valve 1 -N80- | 87 | ||||||||||||||
18 | - | Fuse 18 on fuse holder B -SB18- | 5A | - | Control unit in dash panel insert -J285- Rear right fog light bulb -L47- | 55a | ||||||||||||||
19 | - | Fuse 19 on fuse holder B -SB19- | 5A | - | Side light relay -J3- Radio -R- Onboard supply control unit -J519- (T73a/42)
| 75 | ||||||||||||||
20 | - | Fuse 20 on fuse holder B -SB20- | 5A | - | Control unit in dash panel insert -J285- Steering column combination switch -E595-1) | 30 | ||||||||||||||
21 | - | Fuse 21 on fuse holder B -SB21- | 10A | - | Onboard supply control unit -J519- (T73a/66)
| 30 | ||||||||||||||
22 | - | Fuse 22 on fuse holder B -SB22- | 5A | - | Diagnostic connection -U31- Air conditioning system control unit -J301- Climatronic control unit -J255- Ignition key withdrawal lock solenoid -N376- | 30 | ||||||||||||||
23 | - | Fuse 23 on fuse holder B -SB23- | 7.5A | - | Onboard supply control unit -J519- (T73b/39) Engine control unit -J623- Automatic gearbox control unit -J217- Selector lever -E313- | 30 | ||||||||||||||
24 | - | Fuse 24 on fuse holder B -SB24- | - | Not assigned | ||||||||||||||||
25 | - | Fuse 25 on fuse holder B -SB25- | 5A | - | High-pressure sender -G65- Air conditioning system relay -J32- Air conditioning system control unit -J301- Diagnostic connection -U31- | 15 | ||||||||||||||
26 | - | Fuse 26 on fuse holder B -SB26- | 5A 7.5A 3) | - | Power steering control unit -J500- Air mass meter -G70- | 15 | ||||||||||||||
27 | - | Fuse 27 on fuse holder B -SB27- | 5A | - | Reversing light switch -F4- | 15 | ||||||||||||||
28 | - | Fuse 28 on fuse holder B -SB28- | - | Not assigned | ||||||||||||||||
29 | - | Fuse 29 on fuse holder B -SB29- | 10A | - | Fuel pressure regulating valve -N276- Fuel metering valve -N290- | 87 | ||||||||||||||
30 | - | Fuse 30 on fuse holder B -SB30- | 10A | - | Coolant circulation pump 2 -V178- Exhaust gas recirculation cooler changeover valve -N345- Charge pressure control solenoid valve -N75- | 87 | ||||||||||||||
31 | - | Fuse 31 on fuse holder B -SB31- | 10A | - | Fuel supply relay -J643- Automatic glow period control unit -J179- | 87 | ||||||||||||||
32 | - | Fuse 32 on fuse holder B -SB32- | 30A | - | Engine control unit -J623- | 87 | ||||||||||||||
33 | - | Fuse 33 on fuse holder B -SB33- | 5A | - | Clutch pedal switch -F36- Brake light switch -F- Radiator fan control unit -J293- | 87 | ||||||||||||||
34 | - | Fuse 34 on fuse holder B -SB34- | 7.5A 15A1) | - | Right headlight main beam bulb -M32- Left headlight main beam bulb -M30-1) Control unit in dash panel insert -J285-1) | 56a | ||||||||||||||
35 | - | Fuse 35 on fuse holder B -SB35- | 10A | - | Engine control unit -J623- | 87 | ||||||||||||||
36 | - | Fuse 36 on fuse holder B -SB36- | 15A 20A 1) | - | Fuel system pressurisation pump -G6- Fuel supply relay -J643- | 87 | ||||||||||||||
37 | - | Fuse 37 on fuse holder B -SB37- | - | Not assigned | ||||||||||||||||
38 | - | Fuse 38 on fuse holder B -SB38- | 7.5A | - | Left headlight main beam bulb -M30- Control unit in dash panel insert -J285- | 56a | ||||||||||||||
39 | - | Fuse 39 on fuse holder B -SB39- | 10A | - | Right headlight dipped beam bulb -M31- | 56b | ||||||||||||||
40 | - | Fuse 40 on fuse holder B -SB40- | 30A | - | Fresh air blower switch -E9- Fresh air blower control unit -J126- | 75 | ||||||||||||||
41 | - | Fuse 41 on fuse holder B -SB41- | - | Reserve | ||||||||||||||||
42 | - | Fuse 42 on fuse holder B -SB42- | 15A | - | Cigarette lighter -U1- | 75 | ||||||||||||||
43 | - | Fuse 43 on fuse holder B -SB43- | 15A | - | Onboard supply control unit -J519- (T73b/13)
| 30 | ||||||||||||||
44 | - | Fuse 44 on fuse holder B -SB44- | 5A 10A1) | - | Anti-theft alarm ultrasonic sensor -G209- Alarm horn -H12- | 30 | ||||||||||||||
45 | - | Fuse 45 on fuse holder B -SB45- | 15A | - | Radio -R- | 30 | ||||||||||||||
46 | - | Fuse 46 on fuse holder B -SB46- | 20A | - | Onboard supply control unit -J519- (T73a/73)
| 30 | ||||||||||||||
47 | - | Fuse 47 on fuse holder B -SB47- | 20A | - | Onboard supply control unit -J519- (T73a/68)
| 30 | ||||||||||||||
48 | - | Fuse 48 on fuse holder B -SB48- | 25A | - | Onboard supply control unit -J519- (T73a/16)
| 30 | ||||||||||||||
49 | - | Fuse 49 on fuse holder B -SB49- | 5A | - | Onboard supply control unit -J519-2)
| 30 | ||||||||||||||
50 | - | Fuse 50 on fuse holder B -SB50- | 25A | - | Driver door control unit -J386- | 30 | ||||||||||||||
51 | - | Fuse 51 on fuse holder B -SB51- | 25A | - | Front passenger door control unit -J387- | 30 | ||||||||||||||
52 | - | Fuse 52 on fuse holder B -SB52- | 30A | - | Rear left door control unit -J388- Rear right door control unit -J389- | 30 | ||||||||||||||
53 | - | Fuse 53 on fuse holder B -SB53- | 30A | - | Onboard supply control unit -J519- (T73b/67)
| 30 | ||||||||||||||
54 | - | Fuse 54 on fuse holder B -SB54- | 15A | - | Left fog light bulb -L22- Right fog light bulb -L23- | 55 | ||||||||||||||
55 | - | Fuse 55 on fuse holder B -SB55- | 15A | - | Ignition coil 1 with output stage -N70- Ignition coil 2 with output stage -N127- Ignition coil 3 with output stage -N291- Ignition coil 4 with output stage -N292- | 87 | ||||||||||||||
56 | - | Fuse 56 on fuse holder B -SB56- | - | Not assigned | ||||||||||||||||
57 | - | Fuse 57 on fuse holder B -SB57- | 5A | - | Left side light bulb -M1- Left tail light -MX3- | 30 | ||||||||||||||
58 | - | Fuse 58 on fuse holder B -SB58- | 5A | - | Right side light bulb -M3- Right tail light -MX4- | 87 | ||||||||||||||
59 | - | Fuse 59 on fuse holder B -SB59- | 10A | - | Left headlight dipped beam bulb -M29- | 56b | ||||||||||||||
60 | - | Fuse 60 on fuse holder B -SB60- | - | Reserve |
|
|
No. | Current Flow Diagram designation | Nominal value | Function/component | Terminal | ||||||||||||||||
1 | - | Fuse 1 on fuse holder B -SB1- | - | Not assigned | ||||||||||||||||
2 | - | Fuse 2 on fuse holder B -SB2- | 10A | - | Steering column combination switch -E595- Rear window wiper motor -V12- Windscreen and rear window washer pump -V59- | 15 | ||||||||||||||
3 | - | Fuse 3 on fuse holder B -SB3- | 5A | - | Fuel pump relay -J17- Engine control unit -J623- | 15 | ||||||||||||||
4 | - | Fuse 4 on fuse holder B -SB4- | 2A | - | Steering column combination switch -E595-1)Multifunction steering wheel control unit -J453-1) | 15 | ||||||||||||||
5 | - | Fuse 5 on fuse holder B -SB5- | - | Not assigned | ||||||||||||||||
6 | - | Fuse 6 on fuse holder B -SB6- | 5A | - | Control unit in dash panel insert -J285- | 15 | ||||||||||||||
7 | - | Fuse 7 on fuse holder B -SB7- | 5A | - | Headlight range control regulator -E102- Left number plate light -X4- Right number plate light -X5- Switch and instrument illumination regulator -E20-1) | 58 | ||||||||||||||
8 | - | Fuse 8 on fuse holder B -SB8- | - | Not assigned | ||||||||||||||||
9 | - | Fuse 9 on fuse holder B -SB9- | 5A 7.5A1) | - | ABS control unit -J104- TCS and ESP button -E256-1) Steering column combination switch -E595-1) | 15 | ||||||||||||||
10 | - | Fuse 10 on fuse holder B -SB10- | 5A | - | Vehicle speed sender -G68- Onboard supply control unit -J519- (T73a/44)
| 15 | ||||||||||||||
11 | - | Fuse 11 on fuse holder B -SB11- | 5A | - | Headlight range control regulator -E102- Left headlight range control motor -V48- Right headlight range control motor -V49- Steering column combination switch -E595-1) | 15 | ||||||||||||||
12 | - | Fuse 12 on fuse holder B -SB12- | 5A | - | Mirror adjustment switch -E43- | 15 | ||||||||||||||
13 | - | Fuse 13 on fuse holder B -SB13- | 15A | - | Automatic gearbox control unit -J217- Multifunction switch -F125- Selector lever -E313- | 15 | ||||||||||||||
14 | - | Fuse 14 on fuse holder B -SB14- | 5A | - | Airbag control unit -J234- Front passenger airbag deactivated warning lamp -K145-1) | 15 | ||||||||||||||
15 | - | Fuse 15 on fuse holder B -SB15- | - | Not assigned | ||||||||||||||||
16 | - | Fuse 16 on fuse holder B -SB16- | 5A | - | Parking aid control unit -J446- | 15 | ||||||||||||||
17 | - | Fuse 17 on fuse holder B -SB17- | 10A | - | Lambda probe heater -Z19- Lambda probe 1 heater after catalytic converter -Z29- Activated charcoal filter solenoid valve 1 -N80- | 87 | ||||||||||||||
18 | - | Fuse 18 on fuse holder B -SB18- | 5A | - | Control unit in dash panel insert -J285- Rear right fog light bulb -L47- | 55a | ||||||||||||||
19 | - | Fuse 19 on fuse holder B -SB19- | 5A | - | Side light relay -J3- Radio -R- Onboard supply control unit -J519- (T73a/42)
| 75 | ||||||||||||||
20 | - | Fuse 20 on fuse holder B -SB20- | 5A | - | Control unit in dash panel insert -J285- Steering column combination switch -E595-1) | 30 | ||||||||||||||
21 | - | Fuse 21 on fuse holder B -SB21- | 10A | - | Onboard supply control unit -J519- (T73a/66)
| 30 | ||||||||||||||
22 | - | Fuse 22 on fuse holder B -SB22- | 5A | - | Diagnostic connection -U31- Air conditioning system control unit -J301- Climatronic control unit -J255- Ignition key withdrawal lock solenoid -N376- | 30 | ||||||||||||||
23 | - | Fuse 23 on fuse holder B -SB23- | 7.5A | - | Onboard supply control unit -J519- (T73b/39) Engine control unit -J623- Automatic gearbox control unit -J217- Selector lever -E313- Rain sensor -G213- | 30 | ||||||||||||||
24 | - | Fuse 24 on fuse holder B -SB24- | - | Not assigned | ||||||||||||||||
25 | - | Fuse 25 on fuse holder B -SB25- | 5A | - | High-pressure sender -G65- Air conditioning system relay -J32- Air conditioning system control unit -J301- Diagnostic connection -U31- Automatic anti-dazzle interior mirror -Y7- | 15 | ||||||||||||||
26 | - | Fuse 26 on fuse holder B -SB26- | 7.5A | - | Power steering control unit -J500- Air mass meter -G70- | 15 | ||||||||||||||
27 | - | Fuse 27 on fuse holder B -SB27- | 5A | - | Reversing light switch -F4- | 15 | ||||||||||||||
28 | - | Fuse 28 on fuse holder B -SB28- | - | Not assigned | ||||||||||||||||
29 | - | Fuse 29 on fuse holder B -SB29-3) | 15A | - | Ignition coil 1 with output stage -N70- Ignition coil 2 with output stage -N127- Ignition coil 3 with output stage -N291- Ignition coil 4 with output stage -N292- | 87 | ||||||||||||||
29 | - | Fuse 29 on fuse holder B -SB29-4) | 10A | - | Fuel pressure regulating valve -N276- Fuel metering valve -N290- | 87 | ||||||||||||||
30 | - | Fuse 30 on fuse holder B -SB30- | 10A | - | Coolant circulation pump 2 -V178- Exhaust gas recirculation cooler changeover valve -N345- Charge pressure control solenoid valve -N75- | 87 | ||||||||||||||
31 | - | Fuse 31 on fuse holder B -SB31-3) | 10A | - | Injector, cylinder 1 -N30- Injector, cylinder 2 -N31- Injector, cylinder 3 -N32- Injector, cylinder 4 -N33- | 87 | ||||||||||||||
31 | - | Fuse 31 on fuse holder B -SB31-4) | 10A | - | Fuel supply relay -J643- Automatic glow period control unit -J179- | 87 | ||||||||||||||
32 | - | Fuse 32 on fuse holder B -SB32- | 30A 10A1) | - | Engine control unit -J623- | 87 | ||||||||||||||
33 | - | Fuse 33 on fuse holder B -SB33- | 5A | - | Clutch pedal switch -F36- Brake light switch -F- Radiator fan control unit -J293- | 87 | ||||||||||||||
34 | - | Fuse 34 on fuse holder B -SB34- | 7.5A 15A1) | - | Right headlight main beam bulb -M32- Left headlight main beam bulb -M30-1) Control unit in dash panel insert -J285-1) | 56a | ||||||||||||||
35 | - | Fuse 35 on fuse holder B -SB35- | - | Not assigned | ||||||||||||||||
36 | - | Fuse 36 on fuse holder B -SB36- | 15A 20A1) | - | Fuel system pressurisation pump -G6- Fuel supply relay -J643- | 87 | ||||||||||||||
37 | - | Fuse 37 on fuse holder B -SB37- | - | Not assigned | ||||||||||||||||
38 | - | Fuse 38 on fuse holder B -SB38- | 7.5A | - | Left headlight main beam bulb -M30- Control unit in dash panel insert -J285- | 56a | ||||||||||||||
39 | - | Fuse 39 on fuse holder B -SB39- | 10A | - | Right headlight dipped beam bulb -M31- | 56b | ||||||||||||||
40 | - | Fuse 40 on fuse holder B -SB40- | 30A | - | Fresh air blower switch -E9- Fresh air blower control unit -J126- | 75 | ||||||||||||||
41 | - | Fuse 41 on fuse holder B -SB41- | - | Not assigned | ||||||||||||||||
42 | - | Fuse 42 on fuse holder B -SB42- | 15A | - | Cigarette lighter -U1- | 75 | ||||||||||||||
43 | - | Fuse 43 on fuse holder B -SB43- | 15A | - | Onboard supply control unit -J519- (T73b/13)
| 30 | ||||||||||||||
44 | - | Fuse 44 on fuse holder B -SB44- | 5A 10A1) | - | Anti-theft alarm ultrasonic sensor -G209- Alarm horn -H12- | 30 | ||||||||||||||
45 | - | Fuse 45 on fuse holder B -SB45- | 15A | - | Radio -R- Multimedia system control unit -J650-1) | 30 | ||||||||||||||
46 | - | Fuse 46 on fuse holder B -SB46- | 20A | - | Onboard supply control unit -J519- (T73a/73)
| 30 | ||||||||||||||
47 | - | Fuse 47 on fuse holder B -SB47- | 20A | - | Onboard supply control unit -J519- (T73a/68)
| 30 | ||||||||||||||
48 | - | Fuse 48 on fuse holder B -SB48- | 25A | - | Onboard supply control unit -J519- (T73a/16)
| 30 | ||||||||||||||
49 | - | Fuse 49 on fuse holder B -SB49- | 5A | - | Onboard supply control unit -J519-2)
| 30 | ||||||||||||||
50 | - | Fuse 50 on fuse holder B -SB50- | 25A | - | Driver door control unit -J386- | 30 | ||||||||||||||
51 | - | Fuse 51 on fuse holder B -SB51- | 25A | - | Front passenger door control unit -J387- | 30 | ||||||||||||||
52 | - | Fuse 52 on fuse holder B -SB52- | 30A | - | Rear left door control unit -J388- Rear right door control unit -J389- | 30 | ||||||||||||||
53 | - | Fuse 53 on fuse holder B -SB53- | 30A | - | Onboard supply control unit -J519- (T73b/67)
| 30 | ||||||||||||||
54 | - | Fuse 54 on fuse holder B -SB54- | 15A | - | Left fog light bulb -L22- Right fog light bulb -L23- | 55 | ||||||||||||||
55 | - | Fuse 55 on fuse holder B -SB55- | - | Not assigned | ||||||||||||||||
56 | - | Fuse 56 on fuse holder B -SB56- | - | Not assigned | ||||||||||||||||
57 | - | Fuse 57 on fuse holder B -SB57- | 5A | - | Left side light bulb -M1- Left tail light -MX3- | 30 | ||||||||||||||
58 | - | Fuse 58 on fuse holder B -SB58- | 5A | - | Right side light bulb -M3- Right tail light -MX4- | 87 | ||||||||||||||
59 | - | Fuse 59 on fuse holder B -SB59- | 10A | - | Left headlight dipped beam bulb -M29- | 56b | ||||||||||||||
60 | - | Fuse 60 on fuse holder B -SB60- | - | Not assigned |
|
|
No. | Current Flow Diagram designation | Nominal value | Function/component | Terminal | ||||||||||||||||
1 | - | Fuse 1 on fuse holder B -SB1- | - | Not assigned | ||||||||||||||||
2 | - | Fuse 2 on fuse holder B -SB2- | 10 A | - | Steering column combination switch -E595-
| 15 | ||||||||||||||
3 | - | Fuse 3 on fuse holder B -SB3- | 7.5 A | - | Fuel pump relay -J17- Onboard supply control unit -J519-
Fuel pump control unit -J538- Engine control unit -J623- Fuel supply relay -J643- | 15 | ||||||||||||||
4 | - | Fuse 4 on fuse holder B -SB4- | 7.5 A | - | Steering column combination switch -E595-
| 15 | ||||||||||||||
5 | - | Fuse 5 on fuse holder B -SB5- | - | Not assigned | ||||||||||||||||
6 | - | Fuse 6 on fuse holder B -SB6- | - | Not assigned | ||||||||||||||||
7 | - | Fuse 7 on fuse holder B -SB7- | 15 A | - | Left number plate light -X4- Right number plate light -X5- Switch and instrument illumination regulator -E20- | 58 | ||||||||||||||
8 | - | Fuse 8 on fuse holder B -SB8- | - | Not assigned | ||||||||||||||||
9 | - | Fuse 9 on fuse holder B -SB9- | 7.5 A | - | ABS control unit -J104- TCS and ESP button -E256- Tyre Pressure Loss Indicator button -E492- Steering column combination switch -E595-
| 15 | ||||||||||||||
10 | - | Fuse 10 on fuse holder B -SB10- | 7.5 A | - | Radio -R- | 15 | ||||||||||||||
11 | - | Fuse 11 on fuse holder B -SB11- | 10 A | - | Headlight range control regulator -E102- Steering column combination switch -E595-
Headlight range control unit -J431- Dash panel insert -KX2-
Left headlight range control motor -V48- Right headlight range control motor -V49- | 15 | ||||||||||||||
12 | - | Fuse 12 on fuse holder B -SB12- | 7.5 A | - | Mirror adjustment switch -E43- Driver side exterior mirror -VX4- Front passenger side exterior mirror -VX5- | 15 | ||||||||||||||
13 | - | Fuse 13 on fuse holder B -SB13- | 10 A | - | Automatic gearbox control unit -J217- | 15 | ||||||||||||||
14 | - | Fuse 14 on fuse holder B -SB14- | 15 A | - | Airbag control unit -J234- | 15 | ||||||||||||||
15 | - | Fuse 15 on fuse holder B -SB15- | - | Not assigned | ||||||||||||||||
16 | - | Fuse 16 on fuse holder B -SB16- | 10 A | - | Parking aid control unit -J446- | 15 | ||||||||||||||
17 | - | Fuse 17 on fuse holder B -SB17- | 10 A | - | Windscreen and rear window washer pump -V59- | 87 | ||||||||||||||
18 | - | Fuse 18 on fuse holder B -SB18- | 7.5 A | - | Dash panel insert -KX2-
Rear right fog light bulb -L47- | 55a | ||||||||||||||
19 | - | Fuse 19 on fuse holder B -SB19- | 7.5 A | - | Side light relay -J3- Radio -R- Onboard supply control unit -J519-
| 75 | ||||||||||||||
20 | - | Fuse 20 on fuse holder B -SB20- | 10 A | - | Dash panel insert -KX2-
Steering column combination switch -E595-
Main relay -J271-3) Terminal 30 voltage supply relay -J317-4) | 30 | ||||||||||||||
21 | - | Fuse 21 on fuse holder B -SB21- | 15 A | - | Onboard supply control unit -J519-
| 30 | ||||||||||||||
22 | - | Fuse 22 on fuse holder B -SB22- | 10 A | - | Diagnostic connection -U31- Rain and light sensor -G397- Side light relay -J3- Heated exterior mirror relay -J99- Climatronic control unit -J255- Air conditioning system control unit -J301- Ignition key withdrawal lock solenoid -N376- | 30 | ||||||||||||||
23 | - | Fuse 23 on fuse holder B -SB23- | 10 A | - | Selector lever -E313- Rain sensor -G213- Automatic gearbox control unit -J217- Onboard supply control unit -J519- Engine control unit -J623- | 30 | ||||||||||||||
24 | - | Fuse 24 on fuse holder B -SB24- | 15 A | - | Onboard supply control unit -J519-
| 30 | ||||||||||||||
25 | - | Fuse 25 on fuse holder B -SB25- | 15 A | - | Interior mirror -EX5-
High-pressure sender -G65- Climatronic control unit -J255- Radiator fan control unit -J293- Air conditioning system control unit -J301- Air conditioner compressor regulating valve -N280- Diagnostic connection -U31- | 15 | ||||||||||||||
26 | - | Fuse 26 on fuse holder B -SB26- | 20 A | - | Air mass meter -G70- Air conditioning system relay -J32- Power steering control unit -J500- | 15 | ||||||||||||||
27 | - | Fuse 27 on fuse holder B -SB27- | 15 A | - | Reversing light switch -F4- | 15 | ||||||||||||||
28 | - | Fuse 28 on fuse holder B -SB28- | 15 A | - | Lambda probe 1 after catalytic converter -GX7-
Lambda probe 1 before catalytic converter -GX10-
Injector, cylinder 1 -N30- Injector, cylinder 2 -N31- Injector, cylinder 3 -N32- Injector, cylinder 4 -N33- Activated charcoal filter solenoid valve 1 -N80- Automatic glow period control unit -J179-4) | 87 | ||||||||||||||
29 | - | Fuse 29 on fuse holder B -SB29- | 20 A 3) 15 A 4) | - | Ignition coil 1 with output stage -N70-7) Ignition coil 2 with output stage -N127-7) Fuel pressure regulating valve -N276-4) Fuel metering valve -N290-4) Ignition coil 3 with output stage -N291-7) Ignition coil 4 with output stage -N292-7) Output stage -N122-6) Ignition transformer -N152-6) | 87 | ||||||||||||||
30 | - | Fuse 30 on fuse holder B -SB30- | - | - | Not assigned | |||||||||||||||
31 | - | Fuse 31 on fuse holder B -SB31-3) | 15 A | - | Ignition coil 1 with output stage -N70-8) Ignition coil 2 with output stage -N127-8) Ignition coil 3 with output stage -N291-8) Ignition coil 4 with output stage -N292-8) Charge pressure control solenoid valve -N75-4) Automatic glow period control unit -J179-4) Exhaust gas recirculation cooler changeover valve -N345-4) Coolant circulation pump 2 -V178-4) | 87 | ||||||||||||||
32 | - | Fuse 32 on fuse holder B -SB32- | 30 A | - | Engine control unit -J623- | 87 | ||||||||||||||
33 | - | Fuse 33 on fuse holder B -SB33- | 10 A | - | Brake light switch -F-Clutch pedal switch -F36- Air conditioning system relay -J32- Radiator fan control unit -J293- | 87 | ||||||||||||||
34 | - | Fuse 34 on fuse holder B -SB34- | 20 A | - | Front left headlight -MX1-
Front right headlight -MX2-
Dash panel insert -KX2-
| 56a | ||||||||||||||
35 | - | Fuse 35 on fuse holder B -SB35- | - | Not assigned | ||||||||||||||||
36 | - | Fuse 36 on fuse holder B -SB36- | 20 A | - | Fuel system pressurisation pump -G6- Fuel pump relay -J17- Fuel supply relay -J643- | 87 | ||||||||||||||
37 | - | Fuse 37 on fuse holder B -SB37- | - | Not assigned | ||||||||||||||||
38 | - | Fuse 38 on fuse holder B -SB38- | 30 A | - | Automatic gearbox control unit -J217- | 30 | ||||||||||||||
39 | - | Fuse 39 on fuse holder B -SB39- | 15 A | - | Front right headlight -MX2-
| 56b | ||||||||||||||
40 | - | Fuse 40 on fuse holder B -SB40- | 30 A | - | Fresh air blower control unit -J126- | 75 | ||||||||||||||
41 | - | Fuse 41 on fuse holder B -SB41- | - | Not assigned | ||||||||||||||||
42 | - | Fuse 42 on fuse holder B -SB42- | 20 A | - | Cigarette lighter -U1- | 75 | ||||||||||||||
43 | - | Fuse 43 on fuse holder B -SB43- | 20 A | - | Onboard supply control unit -J519-
| 30 | ||||||||||||||
44 | - | Fuse 44 on fuse holder B -SB44- | 10 A | - | Anti-theft alarm sensor -G578- Anti-theft alarm system horn -H8- | 30 | ||||||||||||||
45 | - | Fuse 45 on fuse holder B -SB45- | 30 A | - | Radio -R- | 30 | ||||||||||||||
46 | - | Fuse 46 on fuse holder B -SB46- | 30 A | - | Onboard supply control unit -J519-
| 30 | ||||||||||||||
47 | - | Fuse 47 on fuse holder B -SB47- | 30 A | - | Onboard supply control unit -J519-
| 30 | ||||||||||||||
48 | - | Fuse 48 on fuse holder B -SB48- | 30 A | - | Onboard supply control unit -J519-
| 30 | ||||||||||||||
49 | - | Fuse 49 on fuse holder B -SB49- | 15 A | - | Onboard supply control unit -J519-
| 30 | ||||||||||||||
50 | - | Fuse 50 on fuse holder B -SB50- | 30 A | - | Driver door control unit -J386-1) Front left window regulator switch -E40- Driver side window regulator motor -V147- | 30 | ||||||||||||||
51 | - | Fuse 51 on fuse holder B -SB51- | 30 A | - | Front passenger door control unit -J387-1) Window regulator switch in front passenger door -E107- Front passenger side window regulator motor -V148- | 30 | ||||||||||||||
52 | - | Fuse 52 on fuse holder B -SB52- | 30 A | - | Rear left door control unit -J388- Rear right door control unit -J389-Rear left window regulator switch, in door -E52- Rear right window regulator switch, in door -E54- Rear left window regulator motor -V26- Rear right window regulator motor -V27- | 30 | ||||||||||||||
53 | - | Fuse 53 on fuse holder B -SB53- | 30 A | - | Onboard supply control unit -J519-
| 30 | ||||||||||||||
54 | - | Fuse 54 on fuse holder B -SB54- | 20 A | - | Left fog light bulb -L22- Right fog light bulb -L23- | 55 | ||||||||||||||
55 | - | Fuse 55 on fuse holder B -SB55- | - | Not assigned | ||||||||||||||||
56 | - | Fuse 56 on fuse holder B -SB56- | - | Not assigned | ||||||||||||||||
57 | - | Fuse 57 on fuse holder B -SB57- | 7.5 A | - | Front left headlight -MX1-
Left tail light -MX3- | 30 | ||||||||||||||
58 | - | Fuse 58 on fuse holder B -SB58- | 7.5 A | - | Front right headlight -MX2-
Right tail light -MX4- | 87 | ||||||||||||||
59 | - | Fuse 59 on fuse holder B -SB59- | 15 A | - | Front left headlight -MX1-
| 56b | ||||||||||||||
60 | - | Fuse 60 on fuse holder B -SB60- | 15 A | - | Left daytime running light bulb -L174- Right daytime running light bulb -L175- |
|
Relay and fuse carrier 1 -SR1- |
Relay and fuse assignment, from August 2010 |
A - | Fuses in relay plate fuse holder -S1- |
B - | Fuses in relay plate fuse holder -S2- |
1 - | Not assigned |
2 - | Not assigned |
3 - | Not assigned |
4 - | Dipped beam relay -J331- |
q | Slot 4, left |
Fuel supply relay -J643- |
q | Slot 4, right |
5 - | Terminal 30 voltage supply relay -J317- |
q | Only models with diesel engine |
Main relay -J271- |
q | Only models with petrol engine |
6 - | Side light relay -J3- |
q | Slot 6, right |
7 - | Fuel pump relay -J17- |
8 - | Starter inhibitor relay -J207- |
9 - | Air conditioning system relay -J32- |
10 - | X-contact relief relay -J59- |
11 - | Not assigned |
12 - | Not assigned |
13 - | Not assigned |
14 - | Not assigned |
15 - | Not assigned |
No. | Current Flow Diagram designation | Nominal value | Function/component | Terminal | ||||||||||
A | - | Fuses in relay plate fuse holder -S1- | 15A | - | Operating unit for window regulator in driver door -E512- Driver side window regulator motor -V147- Window regulator switch in front passenger door -E107- Front passenger side window regulator motor -V148- | 15 | ||||||||
B | - | Fuses in relay plate fuse holder -S2- | 15A | - | Operating unit for window regulator in driver door -E512- Rear window regulator isolation switch -E39-
| 15 |
|
Relay and fuse assignment, from November 2010 |
A - | Fuses in relay plate fuse holder -S1- |
B - | Fuses in relay plate fuse holder -S2- |
1 - | Not assigned |
2 - | Not assigned |
3 - | Not assigned |
4 - | Fuel pump relay -J17- |
q | Slot 4, left |
Fuel supply relay -J643- |
q | Slot 4, right |
5 - | Terminal 30 voltage supply relay -J317- |
q | Only models with diesel engine |
Main relay -J271- |
q | Only models with petrol engine |
6 - | Dipped beam relay -J331- |
q | Slot 6, left |
Side light relay -J3- |
q | Slot 6, right |
7 - | Air conditioning system relay -J32- |
8 - | Starter inhibitor relay -J207- |
9 - | Not assigned |
10 - | X-contact relief relay -J59- |
11 - | Not assigned |
12 - | Not assigned |
13 - | Not assigned |
14 - | Not assigned |
15 - | Not assigned |
No. | Current Flow Diagram designation | Nominal value | Function/component | Terminal | ||||||||||
A | - | Fuses in relay plate fuse holder -S1- | 15A | - | Operating unit for window regulator in driver door -E512- Driver side window regulator motor -V147- Window regulator switch in front passenger door -E107- Front passenger side window regulator motor -V148- | 15 | ||||||||
B | - | Fuses in relay plate fuse holder -S2- | 15A | - | Operating unit for window regulator in driver door -E512- Rear window regulator isolation switch -E39-
| 15 |
|
Relay and fuse assignment, from August 2011 |
A - | Fuses in relay plate fuse holder -S1- |
B - | Fuses in relay plate fuse holder -S2- |
1 - | Not assigned |
2 - | Not assigned |
3 - | Not assigned |
4 - | Fuel pump relay -J17- |
q | Slot 4, left |
Fuel supply relay -J643- |
q | Slot 4, right |
5 - | Terminal 30 voltage supply relay -J317- |
q | Only models with diesel engine |
Main relay -J271- |
q | Only models with petrol engine |
6 - | Dipped beam relay -J331- |
q | Slot 6, left |
Side light relay -J3- |
q | Slot 6, right |
7 - | Not assigned |
8 - | Starter inhibitor relay -J207- |
9 - | Air conditioning system relay -J32- |
10 - | X-contact relief relay -J59- |
11 - | Not assigned |
12 - | Not assigned |
13 - | Not assigned |
14 - | Not assigned |
15 - | Not assigned |
No. | Current Flow Diagram designation | Nominal value | Function/component | Terminal | ||||||||||
A | - | Fuses in relay plate fuse holder -S1- | 15A | - | Operating unit for window regulator in driver door -E512- Driver side window regulator motor -V147- Window regulator switch in front passenger door -E107- Front passenger side window regulator motor -V148- | 15 | ||||||||
B | - | Fuses in relay plate fuse holder -S2- | 15A | - | Operating unit for window regulator in driver door -E512- Rear window regulator isolation switch -E39-
| 15 |
|
Relay and fuse carrier 1 -SR1- , from May 2012 |
A - | Fuses in relay plate fuse holder -S1- |
B - | Fuses in relay plate fuse holder -S2- |
1 - | Not assigned |
2 - | Not assigned |
3 - | Not assigned |
4 - | Fuel pump relay -J17- |
q | Slot 4, left |
Fuel supply relay -J643- |
q | Slot 4, right |
5 - | Terminal 30 voltage supply relay -J317- |
q | Only models with diesel engine |
Main relay -J271- |
q | Only models with petrol engine |
6 - | Dipped beam relay -J331- |
q | Slot 6, left |
Side light relay -J3- |
q | Slot 6, right |
7 - | Not assigned |
8 - | Starter inhibitor relay -J207- |
9 - | Air conditioning system relay -J32- |
10 - | X-contact relief relay -J59- |
11 - | Not assigned |
12 - | Not assigned |
13 - | Not assigned |
14 - | Not assigned |
15 - | Not assigned |
No. | Current Flow Diagram designation | Nominal value | Function/component | Terminal | ||||||||||
1 | - | Fuses in relay plate fuse holder -S1- | 15A | - | Operating unit for window regulator in driver door -E512- Driver side window regulator motor -V147- Window regulator switch in front passenger door -E107- Front passenger side window regulator motor -V148- | 15 | ||||||||
2 | - | Fuses in relay plate fuse holder -S2- | 15A | - | Operating unit for window regulator in driver door -E512- Rear window regulator isolation switch -E39-
| 15 |
|
Relay and fuse carrier 1 -SR1- , left-hand drive models, from August 2012 |
A - | Fuses in relay plate fuse holder -S1- |
B - | Fuses in relay plate fuse holder -S2- |
1 - | Not assigned |
2 - | Not assigned |
3 - | Not assigned |
4 - | Not assigned |
5 - | Terminal 30 voltage supply relay -J317- |
q | Only models with diesel engine |
Main relay -J271- |
q | Only models with petrol engine |
6 - | Starter inhibitor relay -J207- |
7 - | Not assigned |
8 - | Side light relay -J3- |
q | Slot 8, left |
Dipped beam relay -J331- |
q | Slot 8, right |
9 - | Not assigned |
10 - | X-contact relief relay -J59- |
11 - | Not assigned |
12 - | Not assigned |
13 - | Fuel pump relay -J17- |
q | Slot 13, left |
Fuel supply relay -J643- |
q | Slot 13, right |
14 - | Not assigned |
15 - | Air conditioning system relay -J32- |
No. | Current Flow Diagram designation | Nominal value | Function/component | Terminal | ||||||||||
1 | - | Fuses in relay plate fuse holder -S1- | 15A | - | Operating unit for window regulator in driver door -E512- Driver side window regulator motor -V147- Window regulator switch in front passenger door -E107- Front passenger side window regulator motor -V148- | 15 | ||||||||
2 | - | Fuses in relay plate fuse holder -S2- | 15A | - | Operating unit for window regulator in driver door -E512- Rear window regulator isolation switch -E39-
| 15 |
|
Relay and fuse carrier 1 -SR1- , right-hand drive models, from August 2012 |
A - | Fuses in relay plate fuse holder -S1- |
B - | Fuses in relay plate fuse holder -S2- |
1 - | Not assigned |
2 - | Not assigned |
3 - | Not assigned |
4 - | Not assigned |
5 - | Terminal 30 voltage supply relay -J317- |
q | Only models with diesel engine |
Main relay -J271- |
q | Only models with petrol engine |
6 - | Starter inhibitor relay -J207- |
7 - | Not assigned |
8 - | Side light relay -J3- |
q | Slot 8, left |
Dipped beam relay -J331- |
q | Slot 8, right |
9 - | Not assigned |
10 - | X-contact relief relay -J59- |
11 - | Not assigned |
12 - | Not assigned |
13 - | Fuel pump relay -J17- |
q | Slot 13, left |
Fuel supply relay -J643- |
q | Slot 13, right |
14 - | Not assigned |
15 - | Air conditioning system relay -J32- |
No. | Current Flow Diagram designation | Nominal value | Function/component | Terminal | ||||||||||
1 | - | Fuses in relay plate fuse holder -S1- | 15A | - | Operating unit for window regulator in driver door -E512- Driver side window regulator motor -V147- Window regulator switch in front passenger door -E107- Front passenger side window regulator motor -V148- | 15 | ||||||||
2 | - | Fuses in relay plate fuse holder -S2- | 15A | - | Operating unit for window regulator in driver door -E512- Rear window regulator isolation switch -E39-
| 15 |
|
Relay and fuse carrier 1 -SR1- , left-hand drive models, from August 2015 |
A - | Fuses in relay plate fuse holder -S1- |
B - | Fuses in relay plate fuse holder -S2- |
1 - | Not assigned |
2 - | Not assigned |
3 - | Not assigned |
4 - | Not assigned |
5 - | Terminal 30 voltage supply relay -J317- |
q | Only models with diesel engine |
Main relay -J271- |
q | Only models with petrol engine |
6 - | Starter inhibitor relay -J207- |
7 - | Heated exterior mirror relay -J99- |
8 - | Side light relay -J3- |
q | Slot 8, left |
Dipped beam relay -J331- |
q | Slot 8, right |
9 - | Not assigned |
10 - | X-contact relief relay -J59- |
11 - | Not assigned |
12 - | Not assigned |
13 - | Fuel pump relay -J17- |
q | Slot 13, left |
Fuel supply relay -J643- |
q | Slot 13, right |
14 - | Not assigned |
15 - | Air conditioning system relay -J32- |
No. | Current Flow Diagram designation | Nominal value | Function/component | Terminal | ||||||||||
1 | - | Fuses in relay plate fuse holder -S1- | 15A | - | Operating unit for window regulator in driver door -E512- Driver side window regulator motor -V147- Window regulator switch in front passenger door -E107- Front passenger side window regulator motor -V148- | 15 | ||||||||
2 | - | Fuses in relay plate fuse holder -S2- | 15A | - | Operating unit for window regulator in driver door -E512- Rear window regulator isolation switch -E39-
| 15 |
|
Relay and fuse carrier 1 -SR1- , right-hand drive models, from August 2015 |
A - | Fuses in relay plate fuse holder -S1- |
B - | Fuses in relay plate fuse holder -S2- |
1 - | Not assigned |
2 - | Not assigned |
3 - | Not assigned |
4 - | Not assigned |
5 - | Terminal 30 voltage supply relay -J317- |
q | Only models with diesel engine |
Main relay -J271- |
q | Only models with petrol engine |
6 - | Starter inhibitor relay -J207- |
7 - | Heated exterior mirror relay -J99- |
8 - | Side light relay -J3- |
q | Slot 8, left |
Dipped beam relay -J331- |
q | Slot 8, right |
9 - | Not assigned |
10 - | X-contact relief relay -J59- |
11 - | Not assigned |
12 - | Not assigned |
13 - | Fuel pump relay -J17- |
q | Slot 13, left |
Fuel supply relay -J643- |
q | Slot 13, right |
14 - | Not assigned |
15 - | Air conditioning system relay -J32- |
No. | Current Flow Diagram designation | Nominal value | Function/component | Terminal | ||||||||||
1 | - | Fuses in relay plate fuse holder -S1- | 15A | - | Operating unit for window regulator in driver door -E512- Driver side window regulator motor -V147- Window regulator switch in front passenger door -E107- Front passenger side window regulator motor -V148- | 15 | ||||||||
2 | - | Fuses in relay plate fuse holder -S2- | 15A | - | Operating unit for window regulator in driver door -E512- Rear window regulator isolation switch -E39-
| 15 |
|
